  • Page 1 Installation manual ENABLING BRIGHT OUTCOMES...
  • Page 2 Barco NV Beneluxpark 21, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com Registered office: Barco NV President Kennedypark 35, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com...
  • Page 3 Barco. If the purchaser or a third party carries out modifications or repairs on goods delivered by Barco, or if the goods are handled incorrectly, in particular if the systems are operated incorrectly or if, after the transfer of risks, the goods are subject to influences not agreed upon in the contract, all guarantee claims of the purchaser will be rendered invalid.

  • Page 5: Table Of Contents

    Table of contents 1 Safety information....................................7 General Considerations .................................8 Important safety instructions..............................10 Product safety labels..................................14 High Brightness precautions: Hazard Distance ......................15 HD for fully enclosed projection systems...........................18 HD in function of modifying optics ............................19 Radio equipment (optional) ...............................20 Download Product Manual ................................21 2 Installation process....................................23 Preparation process ..................................24 Installation process ..................................25...
  • Page 6 4.10 Wall or ceiling mount without rigging frame........................56 4.11 Installation of an input board..............................57 4.12 Removal of an input board.................................58 4.13 Software update....................................59 5 Flight case and rigging frame ..............................61 Flight case......................................62 Rigging frame....................................63 6 Pulse SFP input use cases ................................65 Use case 1: SFP+ transceiver + Fiber connection (integrated or separated)..........66 Use case 2: Neutrik OpticalCon Duo + SFP+ transceiver + internal fiber............67 Use case 3: Neutrik OpticalCon Quad + SFP+ transceiver + internal fiber............68...

  • Page 7: Safety Information

    Ensure that you understand and follow all safety guidelines, safety instructions and warnings mentioned in this chapter before installing the UDM projector. Clarification of the term “UDM” used in this document When referring in this document to the term “UDM” means that the content is applicable for following Barco products: •...

  • Page 8: General Considerations

    • Before operating this equipment please read this manual thoroughly and retain it for future reference. • Installation and preliminary adjustments must be performed by qualified Barco personnel or by authorized Barco service dealers. • All warnings on the projector and in the documentation manuals must be adhered to.
  • Page 9 See the product safety manual for details. Users definition Throughout this manual, the term SERVICE PERSONNEL refers to Barco authorized persons having appropriate technical training and experience necessary to be knowledgeable of potential hazards to which they are exposed (including, but not limited to HIGH VOLTAGE ELECTRIC and ELECTRONIC CIRCUITRY and HIGH BRIGHTNESS PROJECTORS) in performing a task, and of measures to minimize the potential risk to themselves or other persons.

  • Page 10: Important Safety Instructions

    Safety information 1.2 Important safety instructions To prevent risk of electrical shock • This product should be operated from a mono phase AC power source. Ensure that the mains voltage and capacity matches the projector electrical ratings: 120-180V / 200-240V (+/-10%), 16A-12A, 50-60Hz. If you are unable to install the AC requirements, contact your electrician.
  • Page 11 • Max units in hanging configuration, 2 units. • When hanging projectors on a truss with the Barco stacking frame, always secure the stack with safety cables between the projectors and the truss. • When using the projector in a hanging configuration, always mount 2 safety cables. See installation manual for the correct use of these cables.
  • Page 12 For lens cleaning follow the instructions precisely as stipulated in the projector manual. • Only use zoom lenses of the Barco TLD+ series on the 4K models of the projector. Using other lenses will damage the internal optics. For suitable fixed TLD+ lenses contact Barco or see Barco website.
  • Page 13 • Remove all power from the projector and refer servicing to Barco authorized service personnel under the following conditions: When the power cord or plug is damaged or frayed.

  • Page 14: Product Safety Labels

    Safety information 1.3 Product safety labels Light beam related safety labels Label image Label description Label location Hazard RG3: not for household use symbol Hazard RG3: optical radiation warning symbol Hazard class 2: laser radiation warning symbol. 0.95 mW - 638 nm. WARNING! DO NOT LOOK INTO THE BEAM NO DIRECT EYE EXPOSURE TO THE PROJECTOR BEAM IS PERMITTED LASER RADIATION - DO NOT STARE INTO LASER RANGING BEAM RG3 IEC EN 62471-5:2015...

