DSP Configurator Inputs

All available inputs are listed vertically along the left side of the DSP Configurator main
workspace. The input groups can be expanded or collapsed by clicking the (expand) or
(collapse) buttons next to the input group names.
There are two types of inputs available:
•

Inputs

The 48 mic/line input channels on the XMP 240 are shown in DSP Configurator under the
Inputs panel.
Figure 25.
Inputs 1 - 24 offer AEC (Acoustic Echo Cancellation) DSP capability. Inputs 25 - 48 do not
have AEC. The 48 channels of Dante inputs and 16 channels of audio via the EXP port are
available as digital sources for the XMP 240 inputs.

Renaming an Input

NOTE: Renaming an AT input in DSP Configurator affects the receiver name in
Inputs
Inputs
Dante Controller. Alternatively, renaming a receiver channel in Dante Controller affects
the name displayed in DSP Configurator (see
on page 93).
• Virtual Returns
Renaming a Receiver or Transmitter
XMP 240 C AT • DSP Configurator Software 20
