  • Page 1 UDX series User Manual ENABLING BRIGHT OUTCOMES...
  • Page 2 Product revision Software Revision: 1.9.x Barco NV Beneluxpark 21, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com...
  • Page 3 Barco. If the purchaser or a third party carries out modifications or repairs on goods delivered by Barco, or if the goods are handled incorrectly, in particular if the systems are operated incorrectly or if, after the transfer of risks, the goods are subject to influences not agreed upon in the contract, all guarantee claims of the purchaser will be rendered invalid.
  • Page 4 Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment FCC responsible: Barco Inc. 3059 Premiere Parkway Suite 400 30097 Duluth GA, United States Tel: +1 678 475 8000...

  • Page 5: Table Of Contents

    3.10 Installation of an input board or a communication board....................59 4 Getting Started.........................................61 Power on projector ...................................62 Switching to standby ..................................64 Power off projector ...................................65 Using the RCU....................................66 Projector Address .....................................68 4.5.1 Controlling the projector.............................69 Quick setup via Direct access..............................70 Software update ....................................72 R5906112 /09 UDX series...
  • Page 6 8.12.5 3D emitter Setup ................................. 146 9 GUI – Macro’s and projector profiles............................. 147 Saving the current projector settings in a profile ......................148 Assigning a created projector profile to a preset......................150 Deleting a projector profile................................ 152 R5906112 /09 UDX series...
  • Page 7 A.11 Dimensions of the rigging frame............................215 A.12 Dimensions of the flight case ..............................216 A.13 Technical Regulations ................................. 217 B Environmental information .................................. 219 Disposal information..................................220 Turkey RoHS compliance ................................. 221 Contact information ..................................222 R5906112 /09 UDX series...
  • Page 8 Overview video timings HDMI 2.0 inputs.......................... 227 Overview video timings DisplayPort 1.2 inputs......................229 Overview video timings HDBaseT inputs ......................... 232 D DMX chart ......................................... 235 DMX chart input board positioning............................236 DMX chart, Basic ................................... 237 DMX chart, Extended .................................. 238 R5906112 /09 UDX series...

  • Page 9: Safety

    Ensure that you understand and follow all safety guidelines, safety instructions and warnings mentioned in this chapter before installing the UDX projector. Clarification of the term “UDX” used in this document When referring in this document to the term “UDX” means that the content is applicable for following Barco products: •...

  • Page 10: General Considerations

    • Before operating this equipment please read this manual thoroughly and retain it for future reference. • Installation and preliminary adjustments should be performed by qualified Barco personnel or by authorized Barco service dealers. • All warnings on the projector and in the documentation manuals should be adhered to.
  • Page 11 Only qualified SERVICE PERSONNEL, knowledgeable of such risks, are allowed to perform service functions inside the product enclosure. R5906112 /09 UDX series...

  • Page 12: Important Safety Instructions

    • Based on international requirements, no person is allowed to enter the projected beam within the zone between the projection lens and the related Hazard Distance (HD). This shall be physically impossible by R5906112 /09 UDX series...
  • Page 13 In the event of fire, use sand, CO or dry powder fire extinguishers. Never use water on an electrical fire. Always have service performed on this projector by authorized Barco service personnel. Always insist on genuine Barco replacement parts. Never use non-Barco replacement parts as they may degrade the safety of this projector.
  • Page 14 For lens cleaning follow the instructions precisely as stipulated in the projector manual. • Only use zoom lenses of the Barco TLD+ series on the 4k models of the UDX. Using other lenses will damage the internal optics. For suitable fixed TLD+ lenses contact Barco or see Barco website.
  • Page 15 Replacement parts: When replacement parts are required, be sure the service technician has used original Barco replacement parts or authorized replacement parts which have the same characteristics as the Barco original part. Unauthorized substitutions may result in degraded performance and reliability, fire, electric shock or other hazards.

  • Page 16: Product Safety Labels

    EVITER TOUTE EXPOSITION DIRECTE DES YEUX AU FAISCEAU DU PROJECTEUR. RAYONNEMENT LASER - NE PAS REGARDER DANS LE FAISCEAU DU TELEMETRE. RG3 IEC EN 62471-5:2015. CLASS 2 IEC EN 60825-1:2014. DISTANCE DE SECURITE : CONSULTER LE MANUEL DE SECURITE. R5906112 /09 UDX series...

  • Page 17: High Brightness Precautions: Hazard Distance (Hd)

    3.0 meter to prevent potential exposure, for example by an individual sitting on another individual's shoulders, within the HD. Sufficiently large separation height may be achieved by mounting the image projector on the ceiling or through the use of physical barriers. R5906112 /09 UDX series...
  • Page 18 The restricted area sticker can be replaced by a sticker with only the symbol. RESTRICTED AREA Image 1-3 USA market (For FDA notice No 57) For LIPs (Laser Illuminated Projectors) installed in the USA market other restriction zone conditions apply. R5906112 /09 UDX series...
  • Page 19 • This product can only be installed by Barco or sold or leased only to valid laser light show variance holders. In other words our installers are required to have an approved laser light show variance. Such installers may currently hold a valid variance for production of Class IIIb and IV laser light shows and/or for incorporation of the RG3 LIPs into their shows.

  • Page 20: Hd For Fully Enclosed Projection Systems

    The light emitted from the screen within the observation shall never exceed the RG2 exposure limit, determined at 10 cm. The HD can be neglected if the measured light at the screen surface is below 5000 diffuse cd/m² or 15000 LUX. R5906112 /09 UDX series...

  • Page 21: Hd In Function Of Modifying Optics

    UDX 4K40, UDX 4K40 LC, UDX W40, UDX W40 LC, UDX U40, UDX U40 LC UDX 4K32, UDX W32, UDX U32 UDX 4K26, UDX W26 UDX 4K22, UDX W22 Throw Ra o (TR) Image 1-5 Hazard Distance Throw Ratio R5906112 /09 UDX series...
  • Page 22 Safety R5906112 /09 UDX series...

  • Page 23: Pulse Remote Control Unit

    Function of the RGB filter button • Displaying and Programming addresses into the RCU • Using the XLR connector of the RCU • Using the mini-jack connector of the RCU • Silicone protection sleeve for the RCU (optional) R5906112 /09 UDX series...

  • Page 24: Remote Control, Battery Installation

    Insert (1) both lower tabs of the battery cover in the gaps at the bottom of the remote control, and press (2) the cover until it clicks in place. Image 2-3 When replacing batteries, the broadcast address of the RCU will be reset to its default value '0'. R5906112 /09 UDX series...
  • Page 25 CAUTION: Replace with the correct battery type. Use two AA size batteries. There is a risk of explosion if the battery is replaced with an incorrect type. CAUTION: Replace the battery as explained above. There is a risk of explosion if the battery is incorrectly installed. R5906112 /09 UDX series...

  • Page 26: Remote Control, Protocol Setup

    Depending on the projector to control the remote control can be switched between these protocols. Which protocol to use • The NEC protocol has to be used for Barco projectors based on the Pulse platform: F70, F80, F90, HDX 4K, UDX, XDL, etc. •...

  • Page 27: Remote Control, On/Off Button

    RCU off will extend the battery life time of the remote control. To activate the remote control press the on/off button. To deactivate the remote control press the on/off button again. Default when (re)placing batteries, is “ON”. Image 2-5 R5906112 /09 UDX series...

  • Page 28: Functionality Overview

    Default value button Lens shift Lens focus Menu open / close RGB filter Menu selection, OK button Test patterns Menu navigation Power on Input selection Power off Address button 3.5 mm jack Numeric buttons RCU on / off R5906112 /09 UDX series...

  • Page 29: Functions Of The "Button Pressed Indicator

    Continuously lit (up to 5 seconds) when address digits are expected after pressing the ADDR button. • Slowly flashes (2 times a second) when the battery level is becoming low; typically when more than 85% of the useful life is past. R5906112 /09 UDX series...

