  • Page 1 Installation Manual ENABLING BRIGHT OUTCOMES...
  • Page 2 Registered office: Barco NV President Kennedypark 35, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com Barco NV Beneluxpark 21, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com...
  • Page 3 Barco. If the purchaser or a third party carries out modifications or repairs on goods delivered by Barco, or if the goods are handled incorrectly, in particular if the systems are operated incorrectly or if, after the transfer of risks, the goods are subject to influences not agreed upon in the contract, all guarantee claims of the purchaser will be rendered invalid.
  • Page 4 Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment FCC responsible: Barco Inc. 3059 Premiere Parkway Suite 400 30097 Duluth GA, United States Tel: +1 678 475 8000...

  • Page 5: Table Of Contents

    HD for fully enclosed projection systems ..........................18 HD in function of modifying optics ............................20 2 Installation preparations...................................21 Installation requirements ................................22 Unpacking the projector ................................23 UDX flight case....................................24 Initial inspection ....................................25 Projector configurations ................................25 Projector air inlets and outlets ..............................30 Free download of Projector Toolset............................30 External cooler and hoses ................................31...
  • Page 6 11.7 Mounting the back cover................................111 11.8 Mounting the small top cover ..............................111 A Specifications.........................................113 Specifications of the UDX-4K40 .............................114 Specifications of the UDX-4K32 .............................115 Specifications of the UDX-4K22 .............................117 Specifications of the UDX-W40 ..............................118 Specifications of the UDX-W32 ............................. 120 R5906113 /08...
  • Page 7 Specifications of the UDX-W22 ............................. 123 Specifications of the UDX-U40............................... 124 Specifications of the UDX-U32............................... 126 A.10 Dimensions of a UDX .................................. 128 A.11 Dimensions of the rigging frame............................128 A.12 Dimensions of the flight case ..............................129 A.13 Technical Regulations ................................. 129 B Stacking UDX projectors ..................................
  • Page 8 R5906113 /08...

  • Page 9: Safety

    Ensure that you understand and follow all safety guidelines, safety instructions and warnings mentioned in this chapter before installing the UDX projector. Clarification of the term “UDX” used in this document When referring in this document to the term “UDX” means that the content is applicable for following Barco products: •...

  • Page 10: General Considerations

    • Before operating this equipment please read this manual thoroughly and retain it for future reference. • Installation and preliminary adjustments should be performed by qualified Barco personnel or by authorized Barco service dealers. • All warnings on the projector and in the documentation manuals should be adhered to.

  • Page 11: Important Safety Instructions

    The term USER and OPERATOR refers to any person other than SERVICE PERSONNEL, AUTHORIZED to operate professional projection systems. The UDX projector is intended "FOR PROFESSIONAL USE ONLY" by AUTHORIZED PERSONNEL familiar with potential hazards associated with high voltage, high intensity light beams and high temperatures generated by the light source and associated circuits.
  • Page 12 • Never stack more than 2 UDX projectors in a hanging configuration (truss) and never stack more than 3 UDX projectors in a base stand configuration (table mount).
  • Page 13 In the event of fire, use sand, CO or dry powder fire extinguishers. Never use water on an electrical fire. Always have service performed on this projector by authorized Barco service personnel. Always insist on genuine Barco replacement parts. Never use non-Barco replacement parts as they may degrade the safety of this projector.
  • Page 14 For lens cleaning follow the instructions precisely as stipulated in the projector manual. • Only use zoom lenses of the Barco TLD+ series on the 4k models of the UDX. Using other lenses will damage the internal optics. For suitable fixed TLD+ lenses contact Barco or see Barco website.

  • Page 15: Product Safety Labels

    Use an appropriate forklift to raise flight cases and take the necessary precautions to avoid personnel injury. Safety Data Sheets for Hazardous Chemicals For safe handling information on chemical products, consult the Safety Data Sheet (SDS). SDSs are available upon request via safetydatasheets@barco.com. 1.3 Product safety labels Light beam related safety labels Label image...

  • Page 16: High Brightness Precautions: Hazard Distance (Hd)

    Safety 1.4 High Brightness precautions: Hazard Distance (HD) Hazard Distance (HD) is the distance measured from the projection lens at which the intensity or the energy per surface unit becomes lower than the applicable exposure limit on the cornea or on the skin.
  • Page 17 Safety (A) SIDE VIEW (B) TOP VIEW Image 1-2 Side view. Theater. Top view. Restriction Zone in the theater. Restricted Access location (boot area of Separation Height. projector). SWSeparation Width. Projector. Based on national requirements, no person is allowed to enter the projected beam within the zone between the projection lens and the related hazard distance (HD).

  • Page 18: Hd For Fully Enclosed Projection Systems

    • This product can only be installed by Barco or sold or leased only to valid laser light show variance holders. In other words our installers are required to have an approved laser light show variance. Such installers may currently hold a valid variance for production of Class IIIb and IV laser light shows and/or for incorporation of the RG3 LIPs into their shows.
  • Page 19 Safety RESTRICTED AREA DIFFUSE REFLECTION Image 1-4 Restricted Access location (enclosed projection Restriction Zone. area). Projection Distance. Projector. SWSeparation Width. Must be minimum 1 meter. Theater (observation area). For this type of setup 3 different HD shall be considered: • HD as discussed in “High Brightness precautions: Hazard Distance (HD)”, page 16, relevant for intrabeam exposure.

