  • Page 1 PRIMERGY RX300 S2 Server Options Guide Edition March 2007...

  • Page 2: Copyright And Trademarks

    Gesellschaft für Technik-Dokumentation mbH www.cognitas.de Copyright and Trademarks Copyright © 2007 Fujitsu Siemens Computers GmbH. All rights reserved. Delivery subject to availability; right of technical modifications reserved. All hardware and software names used are trademarks of their respective manufacturers.

  • Page 3: Table Of Contents

    Contents Introduction ......7 Overview of the documentation ....7 Options and upgrade .
  • Page 4 Contents Accessible drives ......45 Installing a FD drive ..... . . 46 Installing a LocalView module .
  • Page 5 Contents Completion ......107 15.1 Closing the server ..... . . 107 Appendix .

  • Page 7: Introduction

    The PRIMERGY RX300 S2 has been designed for multi-server configurations (clusters), front-end solutions, e-commerce applications and ERP solutions. The PRIMERGY RX300 S2 is outstanding for applications and fields of use that demand maximum scalability, performance and availability in a space-saving rack cabinet.
  • Page 8 – The “Warranty” manual (printed copy always supplied with the server, and available as a PDF file on the ServerBooks DVD supplied) – The Operating Manual for PRIMERGY RX300 S2 (PDF available on the ServerBooks DVD supplied) – The Technical Manual for the system board D1889/D2089 (PDF available on the ServerBooks DVD supplied) –...

  • Page 9: Options And Upgrade

    Introduction Options and upgrade Options and upgrade Second processor The system board can be upgraded with a second processor. Only processors of the same type may be used on the system board. The second processor must have the same clock frequency and the same cache as the first processor. Upgrading of the main memory The eight slots for the main memory are suitable for PC2-3200 DDR DIMM memory modules.
  • Page 10 Options and upgrade Introduction LocalView module (alphanumeric system display) The LocalView module provides you with the option of displaying system infor- mation and hardware system faults alphanumerically. This is an intelligent module with a micro-controller and its own memory, which functions indepen- dently of the server system.
  • Page 11 Introduction Options and upgrade RemoteView RemoteView provides you with a comprehensive test and diagnostics package. The test and diagnostics software is stored on a chipDISK. The chipDISK is a memory component with an IDE interface. In the event of a fault the test and diagnostics software is automatically loaded from the chipDISK and executed.

  • Page 12: Notational Conventions

    Notational conventions Introduction Notational conventions The following notational conventions are used in this manual: Text in italics indicates commands, menu items or software programs. „Quotation marks“ indicate names of chapters and terms that are being emphasized. Ê describes activities that must be performed in the order shown.

  • Page 13: Procedure

    Procedure CAUTION! The actions described in these instructions should only be performed by technical specialists or service personnel. Equipment repairs should only be performed by authorized, qualified staff. Any unauthorized opening and improper repairs could expose the user to risks (electric shock, energy hazards, fire hazards) and could also damage the equipment.

  • Page 15: Safety Notes

    Safety notes The following safety notes are also provided in the “Safety notes and other important information” manual. This device complies with the relevant safety regulations for data processing equipment. If you have any questions about where you can set up the device, contact your sales outlet or our customer service team.
  • Page 16 Safety notes Installation and operation CAUTION! If the rack model is integrated in an installation that receives power from an industrial (public) power supply network with the IEC309 connector, the (public) power supply protection must comply with the requirements for the non-industrial (public) power supply networks for the type A connector.
  • Page 17 Safety notes CAUTION! Always connect the device and the attached peripherals to the same power circuit. Otherwise you run the risk of losing data if, for example, the central processing unit is still running but the peripheral device (e.g. storage subsystem) has failed during a power outage. Data cables to peripheral devices must be adequately shielded.
  • Page 18 Safety notes CAUTION! The components marked with a warning label (e.g. lightning symbol) may only be opened, removed or exchanged by authorized, qualified personnel. The hot-plug power supply units are exceptions to this rule. The warranty expires if the device is damaged during the installation or replacement of system expansions.
  • Page 19 Safety notes Notes on handling CDs and CD-/DVD-ROM drives CAUTION! Use only CDs in proper condition in the CD-/DVD-ROM drive of your server to prevent data loss, damage to the device and injuries. Therefore, check each CD for damage, cracks, breakage etc. before inserting it in the drive.
  • Page 20 Safety notes Modules with electrostatic-sensitive components Systems and components that might be damaged by electrostatic discharge (ESD) are marked with the following label: Figure 1: ESD label When you handle components fitted with ESDs, you must observe the following points under all circumstances: Remove the power plug(s) from the power socket(s) before inserting or removing components containing ESDs.

