Configuration — Ethernet Modules
Avaya Virtual Services Platform 9000
3.1
NN46250-508, 02.01
June 2011

Advertisement

Table of Contents
loading

Related Manuals for Avaya Virtual Services Platform 9000 Series

Summary of Contents for Avaya Virtual Services Platform 9000 Series

  • Page 1 Configuration — Ethernet Modules Avaya Virtual Services Platform 9000 NN46250-508, 02.01 June 2011...
  • Page 2 Product provided by Avaya including the selection, arrangement and While reasonable efforts have been made to ensure that the design of the content is owned either by Avaya or its licensors and is information in this document is complete and accurate at the time of protected by copyright and other intellectual property laws including the printing, Avaya assumes no liability for any errors.

  • Page 3: Table Of Contents

    Chapter 6: Port reference....................Chapter 7: Customer service..................... Getting technical documentation....................... 39 Getting product training..........................39 Getting help from a distributor or reseller....................39 Getting technical support from the Avaya Web site.................. 40 Index............................. Configuration — Ethernet Modules June 2011...
  • Page 4 Configuration — Ethernet Modules June 2011...

  • Page 5: Chapter 1: New In This Release

    Chapter 1: New in this release The following sections detail what's new in Avaya Virtual Services Platform 9000 Configuration — Ethernet Modules (NN46250–508) for Release 3.1. Features There are no feature-related changes. Other changes See the following section for information about changes that are not feature-related.
  • Page 6 New in this release Configuration — Ethernet Modules June 2011...

  • Page 7: Chapter 2: Introduction

    Chapter 2: Introduction Use this document to configure the Virtual Services Platform 9000 Ethernet modules. • Ethernet module fundamentals on page 9 • Ethernet module configuration using EDM on page 19 • Ethernet module configuration using ACLI on page 25 •...
  • Page 8 Introduction Configuration — Ethernet Modules June 2011...

  • Page 9: Chapter 3: Ethernet Module Fundamentals

    12 Port speed and duplex mode The Avaya Virtual Services Platform 9000 Ethernet modules support various data rates; these include 10 Mbit/s, 100 Mbit/s, 1000 Mbit/s, and 10 Gbit/s. Some modules support several data rates and use Autonegotiation to determine the appropriate data rate.
  • Page 10 Although all Virtual Services Platform 9000 1000BASE-T ports support Autonegotiation,there can be situations where Autonegotiation does not function properly,and a link remains down. If this situation occurs, Avaya recommends that you disable Autonegotiation and configure matching speed andduplex on both sides of the link (usually 10 Mbit/s and full-duplex).This Configuration —...
  • Page 11 Because RFI is part of the Autonegotiation function, if you disable Autonegotiation, you automatically disable RFI. Therefore, Avaya recommends that you enable Autonegotiation on Gigabit Ethernet links in all cases where the devices on both ends of a fiber link support Autonegotiation.

  • Page 12: Ethernet Module Features

    MLT and Link Aggregation Control Protocol groups port speed Avaya recommends that all ports that belong to the same MLT group or Link Aggregation Control Protocol (LACP) group use the same port speed, for example, 1 Gbit/s, even if you use Autonegotiation.
  • Page 13 Ethernet module features Module Module description connections. Refer to Avaya Virtual Services Platform 9000 Installation — SFP Hardware Components (NN46250–305) for a list of supported SFPs. 9048GT 48 port 10/100/1000 megabit per second (Mb/s) Ethernet Copper interface module with RJ45 connectors.
  • Page 14 Ethernet module fundamentals Model number Product number Description μm multimode fiber. Suited for campus LANs. 10GBASE-LR/LW AA1403011-E6 1310 nm SMF. The range is up to 10 km. 10GBASE-ER/EW AA1403013-E6 1550 nm SMF. The range is up to 40 km. 10GBASE-CX AA1403018-E6 to 4-pair twinaxial copper cable AA1403021-E6...
  • Page 15 The 9048GB interface module is a 48 port 1 Gb/s small form-factor pluggable (SFP) interface module that supports multimode fiber (MMF), single-mode fiber (SMF), and copper connections. The following table details the SFP connectors supported by the Avaya Virtual Services Platform 9000 Table 4: 9048GB compatible connectors...
  • Page 16 Ethernet module fundamentals Model ROHS product Description number AA1419061-E6 1470 nm, up to 70 km AA1419062-E6 1490 nm, up to 70 km AA1419063-E6 1510 nm, up to 70 km AA1419064-E6 1530 nm, up to 70 km AA1419065-E6 1550 nm, up to 70 km AA1419066-E6 1570 nm, up to 70 km AA1419067-E6...
  • Page 17 Ethernet module features Because you can change SFPs, inconsistencies can arise in the configuration file if you swap SFPs of different speeds. The port operates correctly after you change the SFP, but the configuration file can contain inappropriate Autonegotiation settings because of prior CLI actions.
  • Page 18 Ethernet module fundamentals Configuration — Ethernet Modules June 2011...