  • Page 20: Hd In Function Of Modifying Optics

    Safety 1.6 HD in function of modifying optics Hazard Distance UDX 4K40, UDX 4K40 LC, UDX W40, UDX W40 LC, UDX U40, UDX U40 LC UDX 4K32, UDX W32, UDX U32 UDX 4K26, UDX W26 UDX 4K22, UDX W22 Throw Ra o (TR)

  • Page 21: Installation Preparations

    About this chapter Read this chapter before installing the UDX projector. It contains important information concerning installation requirements for the projector, such as minimum and maximum allowed ambient temperature, humidity conditions, required safety area around the installed projector, required power net, etc.

  • Page 22: Installation Requirements

    Installation preparations 2.1 Installation requirements Environment conditions Table below summarizes the physical environment in which the UDX may be safely operated or stored. Operating Non-Operating Environment Ambient Temperature 0°C (32°F) to 40 °C (104 °F) -15°C (5°F) to 60°C (140°F)

  • Page 23: Unpacking The Projector

    Projector weight Do not underestimate the weight of the UDX. The projector weights about ±92 kg (±202 lbs) without lens. Be sure that the pedestal on which the projector has to be installed is capable of handling five (5) times the complete load of the system.

  • Page 24: Udx Flight Case

    Introduction of the UDX flight case The UDX flight case is designed to transport the UDX in a safe and secure manner, with or without being mounted in its rigging frame. There's also sufficient space in the flight case to place the projector while mounted in the UDX rigging frame.

  • Page 25: Initial Inspection

    Installation preparations the UDX flight case easy to handle. The floor of the flight case wagon is equipped with two small covered compartments to store the remote control and the rigging clamps. Image 2-4: UDX Flight case Order number flight case: R9855884 The dimensions of the flight case are optimal for maximum utilization of the floor area of a truck.
  • Page 26 Installation preparations Rear / Table (R/T) Rear / Ceiling (R/C) (upside down) Rear / Ceiling (R/C) (table position) Front projection The projector is installed, either in a table mount or ceiling mount configuration, at the same side of the screen as the audience.
  • Page 27 Installation preparations AUDIENCE BACKSTAGE Image 2-7: Rear projection AUDIENCE BACKSTAGE Image 2-8: Rear projection, ceiling mounted in table position R5906113 /08...
  • Page 28 Installation preparations Positioning the projector Image 2-9: Positioning the projector The projector should be installed at right angles (horizontally and vertically) to the screen at a distance PD. Note the distance (A) between lens centre and table surface is slightly variable. This distance (A) is nominal 223 mm in case all feet are turned in completely and the vertical lens shift is set to zero (0).
  • Page 29 Installation preparations +130% +130% -40% +40% -100% -40% -100% +40% Image 2-10: Vertical and horizontal shift range DMD. Field of view. It is mechanical possible to shift outside the recommended field of view, but it will result in a decline of image quality depending on the used lens and the zoom position of the used lens.

  • Page 30: Projector Air Inlets And Outlets

    Air inlets and outlets Image 2-12 The UDX has 4 air inlet channels and 2 air outlets. The air outlets are located at the rear of the projector. The air inlets are located at the top, bottom and right side of the projector.

  • Page 31: External Cooler And Hoses

    Only coolers and hoses exclusively developed for this application and approved by Barco are allowed to be used in this setup. The cooler is controlled by the projector and ensures that the ambient temperature of the laser banks, phosphor wheel and diffuser wheel are within specs.
  • Page 32 Installation preparations R5906113 /08...

  • Page 33: Pulse Remote Control Unit

    Pulse Remote Control Unit Overview • Remote control, battery installation • Remote control, protocol setup • Remote control, on/off button • Functionality overview • Functions of the “button pressed indicator” • Function of the RGB filter button • Displaying and Programming addresses into the RCU •...

  • Page 34: Remote Control, Battery Installation

    Pulse Remote Control Unit 3.1 Remote control, battery installation Where to find the batteries for the remote control ? The batteries are not placed in the remote control unit to avoid control operation in its package, resulting in a shorter battery life time. At delivery the batteries can be found in a separated bag attached to the remote control unit.

  • Page 35: Remote Control, Protocol Setup

    Depending on the projector to control the remote control can be switched between these protocols. Which protocol to use • The NEC protocol has to be used for Barco projectors based on the Pulse platform: F70, F80, F90, HDX 4K, UDX, XDL, etc. •...

  • Page 36: Functionality Overview

    Pulse Remote Control Unit To activate the remote control press the on/off button. To deactivate the remote control press the on/off button again. Default when (re)placing batteries, is “ON”. Image 3-5 3.4 Functionality overview Remote Control Unit buttons Image 3-6 Button pressed indicator Backspace (while entering values) Shutter open...

  • Page 37: Functions Of The "Button Pressed Indicator

    Pulse Remote Control Unit 3.5 Functions of the “button pressed indicator” Functions button pressed indicator • Rapidly flashes when commands are sent, this is the normal “button pressed” indication. • 1 Short flash when remote control is switched ON by means of the on/off button. •...

  • Page 38: Using The Xlr Connector Of The Rcu

    Pulse Remote Control Unit 3.8 Using the XLR connector of the RCU Connecting a cable with the XLR connector will reset the broadcast address of the RCU to its default value '0'. How to use the XLR connector Remove the XLR cover by pulling it backwards. Image 3-7 Connect a cable with XLR plug into the XLR connector of the RCU.

  • Page 39: Silicone Protection Sleeve For The Rcu (Optional)

    (optional) Introduction Barco offers a silicone form fitting protection sleeve for the Pulse RCU. The silicone material keeps it comfortably, non slip and soft touch. All buttons and holes remain accessible. The sleeve is quick and easy installed. For ordering information see Barco website.
  • Page 40 Pulse Remote Control Unit R5906113 /08...

  • Page 41: Physical Installation

    Physical Installation Overview • Connecting the projector with the power net • Alignment of a table mounted projector • Connecting the projector to the external cooler R5906113 /08...

