Barco UDX Series Installation Manual

Hide thumbs Also See for UDX Series:
Table of Contents

Advertisement

Quick Links

Download this manual
UDX
Installation manual
ENABLING BRIGHT OUTCOMES

Advertisement

Table of Contents
loading

Related Manuals for Barco UDX Series

Summary of Contents for Barco UDX Series

  • Page 1 Installation manual ENABLING BRIGHT OUTCOMES...
  • Page 2 Registered office: Barco NV President Kennedypark 35, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com Barco NV Beneluxpark 21, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com...
  • Page 3 Barco. If the purchaser or a third party carries out modifications or repairs on goods delivered by Barco, or if the goods are handled incorrectly, in particular if the systems are operated incorrectly or if, after the transfer of risks, the goods are subject to influences not agreed upon in the contract, all guarantee claims of the purchaser will be rendered invalid.

  • Page 5: Table Of Contents

    Table of contents 1 Safety information....................................7 General considerations ..................................8 Safety training to be provided by the installer .........................10 Important safety instructions..............................11 Product safety labels..................................15 High Brightness precautions: Hazard Distance ......................16 HD for fully enclosed projection systems...........................19 HD in function of modifying optics ............................20 Radio equipment (optional) ...............................21 Download Product Manual ................................22 2 Installation process....................................23...
  • Page 6 Alignment of projector in the rigging frame........................55 4.10 Installation of an input board..............................56 4.11 Removal of an input board.................................57 4.12 Software update....................................58 5 Maintenance.......................................61 Cleaning the lens ....................................62 Cleaning the exterior of the projector...........................63 Replacement of the metal dust filters ..........................64 Replacement of the synthetic air filter ..........................66 6 Flight case and rigging frame ..............................67 UDX flight case....................................68...

  • Page 7: Safety Information

    Ensure that you understand and follow all safety guidelines, safety instructions and warnings mentioned in this chapter before installing the UDX projector. Clarification of the term “UDX” used in this document When referring in this document to the term “UDX” means that the content is applicable for following Barco products: •...

  • Page 8: General Considerations

    • Before operating this equipment please read this manual thoroughly and retain it for future reference. • Installation and preliminary adjustments should be performed by qualified Barco personnel or by authorized Barco service dealers. • All warnings on the projector and in the documentation manuals should be adhered to.
  • Page 9 Safety information Notice on laser radiation The laser distance meter that is optional equipment for this projector can emit a class 2 laser ranging beam of 0.95 mW / 638 nm. When installed correctly, this distance meter is located on the front side of the projector (see Image 1-1).

  • Page 10: Safety Training To Be Provided By The Installer

    Safety information 1.2 Safety training to be provided by the installer Users definition The UDX projector is intended for persons who have been instructed and trained by a skilled person (installer or service personnel) to identify energy sources that may cause injury and to take precautions to avoid unintentional contact with or exposure to those energy sources.

  • Page 11: Important Safety Instructions

    Safety information 1.3 Important safety instructions To prevent the risk of electrical shock • This product should be operated from a mono phase AC power source. Ensure that the mains voltage and capacity matches the projector electrical ratings (120-160V / 200-240V (+/- 10%), 20A, 50-60 Hz). If you are unable to install the AC requirements, contact your electrician.
  • Page 12 In the event of fire, use sand, CO or dry powder fire extinguishers. Never use water on an electrical fire. Always have service performed on this projector by authorized Barco service personnel. Always insist on genuine Barco replacement parts. Never use non-Barco replacement parts as they may degrade the safety of this projector.
  • Page 13 For lens cleaning follow the instructions precisely as stipulated in the projector manual. • Only use zoom lenses of the Barco TLD+ series on the 4k models of the UDX. Using other lenses will damage the internal optics. For suitable fixed TLD+ lenses contact Barco or see Barco website.
  • Page 14 Replacement parts: When replacement parts are required, be sure the service technician has used original Barco replacement parts or authorized replacement parts which have the same characteristics as the Barco original part. Unauthorized substitutions may result in degraded performance and reliability, fire, electric shock or other hazards.