  • Page 19: Chapter 4: Ethernet Module Configuration Using Edm

    Chapter 4: Ethernet module configuration using EDM Configure an Ethernet port to ensure proper operation and optimum performance of the port. • Enabling a module on page 19 • Disabling a module on page 20 • Configuring an Ethernet port on page 21 •...

  • Page 20: Disabling A Module

    Ethernet module configuration using EDM Name Description CardAssemblyDate The assembly date of the card. CardHWConfig The card hardware configuration. AdminStatus The administrative status of the card. Use this field to enable, disable, or reset the card. OperStatus The current operational status of the card. ModuleType The module type.

  • Page 21: Configuring An Ethernet Port

    Configuring an Ethernet port Configuring an Ethernet port Prerequisites Important: You cannot configure Auto-Negotiation for 10 Gbit/s ports. Important: Ensure that all ports that belong to the same MLT or LACP group use the same port speed. Configure an Ethernet port so it operates optimally for your network. 1.
  • Page 22 Ethernet module configuration using EDM Name Description VendorDescr Displays the vendor of the connector plugged in the port. AdminStatus Configures the port as enabled (up) or disabled (down) or testing. OperStatus Displays the current status of the port. LastChange Displays the timestamp of the last change. LinkTrap Enable or disable link trapping.

  • Page 23: Associating A Port To A Vrf Instance

    Associating a port to a VRF instance Name Description OperRouting Displays the currently saved AdminRouting value. HighSecureEnable Enables or disables the high secure feature for this port. IngressRatePeak Configures the peak rate in Kb/s. IngressRateSvc Configures the service rate in Kb/s EgressRateLimitState Enables or disables egress port-based shaping to bind the maximum rate at which...
  • Page 24 Ethernet module configuration using EDM 5. To the right of the BrouterVrfId box, click the ellipsis (...) button. 6. In the BrouterVrfId dialog box, select the required VRF. 7. Click OK. 8. Click Apply. VRF field descriptions Use the data in the following table to use the VRF tab. Name Description VrfIds...

  • Page 25: Chapter 5: Ethernet Module Configuration Using Acli

    Chapter 5: Ethernet module configuration using ACLI Configure an Ethernet port to ensure proper operation and optimum performance of the port. • Enabling a module on page 25 • Disabling a module on page 26 • Configuring 10/100/1000 Mbit/s 9048GT Ethernet ports with Autonegotiation on page 26 •...

  • Page 26: Disabling A Module

    Ethernet module configuration using ACLI Disabling a module Prerequisites You must log on to the Global Configuration mode in ACLI. Disable an Ethernet module before you remove it from the chassis to minimize traffic loss. Traffic does not flow on a disabled module. Disable a module: slot shutdown {slot[-slot][,...]} Variable definitions...
  • Page 27 To use Custom Autonegotiation Advertisement (CANA), you must enable Autonegotiation. Important: Avaya recommends that all ports that belong to the same MLT or Link Aggregation Control Protocol (LACP) group use the same port speed. In the case of MLTs, the software does not enforce this.

  • Page 28: Configuring 9048Gt Ethernet Ports Without Autonegotiation

    Ethernet module configuration using ACLI Use the data in following table to use the auto-negotiation-advertisements command. Table 8: Variable definitions Variable Value [port {slot/port[-slot/port][,...]}] Specifies which port to configure the CANA advertisement settings of. You must enable Autonegotiation to use CANA. The default form of this command is default auto-negotiation- advertisements [port {slot/...