  • Page 42: Connecting The Projector With The Power Net

    Physical Installation 4.1 Connecting the projector with the power net CAUTION: Use only the power cord provided with the projector. How to connect with local power net Ensure that the power switch stands in the '0' (OFF) position (reference 1 Image 4-1). Image 4-1: Power input Connect the female side of the power cord with the power input socket of the projector (reference 2).

  • Page 43: Connecting The Projector To The External Cooler

    2 cooling tubes of 8 meters length • The data cable to connect between the UDX and the external cooler How to access the hose connections on the projector Remove the back cover of the projector. See “Removal of the back cover”, page 108.
  • Page 44 Physical Installation Image 4-5 Install the back cover again, without the protective plate. See “Mounting the back cover”, page 111. How to connect the hoses and cable? Ensure that all connectors of the hoses, chillers and projector are clean. Wipe away any dust before attaching. Connect the hoses between the projector and external cooler as illustrated in Image 4-6 (reference 1).

  • Page 45: Lenses & Lens Selection

    Lenses & Lens selection Overview • Available lenses • Lens selection • Lens installation • Lens removal • Scheimpflug adjustment R5906113 /08...

  • Page 46: Available Lenses

    Limited amount of available lenses The 4k variants of the UDX projectors have an Actuator built in them to help provide a clear 4k image. This extra device means that less space is available in the projector for lenses, thus causing a more restricted amount of lenses that can be used.

  • Page 47: Lens Selection

    How to select the right lens Determine the required screen width (SW). Determine the approximate position of the projector in the room. Start up the Lens Calculator on the Barco website: https://lenscalculator.barco.com/ to determine the possible lenses for your configuration.
  • Page 48 Lenses & Lens selection How to install Place the lens holder in the “unlocked” position. Do this by pulling the lens lock handle (reference 1, Image 5- 10) outward and then towards the lens power supply socket (reference 2) as illustrated. Image 5-10: Lens installation, preparation Remove the dust cover from the lens opening.

  • Page 49: Lens Removal

    Lenses & Lens selection Image 5-12: Lens installation Insert the lens until the connector seats into the socket and de secondary lock (reference 3) makes an audible clicking sound. Warning: Do not release the Lens yet, as the Lens may fall out of the Lens Holder. Secure the lens in the lens holder by sliding the primary lens lock handle into the “locked”...
  • Page 50 Lenses & Lens selection Image 5-14: Unlock the lens Pull down the secondary lock on the lower left side of the lens holder as illustrated (Image 5-15). Gently pull the lens out of the lens holder. Image 5-15: Lens removal It's recommended to place the Lens caps of the original Lens packaging, back on both sides of the removed Lens to protect the optics of the Lens.

  • Page 51: Scheimpflug Adjustment

    Lenses & Lens selection Image 5-16 5.5 Scheimpflug adjustment What is Scheimpflug? The lens holder has to be adjusted so that the “sharp focus plane” of the projected image falls together with the plane of the screen (Fp1→Fp2). This is achieved by changing the distance between the DMD plane and the lens plane (Lp1→Lp2).
  • Page 52 Lenses & Lens selection Scheimpflug adjustment points Image 5-18: Scheimpflug adjustments Scheimpflug adjustment screw Lock screw Scheimpflug adjustment screw Lock screw Scheimpflug adjustment screw Lock screw Required tools • Allen wrench 5 mm • Allen wrench 8 mm • Torque wrench with 8 mm hex socket Preparation steps: Project a green focus test pattern in 4k.
  • Page 53 Lenses & Lens selection Image 5-20: Center focusing Scheimpflug adjustment steps Sharpen the image at the bottom left corner of the screen by turning the upper left Scheimpflug adjustment screw either clockwise or counterclockwise (reference 1 Image 5-21). Use a 5 mm Allen wrench. Image 5-21: Left bottom focusing As a result of this action, the focus in the center will fade a bit.
  • Page 54 Lenses & Lens selection Image 5-23: Top focusing Optimize the focus of the projected image in the center of the screen using the motorized focus control (Local Keypad). Image 5-24 Repeat from step 1 until the projected focus pattern is as sharp as possible in the center, left, right, top and bottom of the screen.

  • Page 55: Input & Communication

    Input & Communication Overview • Introduction • Removal of an input board • Installation of an input board or a communication board • Input source connections – Quad combo input Mark II • Input source connections – Quad combo input Mk I •...

  • Page 56: Introduction

    Free input slot (here filled with the Quad DP 1.2 Input board) 6.2 Removal of an input board WARNING: The procedures below may only be performed by Barco trained and qualified technicians. CAUTION: Always wear a wrist band which is connected to the ground while handling the electrostatic discharge (ESD) sensitive parts.

  • Page 57: Installation Of An Input Board Or A Communication Board

    After removing one of the input modules, immediately replace with an other one or install a dummy front plate on the unused input slot. 6.3 Installation of an input board or a communication board WARNING: The procedures below may only be performed by Barco trained and qualified technicians. R5906113 /08...
  • Page 58 Input & Communication CAUTION: Always wear a wrist band which is connected to the ground while handling the electrostatic discharge (ESD) sensitive parts. Required tools Phillips screwdriver PH1 The procedure below is applicable to all the input modules of the Input & Communication Unit of the projector.

