Bay Networks BayStack ARN Routers none Installation And Operating Manual page 141

Table D-5.
Bay Networks Termination
Pin Signal
38 VSD+
36 VSD-
34 VRT+
33 VRT-
32 VST+
31 VST-
37 VRD+
35 VRD-
6 Data Set Ready+
8 Data Terminal Ready+
4 Request to Send+
5 Clear to Send+
40 VTT+
39 VTT-
1 Frame Ground
9 Data Carrier Detect+
19 Signal Ground
Pin 19 > 20 > 23 > 7
Pin 41 > 42 > 43
Pin 13 > 28
Pin 14 > 29
114200 Rev. A
V.35 Interface (Order No. 7220)
Local Wire Connections
Requirements for European Operation
Remote Termination
Pin Signal
P Send Data A
S Send Data B
V Receive Timing A
X Receive Timing B
Y Send Timing A
AA Send Timing B
R Receive Data A
T Receive Data B
E Data Set Ready
H Data Terminal Ready
C Request to Send
D Clear to Send
U Terminal Timing A
W Terminal Timing B
A Frame Ground
F Data Carrier Detect
B Signal Ground
D-5