  • Page 15: High Brightness Precautions: Hazard Distance

    Safety information 1.4 High Brightness precautions: Hazard Distance Hazard Distance (HD) is the distance measured from the projection lens at which the intensity or the energy per surface unit becomes lower than the applicable exposure limit on the cornea or on the skin.
  • Page 16 The LIP shall be installed by Barco or by a trained and Barco-authorized installer or shall only be transferred to laser light show variance holders. This is applicable for dealers and distributors since they may need to install the LIP (demo install) and/or they transfer (sell, rent, lease) the LIP.
  • Page 17 Safety information In addition to temporary installations (e. g.: rental and staging, lease, events …) the following requirements apply: • Rental companies shall have a laser light show variance because they have direct relationship with the installers of the rented equipment. •...

  • Page 18: Hd For Fully Enclosed Projection Systems

    Safety information 1.5 HD for fully enclosed projection systems Hazard Distance (HD) is the distance measured from the projection lens at which the intensity or the energy per surface unit becomes lower than the applicable exposure limit on the cornea or on the skin.

  • Page 19: Hd In Function Of Modifying Optics

    Safety information 1.6 HD in function of modifying optics Hazard distance Throw Ra o (TR) Image 1-5 Hazard Distance Throw Ratio R5911438 /03...

  • Page 20: Radio Equipment (Optional)

    The UDM is restricted to indoor use only when operating in the 5150 to 5250 MHz frequency range. Hereby, Barco declares that the radio equipment type UDM is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.barco.com/support...

  • Page 21: Download Product Manual

    Safety information 1.8 Download Product Manual Download Product Manual Product manuals and documentation are available online at www.barco.com/td. Registration may be required; follow the instructions given on the website. IMPORTANT! Read Installation Instructions before connecting equipment to the mains power supply.
  • Page 22 Safety information R5911438 /03...

  • Page 23: Installation Process

    Installation process Preparation process........................24 Installation process ........................25 Additional install options........................27 About this chapter This chapter gives an overview of all the different stages in the installation process that has to be followed in chronological order to set the UDM projector up and running. The stages are grouped in three processes: Preparation, Installation and Options.

  • Page 24: Preparation Process

    Installation process 2.1 Preparation process Prepare for installation Ensure that you understand all safety topics described in the chapter “Safety information”, page 7. Check if all installation requirements are fulfilled such as: • the environmental conditions of the installation area, •...

  • Page 25: Installation Process

    Install the batteries of the Remote Control Unit (RCU). See chapter “Remote control, battery installation”, page Installation of the Projector Toolset on local laptop. Download and install the latest version from the Barco website. See chapter “Download Projector Toolset”, page 42.
  • Page 26 Installation process registration is completed. When the registration screen appears choose for REGISTER NOW and follow the on-screen instructions. Caution: The light source will remain off if not registered after 100 hours run time. Check for the latest projector software package. See chapter “Software update”, page 59. R5911438 /03...

  • Page 27: Additional Install Options

    Installation process 2.3 Additional install options Overview Installation of an optional input board (e.g. Quad DP 1.2 input or the SFP input ) or replacing an input board. • for removal see “Removal of an input board”, page 58. • for installation see “Installation of an input board”, page 57.
  • Page 28 Installation process R5911438 /03...

  • Page 29: Prepare To Install

    In addition, careful consideration of things such as image size, projector placement and type of screen to use are critical to the optimum use of this projection system. Barco provides a guarantee relating to manufacturing as part of the legally stipulated terms of guarantee. Observing the specification mentioned an this chapter is critical for the projector performance.

  • Page 30: Installation Requirements

    Prepare to install 3.1 Installation requirements Environment conditions Table below summarizes the physical environment in which the projector safely operates or can be stored. Operating Non-Operating Environment Ambient Temperature 0-1000 meter: 0°C (32°F) to 40°C (104°F) -15°C (5°F) to 60°C (140°F) (depends on altitude) 1000-3000 meter: 0°C (32°F) to 30°C (86°F) Humidity...
  • Page 31 Prepare to install Image 3-2: Airflow, hot air Since the projector is foreseen to be stacked while in the rigging frame, the minimum distance space around the top and bottom air inlets should be the distance between two stacked projectors while in the rigging frame.