  • Page 59: Input Source Connections - Quad Combo Input Mark Ii

    About the Quad combo input Mark II Due to demand from the market, Barco has created a second generation of the Input board to support 12G input and throughput on the SDI connectors. From the release of this board onward, the Quad combo input will be supported and will be the standard input board in every Input &...
  • Page 60 Input & Communication Only Input A accepts 12G SDI signals . While it is technically possible to connect a 12G SDI source to Input B and connect that source to another projector in line (using Input/Output D), this first projector itself will not be able to process the 12G signal. HD, 3G &...
  • Page 61 Input & Communication Overview Mark 2 Quad Combo Input board SDI IN SDI IN/OUT 3G/12G SYNC SYNC SYNC SYNC SYNC SYNC SYNC HDMI SYNC HDBT 1 HDBT 2 Image 6-9 Quad SDI channel A: 3G/12G input DisplayPort Input Quad SDI channel B: 3G input HDMI input Quad SDI channel C: 3G SDI input + 3G/12G HDBaseT input 1...
  • Page 62 Up to 4096 x 2160 @50 Hz • Up to 4096 x 2160 @60 Hz Native video timings • UDX-U-series: 1600 x 1200 @60 Hz • UDX-W-series: 1920 x 1200 @60 Hz • UDX-4k-series: 3840 x 2400 @60 Hz CAUTION: The HDBaseT inputs can bridge a distance of 100 m but are sensitive to radiated electromagnetic interference: radiated electromagnetic interference (e.g.
  • Page 63 2048 x 2160 @50 Hz • 2048 x 2400 @60 Hz Native video timings • UDX-U-series: 1600 x 1200 @60 Hz • UDX-W-series: 1920 x 1200 @60 Hz • UDX-4k-series: 3840 x 2160 @60 Hz CAUTION: In order to display high resolution images (e.g.: 3840 x 2160 @60 Hz) via the DP1.2 input, the quality of the cable must be adequate, in addition the length of the cable can also influence the performance.

  • Page 64: Input Source Connections - Quad Combo Input Mk I

    • Loop-through functionality • 12G SDI support • Network connectivity on HDBaseT inputs To upgrade your input board to the Mark 2 board, contact Barco. Overview Mark 1 Quad Combo Input board SDI IN SDI IN/OUT SYNC SYNC SYNC...
  • Page 65 Input & Communication Color space YCbCr Color depth 10 bpc Chroma sampling 4:2:2 Not supported • Audio support • 3D support • Interlaced support • Segmented frame support • Loop-through functionality Video timings Type Port type Format progressive HD-SDI Single link Up to 1920 x 1080 @24 Hz Quad link Up to 1920 x 1080 @25 Hz...
  • Page 66 Up to 4096 x 2160 @50 Hz • Up to 4096 x 2160 @60 Hz Native video timings • UDX-U-series: 1600 x 1200 @60 Hz • UDX-W-series: 1920 x 1200 @60 Hz • UDX-4k-series: 3840 x 2400 @60 Hz CAUTION: The HDBaseT inputs can bridge a distance of 100 m but are sensitive to radiated electromagnetic interference: radiated electromagnetic interference (e.g.
  • Page 67 1600 x 1200 @120 Hz layout) • 2560 x 1080 @120 Hz • 2560 x 1600 @120 Hz Native video • UDX-U-series: 1600 x 1200 @60 Hz timings • UDX-W-series: 1920 x 1200 @60 Hz • UDX-4k-series: 3840 x 2400 @60 Hz R5906113 /08...

  • Page 68: Input Source Connections - Quad Dp 1.2 Input Board

    Input & Communication 6.6 Input source connections – Quad DP 1.2 Input board Quad DP 1.2 Input board DP A SYNC DP B SYNC DP C SYNC DP D SYNC Image 6-11 Quad DisplayPort channel A input Quad DisplayPort channel B input Quad DisplayPort channel C input Quad DisplayPort channel D input The yellow LED lights up when valid input sync is detected.

  • Page 69: Input Source Connections - Sfp Input Board

    UDX-4k-series: 3840 x 2400 @60 Hz 6.7 Input source connections – SFP Input Board The Barco SFP Input Board has been designed and tested to work alongside the Barco SFP Output Board. However, it is possible that the SFP Input board can also work with other third-party devices that support 12G over fiber.
  • Page 70 Input & Communication SYNC SYNC Opt A Opt B SFP A SFP B Image 6-12 Neutrik Duo optical connector or Neutrik Quad optical connector Neutrik Duo optical connector or Neutrik Quad optical connector 2x12G SDI/10GE transceiver Input specifications For readability, the video timings listed are summarized. For the full list of video timings, refer to the appendices.
  • Page 71 SFP+ fiber transceiver Optional breakout Optical adapter Barco delivers only the Fiber-Network input board and SFP+ fiber transceivers. The customer has to buy the SFP+ transceiver and the optional breakout adapter or the fiber integrated cable. Remove the plate covering the access to the SFP cages.
  • Page 72 Advanced quad cable Internal fiber cable Barco delivers only the Fiber-Network input board and SFP+ fiber transceivers. The customer has to buy the SFP+ transceiver, the Neutrik OpticalCon Quad, the internal cable and cable. Remove one plate covering the access to a Neutrik connector location.

  • Page 73: Communication Connections

    Neutrik OpticalCon Quad Advanced Quad cable Barco delivers only the Fiber-Network input board and SFP+ fiber transceiver. The customer has to buy the SFP+ transceivers, both Neutrik connectors, the internal cable and the cable. Remove both plates covering the access to a Neutrik connector locations.
  • Page 74 Sub-D connector and an USB connector acting as RS input when connected to an USB input of a PC. You can use the RS232/RS422 input to connect a local PC to your UDX series projector. By this way you can configure and control your projector from your local PC.
  • Page 75 Input & Communication RS232/422 input (Sub-D) port Description TXD- : Transmitted Data DTR : Data Terminal Ready [RS232] TXD+ : Transmitted Data [RS422] GND : Ground DSR : Data Set Ready [RS232] RXD+ : Received Data [RS422] — (not connected) — CTS : Clear To Send RI : Ring Indicator RS232...