  • Page 30: Function Of The Rgb Filter Button

    Green only • Blue only • Red + Green • Green + Blue • Red + Blue • Red + Green + Blue • After powering up, the colors will always revert back to full RGB. R5906112 /09 UDX series...

  • Page 31: Displaying And Programming Addresses Into The Rcu

    Alternatively, you can also press “0” and “3”. This way, the button pressed indicator goes out immediately. To enter address 31, then press “3” and “1” on the digit button on the RCU and the button pressed indicator goes out immediately. R5906112 /09 UDX series...

  • Page 32: Using The Xlr Connector Of The Rcu

    Connect a cable with XLR plug into the XLR connector of the RCU. Connect the other end of the cable with the XLR input of the projector. Note: While the XLR cable is connected, the IR beam of the RCU is switched off. R5906112 /09 UDX series...

  • Page 33: Using The Mini-Jack Connector Of The Rcu

    Connect a cable with the mini-jack connector (reference 2 Image 2-8) of the RCU. Connect the other end of the cable with the mini-jack input of the projector. Image 2-8 Note: While the mini-jack cable is connected, the IR beam of the RCU is switched off. R5906112 /09 UDX series...

  • Page 34: Silicone Protection Sleeve For The Rcu (Optional)

    (optional) Introduction Barco offers a silicone form fitting protection sleeve for the Pulse RCU. The silicone material keeps it comfortably, non slip and soft touch. All buttons and holes remain accessible. The sleeve is quick and easy installed. For ordering information see Barco website.

  • Page 35: Input & Communication

    Input source connections – Quad DP 1.2 Input board • Input source connections – SFP Input Board • LED and Button indication chart • Removal of an input board • Installation of an input board or a communication board R5906112 /09 UDX series...

  • Page 36: Introduction

    1.2 input board). Image 3-1 Local Keypad and LCD panel Communication Panel Optional antenna for WiFi connection Quad Combo Input board Optional antenna for GSM Free input slot (here filled with the Quad DP 1.2 Input board) R5906112 /09 UDX series...

  • Page 37: Local Keypad And Lcd Panel

    • Active functions (Enabled Functions). Toggle between the two indications by using the Menu button on the keypad, or on the remote control. The LCD Display will fade out 30 seconds after the last key operation. R5906112 /09 UDX series...

  • Page 38: Communication Connections

    Sub-D connector and an USB connector acting as RS input when connected to an USB input of a PC. You can use the RS232/RS422 input to connect a local PC to your UDX series projector. By this way you can configure and control your projector from your local PC.
  • Page 39 If the only file on the USB device is the firmware file (a “*.fw” file), the projector will automatically start one of the following processes. • cornet<version nr>.fw: The projector will upgrade or downgrade, depending on the version number. • LogExtractor.fw: The log files will be downloaded. R5906112 /09 UDX series...
  • Page 40 Input & Communication Make sure that any used USB-stick is FAT32 compatible and contains no other files or folders. R5906112 /09 UDX series...

  • Page 41: Input Source Connections - Quad Combo Input Mark Ii

    About the Quad combo input Mark II Due to demand from the market, Barco has created a second generation of the Input board to support 12G input and throughput on the SDI connectors. From the release of this board onward, the Quad combo input will be supported and will be the standard input board in every Input &...
  • Page 42 3G SDI follows the SMPTE 425M standard Level A 12G-SDI follows the SMPTE ST-2082-1 and ST-2082-10 standards. Color space YCbCr Color depth 10 bpc Chroma sampling 4:2:2 Audio support not supported For future release • 3D support • Interlaced support R5906112 /09 UDX series...
  • Page 43 Up to 4096 x 2160 @60 Hz Native video timings • UDX-U-series: 1600 x 1200 @60 Hz • UDX-W-series: 1920 x 1200 @60 Hz • UDX-4k-series: 3840 x 2400 @60 Hz For the full list of video timings, see Appendix R5906112 /09 UDX series...
  • Page 44 Input specifications – DisplayPort 1.2 input For readability, the video timings listed are summarized. For the full list of video timings, refer to the appendices. Pixel rate Up to 600 MHz pixel clock Color space • YCbCr 4:2:2 R5906112 /09 UDX series...
  • Page 45 • 2560 x 1080 @120 Hz • 2560 x 1600 @120 Hz Native video • UDX-U-series: 1600 x 1200 @60 Hz timings • UDX-W-series: 1920 x 1200 @60 Hz • UDX-4k-series: 3840 x 2400 @60 Hz R5906112 /09 UDX series...

  • Page 46: Input Source Connections - Quad Combo Input Mk I

    • Loop-through functionality • 12G SDI support • Network connectivity on HDBaseT inputs To upgrade your input board to the Mark 2 board, contact Barco. Overview Mark 1 Quad Combo Input board SDI IN SDI IN/OUT SYNC SYNC SYNC...
  • Page 47 Up to 4096 x 2160 @50 Hz • Up to 4096 x 2160 @60 Hz Native video timings • UDX-U-series: 1600 x 1200 @60 Hz • UDX-W-series: 1920 x 1200 @60 Hz • UDX-4k-series: 3840 x 2400 @60 Hz R5906112 /09 UDX series...
  • Page 48 Input specifications – DisplayPort 1.2 input For readability, the video timings listed are summarized. For the full list of video timings, refer to the appendices. Pixel rate Up to 600 MHz pixel clock Color space • YCbCr 4:2:2 R5906112 /09 UDX series...
  • Page 49 • 2560 x 1080 @120 Hz • 2560 x 1600 @120 Hz Native video • UDX-U-series: 1600 x 1200 @60 Hz timings • UDX-W-series: 1920 x 1200 @60 Hz • UDX-4k-series: 3840 x 2400 @60 Hz R5906112 /09 UDX series...

  • Page 50: Input Source Connections - Quad Dp 1.2 Input Board

    Up to 2048 x 1080 @48 Hz • Up to 4096 x 2160 @50 Hz • Up to 4096 x 2160 @60 Hz • Up to 2560 x 1600 @120 Hz For the full list of video timings, see Appendix R5906112 /09 UDX series...
  • Page 51 Passive 2 column mode (2x1 1920 x 2160 @60 Hz stereo layout) Native video • UDX-U-series: 1600 x 1200 @60 Hz timings • UDX-W-series: 1920 x 1200 @60 Hz • UDX-4k-series: 3840 x 2400 @60 Hz R5906112 /09 UDX series...

  • Page 52: Input Source Connections - Sfp Input Board

    Input & Communication 3.7 Input source connections – SFP Input Board The Barco SFP Input Board has been designed and tested to work alongside the Barco SFP Output Board. However, it is possible that the SFP Input board can also work with other third-party devices that support 12G over fiber.
  • Page 53 SFP+ fiber transceiver Optional breakout Optical adapter Barco delivers only the Fiber-Network input board and SFP+ fiber transceivers. The customer has to buy the SFP+ transceiver and the optional breakout adapter or the fiber integrated cable. Remove the plate covering the access to the SFP cages.
  • Page 54 Advanced quad cable Internal fiber cable Barco delivers only the Fiber-Network input board and SFP+ fiber transceivers. The customer has to buy the SFP+ transceiver, the Neutrik OpticalCon Quad, the internal cable and cable. Remove one plate covering the access to a Neutrik connector location.
  • Page 55 Neutrik OpticalCon Quad Advanced Quad cable Barco delivers only the Fiber-Network input board and SFP+ fiber transceiver. The customer has to buy the SFP+ transceivers, both Neutrik connectors, the internal cable and the cable. Remove both plates covering the access to a Neutrik connector locations.

  • Page 56: Led And Button Indication Chart

    GREEN Light source is on in normal mode GREEN-ORANGE Light source is on in CLO mode ERR (error LED) No error RED toggles on/off Error ORANGE toggles on/off Warning IR signal received GREEN IR signal acknowledged R5906112 /09 UDX series...

  • Page 57: Removal Of An Input Board

    Input & Communication 3.9 Removal of an input board WARNING: The procedures below may only be performed by Barco trained and qualified technicians. CAUTION: Always wear a wrist band which is connected to the ground while handling the electrostatic discharge (ESD) sensitive parts.
  • Page 58 CAUTION: Ensure that unused input slots of the Input & Communication Unit are always covered with a dummy front plate. After removing one of the input modules, immediately replace with an other one or install a dummy front plate on the unused input slot. R5906112 /09 UDX series...

