Assigning SNMP Parameters
Use the SNMP Configuration screen to display and modify parameters for
the Simple Network Management Protocol (SNMP). The switch includes
an on-board SNMP agent which monitors the status of its hardware, as
well as the traffic passing through its ports. A computer attached to the
network, called a Network Management Station (NMS), can be used to
access this information. Access rights to the on-board agent are controlled
by community strings. To communicate with the switch, the NMS must
first submit a valid community string for authentication. The options for
configuring community strings and related trap functions are described in
the following sections.
<APPLY>
Use <TAB> or arrow keys to move, <Space> to scroll options.
Parameter
Send Authentication Fail
Traps
SNMP Communities
IP Trap Managers
SNMP Configuration
==================
Send Authentication Fail Traps : ENABLED
SNMP Communities ...
IP Trap Managers ...
Description
Issue a trap message to specified IP trap managers
whenever authentication of an SNMP request fails. (The
default is disabled.)
Assigns SNMP access based on specified strings.
Specifies management stations that will receive
authentication failure messages or other trap messages
from the switch.
M
ANAGEMENT
<OK>
S
M
ETUP
<CANCEL>
ENU
2-19