  • Page 21: Preparation

    Preparation CAUTION! Observe the safety instructions in the chapter „Safety notes“ on page Removing the server form the rack Ê Terminate all applications and shut down the server correctly. Ê If your operating system has not switched off the sever, press the on/off switch.
  • Page 22 Removing the server form the rack Preparation Depending on how accessible the server is in the rack cabinet, it can make sense to remove it from the cabinet. If you do not want to remove the server from the rack cabinet, please skip this page. Figure 3: Removing the server from the rack cabinet Ê...

  • Page 23: Opening The Server

    Preparation Opening the server Opening the server Figure 4: Removing the top cover Ê Pess the two locking buttons (1) downward and remove the cover (2). Ê Slide the cover to the rear side and remove it (2). Options Guide RX300 S2...

  • Page 25: Main Memory

    Main memory CAUTION! Observe the safety instructions in the chapter „Safety notes“ on page The system board supports up to 16 Gbytes of main memory. 8 slots (4 memory banks with 2 slots each) are provided for the main memory. Each memory bank is equipped with two 512-Mbyte, 1-Gbyte or 2-Gbyte registered DDR2 400 (PC2-3200) memory modules.

  • Page 26: Memory Module Population

    Memory module population Main memory Memory module population Memory bank 3 - DIMM-3B Memory bank 3 - DIMM-3A Memory bank 2 - DIMM-2B Memory bank 2 - DIMM-2A Memory bank 1 - DIMM-1B Memory bank 1 - DIMM-1A Memory bank 0 - DIMM-0B Memory bank 0 - DIMM-0A Figure 5: Structure of the main memory in memory banks and memory modules –...

  • Page 27: System Requirements

    Main memory Memory module population Memory mirroring Either 4 or 8 identical memory modules are required for memory mirroring: Memory bank Channel (module) population 4 identical memory modules 4 identical memory modules 4 identical memory modules Memory Mirroring with 4 or 8 DIMMs •...

  • Page 28: Upgrading/Replacing The Main Memory

    Upgrading/replacing the main memory Main memory Upgrading/replacing the main memory Ê Open the server as described in the chapter „Safety notes“ on page Removing the air duct over the main memory and the processors Figure 7: Removing the air duct over the main memory and the processors Ê...
  • Page 29 Main memory Upgrading/replacing the main memory Figure 8: populating memory module slots Figure 9: Removing a memory module Ê Press the holders on either side of the mounting location concerned outward (1). Ê Pull the memory module out of the mounting location (2). Options Guide RX300 S2...
  • Page 30 Upgrading/replacing the main memory Main memory Figure 10: Inserting a memory module Ê Press the holders on either side of the mounting location concerned outward. Ê Insert the memory module in the mounting location (1) until the holders at the sides engage (2). Options Guide RX300 S2...
  • Page 31 Main memory Upgrading/replacing the main memory Inserting air duct Figure 11: Installing the air duct over the memory and processors Ê Reinstall the air duct over the system fans. CAUTION! Ensure that no damage is caused to the cables! Options Guide RX300 S2...
  • Page 32 Upgrading/replacing the main memory Main memory Figure 12: Guiding edge between the air duct and fanbox Figure 13: Support point of the air duct. Ê Pay attention to the guiding edge between the air duct and the fan box (1) and ensure a correct fit, especially at the places (2, 3 and 4).