  • Page 59: Installation Of An Input Board Or A Communication Board

    Input & Communication 3.10 Installation of an input board or a communication board WARNING: The procedures below may only be performed by Barco trained and qualified technicians. CAUTION: Always wear a wrist band which is connected to the ground while handling the electrostatic discharge (ESD) sensitive parts.
  • Page 60 IMPORTANT LAST STEP — Update the firmware of the installed module. Use the complete software package to install the firmware via Projector Toolset or USB stick. Tip: When a complete new software image is placed on the projector, all programmable components will be updated with the latest version. R5906112 /09 UDX series...

  • Page 61: Getting Started

    • direct access to all connected sources. Overview • Power on projector • Switching to standby • Power off projector • Using the RCU • Projector Address • Quick setup via Direct access • Software update R5906112 /09 UDX series...

  • Page 62: Power On Projector

    Once the projector is started, press Status to get an overview of parameters such as : • Device serial number and article number • Current firmware version and model name • Current illumination (in percentage) • Projector runtime in hours • Uptime in hours R5906112 /09 UDX series...
  • Page 63 Press the Input Selection button on the keypad or on the remote control until: • the LED of the selected source (the “SEL” LED) lit up GREEN, and • the image of the selected source is projected. Image 4-3 R5906112 /09 UDX series...

  • Page 64: Switching To Standby

    The projector goes to standby mode. The after-cooling cycle will start (about 30 seconds). During this period the Power on/off button will blink. Once the after-cooling cycle has ended, the projector will be in standby mode and the Power on/off button will be lit WHITE. 30 s Image 4-4 R5906112 /09 UDX series...

  • Page 65: Power Off Projector

    4.3 Power off projector CAUTION: This procedure assumes the projector is in standby mode. How to power off Switch off the projector with the mains switch. '0' must be pressed. Image 4-5 Unplug the power cord from the projector. R5906112 /09 UDX series...

  • Page 66: Using The Rcu

    When using the wireless remote control, make sure you are within the effective operating distance (30 m, 100 ft in a straight line). The remote control unit will not function properly if strong light strikes the sensor window or if there are obstacles between the remote control unit and the projector IR sensor. R5906112 /09 UDX series...
  • Page 67 Using the RCU in combination with a 3D emitter When using a 3D emitter that radiates IR beams (e. g. the optional 3D emitter that Barco provides), the IR beams of the 3D emitter may interfere with the IR communication between projector and the RCU.

  • Page 68: Projector Address

    Getting Started 4.5 Projector Address Projector address Address installed in the projector to be individually controlled. Broadcast address Projector will always execute the command coming from a RCU programmed with that broadcast address. R5906112 /09 UDX series...

  • Page 69: Controlling The Projector

    The choice between '0' and '1' can be selected in the GUI: “System Settings” → “Communication” →“IR Control “. Placing new batteries in the remote control or plugging the remote to a projector via a cable will automatically reset the address back to its default value '0'. R5906112 /09 UDX series...

  • Page 70: Quick Setup Via Direct Access

    The Source selection menu opens on the LCD display. Image 4-9: Input selection Use the arrow keys to select the desired source. Quick test pattern selection Press the Test pattern button on the remote control or local keypad. R5906112 /09 UDX series...
  • Page 71 Getting Started Image 4-10 The Test pattern menu opens on the LCD display. Use the arrow keys to select the desired test pattern. R5906112 /09 UDX series...

  • Page 72: Software Update

    Download the latest firmware (format .fw) from Barco's website in the same way as for Projector Toolset. Start Projector Toolset and make a connection with the projector. For more information, see the Projector Toolset user guide.
  • Page 73 Power on the projector. Wait until the Power on/off button is either lit white or blue. Download the latest firmware file ( format .fw) from Barco's website. The firmware can be downloaded for free from Barco's website, (URL: http://www.barco.com). Click on myBarco and log in to get access to secured information.
  • Page 74 Getting Started R5906112 /09 UDX series...

  • Page 75: Graphic User Interface (Gui)

    Graphic User Interface (GUI) Overview • Overview • Navigation • Test Patterns R5906112 /09 UDX series...

  • Page 76: Overview

    The OSD interface uses tabs to display the main menu. Each main menu contains submenus. The OSD can be disabled by pressing the OSD on/off button. Image 5-2: Home menu R5906112 /09 UDX series...
  • Page 77 The projector's software platform uses access levels what each user can do. A standard user has access to all projector functionality. A certified service technician has also access to the service menu. This menu is password protected. R5906112 /09 UDX series...

  • Page 78: Navigation

    To enter the value as a direct number, press OK, input the digit(s), and then press OK again to execute and exit cursor mode e.g. OK 79 OK. Within an input field, use the * button as backspace button to remove an entered digit. Use the # button to enter a dot (.). R5906112 /09 UDX series...
  • Page 79 OK. Select the backspace button and press OK to remove the last entered digit. Menu memory The OSD menu remembers the last selected sub-item as long as the projector is running. The menu memory is reset when restarting the projector from standby. R5906112 /09 UDX series...

  • Page 80: Test Patterns

    Full screen black / white / blue / green / red / cyan / magenta / yellow • Grid • Horizontal Ramp • Vertical Ramp • To turn the test pattern off, return to the previous menu. R5906112 /09 UDX series...

  • Page 81: Gui - Source

    GUI – Source About the Source menu This menu is used to select, review and configure sources into the projector. Overview of features • Displaying a single source • Displaying multiple sources: Stitched layouts • Connector Settings R5906112 /09 UDX series...

  • Page 82: Displaying A Single Source

    Press Menu to activate the menus and select Source. Image 6-1: Select Source Press OK. The Select Source menu is displayed with the actual available sources filled out. Image 6-2: Input selection Select the desired input. R5906112 /09 UDX series...

  • Page 83: Displaying Multiple Sources: Stitched Layouts

    Even if passive stereo sources are selected, the output of this projector can only be in either 2D or in Active Stereo. Advanced image processing will make sure a passive stereo image is properly converted to active stereo. How to select a stitched layout Press Menu to activate the menus and select Source. R5906112 /09 UDX series...
  • Page 84 Image 6-4: Input selection menu Select the desired stitched input. Tip: If the V&AR board is installed, scroll all the way down the Input Selection menu for the stitched options on that board. Image 6-5: Input Selection menu, stitched options R5906112 /09 UDX series...

  • Page 85: Connector Settings

    Scroll down to the bottom of the list of available sources and select Connector Settings. Image 6-7: Source menu, Connector Settings The available input connectors are displayed. Image 6-8: Select source Select the desired connector. The Connector Settings menu for this connector will be displayed. R5906112 /09 UDX series...
  • Page 86 To force a limit on the used signal range, select one of the available signal ranges. • To set a video timing other than the one native for the connector, select one of the options under EDID. Note: You cannot change the EDID for SDI connectors. R5906112 /09 UDX series...

  • Page 87: Gui - Image

    • Adjusting the sharpness • Adjusting the gamma correction • Setting the desired Gamma type • Digital Shift & Zoom • P7 Realcolor • Setting the output resolution • Displaying HDR content – Perceptual Quantizer (PQ) R5906112 /09 UDX series...

  • Page 88: Setting Image Levels Manually

    How to set up Brightness Level In the main menu, select Image → Brightness. Image 7-3: Image menu — Brightness Use the ◄ or ► key to change the brightness until the desired value is reached (adjustable between –1 and 1). R5906112 /09 UDX series...
  • Page 89 Use the ◄ or ► key to change the saturation until the desired value is reached (adjustable between 0 and 2). Image 7-6: Saturation slider If necessary, use the ▲ or ▼ key to select the other image adjustment options. R5906112 /09 UDX series...

