Configuring the Serial Port

You can access the on-board configuration program by attaching a VT100
compatible device to the switch's serial port. (For more information on
connecting to this port, see "Required Connections" on page 1-2.) The
communication parameters for this port can be accessed from the Serial
Port Configuration screen shown below and described in the following
table.
<APPLY>
Use <TAB> or arrow keys to move. <Space> to scroll options
Parameter
Management
Mode
Baud rate
Data bits
Stop bits
Serial Port Configuration
=========================
Management Mode
Baud rate
Data bits
Stop bits
Parity
Time-Out (in minutes)
Auto Refresh (in seconds) : 5
Default Description
Console Indicates that the console port settings are for
Mode direct console connection.
19200 The rate at which data is sent between devices.
Options : 2400, 4800, 9600, 19200 and auto
detection.
Note that when Auto is selected, you need to first
press the Enter key once to set the data rate and
initialize the connection.
8 bits Sets the data bits of the RS-232 port.
Options : 7, 8
1 bit Sets the stop bits of the RS-232 port.
Options : 1, 2
M
ANAGEMENT
: CONSOLE MODE
: 19200
: 8
: 1
: NONE
: 10
<OK>
S M
ETUP
<CANCEL>
2-17
