LCD MONITOR
OPERATION MANUAL

Advertisement

Table of Contents
loading

Summary of Contents for Sharp PN-HM851

  • Page 1 PN-HM851 PN-HM751 PN-HM651 PN-HB851 PN-HB751 PN-HB651 LCD MONITOR OPERATION MANUAL...
  • Page 2 IMPORTANT: Model No.: To aid reporting in case of loss or theft, please record the product’s model and serial numbers in the space provided. The numbers are located in the rear of the product. Serial No.: U.S.A. ONLY...
  • Page 3: Important Information

    IMPORTANT INFORMATION WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. The lightning flash with arrowhead symbol, within a triangle, is intended to alert the user to the CAUTION presence of uninsulated “dangerous voltage” RISK OF ELECTRIC within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric...
  • Page 4: Dear Sharp Customer

    DEAR SHARP CUSTOMER Thank you for your purchase of a SHARP LCD product. To ensure safety and many years of trouble-free operation of your product, please read the Safety Precautions carefully before using this product. SAFETY PRECAUTIONS Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled.
  • Page 5 SAFETY PRECAUTIONS (Continued) 19. Batteries — Incorrect use of batteries may cause the batteries to burst or ignite. A leaky battery may corrode the equipment, dirty your hands or spoil your clothing. In order to avoid these problems, make sure to observe the precautions below: • Use the specified batteries only.
  • Page 6: Tips And Safety Instructions

    - Never rub or tap the monitor with hard objects. The Power Cord - Please understand that SHARP CORPORATION bears no - Use only the power cord supplied with the monitor. responsibility for errors made during use by the customer or...
  • Page 7: Mounting Precautions

    • Mounting the monitor on the wall requires special expertise the bottom side. and the work must be performed by an authorized SHARP - Set the PORTRAIT/LANDSCAPE INSTALL in the dealer. You should never attempt to perform any of this work MONITOR menu to PORTRAIT.
  • Page 8: Table Of Contents

     USB flash drive / SD card cover fixing screw: 1  Wireless LAN antenna: 2 * SHARP Corporation holds authorship rights to the Utility Disk program. Do not reproduce it without permission. * For environmental protection! Do not dispose of batteries in household waste. Follow the disposal instructions for your area.
  • Page 9: Part Names

    Offering this attachment location 12. USB port (USB 3.0 compliant) (See page 12.) is not a guarantee that future compatible hardware 13. USB port (USB 2.0 compliant) (See page 12.) attachments will be released. 24. Vents 25. Handles Caution • Consult your SHARP dealer for attachment/detachment of optional parts.
  • Page 10 Part Names nRemote control unit 1. Signal transmitter 2. Operation buttons (See page 20.)
  • Page 11: Connecting Peripheral Equipment

    Connecting Peripheral Equipment 1. HDMI1 input terminal Caution 2. HDMI2 input terminal • Be sure to turn off the main power switch and disconnect • Use a commercially available HDMI cable (conforming to the plug from the power outlet before connecting/ the HDMI standard) that supports 4K. disconnecting cables. Also, read the manual of the • Select the audio input terminal to be used in AUDIO equipment to be connected.
  • Page 12 Connecting Peripheral Equipment 8. DisplayPort output terminal • The screen displayed on this monitor and the audio output from this monitor can be output to an external device. • Use a commercially available DisplayPort cable (conforming to the DisplayPort standard) that supports • Outputting HDCP-encrypted video requires an external device which supports HDCP. • This terminal can be used to make a daisy chain connection* by connecting same series monitors to each other through the DisplayPort input terminal of each monitor.
  • Page 13: Connecting The Power Cord

    Connecting the Power Cord Caution • Use only the power cord supplied with the monitor. 1. Turn off the main power switch. 2. Plug the power cord (supplied) into the AC input terminal. 3. Plug the power cord (supplied) into the power outlet. Main power AC input switch terminal Power cord (Supplied) For power...
  • Page 14: Removing The Handles