  • Page 15: Product Safety Labels

    Safety information 1.4 Product safety labels Light beam related safety labels Label image Label description Label location Hazard RG3: not for household use symbol Hazard RG3: optical radiation warning symbol Hazard class 2: laser radiation warning symbol. 0.95 mW - 638 nm. DECEMBER 12, 2019 WARNING! DO NOT LOOK INTO THE LIGHT BEAM.

  • Page 16: High Brightness Precautions: Hazard Distance

    Safety information 1.5 High Brightness precautions: Hazard Distance Hazard Distance (HD) is the distance measured from the projection lens at which the intensity or the energy per surface unit becomes lower than the applicable exposure limit on the cornea or on the skin.
  • Page 17 The LIP shall be installed by Barco or by a trained and Barco-authorized installer or shall only be transferred to laser light show variance holders. This is applicable for dealers and distributors since they may need to install the LIP (demo install) and/or they transfer (sell, rent, lease) the LIP.
  • Page 18 Safety information In addition to temporary installations (e. g.: rental and staging, lease, events …) the following requirements apply: • Rental companies shall have a laser light show variance because they have direct relationship with the installers of the rented equipment. •...

  • Page 19: Hd For Fully Enclosed Projection Systems

    Safety information 1.6 HD for fully enclosed projection systems Hazard Distance (HD) is the distance measured from the projection lens at which the intensity or the energy per surface unit becomes lower than the applicable exposure limit on the cornea or on the skin.

  • Page 20: Hd In Function Of Modifying Optics

    Safety information 1.7 HD in function of modifying optics Hazard Distance UDX 4K40, UDX 4K45 LC, UDX W40, UDX W45 LC, UDX U40, UDX U45 LC UDX 4K22, UDX W22 UDX 4K32, UDX W32, UDX U32 UDX 4K26, UDX W26 Throw Ra o (TR) Image 1-5 Hazard Distance...

  • Page 21: Radio Equipment (Optional)

    The UDX is restricted to indoor use only when operating in the 5150 to 5250 MHz frequency range. Hereby, Barco declares that the radio equipment type UDX is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.barco.com/support...

  • Page 22: Download Product Manual

    Safety information 1.9 Download Product Manual Download Product Manual Product manuals and documentation are available online at www.barco.com/td. Registration may be required; follow the instructions given on the website. IMPORTANT! Read Installation Instructions before connecting equipment to the mains power supply.

  • Page 23: Installation Process

    Installation process Preparation process........................24 Installation process ........................25 Additional install options........................27 About this chapter This chapter gives an overview of all the different stages in the installation process that has to be followed in chronological order to set the projector up and running. The stages are grouped in three processes: Preparation, Installation and Options.

  • Page 24: Preparation Process

    Installation process 2.1 Preparation process Prepare for installation Ensure that you understand all safety topics described in the chapter “Safety information”, page 7. Check if all installation requirements are fulfilled such as: • the environmental conditions of the installation area, •...

  • Page 25: Installation Process

    Install the batteries of the Remote Control Unit (RCU). See chapter “Remote control, battery installation”, page Installation of the Projector Toolset on local laptop. Download and install the latest version from the Barco website. See chapter “Download Projector Toolset”, page 42.
  • Page 26 Installation process If needed change the projector orientation (e.g. Front/Table, Front/Ceiling, Rear/Table, Rear Ceiling). See user guide of the projector for the software settings of the projector orientation. Check for the latest projector software package. See chapter “Software update”, page 58. R5906113 /09...

  • Page 27: Additional Install Options

    Installation process 2.3 Additional install options Overview Installation of an optional input board (e.g. Quad DP 1.2 input or the SFP input ) or replacing an input board. • for removal see “Removal of an input board”, page 57. • for installation see “Installation of an input board”, page 56.
  • Page 28 Installation process R5906113 /09...

  • Page 29: Prepare To Install

    Barco provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms of guarantee. Observing the specification mentioned in this chapter is critical for projector performance.

