For example, the following screen displays settings for VLAN 2, which
includes tagged ports 1-6, and forbidden port 8.
802.1Q VLAN Static Table Configuration
======================================
Unit Egress Ports
1. 111111000000 000000000000 ---- 000000010000 000000000000 ----
2. ------------ ------------ ---- ------------ ------------ ----
3. ------------ ------------ ---- ------------ ------------ ----
4. ------------ ------------ ---- ------------ ------------ ----
5. ------------ ------------ ---- ------------ ------------ ----
6. ------------ ------------ ---- ------------ ------------ ----
Unit Untagged Ports
1. 111111000000 000000000000 ----
2. ------------ ------------ ----
3. ------------ ------------ ----
4. ------------ ------------ ----
5. ------------ ------------ ----
6. ------------ ------------ ----
<APPLY>
Use <TAB> or arrow keys to move, other keys to make changes.
Notes: 1. To allow this switch to participate in a VLAN group that
extends beyond this switch, you must add the VLAN ID for
the required external groups.
2. If a removed port is no longer assigned to any other group as
an untagged port, it will automatically be assigned to VLAN
group 1 as untagged.
VID VLAN Name
------------------------------
2
<OK>
C
ONFIGURING THE
Status
Active
Forbidden Egress Ports
VID : 2
[Show]
[More]
[New]
<CANCEL>
S
WITCH
