- Page 1 Installation and Operating Manual Nova E H...
- Page 2 PREFACE – QUALITY PHILOSOPHY You have decided in favor of SPARTHERM fireplace inserts. Thank you very much for your trust in our company. In a world of excess and mass production, our company stands for the values expressed by our owner, Mr. Gerhard Manfred Rokossa: „High technical quality combined with contemporary design, and service to the...
-
Page 3: Table Of Contents
CONTENT 1. General instructions 5. Cleaning and maintenance 1.1 Scope of delivery 5.1 Cleaning the heat exchanger 1.2 Technical data 5.2 Cleaning the double glazing 5.3 Maintenance of the heat exchanger 2. Installation 2.1 Basic requirement imposed on setup 6. Advisor 2.2 Electrical connection 2.4 Minimum cross sections - convection air 7. -
Page 4: General Instructions
The fireplace can be operated manually or with suitable combustion controllers and appropriate settings. If necessary, consult with OUR HEATING INSERT HAS BEEN TESTED IN ACCORDANCE WITH Spartherm Feuerungstechnik GmbH in this regard. DIN EN 13229 AND SATISFIES THE REQUIREMENTS STIPULATED IN THE CONSTRUCTION PRODUCTS DIRECTIVE. (DECLARATION 1.1 SCOPE OF DELIVERY... -
Page 5: Technical Data
1.2 TECHNICAL DATA The thermal discharge safety device integrated in the heating system will open the cold water inlet at a boiler temperature of approx. 95°C! * The specified values represent the mean value over a combustion. These Nova E H values occur under test conditions, if in 70 min a quantity of approx. - Page 6 Fig. 1a Fig. 1b Nova E H O with wall-penetrating element Nova E H O with frame for front panels GB 6...
- Page 7 Fig. 1c Front panels The thicknesses of thermal insulation material are determined with open air grates in the heating chamber, in accordance with DIN EN 13229. If a closed heating chamber should be created, the thermal insulation material thicknesses must be increased in the verification procedure. Fig.
-
Page 8: Installation
2. INSTALLATION The installation of the water-bearing components, the necessary safety devices, etc. must always be executed by a specialised company. The Nova O must be installed in such a manner that all components, including those that are behind the cladding, are accessible and can be checked at all times! After setup, connection and filling of all installations, and prior to producing the heating chamber (enclosing brick work), the fireplace insert, as well as the associated heating installations, must be checked for leaks... -
Page 9: Electrical Connection
2.2 ELECTRICAL CONNECTION (DIN, DIN EN, state construction ordinances, firing ordinances, etc.) must be complied with and applied! The entire electrical installation of the individual components of the heating HeizAnlV: Heating Systems Ordinance system must only be executed by an authorised specialised company. In this FeuVo: (Firing Installation Ordinance) of the respective regard, all tasks must be executed in accordance with the VDE regulations... - Page 10 Fig. 2a Rear view Front view Ventilation possibility with manual exhauster Immersion sleeve for thermal discharge safety device and pump thermostat Flow connection 1" internal thread Discharge for safety heat exchanger Return connection 1" internal thread Inlet for safety heat exchanger Separate combustion air duct Ø150 Emptying connection ½"...