    Removing the Handles The handles can be removed. Caution • The removable handles and handle screws are for use with this monitor. Do not use them for any other devices. Handle • To attach handles, be sure to use the handles and handle screws which were removed from this monitor. • Be sure the handles are attached securely. Handle screws Attaching the logo sticker You can attach the supplied logo sticker on this monitor. Refer to the following example to attach the sticker as necessary.
  • Page 15: Attaching The Usb Flash Drive / Sd Card Cover

    Attaching the USB flash drive / SD card cover 1. Attach the USB flash drive / SD card cover (supplied) TIPS to this monitor. • If the cover will be attached, use a USB flash drive no USB flash drive / SD card cover (supplied) larger than 2-3/4 inch (70 mm) (L) (excluding the terminal) x 11/16 inch (17 mm) (W) x 5/16 inch (8 mm) (H).
  • Page 16: Preparing The Remote Control Unit

    Preparing the Remote Control Unit Installing the batteries 1. Place your finger on the part marked with the ▲, and then pull the cover off. 2. See the instructions in the compartment and put in the supplied batteries (R03 (“AAA” size) x 2) with their plus (+) and minus (-) sides oriented correctly.
  • Page 17 Preparing the Remote Control Unit Remote control sensor out Point the remote control unit toward the remote control sensor on the front of the monitor. For the monitor in landscape orientation For the monitor in portrait orientation 16.4 feet Remote control 16.4 feet (5m) sensor...
  • Page 18: Turning Power On/Off

    Turning Power On/Off Turning power on/off Caution • Turn on the monitor first before turning on the computer or Press the POWER button to turn the power ON/OFF. playback device. You can also turn the power ON/OFF by pressing the • When switching the main power switch or the POWER MONITOR ON button/MONITOR OFF button on the remote button off and back on, always wait for at least 5 seconds.
  • Page 19: Disabling Power On/Off Operations

    Turning Power On/Off nOperations after first power-on 7. Select “Launcher:SHARP Open Architecture Platform”. Set POWER SAVE MODE When the monitor is turned on for the first time after being shipped from the factory, the power save mode setting screen will be displayed. Set it to YES or NO.
  • Page 20: Basic Operation

    Basic Operation 5. VOLUME +/- (Volume adjustment) Pressing + or - displays the VOLUME menu. V O L U M E Press + or - to adjust the volume. * If you do not press any buttons for about 4 seconds, the VOLUME menu automatically disappears. 6. INFORMATION Displays monitor information. INFORMATION1 01/01/2019 TUE 12:00:00 AM INPUT MODE HDMI1 SIZE...
  • Page 21 Basic Operation 9. FREEZE 16. BRIGHT +/- (Brightness adjustment) Freezes the video shown on the monitor. Pressing + or - displays the BRIGHT menu. To cancel, press any button other than the POWER button, B R I G H T MUTE button or VOLUME button. Freeze is also canceled when the input signal changes Press + or - to adjust the brightness.
  • Page 22 Basic Operation nSwitching the screen size Even when the screen size is changed, the display may remain the same depending on the input signal. WIDE Displays image so it fills the entire screen. ZOOM The image is enlarged to fill the entire screen without changing the aspect ratio. The edges of the image may be cut off.
  • Page 23: Menu Items

    Menu Items Displaying the menu screen 4. Press the button to adjust the setting. SCREEN PICTURE D-SUB Video and audio adjustment and settings of various functions PICTURE BRIGHT are enabled. This section describes how to use the menu CONTRAST AUDIO items.
  • Page 24: Menu Item Details

