Input Cables (Optional)
◆ Input Cable (for RVR-52)
RVR-7101 Input Cable
Cable Length: 1.5 m
RVR-7102 Input Cable
Cable Length: 1.5 m
RVR-7103 4-20mA Probe
Maximum Current Input:
MAX40mA
Interior Resistance: 100 Ω
Output: 2V at 20mA / 0.4V at 4mA
Conversion Accuracy: 0.5%
Cable Length: 1.5 m
67
unit:millimeters
Materials: ① Clip
② Vinyl Coated Electrical Wire
Materials: ① M3.5 Crimp Terminal
② Vinyl Coated Electrical Wire
Materials: ① M3.5 Crimp Terminal
② Vinyl Coated Electrical Wire
Options for TR-5/RTR-5/RVR-5
◆ Wall Attachment
TR-05K1
Screws x 2
Materials: ① Aluminum ② Neoprene
◆ Maintenance Set
TR-00P1
Contents: Rubber packing x 1
Silica gel x 1
Double-sided Adhesive tape x 1
Lock Screw x 2
unit : millimeters
TR-05K2
Materials:
ABS Resin
Silicagel Double Sided
Adhesive Tape
Rubber Packig
Lock Screw