  • Page 30: Installation Requirements

    Prepare to install 3.1 Installation requirements Environment conditions Table below summarizes the physical environment in which the UDX may be safely operated or stored. Operating Non-Operating Environment Ambient Temperature 0°C (32°F) to 40 °C (104 °F) -15°C (5°F) to 60°C (140°F) Humidity 0% RH to 80% RH Non- 0% RH to 90% RH Non-...
  • Page 31 Prepare to install Only ever use the manufacturer's recommended cleaning kit which has been specifically designed for cleaning optical parts, never use industrial strength cleaners on the projector's optics as these will degrade optical coatings and damage sensitive optoelectronics components. Failure to take suitable precautions to protect the projector from the effects of persistent and prolonged air contaminants will culminate in extensive and irreversible ingrained optical damage.

  • Page 32: Unpacking The Projector

    Prepare to install 3.2 Unpacking the projector What has to be done ? The projector is delivered in a cardboard box on a pallet and is secured with banding and fastening clips. Furthermore, to provide protection during transportation, the projector is surrounded with polymeric foam. Once the projector has arrived at the installation site, it needs to be removed from the box and pallet in a safe manner, without damaging the projector.
  • Page 33 Prepare to install Save the original shipping cardboard box and packing material. They will be necessary if you ever have to ship your projector. For maximum protection, repack your projector as it was originally packed at the factory. A plastic lens holder cover is placed into the lens opening of the projector. It's recommended to reuse this cover each time you transport the projector.

  • Page 34: Initial Inspection

    This check should confirm that there are no broken knobs or connectors, that the cabinet and panel surfaces are free of dents and scratches, and that the operating panel is not scratched or cracked. The Barco Sales and Service office should be notified as soon as possible if this is not the case.

  • Page 35: Projector Orientations

    Prepare to install 3.4 Projector orientations Supported projector orientations The projector can be installed on a table or upside down on the ceiling and this in a front projection or rear projection configuration. Depending on the physical configuration of the projector the projected image has to be rotated and/or mirrored as well.
  • Page 36 Prepare to install Some lenses (e.g. UST lenses) may require that the projector orientation needs to be adapted for the desired outcome. R5906113 /09...

  • Page 37: Projector Positioning

    Prepare to install 3.5 Projector positioning Positioning the projector The projector should be installed at right angles (horizontally and vertically) to the screen at a distance PD. Note the distance (A) between lens centre and table surface is slightly variable. This distance (A) is nominal 223 mm in case all feet are turned in completely and the vertical lens shift is set to zero (0).

  • Page 38: Projector Shift And Tilt Range

    Prepare to install 3.6 Projector shift and tilt range Shift range The lens can be shifted with respect to the DMD (P) which result in a shifted image on the screen (Off-Axis). A 100% shift means that the centre point of the projected image is shifted by half the screen size. In other words, the centre point of the projected image falls together with the outline of the image in an On-Axis projection.

  • Page 39: Lens Selection

    How to select the right lens Determine the required screen width (SW). Determine the approximate position of the projector in the room. Start up the Lens Calculator on the Barco website: https://lenscalculator.barco.com/ to determine the possible lenses for your configuration.

  • Page 40: Available Lenses

    Prepare to install 3.8 Available lenses WARNING: Only use TLD+ ZOOM lenses on the 4k variants of the UDX projectors. Using other lenses can touch and damage the mechanics of the build-in Actuator! This can result in loud rattling noises and a damaged Actuator. Limited amount of available lenses The 4k variants of the UDX projectors have an Actuator built in them to help provide a clear 4K image.
  • Page 41 This table only takes into account active lenses at the moment of release of this manual. Lenses that have become end-of life or end-of service are not taken into account. Consult the Barco website for the most up-to-date information on active lenses.

  • Page 42: Download Projector Toolset

    3.9 Download Projector Toolset About Projector Toolset Projector Toolset is a software tool to set up, configure, manage and control Barco projectors. The Projector Toolset software works with configurations that can be loaded. Several configurations can be controlled simultaneously. Even when the configurations are connected via different ways.

  • Page 43: Installation Procedures

    Installation procedures Remote control, battery installation ....................44 Connecting the projector with the power net..................46 Lens installation..........................47 Lens removal ..........................49 Displaying and Programming addresses into the RCU..............51 Using the XLR connector of the RCU .....................52 Setting the projector addresses .....................53 Alignment of a table mounted projector...................54 Alignment of projector in the rigging frame ..................55 4.10 Installation of an input board......................56 4.11 Removal of an input board......................57...