    Menu Items Menu item details The menu will differ depending on the input mode. nSCREEN You can move the menu screen display position each time the INFORMATION button is pressed. AUTO (D-SUB) The CLOCK, PHASE, H-POS, and V-POS are automatically adjusted. Pressing the ENTER button performs adjustment.
  • Page 25 Menu Items nPICTURE You can move the menu screen display position each time the INFORMATION button is pressed. BRIGHT Adjusts the backlight brightness. CONTRAST Adjusts the difference between the bright and dark portions of the image. BLACK LEVEL Adjusts the entire brightness of the video signals. TINT Adjusts the hue. Selecting + changes the color towards green, and selecting - changes it towards magenta.
  • Page 26 Menu Items ADVANCED AUTO (D-SUB) The ANALOG GAIN and ANALOG OFFSET are automatically adjusted. Pressing the ENTER button performs adjustment. ANALOG GAIN (D-SUB) Adjusts the bright portions of the video input signal. ANALOG OFFSET (D-SUB) Adjusts the dark portions of the video input signal. Reduce the image noise.
  • Page 27 Menu Items nSETUP DATE/TIME SETTING Display the date and time. When select SET, input mode change to APPLICATION, and you can set the date and time. When APPLICATION is set to DISABLE, SET does not appear. Set in the displayed screen. TIME FORMAT (when APPLICATION is ENABLE) Set the time display format.
  • Page 28 Menu Items AUDIO OPTION AUDIO OUTPUT Sets the volume of sound output from the audio output terminal. VARIABLE1 ..You can adjust the volume from the speakers of this monitor and the audio output terminal simultaneously by using VOLUME. VARIABLE2 ..You can adjust the volume from the audio output terminal by using VOLUME. Sound will not be output from the speakers of this monitor.
  • Page 29 Menu Items POWER SAVE MODE When OFF is selected, startup time from standby mode is reduced. Note, however, that more power will be consumed in standby mode. Android continues to run in standby mode. When ON is selected, current consumption is reduced while the monitor is in standby mode. Android is also shut down. Note, however, that the startup time from standby mode becomes longer.
  • Page 30 Menu Items PIP/PbyP PIP MODES Sets the display method. OFF ..Displays one screen. PIP ..Displays a sub screen inside a main screen. PbyP ..Displays a main screen and a sub screen in a line. PbyP2..Displays a main screen which measures 2560 pixels in the longest direction and a sub screen in a line. PIP SIZE Sets the size of the sub screen in PIP mode.
  • Page 31 Menu Items nOTHERS POWER MANAGEMENT POWER MANAGEMENT determines whether or not to switch modes from no signal to the input signal waiting mode. CONNECT AUTO INPUT SELECT Sets whether the input into the input terminal automatically changes when a video signal is input into that terminal. The input via the expansion slot is ignored.
  • Page 32 Menu Items nDual-screen display nQuad-screen display You can display two screens simultaneously. You can display 4 screens simultaneously. Set this function with PIP MODES of PIP/PbyP in the MULTI/ Landscape orientation Portrait orientation PIP menu. Or, press the PIP/PbyP button, and select the mode. Position 1 Position 2 (1920×1080)
  • Page 33 Menu Items nEnlarge TIPS • You can align several monitors and integrate them into a • You might infringe on a copyright of the author which is single large screen to display. protected by copyright law when you display the images of the computer screen and television/VCR simultaneously for • Up to 5 monitors can be aligned in both the horizontal and profit-making or to show the image to the public. vertical directions.
  • Page 34 Menu Items nSCHEDULE (6) BRIGHT Sets the brightness when changing the screen brightness at You can set the time to switch the monitor on and off. a specified time. Set this function with SCHEDULE in the SETUP menu. (See page 27.) Caution D-SUB SCHEDULE...
  • Page 35: Adjustments For Computer Screen Display

    Menu Items nAbout remote control numbers Adjustments for computer screen display If there is another monitor nearby, you can change the remote nAutomatic adjustment control number to prevent the other monitor from being operated by the remote control unit. When you use the D-SUB to display a computer screen for the Set the same number in the monitor and in the remote control first time, or when you change the setting of the computer, use unit.
  • Page 36: Initialization (Reset)/Functional Restriction Setting (Function)

    Initialization (Reset)/Functional Restriction Setting (FUNCTION) You can reset the settings to the factory default settings or RS-232C/LAN restrict operations. Specifies whether to allow control via RS-232C or LAN. (See pages 38 and 49.) 1. Press the FUNCTION button, and then press the MENU OSD DISPLAY button within 10 seconds.
  • Page 37 Initialization (Reset)/Functional Restriction Setting (FUNCTION) APPLICATION Set whether or not APPLICATION mode is used. DISABLE ..Do not use APPLICATION mode. The input mode cannot be changed to APPLICATION. ENABLE ..Use APPLICATION mode. APPLICATION RECOVERY MODE Before selecting this item, connect a commercially available USB keyboard to the USB port.
  • Page 38: Controlling The Monitor With A Computer (Rs-232C)

