Comtech EF Data LBC-4000 Installation And Operation Manual page 55

LBC-4000 L-Band Up/Down Converter System
Remote Control
Command
Parameter (Instruction
Type Code and
qualifier)
Concise N/A
Maintenance
Status
Arguments for
Description of arguments
Command or
(Note that all arguments are ASCII numeric
Response to
codes, that is, ASCII codes between 48 and 57)
Query
70 bytes Query only.
numerical Used to Query the Maintenance status of the unit
in concise format. Response is comma delimited.
Syntax:
CMS_aaa.abbb.bccc.cddd.deee.efff.fggg.ghhh.hiii.i
jjj.jkkk.klll.lmmm.mnnn.nooo.oppp.pqqq.q'cr''lf'
where:
aaa.a = 12 VDC supply #1 in volts
bbb.b = 8 VDC supply #1 in volts
ccc.c = 5 VDC supply #1 in volts
ddd.d = 12 VDC supply #2 in volts
eee.e = 8 VDC supply #2 in volts
fff.f= 5 VDC supply #2 in volts
ggg.g = Ref Osc tuning voltage in volts
hhh.h = Converter A IFLO tuning voltage in volts
iii.i= Converter A RFLO tuning voltage in volts
jjj.j = Converter A Input Power in dBm (Reserved
for future use)
kkk.k = Converter A Output Power in dBm
(Reserved for Future use)
lll.l= Converter A temperature in degrees C
mmm.m = Converter B IFLO tuning voltage in volts
nnn.n= Converter B RFLO tuning voltage in volts
ooo.o = Converter B Input Power in dBm
(Reserved for future use)
ppp.p = Converter B Output Power in dBm
(Reserved for future use)
qqq.q = Converter B temperature in degrees C
MN/LBC4000.IOM
Revision 2
Response to
Command
(target to
controller)
N/A
A-15
Query Response to
(Instruction Query
Code and (target to
qualifier) controller)
CMS_ CMS_
x....x
(see description for
details of
arguments)