  • Page 76: Led And Button Indication Chart

    Input & Communication 6.9 LED and Button indication chart Button Backlight Status Description Button Color status Standby button Blinking WHITE (slow) Projector starts up (booting) Blinking WHITE (fast) Firmware upgrade Solid WHITE Projector is in Standby mode Blinking BLUE Projector goes to ON mode Solid BLUE Projector is ON Blinking RED...

  • Page 77: Wifi & Gsm Module

    WiFi & GSM Module Regulatory information for US and Canada can be accessed in the OSD of the projector. In order access it, select System Settings → Regulatory Information → Country. R5906113 /08...

  • Page 78: Compliance Fcc

    WiFi & GSM Module 7.1 Compliance FCC Federal Communication Commission Interference Statement You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules.

  • Page 79: Installation Of The Wifi Module

    Cet appareil numérique de la classe A est conforme a la norme NMB-003 du Canada. 7.3 Installation of the WiFi module WARNING: The procedures below may only be performed by Barco trained and qualified technicians. CAUTION: Always wear a wrist band which is connected to the ground while handling the electrostatic discharge (ESD) sensitive parts.
  • Page 80 WiFi & GSM Module Image 7-1 Plug in the antenna wire connector on the WIFI module. Ensure to use bottom connection. Image 7-2 Place the WiFi module (2) upon the plastic socket (1). Note that the plastic socket is provided with two positioning pins which fits the small holes of the WiFi module.
  • Page 81 WiFi & GSM Module Image 7-4 Install the data wire by plugging in the electrical connectors (connector J327, reference 1). Image 7-5 Position the antenna (7) in the hole on the front side of the Communication module. Secure the antenna wire by installing the lock washer and nut (8). R5906113 /08...
  • Page 82 WiFi & GSM Module Image 7-6 Turn on the antenna (9). Image 7-7 Stick the black label with certification numbers on the front plate of the communication board. Image 7-8: Example of the black label on the communication board Reinsert the communication board. R5906113 /08...

  • Page 83: Installation Of The Gsm Module

    WiFi & GSM Module 7.4 Installation of the GSM module WARNING: The procedures below may only be performed by Barco trained and qualified technicians. CAUTION: Always wear a wrist band which is connected to the ground while handling the electrostatic discharge (ESD) sensitive parts.
  • Page 84 WiFi & GSM Module Image 7-10 Slide in the SIM card into the SIM card holder (2). Ensure that the truncated corner of the SIM card is facing the edge of the module (3). Image 7-11 Plug in the antenna wire connector on the front side of the GSM module (4). Image 7-12 Insert the GSM module with antenna wire into the connector (5).
  • Page 85 WiFi & GSM Module Image 7-13 Push the antenna connector through the hole in the front plate and secure the antenna wire by installing the lock washer and nut (7). Image 7-14 Install the antenna by screwing it on its base (8). Stick the black label with certification numbers on the front plate of the communication board.
  • Page 86 WiFi & GSM Module R5906113 /08...

  • Page 87: Laser Range Finder & Camera Kit

    Purpose of the laser range finder & camera kit Barco provides a kit with a laser range finder and USB camera to help measure the distance from the front of the projector to the projected surface. And this by the simple press of a button.

  • Page 88: Overview

    • Laser range finder & camera assembly • 2 Allen screws (M4 x 6) • A new cover plate for the UDX front cover • Battery holder (optional) • 2 Torx screws (M3 x 8 T10) The battery holder is fit for 2 AA batteries. These batteries are not included in the kit.

  • Page 89: Installing The Laser Range Finder

    Laser range finder & camera kit 8.2 Installing the laser range finder Required tools • Allen wrench 3 mm • Torx wrench T10 Required parts • The laser range finder & camera kit • AA batteries (2 pieces, not included in the kit) Replacing the cover plate Remove the front cover.

  • Page 90: Adjusting The Laser Range Finder

    Laser range finder & camera kit Image 8-5: Mounting the laser range finder assembly onto the UDX Use the USB cable on the front side of the projector labeled “2” (reference 1, Image 8-5) and plug it in the USB connector of the camera (reference 2, Image 8-1).
  • Page 91 Laser range finder & camera kit Adjusting the laser range finder Make sure your projector is mounted perpendicular to the screen. For more info, see “Alignment of a table mounted projector”, page 42. Turn off the light source and activate the laser ranging. Test to see if the laser range goes similarly perpendicular to the screen as the light source did.
  • Page 92 Laser range finder & camera kit R5906113 /08...

  • Page 93: Getting Started

    Getting Started How to control the projector ? The projector can be controlled by the local keypad, by the remote control unit or by browser application. Location of the local keypad ? The local keypad is located on the input side of the projector. Remote control functions.

  • Page 94: Power On Projector

    The current mains input voltage is indicated on the voltmeter just above the power switch. The background image of the startup screen and info screens can be changed with Projector Toolset with an installed UDX plug-in. Status overview Once the projector is started, press Status to get an overview of parameters such as : •...

  • Page 95: Switching To Standby

    Getting Started • Chosen source • Current resolution and refresh rate • Chosen communication method and IP address (if connected) • Active functions Starting image projection Make sure the available sources are connected to the appropriate input ports. Tip: If properly connected, the “SYNC” LED will light up ORANGE. Press the Input Selection button on the keypad or on the remote control until: •...