    Controlling the Monitor with a computer (RS-232C) Communication conditions You can control this monitor from a computer via RS-232C (COM port) on the computer. You can also connect multiple monitors via a daisy chain by Set the RS-232C communication settings on the computer to using a computer.
  • Page 39 Controlling the Monitor with a computer (RS-232C) nResponse code format nCommunication interval When a command has been executed correctly • After OK or ERR is returned, you must send the following commands. Return code To set a timeout for the command response, specify 10 , 0A seconds or longer. A response is returned after a command is executed. When connecting multiple monitors in a daisy chain, set the timeout to at least the product of the monitor’s position from * If an ID number has been assigned...
  • Page 40 Controlling the Monitor with a computer (RS-232C) nCommands for ID control IDLK ..The parameter of this command sets the ID number of the monitor. The monitor is subject to all The command examples shown on this page assume the subsequent commands. following connection and ID number set up.
  • Page 41 Controlling the Monitor with a computer (RS-232C) nRepeater control This system has a function to allow setting of multiple monitors connected in a daisy chain using a single command. This function is called repeater control. You can use Repeater control function without assigning ID numbers. [Example] Set 1 Set 2...
  • Page 42: Rs-232C Command Table

    Controlling the Monitor with a computer (RS-232C) RS-232C command table How to read the command table Command: Command field (See page 38.) Direction: W When the “Parameter” is set in the parameter field (see page 38), the command functions as described under “Control/Response Contents”.
  • Page 43 Controlling the Monitor with a computer (RS-232C) PICTURE menu Function Command Direction Parameter Reply Control/Response contents BRIGHT VLMP 0-31 0-31 CONTRAST CONT 0-60 0-60 BLACK LEVEL BLVL 0-60 0-60 TINT TINT 0-60 0-60 COLORS COLR 0-60 0-60 SHARPNESS SHRP 0-24 0-24 COLOR COLOR MODE...
  • Page 44 Controlling the Monitor with a computer (RS-232C) AUDIO menu Function Command Direction Parameter Reply Control/Response contents TREBLE AUTR -5-5 -5-5 ○ BASS AUBS -5-5 -5-5 BALANCE AUBL -10-10 -10-10 RESET ARST SETUP menu Function Command Direction Parameter Reply Control/Response contents DATE/TIME SETTING DATE AABBCCDDEE AABBCCDDEE AA: Year, BB: Month, CC: Day, DD: Hour, EE: Minute...
  • Page 45 Controlling the Monitor with a computer (RS-232C) Function Command Direction Parameter Reply Control/Response contents COMMUNICATION MONITOR CONTROL CTLS 0-2 0: RS-232C, 1: LAN, 2: APPLICATION ● SETTING SELECT BAUD RATE BAUD 0-2 0: 9600bps, 1: 19200bps, 2: 38400bps ID SETTING ID No.
  • Page 46 Controlling the Monitor with a computer (RS-232C) MULTI/PIP menu Function Command Direction Parameter Reply Control/Response contents ENLARGE ENLG 0-1 0: OFF, 1: ON Enlarge mode EMAG 1-4 1: 2 x 2, 2: 3 x 3, 3: 4 x 4, 4: 5 x 5 EMHV 12(21)-55 11-55 1 x 2 (2 x 1) to 5 x 5 (“m x n”...
  • Page 47 Controlling the Monitor with a computer (RS-232C) Function Command Direction Parameter Reply Control/Response contents PIP MODES MWIN 0-3 0: OFF, 1: PIP, 2: PbyP, 3: PbyP2 PIP SIZE MPSZ 1-64 1-64 PIP POS ThE lONgEST DIREcTION MhPS 0-100 0-100 ThE ShORTEST DIREcTION MVPS 0-100 0-100...
  • Page 48 Controlling the Monitor with a computer (RS-232C) Initialization/Functional Restriction Setting (FUNCTION) menu Function Command Direction Parameter Reply Control/Response contents ALL RESET RSET 0: ALL RESET 1, 1: ALL RESET 2 ● ADJUSTMENT LOCK ALCK 0 OFF ○ 1: ON 1, 2: ON 2 ●...
  • Page 49: Controlling The Monitor With A Computer (Lan)