  • Page 32: Unpacking The Projector

    Prepare to install 3.2 Unpacking the projector Unpacking process and handling The projector can be delivered in a cardboard box on a pallet or within a rigging frame inside a flight case. This chapter describes how to unpack the projector from the cardboard box. For how to handle the projector with rigging frame and flight case see “Flight case and rigging frame”, page 61.
  • Page 33 Prepare to install Image 3-4 Save the original shipping cardboard box and packing material. They will be necessary if you ever have to ship your projector. For maximum protection, repack your projector as it was originally packed at the factory. A plastic lens holder cover is placed into the lens opening of the projector.

  • Page 34: Initial Inspection

    This check should confirm that there are no broken knobs or connectors, that the cabinet and panel surfaces are free of dents and scratches, and that the operating panel is not scratched or cracked. The Barco Sales and Service office should be notified as soon as possible if this is not the case.

  • Page 35: Projector Orientations

    Prepare to install 3.4 Projector orientations Supported projector orientations The projector can be installed on a table or upside down on the ceiling and this in a front projection or rear projection configuration. Depending on the physical configuration of the projector the projected image has to be rotated and/or mirrored as well.
  • Page 36 Prepare to install Some lenses (e.g. UST lenses) may require that the projector orientation needs to be adapted for the desired outcome. R5911438 /03...

  • Page 37: Projector Positioning

    Prepare to install 3.5 Projector positioning Positioning the projector The projector should be installed at right angles (horizontally and vertically) to the screen at a distance PD. Note the distance (A) between lens centre and table surface is slightly variable. This distance (A) is nominal 223 mm in case all feet are turned in completely and the vertical lens shift is set to zero (0).

  • Page 38: Projector Shift And Tilt Range

    Prepare to install 3.6 Projector shift and tilt range Shift range The lens can be shifted with respect to the DMD (P) which result in a shifted image on the screen (Off-Axis). A 100% shift means that the centre point of the projected image is shifted by half the screen size. In other words, the centre point of the projected image falls together with the outline of the image in an On-Axis projection.

  • Page 39: Lens Selection

    How to select the right lens Determine the required screen width (SW). Determine the approximate position of the projector in the room. Start up the Lens Calculator on the Barco website: https://lenscalculator.barco.com/ to determine the possible lenses for your configuration.

  • Page 40: Available Lenses

    Prepare to install 3.8 Available lenses WARNING: Only use TLD+ ZOOM lenses on the 4k variants of the UDM projectors. Using other lenses can touch and damage the mechanics of the build-in Actuator! This can result in loud rattling noises and a damaged Actuator. Limited amount of available lenses The 4k variants of the UDM projectors have an Actuator built in them to help provide a clear 4K image.
  • Page 41 This table only takes into account active lenses at the moment of release of this manual. Lenses that have become end-of life or end-of service are not taken into account. Consult the Barco website for the most up-to-date information on active lenses.

  • Page 42: Download Projector Toolset

    3.9 Download Projector Toolset About Projector Toolset Projector Toolset is a software tool to set up, configure, manage and control Barco projectors. The Projector Toolset software works with configurations that can be loaded. Several configurations can be controlled simultaneously. Even when the configurations are connected via different ways.

  • Page 43: Installation Procedures

    Installation procedures Remote control, battery installation ....................44 Connecting the projector with the power net..................46 Lens installation..........................47 Lens removal ..........................49 Displaying and Programming addresses into the RCU..............51 Using the XLR connector of the RCU .....................52 Setting the projector addresses .....................53 Alignment of a table mounted projector...................54 Alignment of projector in the rigging frame ..................55 4.10 Wall or ceiling mount without rigging frame ..................56 4.11 Installation of an input board......................57...