  • Page 90: Adjusting The Sharpness

    Image 7-8: Image menu — Sharpness Use the ◄ or ► key to change the sharpness until the desired value is reached. Image 7-9: Sharpness slider If necessary, use the ▲ or ▼ key to select the other image adjustment options. R5906112 /09 UDX series...

  • Page 91: Adjusting The Gamma Correction

    Use the ◄ or ► key to change the gamma value between 1.0 and 2.8 . The default value is 2,2. Tip: The slider can be adjusted with a precision of 0.1. Image 7-11: Gamma slider If necessary, use the ▲ or ▼ key to select the other image adjustment options. R5906112 /09 UDX series...

  • Page 92: Setting The Desired Gamma Type

    Image 7-13: Gamma type menu Select the desired gamma type. Tip: If not sure what gamma type to select, keep the default value AUTO selected. This will determine the used gamma type based on the incoming signal. R5906112 /09 UDX series...

  • Page 93: Digital Shift & Zoom

    For an example, see the following photos. The red lines in the figures represent the DMD outline. Image 7-14: Originally picture, not digitally zoomed Image 7-15: Picture digitally zoomed in Image 7-16: Picture digitally zoomed out R5906112 /09 UDX series...
  • Page 94 Image 7-18: Picture shifted horizontally Image 7-19: Picture shifted vertically Digital Shift & Zoom In the main menu, select Image → Digital Zoom Shift. Image 7-20: Image menu, Digital Zoom Shift The Digital Zoom Shift menu is displayed. R5906112 /09 UDX series...
  • Page 95 When enabled, you can do the following: • Use the ◄ and ► keys to shift the lens (image) in horizontal direction. • Use the ▲ and ▼ keys to shift the lens (image) in vertical direction. R5906112 /09 UDX series...

  • Page 96: P7 Realcolor

    The white point is specified using an x, y coordinate in the CIE 1931 Chart. • Temperature: Configure the white point via a color temperature slider. The white point is specified on a Kelvin scale between 3200K and 13000K tracking along the black body curve. R5906112 /09 UDX series...
  • Page 97 Note: After choosing one of the presets, you can still alter the values of the coordinates to your own choosing, similarly to how you set custom P7 values. Use Reset to return to the default values of the chosen preset. R5906112 /09 UDX series...

  • Page 98: Setting The Output Resolution

    If the main purpose of the projection is text (spreadsheets, presentations, or similar purposes), use the 4K UHD S output resolution for the for the most stable and sharpest output. R5906112 /09 UDX series...

  • Page 99: Displaying Hdr Content - Perceptual Quantizer (Pq)

    The PQ menu is displayed. Image 7-30 Select the desired Unit (nits or foot-lambert). Enter the Screen luminance (either in nits or foot-lambert). Alter the HDR boost if necessary. You can modify this value to somewhere between 0.8 and 1.2. R5906112 /09 UDX series...
  • Page 100 GUI – Image R5906112 /09 UDX series...

  • Page 101: Gui - Installation

    Configuring the lens, Mid position • Laser ranging • Manipulating the rigging frame • Orientation • Warping • Blending & masking • Laser illumination • Setting up the external cooler • Scaling modes • 3D projection R5906112 /09 UDX series...

  • Page 102: Configuring The Lens, Optical Zoom-Focus

    Image 8-1: Lens menu, Focus & Zoom Use the ▲ or ▼ key to zoom the lens in or out. Use the ◄ or ► key to focus the lens to far or near. Image 8-2: Zoom and focus adjustment R5906112 /09 UDX series...

  • Page 103: Configuring The Lens, Shift

    The Lens shift menu is displayed. Image 8-4: Lens shift menu Use the ◄ and ► keys to shift the lens (image) in horizontal direction. Use the ▲ and ▼ keys to shift the lens (image) in vertical direction. R5906112 /09 UDX series...

  • Page 104: Configuring The Lens, Mid Position

    How force lens in Mid position To force lens in Mid position, select Installation → Lens → Shift to Center. Confirm by selecting OK. Image 8-5 The lens will calibrate itself and return to the center position. R5906112 /09 UDX series...

  • Page 105: Laser Ranging

    If you cannot see the display of the laser range finder while performing a laser ranging session, select Show measurement on screen. This way, the measurement will be projected alongside the laser dot and the red border. R5906112 /09 UDX series...
  • Page 106 By default the measurement is in meters. If you want the distance projected in feet, you can change the measurement system in the System settings menu. For more info, refer to “Setting the measurement system”, page 171. R5906112 /09 UDX series...

  • Page 107: Manipulating The Rigging Frame

    Use the ▲ or ▼ button to shift the rigging frame (image) in vertical direction. Use the ◄ or ► button to shift the rigging frame (image) in horizontal direction. Confirm with the OK button. The frame rotation menu is displayed. Image 8-11: Frame rotation menu R5906112 /09 UDX series...
  • Page 108 Use the ◄ or ► button to rotate the rigging frame (image) either clockwise or counterclockwise. Confirm with the OK button to return to the frame shift menu, or use the Menu back button to return to the Lens menu. R5906112 /09 UDX series...

  • Page 109: Orientation

    Use the ▲ or ▼ key to select the desired mounting position and press OK button to activate. Use the ▲ or ▼ key to select the desired projection position and press OK button to activate. R5906112 /09 UDX series...

  • Page 110: Warping

    While an image can be transformed in various ways, pure warping doesn’t affect the colors. Overview • Warping – On/Off • Warping – Screen Size • Warping – 4 corners adjustment • Warping – Bow • Warping – Warp files • Warping – Latency control in a multi projector setup R5906112 /09 UDX series...

  • Page 111: Warping - On/Off

    In the main menu, select Installation → Warp. Image 8-14: Installation menu, Warp The Warp menu is displayed. Image 8-15 In the Warp menu, click Warp to toggle between On and Off. Image 8-16 Image 8-17 R5906112 /09 UDX series...

  • Page 112: Warping - Screen Size

    Image 8-18: Warp outline example How to adjust the image? In the main menu, select Installation → Warp → Screen Size. Image 8-19: Warp Menu, Screen Size The Screen Size menu is displayed. R5906112 /09 UDX series...
  • Page 113 Tip: The value can also be entered by the numeric keys on the remote control. Press * to delete existing numbers, and enter the new value by the numeric keys. Click Apply. R5906112 /09 UDX series...

  • Page 114: Warping - 4 Corners Adjustment

    In the main menu, select Installation → Warp → 4 Corners. Image 8-22: Warp menu, 4 Corners The 4 Corners menu is displayed. Image 8-23: 4 Corners Warping To enable 4 Corners warping, make sure the 4 corners slider is set to On. R5906112 /09 UDX series...
  • Page 115 Tip: A red border corner will be projected along with the current image. The border is a visual aid, showing the result of the warped corners. Repeat from for each corner, until all corners are warped in the desired position. To reset the 4 corner adjustments, select Reset and press the OK button. R5906112 /09 UDX series...

  • Page 116: Warping - Bow

    To enable Bow correction, make sure the Bow slider is enabled (visible by the blue highlight). To perform a symmetric adjustment , make sure the Symmetric slider is set to On (visible by the blue highlight). R5906112 /09 UDX series...
  • Page 117 The correction will occur symmetrically on each side of the center of the highlighted side. Repeat this step for all sides of the picture that has to be corrected, until the desired transformation has been achieved. R5906112 /09 UDX series...
  • Page 118 Adjust angle and linearity (length) individually to obtain the correct correction and confirm. Tip: Adjust the angle by using the up and down arrow keys. Adjust the linearity by using the left and right arrow keys. R5906112 /09 UDX series...
  • Page 119 Image 8-36: Left vector of the upper side of the picture. When completed, a transformation will occur in a way similar to the following example. Observe that the upper side of the picture now has an asymmetric correction. Image 8-37: Example of an asymmetric bow correction R5906112 /09 UDX series...
  • Page 120 GUI – Installation Definition of angle and linearity (length) in the bow warp procedure Image 8-38 To reset the bow adjustments, select Reset and confirm. R5906112 /09 UDX series...