  • Page 44: Remote Control, Battery Installation

    Installation procedures 4.1 Remote control, battery installation Where to find the batteries for the remote control ? The batteries are not placed in the remote control unit to avoid control operation in its package, resulting in a shorter battery life time. At delivery the batteries can be found in a separated bag attached to the remote control unit.
  • Page 45 Installation procedures CAUTION: Replace with the correct battery type. Use two AA size batteries. There is a risk of explosion if the battery is replaced with an incorrect type. CAUTION: Replace the battery as explained above. There is a risk of explosion if the battery is incorrectly installed.

  • Page 46: Connecting The Projector With The Power Net

    Installation procedures 4.2 Connecting the projector with the power net CAUTION: Use only the power cord provided with the projector. How to connect with local power net Ensure that the power switch stands in the '0' (OFF) position (reference 1 Image 4-4). Image 4-4: Power input Connect the female side of the power cord with the power input socket of the projector (reference 2).

  • Page 47: Lens Installation

    Installation procedures 4.3 Lens installation WARNING: Only use TLD+ ZOOM lenses. Using other lenses can touch and damage the mechanics of the build-in Actuator! This can result in loud rattling noises and a damaged Actuator. How to install Place the lens holder in the “unlocked” position. Do this by pulling the lens lock handle (reference 1, Image 4- 5) outward and then towards the lens power supply socket (reference 2) as illustrated.
  • Page 48 Installation procedures Image 4-7: Lens installation Insert the lens until the connector seats into the socket and de secondary lock (reference 3) makes an audible clicking sound. Warning: Do not release the Lens yet, as the Lens may fall out of the Lens Holder. Secure the lens in the lens holder by sliding the primary lens lock handle into the “locked”...

  • Page 49: Lens Removal

    Installation procedures 4.4 Lens removal How to remove Support the lens with one hand while you unlock the lens holder by sliding the primary lock handle outwards and then towards the “unlocked” position as illustrated (Image 4-9). Image 4-9: Unlock the lens Pull down the secondary lock on the lower left side of the lens holder as illustrated (Image 4-10).
  • Page 50 Installation procedures Image 4-11 R5906113 /09...

  • Page 51: Displaying And Programming Addresses Into The Rcu

    Installation procedures 4.5 Displaying and Programming addresses into the RCU Displaying the Projector Address on the Screen. If the projector is on, press the menu key and navigate to the Status page. The projector address and the broadcast address can be seen under the Communication heading. The projector's address is displayed on the LCD status screen and / or the OSD.

  • Page 52: Using The Xlr Connector Of The Rcu

    Installation procedures 4.6 Using the XLR connector of the RCU Connecting a cable with the XLR connector will reset the broadcast address of the RCU to its default value '0'. How to use the XLR connector Remove the XLR cover by pulling it backwards. Image 4-12 Connect a cable with XLR plug into the XLR connector of the RCU.

  • Page 53: Setting The Projector Addresses

    Installation procedures 4.7 Setting the projector addresses Projector address Address installed in the projector to be individually controlled via the RCU or via the serial communication. Broadcast address Projector will always execute the command coming from a RCU programmed with that broadcast address.

  • Page 54: Alignment Of A Table Mounted Projector

    Installation procedures 4.8 Alignment of a table mounted projector How to align Place the projector in the desired location. Take into account the zoom range of the used lens and the size of the screen. Project one of the internal hatch patterns on the screen. Turn the adjustable feet in or out until the projected hatch pattern has a perfect rectangle shape and is leveled.

  • Page 55: Alignment Of Projector In The Rigging Frame

    Installation procedures 4.9 Alignment of projector in the rigging frame How to skew the projector? Turn the skew knob at the back (reference 1) to skew the projector. Image 4-15 How to tilt the projector? Turn the tilt adjustment knob at the back (reference 1) to lift the projector up or down. Image 4-16 How to rotate the projector? Turn the rotate adjustment knob on the left side (reference 1) to rotate the projector.

  • Page 56: Installation Of An Input Board

    Installation procedures 4.10 Installation of an input board WARNING: The procedures below may only be performed by Barco trained and qualified technicians. CAUTION: Always wear a wrist band which is connected to the ground while handling the electrostatic discharge (ESD) sensitive parts.