  • Page 44: Remote Control, Battery Installation

    Installation procedures 4.1 Remote control, battery installation Where to find the batteries for the remote control ? The batteries are not placed in the remote control unit to avoid control operation in its package, resulting in a shorter battery life time. At delivery the batteries can be found in a separated bag attached to the remote control unit.
  • Page 45 Installation procedures CAUTION: Replace with the correct battery type. Use two AA size batteries. There is a risk of explosion if the battery is replaced with an incorrect type. R5911438 /03...

  • Page 46: Connecting The Projector With The Power Net

    Installation procedures 4.2 Connecting the projector with the power net CAUTION: Use only the power cord provided with the projector. WARNING: Do not attempt operation if the AC supply and cord are not within the specified voltage and power range. CAUTION: If the input voltage exceeds a defined limit, the “Overvoltage”...

  • Page 47: Lens Installation

    Installation procedures 4.3 Lens installation WARNING: Only use TLD+ ZOOM lenses. Using other lenses can touch and damage the mechanics of the build-in Actuator! This can result in loud rattling noises and a damaged Actuator. How to install Place the lens holder in the “unlocked” position. Do this by pulling the lens lock handle (reference 1, Image 4- 5) outward and then towards the lens power supply socket (reference 2) as illustrated.
  • Page 48 Installation procedures Image 4-7: Lens installation Insert the lens until the connector seats into the socket and de secondary lock (reference 3) makes an audible clicking sound. Warning: Do not release the lens yet, as the lens may fall out of the lens holder. Secure the lens in the lens holder by sliding the primary lens lock handle into the “locked”...

  • Page 49: Lens Removal

    Installation procedures 4.4 Lens removal How to remove Support the lens with one hand while you unlock the lens holder by sliding the primary lock handle outwards and then towards the “unlocked” position as illustrated (Image 4-9). Image 4-9: Unlock the lens Pull down the secondary lock on the lower left side of the lens holder as illustrated (Image 4-10).
  • Page 50 Installation procedures Image 4-11 R5911438 /03...

  • Page 51: Displaying And Programming Addresses Into The Rcu

    Installation procedures 4.5 Displaying and Programming addresses into the RCU Displaying the Projector Address on the Screen. If the projector is on, press the menu key and navigate to the Status page. The projector address and the broadcast address can be seen under the Communication heading. The projector's address is displayed on the LCD status screen and / or the OSD.

  • Page 52: Using The Xlr Connector Of The Rcu

    Installation procedures 4.6 Using the XLR connector of the RCU Connecting a cable with the XLR connector will reset the broadcast address of the RCU to its default value '0'. How to use the XLR connector Remove the XLR cover by pulling it backwards. Image 4-12 Connect a cable with XLR plug into the XLR connector of the RCU.

  • Page 53: Setting The Projector Addresses

    Installation procedures 4.7 Setting the projector addresses Projector address Address installed in the projector to be individually controlled via the RCU or via the serial communication. Broadcast address Projector will always execute the command coming from a RCU programmed with that broadcast address.

  • Page 54: Alignment Of A Table Mounted Projector

    Installation procedures 4.8 Alignment of a table mounted projector How to align Place the projector in the desired location. Take into account the zoom range of the used lens and the size of the screen. Project one of the internal hatch patterns on the screen. Turn the adjustable feet in or out until the projected hatch pattern has a perfect rectangle shape and is leveled.

  • Page 55: Alignment Of Projector In The Rigging Frame

    Installation procedures 4.9 Alignment of projector in the rigging frame Skew the projector horizontally Turn the skew knob at the rear to adjust the rotation. Image 4-15 Tilt the projector Turn the tilt adjustment knob at the rear to tilt the projector Image 4-16 Rotating the projector Turn the rotate adjustment knob on the right side to rotate the projector.

  • Page 56: Wall Or Ceiling Mount Without Rigging Frame

    Installation procedures 4.10 Wall or ceiling mount without rigging frame General In case of installing the projector to other positions than desktop or ceiling, it is preferred to use the rigging frame designed for this purpose. In cases where this is not possible, suitable 3rd part brackets for safe installation must be used to secure the unit from damage or causing injury.

  • Page 57: Installation Of An Input Board

    Installation procedures 4.11 Installation of an input board WARNING: The procedures below may only be performed by Barco trained and qualified technicians. CAUTION: Always wear a wrist band which is connected to the ground while handling the electrostatic discharge (ESD) sensitive parts.