  • Page 121: Warping - Warp Files

    How to activate an uploaded Warp grid? In the main menu, select Installation → Warp. Image 8-39: Installation menu, Warp In the Warp menu, select Files. Image 8-40: Warp menu, Files The Warp Files menu is displayed. R5906112 /09 UDX series...
  • Page 122 GUI – Installation Image 8-41 If any custom Warp files are available, select the desired warp file. Image 8-42 Click on the on/off button on top to activate the selected warp file. Image 8-43 R5906112 /09 UDX series...

  • Page 123: Warping - Latency Control In A Multi Projector Setup

    Transport delay in the status menu for each projector. Image 8-44 Identify the projector with the longest delay. For each projector in the setup, select Installation → Warp in the main menu. Image 8-45: Installation menu, Warp In the Warp menu, select Transport Delay. R5906112 /09 UDX series...
  • Page 124 Enter the value either by the arrow keys (one step at a time) or directly by the numeric keys on the remote control. Enter “Apply” to confirm the value. Repeat this process for every projector in the setup. R5906112 /09 UDX series...

  • Page 125: Blending & Masking

    From the start (mask) position, you can blend zone size per edge (left, top, right, bottom). For each edge there will be a drop-off curve for the blend zone. Overview • Blend & Mask • Blend Files • Basic black level adjustment • Black Level Files • RGB adjustment R5906112 /09 UDX series...

  • Page 126: Blend & Mask

    Determine the start position of the mask (1) for the masking height and width, together with the desired size of the mask (2) to determine the width of the masked area. When the blending lines are activated, you will get a visual indication of the screen of the installed blending area. R5906112 /09 UDX series...
  • Page 127 Enable blending and activate Show lines. First set the mask width for the right edge of the first projector. Enter a width value equal to the overlap area (width1). Repeat for the left edge of the second projector. R5906112 /09 UDX series...
  • Page 128 GUI – Installation Adjust the offset to cut the image on each side (masking). Image 8-52: Set up for projector 1 Image 8-53: Set up for projector 2 R5906112 /09 UDX series...

  • Page 129: Blend Files

    In the main menu, select Installation → Blend and Mask → Blend Files. Image 8-54: Blend and Mask menu, Blend Files The Blend Files menu is displayed. Image 8-55 If any custom Blend files are available, select the desired file. Image 8-56 R5906112 /09 UDX series...
  • Page 130 GUI – Installation Click on the Enable slider on top to activate the selected Blend file. R5906112 /09 UDX series...

  • Page 131: Basic Black Level Adjustment

    How to adjust the black level manually In the main menu, select Installation → Blend and Mask → Black Level → Basic Black Level. Image 8-58: Black Level menu — Basic Black Level The Basic black level menu is displayed. R5906112 /09 UDX series...
  • Page 132 This value can also be entered by the numeric keys on the remote control. Repeat the same procedure for any other projector connected to this projector, but on the opposite side. Note: Do not forget to disable the Show lines button after you achieved the desired blend zone. R5906112 /09 UDX series...

  • Page 133: Black Level Files

    The Black Level Files menu is displayed. Image 8-61 If any custom Black Level adjustment files are available, select the desired file. Image 8-62 Click on the Enable slider on top to activate the selected Black Level adjustment file. R5906112 /09 UDX series...

  • Page 134: Rgb Adjustment

    How to perform an RGB adjustment In the main menu, select Installation → Blend and Mask → Black Level → RGB Adjustment. Image 8-64: Black Level menu, RGB Adjustment The RGB Adjustment menu is displayed. Image 8-65: RGB Adjustment menu R5906112 /09 UDX series...
  • Page 135 GUI – Installation Select one of the three sliders. Use the left and right arrow keys to modify the gain of the chosen color. Repeat for every slider until the desired result is achieved on screen. R5906112 /09 UDX series...

  • Page 136: Laser Illumination

    The actual power setting is indicated at the bottom of the Power button. Use the Slider to change the power value. Image 8-67 If you want CLO mode to be active, click Enable underneath Constant light output. R5906112 /09 UDX series...

  • Page 137: Setting Up The External Cooler

    How to set up the external cooler In the main menu, select Installation → Illumination → Cooling. Image 8-68: Illumination menu, Cooling The Cooling menu is shown. Image 8-69: Cooling menu In the Cooling menu, select the desired cooling option. R5906112 /09 UDX series...

  • Page 138: Scaling Modes

    In the main menu, select Installation → Scaling. Image 8-70: Installation menu, Scaling The Scaling menu is displayed. Example using a screen of 2,35:1, an input signal of 4:3 and a projector with a native resolution of 3840 x 2400 R5906112 /09 UDX series...
  • Page 139 GUI – Installation Image 8-71: Scaling Menu In the Scaling menu, select the desired scaling mode and confirm. R5906112 /09 UDX series...

  • Page 140: Projection

    For example: when using NVIDIA Quadro cards, use the NVIDIA Control Panel to manage your 3D settings. Overview • Active Stereo & Passive Stereo • Setup process 3D projection • Connection possibilities • Choosing the desired Display Setup • 3D emitter Setup R5906112 /09 UDX series...

  • Page 141: Active Stereo & Passive Stereo

    It is also advised to turn the IR receivers on the projector off to avoid the 3D emitter interference. To turn off the IR receivers, see “Remote control, on/off button”, page 27. R5906112 /09 UDX series...

  • Page 142: Setup Process 3D Projection

    83. Select the desired Display format. For more info, see “Choosing the desired Display Setup”, page 144. Depending on the chosen 3D emitter, correct the 3D setup. For more info, see “3D emitter Setup”, page 146. R5906112 /09 UDX series...

  • Page 143: Connection Possibilities

    1920 x 2160 @60 Hz • Cable 1: left eye, 30 bpp pipe L/R) layout) left column • Cable 2: left eye, right column • Cable 3: right eye, left column • Cable 4: right eye, right column R5906112 /09 UDX series...

  • Page 144: Choosing The Desired Display Setup

    In the main menu, select Installation → Display Setup. Image 8-72: Installation menu, Display setup The Display setup menu is displayed. Image 8-73: Display setup menu Select the desired Display Mode: • AutoStereo (default value) • Mono • ActiveStero R5906112 /09 UDX series...
  • Page 145 GUI – Installation Image 8-74: Display Setup menu options R5906112 /09 UDX series...

  • Page 146: Emitter Setup

    Why change the 3D setup? While Barco can provide a 3D emitter and active shutter glasses as options to this projector, you are also free to use a 3D emitter and active shutter glasses of your own choice. Since glasses and emitter can have various specifications compared to the ones Barco can provide, the 3D setup menu allows you to configure the output image to the specifications of your glasses and emitter.

  • Page 147: Gui - Macro's And Projector Profiles

    Overview • Saving the current projector settings in a profile • Assigning a created projector profile to a preset • Deleting a projector profile R5906112 /09 UDX series...

  • Page 148: Saving The Current Projector Settings In A Profile

    Swap frame pair on / off • Dark time and sync delay values How to save the current projector profile to a macro? In the main menu, select Profiles → New. Only if external cooler is installed R5906112 /09 UDX series...
  • Page 149 You can assign this macro to one of the available preset slots, by selecting a preset slot using the arrow keys. Confirm your selection. Use the arrow keys the okay key to select any of the settings you wish to save in this macro. Save your macro by pressing Create. R5906112 /09 UDX series...

  • Page 150: Assigning A Created Projector Profile To A Preset

    Select the desired projector profile from the dropdown list. The details of the projector profile are displayed. Image 9-5: Details of the profile Use the arrow keys to select a preset slot and confirm with the okay key. R5906112 /09 UDX series...
  • Page 151 GUI – Macro’s and projector profiles Image 9-6: Preset R5906112 /09 UDX series...

  • Page 152: Deleting A Projector Profile

    Image 9-8: Edit Profile menu If not immediately visible, select the undesired profile from the dropdown list. The details of the profile are displayed. Image 9-9: Details of the macro Press Delete and confirm your action. R5906112 /09 UDX series...