  • Page 96: Using The Rcu

    Getting Started How to power off Switch off the projector with the mains switch. '0' must be pressed. Image 9-5 Unplug the power cord from the projector. 9.4 Using the RCU Pointing to the reflective screen Point the front of the RCU to the reflective screen surface. Image 9-6: IR control via reflective screen Hardwired to the XLR input Plug one end of the remote cable in the connector on the bottom of the RCU.

  • Page 97: Projector Address

    Using the RCU in combination with a 3D emitter When using a 3D emitter that radiates IR beams (e. g. the optional 3D emitter that Barco provides), the IR beams of the 3D emitter may interfere with the IR communication between projector and the RCU.

  • Page 98: Quick Setup Via Direct Access

    Getting Started The choice between '0' and '1' can be selected in the GUI: “System Settings” → “Communication” →“IR Control “. Placing new batteries in the remote control or plugging the remote to a projector via a cable will automatically reset the address back to its default value '0'. 9.6 Quick setup via Direct access Quick source selection Press the Input button on the remote control or local keypad.

  • Page 99: Software Update

    Download the latest firmware (format .fw) from Barco's website in the same way as for Projector Toolset. Start Projector Toolset and make a connection with the projector. For more information, see the Projector Toolset user guide.
  • Page 100 Power on the projector. Wait until the Power on/off button is either lit white or blue. Download the latest firmware file ( format .fw) from Barco's website. The firmware can be downloaded for free from Barco's website, (URL: http://www.barco.com). Click on myBarco and log in to get access to secured information.
  • Page 101 Getting Started The update file will be transferred to the projector and installed. The projector will reboot when completed. Take note that the update process can take a long time to complete. R5906113 /08...
  • Page 102 Getting Started R5906113 /08...

  • Page 103: Maintenance

    Maintenance About this chapter This chapter contains general maintenance procedures. Overview • Cleaning the lens • Cleaning the exterior of the projector • Replacement of the metal dust filters • Replacement of the synthetic air filter R5906113 /08...

  • Page 104: Cleaning The Lens

    Maintenance 10.1 Cleaning the lens To minimize the possibility of damage to optical coatings, or scratches to lens surfaces follow the cleaning procedure as described here precisely. Required tools • Compressed air • Clean micro fiber lens cleaning cloth (e.g. Toraysee® cloth(s)) •...
  • Page 105 Maintenance How to replace the small air filter Remove the light processor cover. See “Removal of the left cover”, page 108. Locate the metal filter on the inside of the cover. Push both filter holders to the outside and flip the filter out of the holder as illustrated. Image 10-1: Small metal filter replacement Remove the filter and clean it.

  • Page 106: Replacement Of The Synthetic Air Filter

    Maintenance Clean the metal dust filters Remove most contamination with a vacuum cleaner. Blow remaining dust away with compressed air in an other room or outside. If you cannot clean the filter anymore, insert a new one. 10.4 Replacement of the synthetic air filter WARNING: Switch off the projector and unplug the power cord before starting the procedure.

  • Page 107: Removal And Installation Of The Projector Covers

    Removal and installation of the projector covers Overview • Removal of the front cover • Removal of the left cover • Removal of the back cover • Removal of the small top cover • Mounting the front cover • Mounting the left cover •...

  • Page 108: Removal Of The

    Removal and installation of the projector covers 11.1 Removal of the front cover Required tools 7 mm flat screw driver How to remove Remove the lens. See “Lens removal”, page 49. Release the three captive screws (reference 1). Image 11-1: Front cover removal Remove the front cover.

  • Page 109: Removal Of The Small Top Cover

    Removal and installation of the projector covers How to remove Loosen the captive three screws (reference 1) of the backside of the projector. Use a 7 mm flat screwdriver. Remove the cover from the projector. Image 11-3: Remove back cover 11.4 Removal of the small top cover Required tools 7 mm flat screw driver...

  • Page 110: Mounting The

    Removal and installation of the projector covers Image 11-5: Flip the small top cover 11.5 Mounting the front cover Required tools 7 mm flat screw driver How to mount Place the front cover on its place, with the filter facing the projector. Image 11-6: Mount front cover Fasten the three captive screws (reference 1).

  • Page 111: Mounting The

    Removal and installation of the projector covers Image 11-7: Mount left cover (light processor side) Fasten the four captive screws (reference 1). 11.7 Mounting the back cover Required tools 7 mm flat screw driver How to mount Place the back cover on the backside of the projector. Image 11-8: Mount back cover Fasten the three captive screws (reference 1).
  • Page 112 Removal and installation of the projector covers Image 11-9 Flip down the cover, so that the captive screws nicely fit the inserts (reference 2). Fasten the two captive screws (reference 1, Image 11-9). Image 11-10 R5906113 /08...

  • Page 113: A Specifications

    Specifications About this chapter This chapter gives an overview of the specification of the UDX projector as well as the dimensions and the center of gravity. Overview • Specifications of the UDX-4K40 • Specifications of the UDX-4K32 • Specifications of the UDX-4K22 •...

  • Page 114: Specifications Of The Udx-4K40

    Specifications A.1 Specifications of the UDX-4K40 Specifications Projector type 4K UHD 3-chip DLP digital projector Technology 0.9 DMD™ x3 Resolution 3,840 x 2,400 (4K UHD) / 2,560 x 1,600 (native) / 5,120 x 3,200 (processing) Brightness 37,500 (WQ)/36,500 (4K UHD) center lumens // 36,500 (WQ)/35,500 (4K...