  • Page 58: Removal Of An Input Board

    Installation procedures 4.12 Removal of an input board WARNING: The procedures below may only be performed by Barco trained and qualified technicians. CAUTION: Always wear a wrist band which is connected to the ground while handling the electrostatic discharge (ESD) sensitive parts.

  • Page 59: Software Update

    Download the latest firmware (format .fw) from Barco's website in the same way as for Projector Toolset. Start Projector Toolset and make a connection with the projector. For more information, see the “Projector Toolset”...
  • Page 60 Power on the projector. Wait until the Power on/off button is either lit white or blue. Download the latest firmware file ( format .fw) from Barco's website. The firmware can be downloaded for free from Barco's website, (URL: http://www.barco.com). Click on myBarco and log in to get access to secured information.

  • Page 61: Flight Case And Rigging Frame

    Flight case and rigging frame Flight case ...........................62 Rigging frame..........................63 About flight case and rigging frame The projector can also be delivered with rigging frame installed inside a flight case. R5911438 /03...

  • Page 62: Flight Case

    Flight case and rigging frame 5.1 Flight case Flight case The UDM flight case is designed to transport the UDM in a safe and secure manner, with or without being mounted in its rigging frame. There's also sufficient space in the flight case to place the projector while mounted in the UDM rigging frame.

  • Page 63: Rigging Frame

    56 Rigging frame The UDM series multifunctional rigging frame is designed for the Barco UDM projectors, and can not be used for other equipment. See rigging frame specific documentation for how to install the projector in to the frame.
  • Page 64 Flight case and rigging frame R5911438 /03...

  • Page 65: Pulse Sfp Input Use Cases

    Pulse SFP input use cases Use case 1: SFP+ transceiver + Fiber connection (integrated or separated) ........66 Use case 2: Neutrik OpticalCon Duo + SFP+ transceiver + internal fiber ...........67 Use case 3: Neutrik OpticalCon Quad + SFP+ transceiver + internal fiber .........68 Use case 4: Loop-through mode ....................69 About this chapter This chapter describes the several use cases of the SFP input.

  • Page 66: Use Case 1: Sfp+ Transceiver + Fiber Connection (Integrated Or Separated)

    SFP+ fiber transceiver Optional breakout Optical adapter Barco delivers only the SFP input and SFP+ fiber transceivers. The customer has to buy the SFP+ transceiver and the optional breakout adapter or the fiber integrated cable. How to configure the SFP input Remove the plate covering the access to the SFP cages.

  • Page 67: Use Case 2: Neutrik Opticalcon Duo + Sfp+ Transceiver + Internal Fiber

    Neutrik OpticalCon DUO Cable Internal fiber cable Barco delivers only the SFP input and SFP+ fiber transceivers. The customer has to buy the SFP+ transceiver and the optional breakout adapter or the fiber integrated cable. How to configure the SFP input Remove both plates covering the access to the Neutrik connector locations.

  • Page 68: Use Case 3: Neutrik Opticalcon Quad + Sfp+ Transceiver + Internal Fiber

    Advanced quad cable Internal fiber cable Barco delivers only the SFP input and SFP+ fiber transceivers. The customer has to buy the SFP+ transceiver and the optional breakout adapter or the fiber integrated cable. How to configure the SFP input Remove one plate covering the access to a Neutrik connector location.

  • Page 69: Use Case 4: Loop-Through Mode

    Neutrik OpticalCon Quad Advanced Quad cable Barco delivers only the SFP input and SFP+ fiber transceivers. The customer has to buy the SFP+ transceiver and the optional breakout adapter or the fiber integrated cable. How to configure the SFP input Remove both plates covering the access to a Neutrik connector locations.
  • Page 70 Pulse SFP input use cases R5911438 /03...

  • Page 71: Projector Covers

    WARNING: Switch off the projector and disconnect the power cord from the projector and wait a few minutes (to discharge the capacitors) prior to start with this procedure, unless otherwise specified in the procedure. WARNING: All procedures in this chapter must be performed by “Barco authorized service personnel”. R5911438 /03...