  • Page 153: Gui - System Settings

    Setting the measurement system • Disabling Standby mode • Lens features • Controlling the backlight of the LCD Display • Reset • Lens Calibration • Flex brightness • Rigging frame Calibration • Electronic Convergence • Advanced Settings R5906112 /09 UDX series...

  • Page 154: Communication, Lan Setup

    About a network connection A network connection can be made via a wired connection or via the optional wireless unit. Overview • Introduction to a Network connection • Wired IP address set up • Wireless IP address set up R5906112 /09 UDX series...

  • Page 155: Introduction To A Network Connection

    This must not be 0.0.0.0. If there is no router on the projector's local subnet then just set this field to any IP-Address on the subnet. R5906112 /09 UDX series...

  • Page 156: Wired Ip Address Set Up

    When connected, it is indicated with the connection symbol and the indication Connected. Select APPLY and click OK. How to manually set up the IP address In the main menu, select System Settings → Communication → LAN. Image 10-3: Communication menu, LAN The LAN menu is displayed R5906112 /09 UDX series...
  • Page 157 Repeat steps 4 and 5 for the Subnet mask and Default Gateway. Select APPLY and click OK to confirm all changes. When the connection is established, it is indicated with the connection symbol and the indication Connected. R5906112 /09 UDX series...

  • Page 158: Wireless Ip Address Set Up

    Select the Select SSID dropdown menu and select the desired wireless network. Tip: If the desired wireless network is not in the list or hidden by default, select “Add New SSID”. Fill in the details of the network. R5906112 /09 UDX series...
  • Page 159 Use the ▲ or ▼ key to select Address and press OK button to activate the input box. Use the ▲ or ▼ key to change the selected character. Use the ◄ or ► key to select another character. R5906112 /09 UDX series...
  • Page 160 If required by the chosen wireless network, fill in the username and password and confirm. An automatic IP address is assigned. When connected to this network, it is indicated in the upper right corner of the menu with the term “connected”. R5906112 /09 UDX series...

  • Page 161: Ir Control

    GUI – System Settings 10.2 IR control Overview • Broadcast address • Projector address • IR sensors R5906112 /09 UDX series...

  • Page 162: Broadcast Address

    To change the broadcast address select the radio button of your choice. The following choices are possible: • Generic IR (address 0) • Barco broadcast IR (address 1) Select APPLY and click OK to apply the changes. R5906112 /09 UDX series...

  • Page 163: Projector Address

    Select the current projector address and enter a new address. Select APPLY and click OK to apply the changes. From now on the projector will only listen to this new address and to its broadcast address. R5906112 /09 UDX series...

  • Page 164: Ir Sensors

    To disable an IR sensor, select the slider and drag to the left. A blue slider means an active IR sensor. A gray slider means an inactive IR sensor. Select APPLY and click OK to apply the changes. R5906112 /09 UDX series...

  • Page 165: Setting A Custom Projector Name

    In the Hostname menu, press confirm to edit the Hostname field. Use the digital keyboard to change the Hostname to the desired custom name. Image 10-19 Click OK to confirm the typed name and Click Apply to update the name. R5906112 /09 UDX series...

  • Page 166: Dmx

    If available, the power of the XLR connector on the front side of the projector can be connector enabled and set to a desired value. How to set up DMX? In the main menu, select System Settings → Communication → DMX. Image 10-20: Communication menu, DMX The DMX menu is displayed. R5906112 /09 UDX series...
  • Page 167 Choose whether or not you want the Auto power-down feature to be enabled. If enabled, determine the time- out. If required, enable Art-Net. If enabled, determine the desired Art-Net Universe and Art-Net channel. If a front XLR connector is available on your projector, you can enable the output voltage on this connector. R5906112 /09 UDX series...

  • Page 168: Front Xlr Output Voltage Control

    In the main menu, select System Settings → Communication → DMX. Image 10-23: Communication menu, DMX The DMX menu is displayed. Image 10-24: DMX menu On the bottom of the DMX menu, Enable the XLR connector. Select the desired Output Voltage. R5906112 /09 UDX series...

  • Page 169: Gsm Configuration

    If the code is still the same, it is not necessary to enter the PIN code again. If it is a PIN code, continue with next step. Image 10-26: Enter PIN code Enter the 4 digits of the pin code and select APPLY and click OK. R5906112 /09 UDX series...

  • Page 170: Themes

    How to select a different interface theme In the main menu, select System Settings →Themes. Image 10-27: System Settings Menu — Themes. In the themes menu, select the desired Theme. You can choose one of the following: Light, or Dark. R5906112 /09 UDX series...

  • Page 171: Setting The Measurement System

    How to set a different metric system In the main menu, select System Settings → Units. Image 10-28: System settings menu – Units The Units menu is displayed. Image 10-29: Units menu Set the desired Temperature unit and Length unit. R5906112 /09 UDX series...

  • Page 172: Disabling Standby Mode

    In the main menu, select System Settings. In the System Settings menu, select if you want to enable or disable Standby mode by using the slider underneath Standby. Image 10-30: System Settings Menu, Enable Standby mode R5906112 /09 UDX series...

  • Page 173: Lens Features

    To enable/disable a feature, click on the slider and drag it to the left to disable the feature or the right to enable the feature. When enabled, the slider becomes blue; when disabled, the slider is gray. R5906112 /09 UDX series...

  • Page 174: Controlling The Backlight Of The Lcd Display

    In the main menu, System Settings → Backlight. Image 10-33: System settings, Backlight The Backlight menu will be displayed. Image 10-34: Backlight menu Choose the desired setting for the backlights. Select one of the predetermined options, or a custom value. R5906112 /09 UDX series...

  • Page 175: Reset

    Swap eye Dark time lowest value available ImageTestPattern Test Pattern Off, none selected ImageWarp Screen size 5120x3200 / 2560x1600 4 corner Warp disabled, no warp Warp files Disabled, all warp files deleted Network Communication LAN, Automatic settings R5906112 /09 UDX series...
  • Page 176 The Reset menu is displayed. Image 10-36: Reset menu Navigate to the checkbox next to the settings that need to be reset and press OK. Multiple selections are possible. Select RESET and press OK to reset all selected settings. R5906112 /09 UDX series...

  • Page 177: Lens Calibration

    Vertical shift • Focus • Zoom The text Calibration in progress will be displayed next to selected function until the calibration is completed. When an error is detected, the message Calibration Error is displayed next to function. R5906112 /09 UDX series...

  • Page 178: Flex Brightness

    Maximum Light output setup via OSD menu In the main menu, select System Settings → Maintenance → Flex. Image 10-39: Maintenance menu, Flex The Flex menu is displayed. R5906112 /09 UDX series...
  • Page 179 GUI – System Settings Image 10-40: Flex menu Choose the desired Light output (in lumens) for which you have a code available. Enter the code via the OSD menu and Select APPLY and click OK. R5906112 /09 UDX series...

  • Page 180: Rigging Frame Calibration

    • Vertical shift • Rotate The text Calibration in progress will be displayed next to selected function until the calibration is completed. When an error is detected, the message Calibration Error is displayed next to function. R5906112 /09 UDX series...

  • Page 181: Electronic Convergence

    Image 10-44 Select the desired X or Y value for one of the three colors and confirm. Use the arrow keys to raise or lower the value and confirm. Confirm all changes by pressing Apply. Image 10-45 R5906112 /09 UDX series...
  • Page 182 GUI – System Settings Tip: Press Reset to return all values to the factory settings. Repeat all steps until the desired alignment is achieved. R5906112 /09 UDX series...

  • Page 183: Advanced Settings

    Image 10-47: Maintenance menu, Advanced Settings The Advanced Settings menu item will remain visible until you leave the Maintenance menu. Overview • Advanced Settings – Color • Advanced Settings – Statistics • Checking the status of the Laser Banks R5906112 /09 UDX series...

  • Page 184: Advanced Settings - Color

    The Color menu will be displayed. Image 10-50: Color menu Select the desired value to change and confirm. Change the values to the desired position, taking into account the color gamut values. Select APPLY and click OK. R5906112 /09 UDX series...