  • Page 57: Removal Of An Input Board

    Installation procedures 4.11 Removal of an input board WARNING: The procedures below may only be performed by Barco trained and qualified technicians. CAUTION: Always wear a wrist band which is connected to the ground while handling the electrostatic discharge (ESD) sensitive parts.

  • Page 58: Software Update

    Download the latest firmware (format .fw) from Barco's website in the same way as for Projector Toolset. Start Projector Toolset and make a connection with the projector. For more information, see the “Projector Toolset”...
  • Page 59 Power on the projector. Wait until the Power on/off button is either lit white or blue. Download the latest firmware file ( format .fw) from Barco's website. The firmware can be downloaded for free from Barco's website, (URL: http://www.barco.com). Click on myBarco and log in to get access to secured information.
  • Page 60 Installation procedures R5906113 /09...

  • Page 61: Maintenance

    Maintenance Cleaning the lens..........................62 Cleaning the exterior of the projector ....................63 Replacement of the metal dust filters....................64 Replacement of the synthetic air filter .....................66 About this chapter This chapter contains general maintenance procedures. R5906113 /09...

  • Page 62: Cleaning The Lens

    Maintenance 5.1 Cleaning the lens To minimize the possibility of damage to optical coatings, or scratches to lens surfaces follow the cleaning procedure as described here precisely. Required tools • Compressed air • Clean micro fiber lens cleaning cloth (e.g. Toraysee® cloth(s)) •...

  • Page 63: Cleaning The Exterior Of The Projector

    Maintenance 5.2 Cleaning the exterior of the projector How to clean the exterior of the projector ? Switch off the projector and unplug the projector from the mains power net. Clean the housing of the projector with a damp cloth. Stubborn stains may be removed with a cloth lightly dampened with a mild detergent solution.

  • Page 64: Replacement Of The Metal Dust Filters

    Maintenance 5.3 Replacement of the metal dust filters CAUTION: The high density filter must be replaced on a regular basis, depending on the environment conditions of the projector. WARNING: Switch off the projector and unplug the power cord before starting the procedure. Required tools •...
  • Page 65 Maintenance Image 5-2: Small top cover filter replacement Remove the filter and clean it. Install either the cleaned filter or a new filter (if the old one is no longer usable). Caution: Take notice of the air flow direction of the filter (made visible by a label). Make sure the arrow points towards the inside of the projector.

  • Page 66: Replacement Of The Synthetic Air Filter

    Maintenance 5.4 Replacement of the synthetic air filter WARNING: Switch off the projector and unplug the power cord before starting the procedure. Required parts New synthetic filter How to remove Remove the front cover. See “Removal of the front cover”, page 80. Push both filter holders to the outside and flip the filter out of the holder as illustrated.

  • Page 67: Flight Case And Rigging Frame

    Flight case and rigging frame UDX flight case..........................68 UDX rigging frame ........................69 Stacking UDX projectors .......................70 About flight case and rigging frame The projector can also be delivered with rigging frame installed inside a flight case. R5906113 /09...

  • Page 68: Udx Flight Case

    Flight case and rigging frame 6.1 UDX flight case Introduction of the UDX flight case The UDX flight case is designed to transport the UDX in a safe and secure manner, with or without being mounted in its rigging frame. There's also sufficient space in the flight case to place the projector while mounted in the UDX rigging frame.

  • Page 69: Udx Rigging Frame

    6.2 UDX rigging frame Rigging frame The UDX series multifunctional rigging frame is designed for the Barco UDX projectors, and can not be used for other equipment. See rigging frame specific documentation for how to install the projector in to the frame.

  • Page 70: Stacking Udx Projectors

    Flight case and rigging frame 6.3 Stacking UDX projectors WARNING: UDX projectors can be stacked up on top of each other on a flat surface, or suspended from a truss using the rigging frame. But keep the following in mind: It is allowed to stack maximum three projectors It is allowed to suspend maximum two projectors How to stack...
  • Page 71 Flight case and rigging frame Image 6-5 Repeat the previous step for each overlapping corner of all stacked rigging frames. In long-term installations, it is advised to also install swivels between the two projectors in order to make it easier to access the metal air filter on the top of the projector. R5906113 /09...
  • Page 72 Flight case and rigging frame R5906113 /09...