  • Page 29: Configuring 100/1000 Mbit/S 9048Gb Ethernet Ports

    Configuring 100/1000 Mbit/s 9048GB Ethernet ports Variable definitions Use the data in following table to use the duplex command. Table 9: Variable definitions Variable Value [port {slot/port[-slot/port][,...]}] Specifies which port to configure the duplex settings of. <half|full> Specifies half-duplex or full-duplex mode for 10/100/1000 Mbit/s ports;...
  • Page 30 Ethernet module configuration using ACLI 1. Enable Autonegotiation: auto-negotiate [port {slot/port[-slot/port][,...]}] enable 2. Enable flow control as required: tx-flow-control [port {slot/port[-slot/port][,...]}] enable 3. Optionally, create a name for the port or group of ports: name [port {slot/port[-slot/port][,...]}] WORD<0–42> 4. Optionally, disable the interface: shutdown [port {slot/port[-slot/port][,...]}] Variable definitions Use the data in the following table to use the auto-negotiate command.
  • Page 31 Configuring 100/1000 Mbit/s 9048GB Ethernet ports Table 13: Variable definitions Variable Value [port {slot[-slot][,...]}] Specifies the port or ports that you want to configure. The no form of this command is shutdown [port {slot[-slot] [,...]}] Use the data in the following table to use the tx-flow-control command. Table 14: Variable definitions Variable Value...

  • Page 32: Configuring 10 Gb/S 9024Xl Ethernet Ports

    Ethernet module configuration using ACLI Configuring 10 Gb/s 9024XL Ethernet ports Prerequisites You must log on to the Interface Configuration mode in ACLI. Important: You cannot configure Auto-Negotiation for 10 Gbit/s ports. Important: Ensure that all ports that belong to the same MLT or LACP group use the same port speed.

  • Page 33: Associating A Port To A Vrf Instance

    Associating a port to a VRF instance Prerequisites • The VRF instance must exist. For more information about the creation of VRFs, see Avaya Virtual Services Platform 9000 Configuration — IP Routing, NN46250-505. • You must log on to the Interface Configuration mode in ACLI.
  • Page 34 Ethernet module configuration using ACLI Table 16: Variable definitions Variable Value <WORD 0-16> Configures the VRF name. Configuration — Ethernet Modules June 2011...

  • Page 35: Chapter 6: Port Reference

    For more information about other port-related parameters, see the documents referenced in the following table. Table 17: Documentation references For more information about access-diffserv Avaya Virtual Services Platform 9000 Configuration — QoS and ACL-Based Filtering, NN46250-502 action Avaya Virtual Services Platform 9000 Configuration — IP Routing, NN46250-505 and Avaya Virtual Services Platform 9000 Configuration —...
  • Page 36 Avaya Virtual Services Platform 9000 Administration, NN46250-600 high-secure Avaya Virtual Services Platform 9000 Security, NN46250-601 Avaya Virtual Services Platform 9000 Configuration — IP Routing, NN46250-505 ipv6 Avaya Virtual Services Platform 9000 Configuration — IP Routing, NN46250-505 lacp Avaya Virtual Services Platform 9000 Configuration —...
  • Page 37 For more information about tagged-frames-discard Avaya Virtual Services Platform 9000 Configuration — VLANs and Spanning Tree, NN46250-500 untagged-frames-discard Avaya Virtual Services Platform 9000 Configuration — VLANs and Spanning Tree, NN46250-500 vlacp Avaya Virtual Services Platform 9000 Configuration — Link Aggregation, MLT, and SMLT, NN46250-503 Avaya Virtual Services Platform 9000 Configuration —...
  • Page 38 Port reference Configuration — Ethernet Modules June 2011...

  • Page 39: Chapter 7: Customer Service

    Chapter 7: Customer service Visit the Avaya Web site to access the complete range of services and support that Avaya provides. Go www.avaya.com or go to one of the pages listed in the following sections. Navigation • Getting technical documentation on page 39 •...

  • Page 40: Getting Technical Support From The Avaya Web Site

    Customer service Getting technical support from the Avaya Web site The easiest and most effective way to get technical support for Avaya products is from the Avaya Technical Support Web site at www.avaya.com/support. Configuration — Ethernet Modules June 2011...
