This appendix provides technical specifications and a product overview of the
ARN and its interface options. This appendix lists
•
•
•
Physical Specifications
The dimensions and weight of the ARN are as follows:
•
•
•
•
Your installation site must provide a certain amount of free space around the ARN
to dissipate heat. The space requirements for installing the ARN at your site are as
follows:
•
•
•
114200 Rev. A
Physical, electrical, and environmental specifications
Hardware communications options
BayStack ARN configurations
Height: 2.8 in. (7.1 cm)
Width: 17.25 in. (43.8 cm)
Depth: 12.5 in. (31.8 cm)
Weight: 15 lb (6.8 kg)
Width: 22.5 in. (57.2 cm)
Minimum depth: 15 in. (38.1 cm)
Depth for servicing: 25 in. (63.5 cm)
Technical Specifications
Appendix C
C-1