  • Page 73: Pulse Sfp Input Use Cases

    Pulse SFP input use cases Use case 1: SFP+ transceiver + Fiber connection (integrated or separated) ........74 Use case 2: Neutrik OpticalCon Duo + SFP+ transceiver + internal fiber ...........75 Use case 3: Neutrik OpticalCon Quad + SFP+ transceiver + internal fiber .........76 Use case 4: Loop-through mode ....................77 About this chapter This chapter describes the several use cases of the SFP input.

  • Page 74: Use Case 1: Sfp+ Transceiver + Fiber Connection (Integrated Or Separated)

    SFP+ fiber transceiver Optional breakout Optical adapter Barco delivers only the SFP input and SFP+ fiber transceivers. The customer has to buy the SFP+ transceiver and the optional breakout adapter or the fiber integrated cable. How to configure the SFP input Remove the plate covering the access to the SFP cages.

  • Page 75: Use Case 2: Neutrik Opticalcon Duo + Sfp+ Transceiver + Internal Fiber

    Neutrik OpticalCon DUO Cable Internal fiber cable Barco delivers only the SFP input and SFP+ fiber transceivers. The customer has to buy the SFP+ transceiver and the optional breakout adapter or the fiber integrated cable. How to configure the SFP input Remove both plates covering the access to the Neutrik connector locations.

  • Page 76: Use Case 3: Neutrik Opticalcon Quad + Sfp+ Transceiver + Internal Fiber

    Advanced quad cable Internal fiber cable Barco delivers only the SFP input and SFP+ fiber transceivers. The customer has to buy the SFP+ transceiver and the optional breakout adapter or the fiber integrated cable. How to configure the SFP input Remove one plate covering the access to a Neutrik connector location.

  • Page 77: Use Case 4: Loop-Through Mode

    Neutrik OpticalCon Quad Advanced Quad cable Barco delivers only the SFP input and SFP+ fiber transceivers. The customer has to buy the SFP+ transceiver and the optional breakout adapter or the fiber integrated cable. How to configure the SFP input Remove both plates covering the access to a Neutrik connector locations.
  • Page 78 Pulse SFP input use cases R5906113 /09...

  • Page 79: Projector Covers

    Projector covers Removal of the front cover......................80 Removal of the left cover.......................81 Removal of the back cover ......................82 Removal of the small top cover ......................83 Mounting the front cover........................84 Mounting the left cover ........................85 Mounting the back cover .......................86 Mounting the small top cover ......................87 About this chapter Most maintenance and service procedures demand removing one or more of the projector covers to gain access to the parts to maintain or to service.

  • Page 80: Removal Of The

    Projector covers 8.1 Removal of the front cover Required tools 7 mm flat screw driver How to remove Remove the lens. See “Lens removal”, page 49. Release the three captive screws (reference 1). Image 8-1: Front cover removal Remove the front cover. R5906113 /09...

  • Page 81: Removal Of The Left Cover

    Projector covers 8.2 Removal of the left cover Required tools 7 mm flat screw driver How to remove Loosen the four captive screws (reference 1) of the light processor cover. Use a 7 mm flat screwdriver. Remove the cover from the projector. Image 8-2: Removal of the left cover (light processor side) R5906113 /09...

  • Page 82: Removal Of The

    Projector covers 8.3 Removal of the back cover Required tools 7 mm flat screw driver How to remove Loosen the captive three screws (reference 1) of the backside of the projector. Use a 7 mm flat screwdriver. Remove the cover from the projector. Image 8-3: Remove back cover R5906113 /09...

  • Page 83: Removal Of The Small Top Cover

    Projector covers 8.4 Removal of the small top cover Required tools 7 mm flat screw driver How to remove Loosen the two captive screws (reference 1) of the small top cover at the back side of the projector. Image 8-4 Caution: Only loosen the captive screws at the backside of the projector.

  • Page 84: Mounting The

    Projector covers 8.5 Mounting the front cover Required tools 7 mm flat screw driver How to mount Place the front cover on its place, with the filter facing the projector. Image 8-6: Mount front cover Fasten the three captive screws (reference 1). Mount the lens again.