-
Page 11: Minimum Cross Sections - Convection Air
2.4 MINIMUM CROSS SECTIONS - CONVECTION AIR Return 1" internal thread Inlet for safety heat exchanger ½" external thread The minimum cross sections for convection air (supply air and recirculating Flow 1" internal thread air) for the heating insert with metallic coasting temperature box in the Discharge for safety heat exchanger ½"... -
Page 12: Return Flow Temperature Boost
2.8 THERMAL DISCHARGE SAFET Y DEVICE A separate safety valve must also be installed, if such a safety valve is installed at a different point in the entire system (comply with TRD 721!) As the heating of the Nova E H O is not automatic, nor can it be quickly 2.7 RETURN FLOW TEMPERATURE BOOST shut-off, the hot water insert must be equipped with a thermal discharge... -
Page 13: Thermal Pump Controller
• Minimum water throughput of approx. 900 kg/h must be ensured. It must Electrical connection of the thermostat pump controller not be possible to shut off this supply line! Thermostat as pump controller (e.g. Afriso) with approx. 3.0 m connecting line 2 x 0.75 mm •... -
Page 14: Integration In A Heating System
controller is approximately 500 W at alternating current AC 230. among other things. The factory settings of the thermostat have been pre-set to approximately The following sample calculation can be helpful for dimensioning the buffer 62°C. With this pre-set, the switch-on temperature and switch-off tank: temperature of the circulation pump of the return flow boost are defined The following assumptions have been made in this regard:... -
Page 15: Chimney Connection / Connecting Pieces
2.11 CHIMNEY CONNECTION / CONNECTING PIECES For installation, removal of the front combustion chamber chamotte (cha- motte brick no.: 7 and 8 Fig. 4) and of the combustion chamber floor are The Nova E H O is connected to the chimney with the connecting pieces necessary. -
Page 16: Changing The Door Stop
2.13 CHANGING THE DOOR STOP If the door stop is to be changed, this is also possible after the overall system has been completed. For this, a new door must be ordered with specification of the order number, which then can be replaced thanks to the universal frame. -
Page 17: Combustion Chamber Lining
2.14 COMBUSTION CHAMBER LINING Chamotte bricks: Order number: 10 12 861 Installation of the combustion chamber lining 2a, 2b, 2c 10 12 870 The individual chamotte bricks of the combustion chamber lining must be 10 12 867 installed as numbered, starting with number (1). The rear wall chamotte 10 12 869 bricks (2a to 2c) have the same dimensions so that they do not need to be 10 12 866... -
Page 18: Initial Commissioning
The slot that occurs between the steel The initial commissioning must only be executed after all necessary body and the baffle plate is a measure components are connected and all necessary safety devices are integrated for reducing the smoke that escapes and functional. -
Page 19: Cleaning And Maintenance
• The fireplace insert locking door must always be operated with a - Combustion must be operated with a closed door. self-closing door. This means that the combustion chamber door is gen- - Chimney draught: 12 Pa erally closed. The door may only be opened to put on more firewood or - Wood: Dry beech wood (moisture <... -
Page 20: Cleaning The Heat Exchanger
5.1 CLEANING THE HEAT EXCHANGER and place on the supports). Then slide in the turbulators (these do not require a specific direction) and insert the flame baffle plates in such a The heat exchanger can only function at full efficiency if it is regularly manner that the flue gas gap is on the rear of the device. -
Page 21: Maintenance Of The Heat Exchanger
5.3 MAINTENANCE OF THE HEAT EXCHANGER Problem description Solution Thermal discharge safety device - The buffer tank is „full“. Withdraw heat from the tank. trips constantly (constant water - Check function and settings of the pump thermostat and the At regular intervals during the heating season, the water pressure of the outflow through the discharge). -
Page 22: General Warranty Terms And Conditions
Setting up or installing this product requires specialized knowl- edge. Our products may therefore only be installed and commissioned by If such proof is not produced Spartherm Feuerungstechnik GmbH shall not specialized firms and in compliance with statutory regulations as amended. -
Page 23: Defect Remediation/Repairs
• Improper handling of fragile components such as glass and ceramics Damage and compensation claims not based on a defective unit supplied • Improper handling and/or use by Spartherm Feuerungstechnik GmbH are excluded and are not covered by • Lack of maintenance the warranty undertaking. -
Page 24: Commissioning Protocol
8. COMMISSIONING PROTOCOL Device no.: Date: see rating plate) Name and address of fireplace operator Name and address of heating system installation company: Name and address of stove fitter: Heating system ventilated: Has the actual delivery pressure been checked? Negative pressures greater than 20-25 Pa can influence correct operation. - Page 25 NOTES GB 25...
- Page 26 NOTES GB 26...
- Page 27 GB 27...
- Page 28 IT Il vostro rivenditore specializzato | E Sus comercios especializados NL Uw vakhandelaar | PL Państwa sprzedawca | РУС Ваш дилер Spartherm Feuerungstechnik GmbH · Maschweg 38 · D-49324 Melle Phone +49 (0) 5422 94 41-0 · Fax +49 (0) 5422 9441-14 · www.spartherm.com GB 28...
