L-Band Up/Down Converter System
Introduction
1.3 S
PECIFICATIONS
Characteristic
LBC-4000 L-Band Down Converter IDU
Input Frequency
Output Frequency
Input/Output Impedance
Input Return Loss
Output Return Loss
Input Connector
Output Connector
Gain
User Attenuator Range
Output Power, P1dB
Third Order Intercept
Carrier Spurious
Non-Carrier Spurious
LBC-4000 L-Band Up Converter IDU
Input Frequency
Output Frequency
Input/Output Impedance
Input Return Loss
Output Return Loss
Input Connector
Output Connector
Gain
User Attenuator Range
Input Power Level
Output Power, P1dB
Third Order Intercept
Carrier Spurious
Non-Carrier Spurious
Transmit Phase Noise
External Reference

Table 1-1. Specifications

Specifications

950-2000 MHz, 125 kHz steps (1 kHz optional)
70± 18 MHz (140± 36 MHz optional)
50Ω
15 dB minimum
18 dB minimum
N, Female
BNC, Female
35 dB nominal at minimum attenuation
0 to 40 dB, in 0.25 dB steps (0.1 dB optional)
+10 dBm minimum
+20 dBm minimum
-60 dBc
-60 dBm
70 ± 18 MHz (140 ± 36 MHz optional)
950-2000 MHz, 125 kHz steps (1 kHz optional)
50Ω
15 dB minimum
18 dB minimum
BNC, Female
N, Female
25± 1 dB nominal at minimum attenuation
0 to 40 dB, in 0.25 dB steps (0.1 dB optional)
To +10 dBm, maximum
+10 dBm minimum
+20 dBm minimum
-60 dBc
-75 dBm
Exceeds requirements of MIL-STD-188-164A
5 MHz, 10 MHz –5/+5 dBm
