USB-Serial Conversion Cable
Windows XP/Vista/7/8/10 *1
Applicable OS
E5EC/E5AC:CX-Thermo version 4.5 or higher
Applicable software
E5EC-B:CX-Thermo version 4.65 or higher *3
Applicable models E5@C-T Series, E5@C Series, and E5CB Series
USB interface standard Conforms to USB Specification 2.0.
DTE speed 38,400 bps
Computer: USB (type A plug)
Connector
Digital Temperature Controller:
specifications
Special serial connector
Bus power (Supplied from USB host controller.) *2
Power supply
Power supply voltage 5 VDC
Current consumption 450 mA max.
4.7±0.2 VDC
Output voltage (Supplied from USB-Serial Conversion Cable
to the Digital Temperature Controller.)
250 mA max.
Output current (Supplied from USB-Serial Conversion Cable
to the Digital Temperature Controller.)
Ambient operating
0 to 55°C (with no condensation or icing)
temperature
Ambient operating
10% to 80%
humidity
Storage temperature -20 to 60°C (with no condensation or icing)
Storage humidity 10% to 80%
Altitude 2,000 m max.
Weight Approx. 120 g
Windows is a registered trademark of Microsoft Corporation in the
United States and or other countries.
*1. CX-Thermo version 4.65 or higher runs on Windows 10.
*2. Use a high-power port for the USB port.
*3. CX-Thermo version 4.67 or higher is required for the E5CC-B
linear current output type.
Note: A driver must be installed on the computer. Refer to the Instruction
Manual included with the Cable for the installation procedure.

Communications Specifications

Transmission line
RS-485: Multidrop
connection method
Communications RS-485 (two-wire, half duplex)
Synchronization method Start-stop synchronization
Protocol CompoWay/F, or Modbus
Baud rate *
9600, 19200, 38400, or 57600 bps
Transmission code ASCII
Data bit length *
7 or 8 bits
Stop bit length *
1 or 2 bits
Vertical parity (none, even, odd)
Error detection Block check character (BCC) with
CompoWay/F or CRC-16 Modbus
Flow control None
Interface RS-485
Retry function None
Communications buffer 217 bytes
Communications 0 to 99 ms
response wait time Default: 20 ms
* The baud rate, data bit length, stop bit length, and vertical parity can
be individually set using the Communications Setting Level.

Communications Functions

You can use the memory in the PLC to read and write
E5@C parameters, start and stop operation, etc. The
E5@C automatically performs communications with
PLCs. No communications programming is required.
Number of connected Digital Temperature Controllers:
32 max. (Up to 16 for the FX Series)
Applicable PLCs
Programless
OMRON PLCs
communications *1
CS Series, CJ Series, CP Series,
NJ Series, or NX1P
Mitsubishi Electric PLCs
MELSEC Q Series, L Series, FX3 Series,
or iQ-R Series
KEYENCE PLCs
KEYENCE KV Series
E5EC/E5EC-B/E5AC
When Digital Temperature Controllers are
connected, set points and RUN/STOP
commands can be sent from the Digital
Temperature Controller that is set as the
Component
master to the Digital Temperature
Communications *1
Controllers that are set as slaves.
Slope and offsets can be set for the set point.
Number of connected Digital Temperature
Controllers: 32 max. (including master)
When Digital Temperature Controllers are
connected, the parameters can be copied
Copying *2
from the Digital Temperature Controller that is
set as the master to the Digital Temperature
Controllers that are set as slaves.
MELSEC is a registered trademark of Mitsubishi Electric Corporation.
KEYENCE is a registered trademark of Keyence Corporation.
*1. A Temperature Controller with version 1.1 or higher is required.
A Temperature Controller with version 2.1 or higher is required for
the FX Series or the KV Series.
*2. Both the programless communications and the component
communications support the copying.
Current Transformer (Order Separately) Ratings
E54-CT1
E54-CT3
Dielectric strength 1,000 VAC for 1 min
Vibration resistance
E54-CT1: Approx. 11.5 g
Weight
E54-CT3: Approx. 50 g
E54-CT3 Only
Accessories Armatures (2)
Plugs (2)
Heater Burnout Alarms and SSR Failure Alarms
Models with detection for singlephase
CT input (for heater heaters: One input
current detection) Models with detection for singlephase or
three-phase heaters: Two inputs
Maximum heater
50 A AC
current
Input current
±5% FS ±1 digit max.
indication accuracy
Heater burnout alarm 0.1 to 49.9 A (in units of 0.1 A)
setting range *1 Minimum detection ON time: 100 ms *3
SSR failure alarm 0.1 to 49.9 A (in units of 0.1 A)
setting range *2 Minimum detection OFF time: 100 ms *4
*1. For heater burnout alarms, the heater current will be measured
when the control output is ON, and the output will turn ON if the
heater current is lower than the set value (i.e., heater burnout
detection current value).
*2. For SSR failure alarms, the heater current will be measured when the
control output is OFF, and the output will turn ON if the heater current
is higher than the set value (i.e., SSR failure detection current value).
*3. The value is 30 ms for a control period of 0.1 s or 0.2 s.
*4. The value is 35 ms for a control period of 0.1 s or 0.2 s.
Electrical Life Expectancy Curve for
Control Output Relays (Reference Values)
500
300
E5EC/E5EC-B/E5AC
100
250 VAC, 30 VDC
(resistive load)
cosφ = 1
50
30
10
5
3
1
0 1 2 3 4
Switching current (A)
E54-CT1L
E54-CT3L
1,500 VAC for 1 min
50 Hz, 98 m/s 2
E54-CT1L: Approx. 14 g
E54-CT3L: Approx. 57 g
None
5 6
