Only allow the device to be refilled by individuals who are familiar with the
safety instructions and who you have trained on its operation.
The ebios-fire is not a heater but a decorative fire.
Bioethanol is a dangerous substance and must only be stored in the pre-
scribed quantities as per the regulations:
Storage in a cellar: max. 20 litres
Storage in living space: max. 5 litres

1.1 SCOPE OF DELIVERY

ebios-fire with the following features:
• Standing or suspended fireplace
• 1 burner made of stainless steel
• 1 burner mat made of Ceramat FN
• Safety container for all burner types made of stainless steel
• Cover plate (with recess for grip stick) made of stainless steel
• Bottle for moistening the burner mat
• Tank lock with seal
• Fill level indicator
• Wrench for opening and closing the tank lock
• Cold hand for lifting off and setting down the cover plate.
• Funnel for filling the burner
• Stick lighter
• Rating plate
• Ethanol 5L canister with outlet valve for initial commissioning
(only within Germany)
• Supplied pre-assembled in transport-friendly disposable cardboard
packaging
Item Designation
A Cover plate
B Fill level indicator
C Filling opening
D Burner channel
E Safety container
F Tank

2. INSTALLATION INSTRUCTIONS

The device must not be able to tilt and must be positioned horizontally.
Secure the wall-mounted models and floor-mounted models on the wall or
floor. This is in the interest of your own safety.
GB 5
GB
Fig.1