  • Page 33: Processors

    Processors CAUTION! Observe the safety instructions in the chapter „Safety notes“ on page CAUTION! Processors are modules which can react extremely sensitively to electro- static discharges and which must therefore always be handled with care. After a processor has been removed from its protective sleeve or from its socket, place it with its smooth side down on a non-conducting, antistatic surface.
  • Page 34 Installing a second processor Processors Figure 14: Removing processor dummy module Ê Pull the processor dummy out. CAUTION! Keep the dummy cover for future use. If you remove the processor again and do not replace it with a new one, reinstall the dummy cover to ensure that the system is cooled properly.
  • Page 35 Processors Installing a second processor Figure 15: Empty processor slot Ê Release the socket lifter by pressing it sideways and pull it upward as far as it will go. Options Guide RX300 S2...
  • Page 36 Installing a second processor Processors Figure 16: Inserting processor Ê Position the new processor over the socket and then carefully press it into the socket (1). CAUTION! The processor can only be installed in one particular direction. Note the marking on one of the corners. To avoid damaging the pins or the processor, do not force it into the socket.
  • Page 37 Processors Installing a second processor Figure 17: places of the springs round the heat sink support pins Ê Check whether the springs round the heat sink support pins are aligned centrally. Options Guide RX300 S2...
  • Page 38 Installing a second processor Processors Figure 18: Installing heat sink Ê Place the heat sink on the processor. Ê Fasten the heat sink by tightening the four screws in a crossover pattern. CAUTION! Never install a processor without a heat sink as otherwise the processor may overheat, causing a shut-down of the system.

  • Page 39: Replacing The Processor

    Processors Replacing the processor Replacing the processor CAUTION Only processors of the same type may be used on the system board. The second processor must have the same clock frequency and the same cache as the first processor. For dual operation, use a suitable multipro- cessor operating system.
  • Page 40 Replacing the processor Processors Figure 20: Removing an installed processor Ê Release the socket lifter by pressing it sideways and pull it upward as far as it will go (1). Ê Lift the installed processor carefully out of the socket (2). Options Guide RX300 S2...
  • Page 41 Processors Replacing the processor Figure 21: Inserting a new processor Ê Position the new processor over the socket and then carefully press it into the socket (1). CAUTION! The processor can only be installed in one particular direction. Note the marking on one of the corners (2). To avoid damaging the pins or the processor, do not force it into the socket.

  • Page 43: Romb (Raid On Motherboard)

    ROMB (RAID on Motherboard) CAUTION! Observe the safety instructions in the chapter „Safety notes“ on page The on-board SCSI controller can be upgraded to a RAID5 (RAID 0, 1, 5, 10, 50) controller with a "MegaRaid PCI Express™ ROMB" upgrade kit. In this case the on-board INTEL I/O processor is activated by installing a license key and a cache module.
  • Page 44 Installing the ROMB upgrade kit ROMB (RAID on Motherboard) Figure 23: Installing the iButton and the Cache module Ê Install the iButton on the system board (1). Ê Press the holders on either side of the mounting location outward. Ê Insert the cache module. Ê...

  • Page 45: Accessible Drives

    Accessible drives CAUTION! Observe the safety instructions in the chapter „Safety notes“ on page Two free bays are available for accessible drives. One 3,5 Inch x 0,5 Inch is for a FD drive and one 5,25 inch x 0,5 inch is for a CD/DVD-ROM drive available.

