Bay Networks BayStack ARN Routers none Installation And Operating Manual page 53

2.
3.
4.
U L
Redundant Power
100-240~ U L
1.2A
50-60Hz
Figure 1-16. Connecting a PC Console to an ARN
5.
6.
114200 Rev. A
Power off the PC console.
Insert the 9-pin receptacle end of the console cable into the console port
(Figure 1-16).
Attach the null modem crossover adapter to the other end of the console
cable (refer to Figure
Attach the 25-pin receptacle end of the cable-plus-adapter to the PC
console cable 25-pin plug connector.
Connect the complete cable unit to the communications port at the back
of the PC (Figure 1-16).
Installing the BayStack Advanced Remote Node
1-14).
Modem
PC cable
Null modem adapter
Console cable
ARN0056A
1-23