  • Page 72: Cover Locks

    Projector covers 7.1 Cover locks About All the covers are fastened with the same “easylock” tabs. Required tools Flat screwdriver 5 mm Unlocking Push down the inner side of the easylock with a screwdriver. Image 7-1 As a result the lock jumps loose. Locking Ensure that the cover is in the correct position.

  • Page 73: Removal Of The Front, Side And Rear Covers

    Projector covers 7.2 Removal of the front, side and rear covers About The method of removing the covers are equal for the front, side and rear covers. Remove the lens before removing the front cover. Required tools Flat screwdriver 5 mm How to remove the covers Remove the lens.

  • Page 74: Removal Of Top Cover

    Projector covers 7.3 Removal of top cover Required tools Torx screwdriver T20 How to remove the top cover. Release the 6 Torx screws indicated in the illustration. Image 7-7 Lift up the cover of the projector. R5911438 /03...

  • Page 75: Installing The Projector Covers

    Projector covers 7.4 Installing the projector covers CAUTION: Ensure that the top cover is reinstalled in the correct way. It is possible to turn the top cover 180 degrees horizontally, and it will still fit the attachment points. But then the air intake for the light processor fan will be out of position, and by that the cooling will not be sufficient.
  • Page 76 Projector covers R5911438 /03...

  • Page 77: A Dimensional Drawings

    Dimensional drawings Dimensions of the projector ......................78 Dimensions of the rigging frame.....................79 Dimensions of the flight case ......................80 R5911438 /03...

  • Page 78: Dimensions Of The Projector

    Dimensional drawings A.1 Dimensions of the projector Dimensional drawing 175,5 Image A-1: Dimensions are given in millimeters. R5911438 /03...

  • Page 79: Dimensions Of The Rigging Frame

    Dimensional drawings A.2 Dimensions of the rigging frame Dimensional drawing CC Rigging points (Overall dimension) Image A-2: Dimensions are given in millimeters. R5911438 /03...

  • Page 80: Dimensions Of The Flight Case

    Dimensional drawings A.3 Dimensions of the flight case Dimensional drawing 1043 Image A-3: Dimensions are given in millimeters. R5911438 /03...

  • Page 81: Glossary

    Glossary Hazard Distance (HD) is the distance measured from the projection lens at which the intensity or the energy per surface unit becomes lower than the applicable exposure limit on the cornea or on the skin. The light beam is considered (to be) unsafe for exposure if the distance from a person to the light source is less than the HD. Hazard Distance (HD) is the distance measured from the projection lens at which the intensity or the energy per surface unit becomes lower than the applicable exposure limit on the cornea or on the skin.
  • Page 82 Glossary R5911438 /03...

  • Page 83: Index

    Index Address Flight case 61 Program Weight 62 RCU 51 Front cover 73 Alignment Rigging frame 55 Table mounted projector 54 General Considerations 8 CE Certification 20 Connection Hazard Distance 15, 18 Power cable 46 Modifying optics 19 Power net 46 Hazardous Chemicals 13 Cooling liquid circuit warning 11 High Brightness precautions 15...
  • Page 84 Index Clean air 31 Projector Toolset 42 Environment conditions 30 Laser radiation 9 Address 51 Lens Battery Available 40 Installation 44 Installation 47 XLR 52 Removal 49 Rear cover 73 Lens installation 47 Rear projection 18 Lens removal 49 Removal Lens selection 39 Lens 49 Lenses...
  • Page 85 Index Warnings Cooling liquid circuit 11 Weight Flight case 62 Projector 31 Rigging frame 63 RCU 52 R5911438 /03...
  • Page 86 Index R5911438 /03...

  • Page 87: List Of Tools

    List of tools List of tools Cutter knife Flat screwdriver 5 mm Phillips screwdriver PH1 Torx screwdriver T20 R5911438 /03...
  • Page 88 R5911438 /03 | 2020-03-30 Barco NV | Beneluxpark 21, 8500 Kortrijk, Belgium Registered office: Barco NV | President Kennedypark 35, 8500 Kortrijk, Belgium www.barco.com...

This manual is also suitable for:

Udm 4k15Udm 4k22Udm w15Udm w19Udm w22