  • Page 115: Specifications Of The Udx-4K32

    Certifications Compliant with UL60950-1 and EN60950-1 complies with FCC rules & regulations, part 15 Class A and CE EN55032 Class A, Rohs Warranty 3 years A.2 Specifications of the UDX-4K32 Specifications Projector type 4K UHD 3-chip DLP digital projector Technology 0.9"...
  • Page 116 Specifications Light source lifetime 25,000 hrs Optical dowser Digital Picture-in-picture Two sources simultaneously Orientation 360° Sealed DLP™ core standard DMX 512 standard WARP Direct adjust OSD + toolset Image processing Embedded warp & blend Keystone correction Integrated web server CLO (constant light output) Standard Active eye wear (optional), passive circular (optional);...

  • Page 117: Specifications Of The Udx-4K22

    Specifications A.3 Specifications of the UDX-4K22 Specifications Projector type 4K UHD 3-chip DLP digital projector Technology 0.9" DMD™ x3 Resolution 3,840 x 2,400 (4K UHD) / 2,560 x 1,600 (native) / 5,120 x 3,200 (processing) Brightness 20,000 (WQ)/19,000 (4K UHD) center lumens* // 19,000 (WQ)/18,000 (4K...

  • Page 118: Specifications Of The Udx-W40

    Compliant with UL60950-1 and EN60950-1, complies with FCC rules & regulations, part 15 Class A and CE EN55032 Class A, Rohs Warranty 3 years Software upgradeable. Check with your local authorized Barco sales representative for full details. A.4 Specifications of the UDX-W40 Specifications...
  • Page 119 Specifications Light source lifetime 20,000 hrs Optical dowser Digital Picture-in-picture Two sources simultaneously Orientation 360° Sealed DLP™ core standard DMX 512 standard WARP Direct adjust OSD + toolset Image processing Embedded warp & blend Keystone correction Integrated web server CLO (constant light output) Standard Active eye wear (optional), passive circular (optional);...

  • Page 120: Specifications Of The Udx-W32

    Specifications A.5 Specifications of the UDX-W32 Specifications Projector type WUXGA 3-chip DLP digital projector Technology 0.96" DMD™ x3 Resolution 1,920 x 1,200 Brightness 32,000 center lumens* / 31,000 ansi lumen / 34,000 ISO Contrast ratio 2,000:1 Brightness uniformity Aspect ratio...

  • Page 121: Specifications Of The Udx-W26

    Compliant with UL60950-1 and EN60950-1 complies with FCC rules & regulations, part 15 Class A and CE EN55032 Class A, Rohs Warranty 3 years +/- 10% A.6 Specifications of the UDX-W26 Specifications Projector type WUXGA 3-chip DLP digital projector Technology 0.96"...
  • Page 122 (WxLxH) 800 x 1,200 x 685 mm (31.49 x 47.24 x 26.96") Weight 92kg (202 lbs)/shipping weight from factory: 110kg (242 lbs) Standard accessories Power cord, wireless/XLR wired rugged remote control Certifications Warranty 3 years Software upgradeable, please contact your local authorized Barco sales representative R5906113 /08...

  • Page 123: Specifications Of The Udx-W22

    Specifications A.7 Specifications of the UDX-W22 Specifications Projector type WUXGA 3-chip DLP digital projector Technology 0.96" DMD™ x3 Resolution 1,920 x 1,200 Brightness 21,000 center lumens* / 20,000 ansi lumens / 22,500 ISO Contrast ratio 2,000:1 Brightness uniformity Aspect ratio...

  • Page 124: Specifications Of The Udx-U40

    Compliant with UL60950-1 and EN60950-1 complies with FCC rules & regulations, part 15 Class A and CE EN55032 Class A, Rohs Warranty 3 years Software upgradeable, please contact your local authorized Barco sales representative A.8 Specifications of the UDX-U40 Specifications...
  • Page 125 Specifications Light source lifetime 20,000 hrs Optical dowser Digital Picture-in-picture Two sources simultaneously Orientation 360° Sealed DLP™ core standard DMX 512 standard WARP Direct adjust OSD + toolset Image processing Embedded warp & blend Keystone correction Integrated web server CLO (constant light output) Standard Active eye wear (optional), passive circular (optional);...

  • Page 126: Specifications Of The Udx-U32

    Specifications A.9 Specifications of the UDX-U32 Specifications Projector type UXGA 3-chip DLP digital projector Technology 0.96" DMD™ x3 Resolution 1,600 x 1,200 Brightness 30,000 center lumens* / 29,000 ansi lumen / 32,000 ISO Contrast ratio 2,000:1 Brightness uniformity Aspect ratio...
  • Page 127 Specifications Control XLR wired + IR, RS232, Wifi** (opt), GSM** (opt) Network connection 10/100 base-T, RJ-45 connection, Wifi** (optional) Power requirements 120-160V (reduced power) / 200-240V (+/- 10%), 20A, 50-60Hz Max. power consumption 2,900W nom/3,100W max / STBY less than 10W Noise level (typical at 25°C/ 52dB(A) 77°F)

  • Page 128: Dimensions Of A Udx

    Specifications A.10 Dimensions of a UDX Overview Image A-1: Dimensions, in mm Geometrical centre A.11 Dimensions of the rigging frame Overview 1018,97 463,3 978,38 Image A-2: Dimensions, in mm R5906113 /08...

  • Page 129: Dimensions Of The Flight Case

    Specifications A.12 Dimensions of the flight case Overview 1133 Image A-3: Dimensions, in mm A.13 Technical Regulations Certificates Image A-8: Image A-4: Image A-5: Image A-6: CE Image A-7: CEBEC Image A-9: FCC EAC mark Rohs OK mark CCC mark mark label Image A-10:...
  • Page 130 Specifications R5906113 /08...

  • Page 131: B Stacking Udx Projectors

    Stacking UDX projectors R5906113 /08...