  • Page 46: Installing A Fd Drive

    Installing a FD drive Accessible drives Installing a FD drive Ê Open the server as described in the chapter „Preparation“ on page Removing a FD drive dummy module Figure 24: Unlocking the FD drive dummy module Ê Unlock the FD drive dummy module (1). Ê...
  • Page 47 Accessible drives Installing a FD drive Figure 25: Removing dummy module Ê Pull the FD drive dummy module out to the front side. CAUTION! Keep the dummy module for future use. If you remove the FD drive again and do not replace it with a new one, the dummy module must be reinstalled to comply with EMC regulations and to satisfy cooling requirements and fire protection measures.
  • Page 48 Figure 26: Insert FD drive into the mounting frame. The mouning frame and the cable is deliverd in the accessory pack with the PRIMERGY RX300 S2. Ê Insert the FD drive into the mounting frame. Regard the plastic pins. They fix the dive in the frame.
  • Page 49 Accessible drives Installing a FD drive Figure 27: Inserting FD drive module Ê Thread the flat cable in the bay. Ê Push the FD drive module into the bay, until it locks. Options Guide RX300 S2...
  • Page 50 Installing a FD drive Accessible drives Figure 28: Connecting FD drive cable Ê Connect the FD cable to the system board. Ê Close the server, connect it to the power outlet, and switch it on as described in the chapter „Completion“ on page 107.

  • Page 51: Installing A Localview Module

    Accessible drives Installing a LocalView module Installing a LocalView module The LocalView module is an optional extra for the servers of the PRIMERGY series. On the display panel of the LocalView module you can read status messages directly on the server. These status messages provide information on the system and notify you of hardware faults (e.g.
  • Page 52 Installing a LocalView module Accessible drives Removing the FD Drive Figure 30: Unlocking the the FD Drive module (for better visibility, the fanbox is removed) Ê Unlock (1) the FDD module. Ê Push the FDD module to the front (2). Options Guide RX300 S2...
  • Page 53 Accessible drives Installing a LocalView module Figure 31: Removing FD drive cable Ê Remove the FD drive cable from the system board. Options Guide RX300 S2...
  • Page 54 Installing a LocalView module Accessible drives Figure 32: Removing FD-Drive module Ê Pull the FD drive module out. to the front side. Options Guide RX300 S2...
  • Page 55 Accessible drives Installing a LocalView module Figure 33: Threading the cable (for better visibility, the fanbox is removed) Ê Push the cable for the LocalView module through the bay to the front. Options Guide RX300 S2...
  • Page 56 Installing a LocalView module Accessible drives Figure 34: Connecting the cable to the LocalView module Ê Connect the cable to the LocalView module. Options Guide RX300 S2...
  • Page 57 Accessible drives Installing a LocalView module Figure 35: Inserting the LocalView module Ê Slide the LocalView module into the mounting location until it latches in place. Further information on operation and display modes is provided in the documentation for the LocalView module. Ê...

  • Page 58: Installing The Cd/ Dvd-Rom Drive

    Installing the CD/ DVD-ROM drive Accessible drives Installing the CD/ DVD-ROM drive Ê Open the server as described in the chapter „Preparation“ on page Removing the CD/DVD drive dummy module Figure 36: Unlocking the CD/DVD drive dummy module Ê Unlock (1) the CD/DVD drive dummy module. Ê...
  • Page 59 Accessible drives Installing the CD/ DVD-ROM drive Figure 37: Removing dummy module Ê Remove the dummy module. CAUTION! Keep the dummy module for future use. If you remove the accessible drive again and do not replace it with a new one, the dummy module must be reinstalled to comply with EMC regulations and to satisfy cooling requirements and fire protection measures.
  • Page 60 Installing the CD/ DVD-ROM drive Accessible drives Figure 38: Installing the CD/DVD drive into its mounting frame Ê Install the CD/DVD Drive in the mounting frame (the mounting frame is delivered with the drive, and the IDE cable is included to the assessory pack of the server.
  • Page 61 Accessible drives Installing the CD/ DVD-ROM drive Figure 39: Connecting the CD/DVD drive cables Ê Thread the power cable (1) through the bay and connect it to the CD Drive (see also chapter „Appendix“ on page 111). Ê Connect the IDE cable to the drive (see also chapter „Appendix“...
  • Page 62 Installing the CD/ DVD-ROM drive Accessible drives Figure 40: Pushing the CD/DVD drive into the bay Ê Push the drive into the bay completely. Ê Close the server, connect it to the power outlet, and switch it on as described in the chapter „Completion“...