  • Page 185: Advanced Settings - Statistics

    In the main menu, navigate to System Settings → Maintenance → Advanced Settings. Image 10-51: Maintenance menu, Advanced Settings In the Advanced Settings menu, select Statistics. Image 10-52: Advanced Settings menu, Statistics The Statistics will be displayed. Image 10-53: Statistics menu R5906112 /09 UDX series...

  • Page 186: Checking The Status Of The Laser Banks

    Select the desired laser group menu. In the laser banks group page, you can see which laser banks are part of this specific group. You can also see which laser banks are operational and which have failed. R5906112 /09 UDX series...
  • Page 187 GUI – System Settings Image 10-57 If you want notifications to be disabled for a specific group of laser banks, disable the LCD/OSD notifications enabled button. R5906112 /09 UDX series...
  • Page 188 GUI – System Settings R5906112 /09 UDX series...

  • Page 189: Status Menu

    Status menu This is a status menu only. No changes can be made to settings from this menu. Overview • Status menu overview R5906112 /09 UDX series...

  • Page 190: Status Menu Overview

    Warp Displays the Warp status and type of warp used Blend Displays the Warp status and type of Blend used Environment Shows the ambient temperature. Display Shows display settings Active Functions Shows the active function enabled. R5906112 /09 UDX series...

  • Page 191: Maintenance

    Maintenance About this chapter This chapter contains general maintenance procedures. Overview • Cleaning the lens • Cleaning the exterior of the projector R5906112 /09 UDX series...

  • Page 192: Cleaning The Lens

    If smears occur when cleaning lenses, replace the cloth. Smears are the first indication of a dirty cloth. Pressurized air cans are not efficient if there is too much dust on the surface, the pressure is too low R5906112 /09 UDX series...

  • Page 193: Cleaning The Exterior Of The Projector

    Switch off the projector and unplug the projector from the mains power net. Clean the housing of the projector with a damp cloth. Stubborn stains may be removed with a cloth lightly dampened with a mild detergent solution. R5906112 /09 UDX series...
  • Page 194 Maintenance R5906112 /09 UDX series...

  • Page 195: A Specifications

    Specifications of the UDX-W26 • Specifications of the UDX-W22 • Specifications of the UDX-U40 • Specifications of the UDX-U32 • Dimensions of a UDX • Dimensions of the rigging frame • Dimensions of the flight case • Technical Regulations R5906112 /09 UDX series...

  • Page 196: Specifications Of The Udx-4K40

    Quad DP1.2, Fiber SFP input Input resolutions From NTSC up to 4K (4,096 x 2,160) refresh rates: 24hz to 120hz 4K/4KUHD (4096 x 2160/ 3860 x 2400) to 240hz WQXGA (2560 x 1600) Max. pixel clock 600 MHz R5906112 /09 UDX series...
  • Page 197 92kg (202 lbs)/shipping weight from factory: 110kg (242 lbs) Standard accessories Power cord, wireless/XLR wired rugged remote control Certifications Compliant with UL60950-1 and EN60950-1 complies with FCC rules & regulations, part 15 Class A and CE EN55032 Class A, Rohs Warranty 3 years R5906112 /09 UDX series...

  • Page 198: Specifications Of The Udx-4K32

    Optional Inputs Quad DP1.2 Input resolutions From NTSC up to 4K (4,096 x 2,160) refresh rates: 24hz to 120hz 4K/4KUHD (4096 x 2160/ 3860 x 2400) to 240hz WQXGA (2560 x 1600) Max. pixel clock 600 MHz R5906112 /09 UDX series...
  • Page 199 Standard accessories Power cord, wireless/XLR wired rugged remote control Certifications Compliant with UL60950-1 and EN60950-1 complies with FCC rules & regulations, part 15 Class A and CE EN55032 Class A, Rohs Warranty 3 years +/- 10% R5906112 /09 UDX series...

  • Page 200: Specifications Of The Udx-4K22

    Optional Inputs Quad DP1.2 Input resolutions From NTSC up to 4K (4,096 x 2,160) refresh rates: 24hz to 120hz 4K/4KUHD (4096 x 2160/ 3860 x 2400) to 240hz WQXGA (2560 x 1600) Max. pixel clock 600 Mhz R5906112 /09 UDX series...
  • Page 201 Compliant with UL60950-1 and EN60950-1, complies with FCC rules & regulations, part 15 Class A and CE EN55032 Class A, Rohs Warranty 3 years Software upgradeable. Check with your local authorized Barco sales representative for full details. R5906112 /09 UDX series...

  • Page 202: Specifications Of The Udx-W40

    From NTSC up to 4K (4,096 x 2,160) refresh rates: 24hz to 120hz 4K/4KUHD (4096 x 2160/ 3860 x 2400) to 240hz WQXGA (2560 x 1600) Max. pixel clock 600 MHz Software tools Projector Toolset + Android** app + iOS** app R5906112 /09 UDX series...
  • Page 203 92kg (202 lbs)/shipping weight from factory: 110kg (242 lbs) Standard accessories Power cord, wireless/XLR wired rugged remote control Certifications Compliant with UL60950-1 and EN60950-1 complies with FCC rules & regulations, part 15 Class A and CE EN55032 Class A, Rohs Warranty 3 years R5906112 /09 UDX series...

  • Page 204: Specifications Of The Udx-W32

    From NTSC up to 4K (4,096 x 2,160) refresh rates: 24hz to 120hz 4K/4KUHD (4096 x 2160/ 3860 x 2400) to 240hz WQXGA (2560 x 1600) Max. pixel clock 600 MHz Software tools Projector Toolset + Android** app + iOS** app R5906112 /09 UDX series...
  • Page 205 Standard accessories Power cord, wireless/XLR wired rugged remote control Certifications Compliant with UL60950-1 and EN60950-1 complies with FCC rules & regulations, part 15 Class A and CE EN55032 Class A, Rohs Warranty 3 years +/- 10% R5906112 /09 UDX series...

  • Page 206: Specifications Of The Udx-W26

    From NTSC up to 4K (4,096 x 2,560) refresh rates: 24hz to 120hz 4K/4KUHD (4096 x 2160/ 3860 x 2400) to 240hz WQXGA (2560 x 1600) Max. pixel clock 600 Mhz Software tools Projector Toolset + Android app* + iOS app* R5906112 /09 UDX series...
  • Page 207 (WxLxH) 800 x 1,200 x 685 mm (31.49 x 47.24 x 26.96") Weight 92kg (202 lbs)/shipping weight from factory: 110kg (242 lbs) Standard accessories Power cord, wireless/XLR wired rugged remote control Certifications Warranty 3 years Software upgradeable, please contact your local authorized Barco sales representative R5906112 /09 UDX series...

  • Page 208: Specifications Of The Udx-W22

    From NTSC up to 4K (4,096 x 2,560) refresh rates: 24hz to 120hz 4K/4KUHD (4096 x 2160/ 3860 x 2400) to 240hz WQXGA (2560 x 1600) Max. pixel clock 600 Mhz Software tools Projector Toolset + Android app* + iOS app* R5906112 /09 UDX series...
  • Page 209 Power cord, wireless/XLR wired rugged remote control Certifications Compliant with UL60950-1 and EN60950-1 complies with FCC rules & regulations, part 15 Class A and CE EN55032 Class A, Rohs Warranty 3 years Software upgradeable, please contact your local authorized Barco sales representative R5906112 /09 UDX series...

  • Page 210: Specifications Of The Udx-U40

    From NTSC up to 4K (4,096 x 2,160) refresh rates: 24hz to 120hz 4K/4KUHD (4096 x 2160/ 3860 x 2400) to 240hz WQXGA (2560 x 1600) Max. pixel clock 600 MHz Software tools Projector Toolset + Android** app + iOS** app R5906112 /09 UDX series...
  • Page 211 92kg (202 lbs)/shipping weight from factory: 110kg (242 lbs) Standard accessories Power cord, wireless/XLR wired rugged remote control Certifications Compliant with UL60950-1 and EN60950-1 complies with FCC rules & regulations, part 15 Class A and CE EN55032 Class A, Rohs Warranty 3 years R5906112 /09 UDX series...