  • Page 132: Stacking Udx Projectors

    Stacking UDX projectors B.1 Stacking UDX projectors WARNING: UDX projectors can be stacked up on top of each other on a flat surface, or suspended from a truss using the rigging frame. But keep the following in mind: It is allowed to stack maximum three projectors...
  • Page 133 Stacking UDX projectors Image B-3 Repeat the previous step for each overlapping corner of all stacked rigging frames. In long-term installations, it is advised to also install swivels between the two projectors in order to make it easier to access the metal air filter on the top of the projector.
  • Page 134 Stacking UDX projectors R5906113 /08...

  • Page 135: C Overview Video Timings For Video Interfaces

    Overview video timings for video interfaces Overview • Overview video timings • Overview video timings SDI Inputs • Overview video timings HDMI 2.0 inputs • Overview video timings DisplayPort 1.2 inputs • Overview video timings HDBaseT inputs R5906113 /08...

  • Page 136: Overview Video Timings

    C.1 Overview video timings List of compatible signals The following table specifies the video signals that the projector can project. Barco Events projectors supports the signal with “X” in the Compatible signals column. Note: Support for refresh rates 24.00, 30.00, 60.00 Hz automatically includes support of 1/1.001 x those refresh rates.

  • Page 137: Overview Video Timings Sdi Inputs

    Overview video timings for video interfaces Compatible signal 12G SDI Input on Mk Vertical II Input HDBaseT & refresh rate Resolution HDMI 2.0 3G SDI DisplayPort board & HDMI 1.4 (Hz) Inputs Inputs 1.2 Inputs Fiber Inputs Network Inputs 2048 x 1080 —...

  • Page 138: Overview Video Timings Hdmi 2.0 Inputs

    Overview video timings for video interfaces Video timing Vertical refresh rate Type Port Type (active pixels x active (Hz) lines) 1920 x 1080 HD-SDI Single Link & Quad Link 1920 x 1080 HD-SDI Single Link & Quad Link 1920 x 1080 3G-SDI Single Link &...

  • Page 139: Overview Video Timings Displayport 1.2 Inputs

    Overview video timings for video interfaces Video timing Vertical refresh rate (Hz) 3D support? (active pixels x active lines) 1280 x 960 1280 x1024 1400 x 1050 1600 x 1200 1920 x 1080 Frame packing Top – bottom 1920 x 1080 1920 x 1080 1920 x 1080 Side by Side (SbS) progressive...
  • Page 140 Overview video timings for video interfaces Video timing Available layout modes, Vertical refresh rate other than standard Support for 3D? (active pixels x active (Hz) layout (1 x 1 layout) lines) 640 x 480 800 x 600 960 x 1080 4 Quadrant mode (2 x 2 Active 3D layout)
  • Page 141 Overview video timings for video interfaces Video timing Available layout modes, Vertical refresh rate other than standard Support for 3D? (active pixels x active (Hz) layout (1 x 1 layout) lines) 1920 x 2160 2 Column mode (2 x 1 Passive stereo layout) 1920 x 2160...

  • Page 142: Overview Video Timings Hdbaset Inputs

    Overview video timings for video interfaces C.5 Overview video timings HDBaseT inputs Overview The following standard video formats are available for the projector. Note: support for refresh rates 24.00, 30.00, 60.00 Hz automatically includes support of 1/1.001 x those refresh rates. Available layout modes, other Video timing Vertical refresh rate (Hz)
  • Page 143 Overview video timings for video interfaces Available layout modes, other Video timing Vertical refresh rate (Hz) than standard layout (1 x 1 (active pixels x active lines) layout) 3840 x 2160 3840 x 2160 4096 x 2160 4096 x 2160 4096 x 2160 R5906113 /08...
  • Page 144 Overview video timings for video interfaces R5906113 /08...

  • Page 145: Glossary

    Glossary Hazard Distance (HD) is the distance measured from the projection lens at which the intensity or the energy per surface unit becomes lower than the applicable exposure limit on the cornea or on the skin. The light beam is considered (to be) unsafe for exposure if the distance from a person to the light source is less than the HD. Hazard Distance (HD) is the distance measured from the projection lens at which the intensity or the energy per surface unit becomes lower than the applicable exposure limit on the cornea or on the skin.
  • Page 146 Glossary Projector address Address installed in the projector to be individually controlled. Broadcast address Projector will always execute the command coming from a RCU programmed with that broadcast address. R5906113 /08...

  • Page 147: Index

    Index Projector 128 rigging frame 128 Address Distance meter 31, 87 Program DMX input 74 RCU 37 DMX interface 74 Air flow 30 DMX out 74 Air inlets 30 Download plug-in 30 Air outlets 30 Download Projector Toolset 30 Alignment Dust filter Table mounted projector 42 Clean 106...
  • Page 148 Index GSM module Lens installation 47 Installation 77, 83 Lens removal 49 Lens selection 47 Lenses 45 Lens selection 47 Hazard Distance 16, 18 Modifying optics 20 Hazardous Chemicals 15 High Brightness precautions 16 Maintenance 103 Horizontal tilt range 29 Mechanical check 25 How to use mini-jack...
  • Page 149 Index RCU 33 Input 59, 64, 68 Remote Control Unit 33 Fiber 69 SFP 69 Small form-factor pluggable 69 Specifications 113 UDX-4K22 117 Quick setup 98 UDX-4K32 115 UDX-4K40 114 UDX-U32 126 UDX-U40 124 UDX-W22 123 UDX-W26 121 Address 37...
  • Page 150 R5906113 /08 | 2019-09-06 Registered office: Barco NV | President Kennedypark 35, 8500 Kortrijk, Belgium Barco NV | Beneluxpark 21, 8500 Kortrijk, Belgium www.barco.com...

Table of Contents