  • Page 63: Pci Slots

    PCI slots CAUTION! Observe the safety instructions in the chapter „Safety notes“ on page Standard configuration The system board offers five PCI slots. Slots 1-3 are non-hot-plug PCI slots . If two or three slots are occupied, the bus speed is 100 MHz, but, if only slot 3 is occupied IOOP™...

  • Page 64: Installing A Pci Controller In A Low-Profile Slot

    Installing a PCI controller in a low-profile slot PCI slots Installing a PCI controller in a low-profile slot Ê Open the server as described in the chapter „Preparation“ on page Figure 41: Remove the slot cover Ê Push the green PCI board holder toward the rear (1). Ê...
  • Page 65 PCI slots Installing a PCI controller in a low-profile slot Figure 42: Inserting controller Ê Install the controller in the PCI slot and press it carefully into the associated plug-in location on the system board (1). Ensure that the rear cover fits into the recesses (a).

  • Page 66: Installing The Pci Controller In The Riser Card

    Installing the PCI controller in the riser card PCI slots Installing the PCI controller in the riser card Ê Open the server as described in the chapter „Preparation“ on page Figure 43: Removing the riser card Ê Open the knurled screws. CAUTION!! Keep the rear cover of the PCI slot for future use.
  • Page 67 PCI slots Installing the PCI controller in the riser card Figure 44: Removing the riser card Ê Remove the riser card upward. Options Guide RX300 S2...
  • Page 68 Installing the PCI controller in the riser card PCI slots Figure 45: Installing the controller Ê Remove the screw and the slot cover of the associated connector To equip slot 8 with a full-length PCI controller it is necessary to remove slot cover of slot 7 too.
  • Page 69 PCI slots Installing the PCI controller in the riser card Figure 46: Installing controller Ê Insert the controller into the PCI slot and push it down carefully. Ê Fix the slot cover/s with the screw/s. Ê If necessary connect the cables to the controller or other components. Ê...

  • Page 70: Population Of The Pci Slots

    Population of the PCI slots PCI slots Population of the PCI slots Standard configuration with 5 low profile slots Adapter class Adapter priority Slot (order) External SCSI interface Parallel port FC (QLA2340, LP9802) 5, 4 3, 4, 5 LAN Controller 5, 4, 3, 2, 1 RAID 5, 4, 3, 2, 1...

  • Page 71: Remoteview Components

    RemoteView components CAUTION! Observe the safety instructions in the chapter „Safety notes“ on page 10.1 Installing the chipDISK Ê Open the server as described in the chapter „Preparation“ on page Figure 47: Installing the chipDISK Ê Connect the chipDISK to the plug-in location on the system board. CAUTION Note the coding of the chipDISK and plug-in location.

  • Page 72: Remoteview Service Board S2 Lp

    RemoteView Service Board S2 LP RemoteView components 10.2 RemoteView Service Board S2 LP How to install/remove and configure the RSB S2 LP is described in detail in the “RemoteView Service Board S2/ S2 LP 1.x, Mounting and Setting Up” manual. Preferred mounting locations for RSB S2 LP are PCI slots 3, 4, and 5 in the standard configuration with only low profile PCI Slots.
  • Page 73 RemoteView components RemoteView Service Board S2 LP Figure 49: Connecting cables to the system board Ê Connect the power cable (1) and the data cable (2) to the RSB S2 LP. Ê Install the RSB S2 LP into PCI slot 3, 4 or 5 (described in „Installing a PCI controller in a low-profile slot“...

