SMC Networks TigerStack 100 1000BASE-X Management Manual page 23

Menu
BStorm Control
Configuration
Extended Bridge
Configuration
802.1P Configuration
802.1Q VLAN
Base Information
802.1Q VLAN Current
Table Information
802.1Q VLAN Static Table
Configuration
802.1Q VLAN
Port Configuration
Port Security Configuration Allows you to enable and configure port security for
Port GARP Configuration* Configures settings used in multicast filtering.
Port GMRP Configuration* Configures GMRP multicast filtering.
Network Monitor Menu
Port Statistics
RMON Statistics
Unicast Address Table
Multicast Address
Registration Table*
IP Multicast Registration
Table
* Not implemented in this firmware release.
Description
Allows you to enable/disable broadcast storm
control on a per-port basis and set the
packet-per-second threshold.
Displays/configures extended bridge capabilities
provided by this switch.
Configures default port priorities and queue
assignments.
Displays basic VLAN information, such as VLAN
version number and maximum VLANs supported.
Displays VLAN groups and port members.
Configures VLAN groups via static assignments,
including setting port members, or restricting ports
from being dynamically added to a port by the
GVRP protocol.
Displays/configures port-specific VLAN settings,
including PVID, ingress filtering, and GVRP.
the switch.
Displays statistics on network traffic passing
through the selected port.
Displays detailed statistical information for the
selected port such as packet type and frame size
counters.
Provides full listing for unicast addresses, as well as
search and clear functions.
Provides full listing for multicast addresses, as well
as search and clear functions.
Displays all the multicast groups active on this
switch, including multicast IP addresses and
corresponding VLAN IDs.
M M
AIN ENU
2-5