  • Page 212: Specifications Of The Udx-U32

    From NTSC up to 4K (4,096 x 2,160) refresh rates: 24hz to 120hz 4K/4KUHD (4096 x 2160/ 3860 x 2400) to 240hz WQXGA (2560 x 1600) Max. pixel clock 600 MHz Software tools Projector Toolset + Android** app + iOS** app R5906112 /09 UDX series...
  • Page 213 Power cord, wireless/XLR wired rugged remote control, bottom rigging kit/ clamps Certifications Compliant with UL60950-1 and EN60950-1, complies with FCC rules & regulations, part 15 Class A and CE EN55032 Class A, Rohs Warranty 3 years +/- 10% R5906112 /09 UDX series...

  • Page 214: Dimensions Of A Udx

    Specifications A.10 Dimensions of a UDX Overview Image A-1: Dimensions, in mm Geometrical centre R5906112 /09 UDX series...

  • Page 215: Dimensions Of The Rigging Frame

    Specifications A.11 Dimensions of the rigging frame Overview 1018,97 463,3 978,38 Image A-2: Dimensions, in mm R5906112 /09 UDX series...

  • Page 216: Dimensions Of The Flight Case

    Specifications A.12 Dimensions of the flight case Overview 1133 Image A-3: Dimensions, in mm R5906112 /09 UDX series...

  • Page 217: Technical Regulations

    Specifications A.13 Technical Regulations Certificates Image A-7: Image A-4: Image A-5: CE Image A-6: CEBEC Image A-8: FCC Image A-9: EAC mark mark CCC mark mark label RCM mark Image A-10: SGS mark R5906112 /09 UDX series...
  • Page 218 Specifications R5906112 /09 UDX series...

  • Page 219: B Environmental Information

    Environmental information Overview • Disposal information • Turkey RoHS compliance • Contact information R5906112 /09 UDX series...

  • Page 220: Disposal Information

    For more information about recycling of this product, please contact your local city office or your municipal waste disposal service. For details, please visit the Barco website at: http://www.barco.com/AboutBarco/weee Disposal of batteries in the product This product contains batteries covered by the Directive 2006/66/EC which must be collected and disposed of separately from municipal waste.

  • Page 221: Turkey Rohs Compliance

    Environmental information B.2 Turkey RoHS compliance Turkey RoHS compliance Türkiye Cumhuriyeti: AEEE Yönetmeliğine Uygundur. [Republic of Turkey: In conformity with the WEEE Regulation] R5906112 /09 UDX series...

  • Page 222: Contact Information

    Registered office address: President Kennedypark 35, 8500 Kortrijk, Belgium Contact address: Beneluxpark 21, 8500 Kortrijk, Belgium Importers contact information To find your local importer, contact Barco directly or one of Barco's regional offices via the contact information given on Barco's web site, www.barco.com. R5906112 /09...

  • Page 223: C Overview Video Timings For Video Interfaces

    Overview video timings for video interfaces Overview • Overview video timings • Overview video timings SDI Inputs • Overview video timings HDMI 2.0 inputs • Overview video timings DisplayPort 1.2 inputs • Overview video timings HDBaseT inputs R5906112 /09 UDX series...

  • Page 224: Overview Video Timings

    C.1 Overview video timings List of compatible signals The following table specifies the video signals that the projector can project. Barco Events projectors supports the signal with “X” in the Compatible signals column. Note: Support for refresh rates 24.00, 30.00, 60.00 Hz automatically includes support of 1/1.001 x those refresh rates.
  • Page 225 3840 x 2400 — — — 3840 x 2400 — — — 4096 x 2160 — — 4096 x 2160 — — 4096 x 2160 — — 4096 x 2160 — — 4096 x 2160 — — R5906112 /09 UDX series...

  • Page 226: Overview Video Timings Sdi Inputs

    Single Link 4096 x 2160 12G-SDI Single Link Support for refresh rates 24.00, 30.00 and 60.00 Hz automatically includes support of 1/1.001 x those refresh rates. 10: 12G SDI board only, and only on Channel A R5906112 /09 UDX series...

  • Page 227: Overview Video Timings Hdmi 2.0 Inputs

    1920 x 1200 2048 x 1080 2048 x 1080 2048 x 1080 2048 x 1080 2048 x 1080 2048 x 1080 2560 x 1600 2560 x 1600 3840 x 2160 3840 x 2160 3840 x 2160 R5906112 /09 UDX series...
  • Page 228 Vertical refresh rate (Hz) 3D support? (active pixels x active lines) 3840 x 2160 3840 x 2160 3840 x 2400 3840 x 2400 4096 x 2160 4096 x 2160 4096 x 2160 4096 x 2160 4096 x 2160 R5906112 /09 UDX series...

  • Page 229: Overview Video Timings Displayport 1.2 Inputs

    4 Quadrant mode (2 x 2 Active 3D layout) 1400 x 1050 1600 x 1200 1600 x 1200 Active 3D 1920 x 1080 1920 x 1080 11: Other layout modes are only available on Input boards that have multiple DP inputs. R5906112 /09 UDX series...
  • Page 230 3840 x 2160 3840 x 2160 3840 x 2160 Passive Stereo 3840 x 2400 3840 x 2400 4096 x 2160 4096 x 2160 11: Other layout modes are only available on Input boards that have multiple DP inputs. R5906112 /09 UDX series...
  • Page 231 Support for 3D? (active pixels x active (Hz) layout (1 x 1 layout) lines) 4096 x 2160 4096 x 2160 4096 x 2160 11: Other layout modes are only available on Input boards that have multiple DP inputs. R5906112 /09 UDX series...

  • Page 232: Overview Video Timings Hdbaset Inputs

    2048 x 1080 2048 x 1080 2048 x 1080 2048 x 2160 2 Column mode (2 x 1 layout) 2048 x 2160 2 Column mode (2 x 1 layout) 2560 x 1600 2560 x 1600 3840 x 2160 R5906112 /09 UDX series...
  • Page 233 Available layout modes, other Video timing Vertical refresh rate (Hz) than standard layout (1 x 1 (active pixels x active lines) layout) 3840 x 2160 3840 x 2160 4096 x 2160 4096 x 2160 4096 x 2160 R5906112 /09 UDX series...
  • Page 234 Overview video timings for video interfaces R5906112 /09 UDX series...

  • Page 235: D Dmx Chart

    DMX chart Overview • DMX chart input board positioning • DMX chart, Basic • DMX chart, Extended R5906112 /09 UDX series...

  • Page 236: Dmx Chart Input Board Positioning

    DMX support, it is important to take into account to keep the input boards in their original slots. Image D-1 Slot L1, here filled with the Quad combo Input board Slot L2, here filled with the Quad DP 1.2 Input board R5906112 /09 UDX series...

  • Page 237: Dmx Chart, Basic

    Power down / Light source off (if held for 5 seconds) 224 - 255 Reserved for future functionality 12: Only when the Quad Combo input board is installed in slot L1 13: Only when the Quad DisplayPort input board is installed in slot L2 R5906112 /09 UDX series...

  • Page 238: Dmx Chart, Extended

    (LSB) Lens shift horizontal 0 - 255 Set coarse lens shift in horizontal direction (MSB) Lens shift horizontal 0 - 255 Set fine lens shift in horizontal direction (LSB) 14: Only when lens has been calibrated R5906112 /09 UDX series...
  • Page 239 24 - 31 Calibrate lens (zoom, focus and shift) 32 - 255 Reserved for future functionality 15: If the Light Source is forced to a output below its minimum value, it will remain at its minimum output value R5906112 /09 UDX series...
  • Page 240 R5906112 /09 | 2019-09-12 Barco NV | Beneluxpark 21, 8500 Kortrijk, Belgium www.barco.com...

This manual is also suitable for:

Udx-4k22Udx-w32Udx-w26Udx-w22Udx-4k40Udx-4k32 ... Show all

Table of Contents