  • Page 75: External Scsi Interface

    External SCSI interface CAUTION! Observe the safety instructions in the chapter „Safety notes“ on page 11.1 Installing the external SCSI interface Ê Open the server as described in the chapter „Preparation“ on page For standard configuration the external SCSI interface is to install with a low profile slot cover.
  • Page 76 Installing the external SCSI interface External SCSI interface Removing the cache module If a ROMB upgrade kit is incorporated in the server, remove the cache module. Figure 51: Removing the cache module Ê Press the holders on either side of the mounting location outward. Ê...
  • Page 77 External SCSI interface Installing the external SCSI interface Removing fan box Figure 52: Unlocking fan box air duct Ê Unlock the fan box air duct. Figure 53: Removing fan box air duct Ê Pull the fan box air duct out. Options Guide RX300 S2...
  • Page 78 Installing the external SCSI interface External SCSI interface Figure 54: Removing the fan box Ê Unlock all fans (1). Ê Unlock the fan box (2). Ê Push the fan box to the left side (3). Ê Pull out the fan box in an angle (4). Options Guide RX300 S2...
  • Page 79 External SCSI interface Installing the external SCSI interface Removing cable channel cover Figure 55: Remove the three-part cable channel cover. view outside view inside Figure 56: Snap-fits of the three-part cable channel cover Ê Remove the three-part cable channel. Press the upper and lower snap-fit on the outside together.
  • Page 80 Installing the external SCSI interface External SCSI interface Figure 57: Installing cable Ê Insert the slot cover with the SCSI interface. Ê Close the green PCI board holder. Ê Route the SCSI cable as shown in the picture and insert the three-part cable channel cover in the specified order.
  • Page 81 External SCSI interface Installing the external SCSI interface Figure 58: Connecting the SCSI cable to the system board Ê Connect the SCSI cable to the connector SCSI B on the system board (see arrow). Route the cable as shown in the figure. CAUTION! Make sure that the cable is not kinked and not under stress.
  • Page 82 Installing the external SCSI interface External SCSI interface External SCSI interface in the riser card Figure 59: Cable for external SCSI interface (with low profile slot cover) Ê Remove the two screws. Ê Remove the low-profile slot cover from the SCSI-connector. Figure 60: External.
  • Page 83 External SCSI interface Installing the external SCSI interface Figure 61: Removing riser card Ê Remove the riser card. Figure 62: Removing slot cover of slot 6 Ê Remove the screw of the slot cover of slot 6. Ê Remove the slot cover of slot 6. Ê...
  • Page 84 Installing the external SCSI interface External SCSI interface Figure 63: opening cable duct Ê Open the cabel channel cover, see „Removing cable channel cover“ on page Figure 64: external SCSI interface Ê Thread the cable in the cable channel. CAUTION Leave an extra 6 cm cable protruding.
  • Page 85 External SCSI interface Installing the external SCSI interface Figure 65: Inserting riser card Ê Lay the riser card into the server as shown above. Ê Push the SCSI slot cover into Slot 6. Ê Fix the slot cover with the screw. Ê...
  • Page 86 Figure 66: Connecting the external SCSI cable to the system board Ê Connect the SCSI cable to the connector SCSI B on the system board (see arrow). Ê Insert the fan box and the fan box air duct. Ê Press the fans firmly into position. Ê...

