Chapter 2: Hardware Information - Johnson Controls P2000 Hardware Installation

CKM-CE75-E1M
24-10707-112 Rev. D
H
2.
ARDWARE
This chapter provides information about hardware components and technical
specifications for the 12 in. by 14 in. enclosure and CKM-FPO75 power
supply.
12 . 14 . E
IN BY IN
The enclosure already contains the CKM-FPO75 power supply and allows you
to mount the CKM-F8P power distribution module and Mercury access panels
in one compact system. The enclosure comes standard with lock and tamper
switch.
Figure 2-1: 12 in. x 14 in. Enclosure with Power Supply Location
Enclosure Specifications
Category
Power Supply
Mounting Accommodation
Maximum Expansion
Size (W x H x D)
Approximate Weight
1. Authentic Mercury™ devices.
2. Power supply is already included.
I
NFORMATION
NCLOSURE
Description
CKM-FPO75 (75 W)
1
CKM-EP1501, CKM-MR51E, CKM-MR50
2
3 boards
12 in. x 14 in. x 4.5 in. (30.5 cm x 35.6 cm x 11.4 cm)
7.70 lbs (3.5 kg) empty
2-1
Hardware Information