    Controlling the Monitor with a computer (LAN) Command-based control Your monitor can be connected to a LAN allowing you to control it from a computer on the LAN. The connection requires a commercially available LAN cable You can control the monitor using RS-232C commands (UTP cable, Category 5, straight through).
  • Page 50: Troubleshooting

    “STATUS [xxxx]” appears in the corner of the screen. • Are audio cables connected properly? • Is the setting of AUDIO SELECT on the SETUP menu • Hardware has a problem. Turn off the monitor and request correct? repair from your SHARP dealer. (When STATUS ALERT is set to OSD & LED. This varies Unstable video. depending on the setting.) • The signal may be incompatible.
  • Page 51 Internal temperature rises quickly if the vents on the monitor are blocked. - Internal temperature rises quickly if dust accumulates inside the monitor or around the vents. Remove dust if possible. Ask SHARP dealer about removing internal dust.
  • Page 52: Specifications

    Specifications nCompatible signal timing (PC) Digital Analog Screen resolution Vsync (D-sub) HDMI DisplayPort VESA 640 × 480 60Hz 72Hz 75Hz 800 × 600 56Hz 60Hz 72Hz 75Hz 848 × 480 60Hz 1024 × 768 60Hz 70Hz 75Hz 1152 × 864 75Hz 1280 ×...
  • Page 53 Specifications nCompatible signal timing (AV) Screen resolution Frequency HDMI 4096 × 2160p 24Hz 25Hz Yes* 30Hz Yes* 50Hz 59.94Hz 60Hz 3840 × 2160p 24Hz 25Hz 30Hz 50Hz 59.94Hz 60Hz 1920 × 1080p 24Hz 50Hz 59.94Hz 60Hz 1920 × 1080i 50Hz 59.94Hz 60Hz 1280 ×...
  • Page 54 Specifications nChannels that can be used in wireless LAN Frequency band Standard Channel (center frequency) IEEE802.11b/g/n 1-13ch 2412-2472MHz IEEE802.11ac/a/n 36/40/44/48/52/56/60/64ch 5180-5320MHz 100/104/108/112/116/120/124/128/132/136/140ch 5500-5700MHz 149/153/157/161/165ch 5745-5825MHz CANADA IEEE802.11b/g/n 1-11ch 2412-2462MHz MEXICO IEEE802.11ac/a/n 36/40/44/48/52/56/60/64ch 5180-5320MHz 100/104/108/112/116ch 5500-5580MHz 132/136/140ch 5660-5700MHz 149/153/157/161/165ch 5745-5825MHz This device is restricted to indoor use due to its operation in the 5.15 GHz to 5.25 GHz frequency range. FCC requires this product to be used indoors for frequency range 5.15 GHz to 5.25 GHz to reduce the potential for harmful interference to co-channel Mobile Satellite systems.
  • Page 55 Specifications nHDMI input terminal pins nD-sub input terminal pins (HDMI Connector) (Mini D-sub 15 pin) Function Function Function Function TMDS data 2+ TMDS clock shield Red video signal input TMDS data 2 shield 12 TMDS clock- Green video signal input 10 GND TMDS data 2- 13 CEC Blue video signal input...
  • Page 56: Mounting Precautions (For Sharp Dealers And Service Engineers)

    • When moving the monitor, be sure to hold the handles or the parts marked by below. Do not hold the screen. This may cause product damage, failure, or injury. • After mounting, please carefully ensure the monitor is secure, and not able to come loose from the wall or mount. • Do not use any screw holes other than those for mounting brackets, located on the rear of the monitor, for installation. • When using this monitor laying flat on a surface (when the monitor is tilted more than 20 degrees upward from the perpendicular in relation to a level surface), consult an authorized SHARP dealer because there are some specific mounting conditions.
  • Page 57 PN-HM851-HM751-HM651-HB851-HB751-HB651 Mu EN18M(1)