  • Page 87: Parallel Interface

    Parallel interface CAUTION! Observe the safety instructions in the chapter „Safety notes“ on page 12.1 Installing a parallel interface Ê Open the server as described in the chapter „Preparation“ on page For standard configuration the parallel interface is to install into a low- profile slot cover.
  • Page 88 Installing a parallel interface Parallel interface Figure 68: Removing the slot cover Ê Push the PCI board holder backward. Ê Remove the slot cover. Figure 69: Routing the cable Ê Insert the slot cover with the parallel interface. Ê Connect the cable to the system board (see arrow). Ê...
  • Page 89 Parallel interface Installing a parallel interface External Parallel-interface in slot cover with standard height Figure 70: External parallel interface with low-profile slot cover Ê Remove the two screws. Figure 71: External parallel interface with standard slot cover Ê Insert the connector of the parallel interface in the slot cover. Ê...
  • Page 90 Installing a parallel interface Parallel interface Figure 72: Removing the riser card Ê Remove the riser card. Figure 73: Removing the slot cover of slot 8 Ê Remove the slot cover of slot 8. Options Guide RX300 S2...
  • Page 91 Parallel interface Installing a parallel interface Figure 74: Installing the slot cover with the connector of the parallel interface. Ê Insert the slot cover with the parallel interface in slot 8 and fix the slot cover with the screw. Ê Thread the flat cable between the riser board and the plastic side cover. Route the cable as shown in the photo.
  • Page 92 Installing a parallel interface Parallel interface Figure 75: Installing the riser card with parallel interface. Ê Insert the riser card. Ê Route the cable. Ê Connect the cable to the system board. Ê Close the server, connect it to the power outlet, and switch it on as described in the chapter „Completion“...

  • Page 93: Converting From 1- To 2-Channel Version

    Observe the safety instructions in the chapter „Safety notes“ on page For the PRIMERGY RX300 S2 the SCSI backplane is separated into two parts. The 1st SCSI backplane can stay installed for both configurations. For upgrading you must change the second SCSI backplane. Die 1-...
  • Page 94 Converting from 1- to 2-channel version Figure 77: Second SCSI backplane 2-channel configuration (backplane is equal to the first SCSI backplane). Options Guide RX300 S2...

  • Page 95: Removing 2Nd Scsi Backplane

    Converting from 1- to 2-channel version Removing 2nd SCSI backplane 13.1 Removing 2nd SCSI backplane Ê Open the server as described in the chapter „Preparation“ on page Ê Remove all hot-plug hard disks or/and the hot-plug tape drive on the left side (for a description see the Operating Manual).
  • Page 96 Removing 2nd SCSI backplane Converting from 1- to 2-channel version Figure 79: Loosening knurled screw Ê Loosen the knurled screw. Ê Twist the SCSI backplane holder out slightly. Do not damage the hooks. Ê Pull the SCSI backplane holder out. Options Guide RX300 S2...
  • Page 97 Converting from 1- to 2-channel version Removing 2nd SCSI backplane Figure 80: Removing the 2nd SCSI backplane (1-channel) from the holder Ê Unlock the backplane from the snap-fits. Ê Remove the SCSI backplane from the holder. Options Guide RX300 S2...

  • Page 98: Installing 2Nd Scsi Backplane

    Installing 2nd SCSI backplane Converting from 1- to 2-channel version 13.2 Installing 2nd SCSI backplane Figure 81: Inserting the 2nd SCSI backplane (2-channel) into the SCSI backplane holder Ê Insert the 2-channel SCSI backplane in the hooks of the SCSI backplane holder (1).
  • Page 99 Converting from 1- to 2-channel version Installing 2nd SCSI backplane Figure 82: Inserting second SCSI backplane Ê Insert the assembled SCSI backplane holder. Be careful with the hooks. The angle may not be too great. Ê Close the holder. Ê Fasten it with the knurled screw. Options Guide RX300 S2...
  • Page 100 Installing 2nd SCSI backplane Converting from 1- to 2-channel version Figure 83: Cabling the second SCSI backplane Ê Connect the I C cable (1), the power cable (2) and the SCSI-cable (3) to the SCSI backplane. Do not insert the SCSI signal cable. Ê...

  • Page 101: Converting From Low-Profile To Standard Pci Slots

    Converting from low-profile to standard PCI Slots CAUTION! Observe the safety instructions in the chapter „Safety notes“ on page 14.1 Removing lp slot cage Ê Open the server as described in the chapter „Preparation“ on page Figure 84: Removing hot-plug cable Ê...
  • Page 102 Removing lp slot cage Converting from low-profile to standard PCI Slots Figure 85: Removing the slot cage Ê Remove the two screws. Ê Pull the slot cage out. Options Guide RX300 S2...
  • Page 103 Converting from low-profile to standard PCI Slots Removing lp slot cage Figure 86: Without slot cage Ê Equip the riser card as described in part “Installing the PCI controller in the riser card” on page Figure 87: Assembled Riser card Options Guide RX300 S2...