  • Page 85: Mounting The Left Cover

    Projector covers 8.6 Mounting the left cover Required tools 7 mm flat screw driver How to mount Place the cover on its place, with the grating of the filter facing the backside of the projector. Caution: Do NOT try to fasten the cover while holding it upside down (with the filter facing the front side).

  • Page 86: Mounting The

    Projector covers 8.7 Mounting the back cover Required tools 7 mm flat screw driver How to mount Place the back cover on the backside of the projector. Image 8-8: Mount back cover Fasten the three captive screws (reference 1). R5906113 /09...

  • Page 87: Mounting The Small Top Cover

    Projector covers 8.8 Mounting the small top cover Required tools 7 mm flat screw driver How to mount Slide the small top cover into the gapes of the large top cover (reference 1, Image 8-9). Image 8-9 Flip down the cover, so that the captive screws nicely fit the inserts (reference 2). Fasten the two captive screws (reference 1, Image 8-9).
  • Page 88 Projector covers R5906113 /09...

  • Page 89: A Dimensional Drawings

    Dimensional drawings Dimensions of the projector ......................90 Dimensions of the rigging frame.....................91 Dimensions of the flight case ......................92 R5906113 /09...

  • Page 90: Dimensions Of The Projector

    Dimensional drawings A.1 Dimensions of the projector Overview Image A-1: Dimensions, in mm Geometrical centre R5906113 /09...

  • Page 91: Dimensions Of The Rigging Frame

    Dimensional drawings A.2 Dimensions of the rigging frame Overview 1018,97 463,3 978,38 Image A-2: Dimensions, in mm R5906113 /09...

  • Page 92: Dimensions Of The Flight Case

    Dimensional drawings A.3 Dimensions of the flight case Overview 1133 Image A-3: Dimensions, in mm R5906113 /09...

  • Page 93: Glossary

    Glossary Hazard Distance (HD) is the distance measured from the projection lens at which the intensity or the energy per surface unit becomes lower than the applicable exposure limit on the cornea or on the skin. The light beam is considered (to be) unsafe for exposure if the distance from a person to the light source is less than the HD. Hazard Distance (HD) is the distance measured from the projection lens at which the intensity or the energy per surface unit becomes lower than the applicable exposure limit on the cornea or on the skin.
  • Page 94 Glossary R5906113 /09...

  • Page 95: Index

    Index Replace 64 Address Program RCU 51 Enclosed projection 19 Alignment Environment conditions 30 Rigging frame 55 Exclusion zone 10 Table mounted projector 54 Exterior Cleaning 63 Back cover Mount 86 Flight case 67–68 removal 82 Safety 14 Front cover Mount 84 Removal 80 CE Certification 21...
  • Page 96 Index Installation 56 Positioning 37 Removal 57 Power cable Install Connection 46 Options 27 power net Prepare 24 Connection 46 Procedures 43 Power requirements 31 Installation Prepare Lens 47 Intall 24 Installation preparations 29 Prevent Installation process 23, 25 Electrical shock 11 Installation requirements 30 Procedures Clean air 30...
  • Page 97 Index Projector damage 13 Safety Data Sheet (SDS) 14 Servicing 13 Safety Data Sheet (SDS) 14 Safety training 10 Configuratios 73–77 Use cases 73–77 Shift range 38 Skew 55 Small top cover Mount 87 Remove 83 Software update 58 Stacking 70 Table mounted projector Alignment 54 Tilt 55...
  • Page 98 Index R5906113 /09...

  • Page 99: List Of Tools

    List of tools List of tools 7 mm flat screw driver Clean cotton cloth Clean micro fiber lens cleaning cloth (e.g. Toraysee® cloth(s)) Compressed air cutter knife Lens cleaner (e.g. ZEISS lens cleaner, Purosol™ or other water based lens cleaner products) Phillips screwdriver PH1 Vacuum cleaner R5906113 /09...
  • Page 100 R5906113 /09 | 2020-02-21 Registered office: Barco NV | President Kennedypark 35, 8500 Kortrijk, Belgium Barco NV | Beneluxpark 21, 8500 Kortrijk, Belgium www.barco.com...