  • Page 104: Installing Riser Card

    Installing Riser card Converting from low-profile to standard PCI Slots 14.2 Installing Riser card Figure 88: Inserting the Riser card Ê Install the riser card. Options Guide RX300 S2...
  • Page 105 Converting from low-profile to standard PCI Slots Installing Riser card Figure 89: With riser card Ê Fasten the two screws. Ê Close the server, connect it to the power outlet, and switch it on as described in the chapter „Completion“ on page 107.

  • Page 107: Completion

    Completion CAUTION!! Observe the safety instructions in the chapter „Safety notes“ on page 15.1 Closing the server Figure 90: Closing the cover Ê Apply the cover. Ê Push the cover to the front (1). Ê Make sure that the locks engage. Options Guide RX300 S2...
  • Page 108 Closing the server Completion If you have not removed the server from the rack cabinet, please skip this page. Figure 91: Installing the server in a rack cabinet CAUTION! At least two people are required to install the server in the rack cabinet. Do not use the handles on the rack front cover to lift the server into the rack.
  • Page 109 Completion Closing the server Figure 92: Fastening the knurled screws Ê Fasten the server in the rack using the two knurled screws (1). Ê Connect all power plugs to the power outlets. Ê Press the on/off key to start up the server. Options Guide RX300 S2...

  • Page 111: Appendix

    Appendix 16.1 Cabling The following table gives you an overview of the cables: Numbers in the Material number Designation drawings A3C40058008 Parallel Port cable A3C40057192 SV cable PSU A3C40057188 SV cable 24 pol T26139-Y3697-V101 Power Backplane SMB cable A3C40058003 Power cable CD-ROM A3C40057191 SV cable PSU A3C40057185...

  • Page 112: Options Guide

    Cabling Appendix Verkabelung RX300 S2 mit 1 Kanal SCSI optionaler parallel Port PS Bpl CPU0 CPU1 SCSI System FAN CPU FAN3 CPU FAN2 CPU FAN1 CPU FAN1 CPU FAN2 CPU FAN3 System FAN redundant redundant redundant redundant SCSI B SCSI A Panel Floppy 11 10...
  • Page 113 Appendix Cabling Verkabelung RX300 S2 mit 2 Kanal SCSI optionaler parallel Port PS Bpl CPU0 CPU1 SCSI System FAN CPU FAN3 CPU FAN2 CPU FAN1 CPU FAN1 CPU FAN2 CPU FAN3 System FAN redundant redundant redundant redundant SCSI B SCSI A Panel Floppy SCSI...

  • Page 114: Configuration Diagram

    Configuration diagram Appendix 16.2 Configuration diagram board front side middle Bank I (2 Modules) Bay for LocalView LCD Xeon DP or 3.5"x 0,5" Floppy disk Bank II (2 Modules) Bank III (2 Modules) Air channel Xeon DP Bank IV (2 Modules) Bay for 5,25"x 0,5"...

  • Page 115: Hard Disk Mirroring

    2. The second channel of the Ultra 320 SCSI controller is available for external accessible SCSI drives with S26361-F3120-E1 2-channel SCSI cabling of a PRIMERGY RX300 S2 basic unit with on-board controller and "Conversion kit 6 HD 2-channel" For the order of a "Conversion kit 6 HD 2-channel (S26361-F2612-E4)", both channels of the Ultra 320 SCSI controller are connected to one backplane for 3 HDs each.

  • Page 117: Related Publications

    The current version of the necessary manuals can be downloaded free of charge from the Internet. The overview page showing the online documentation available in the Internet can be found via the URL: http://manuals.fujitsu-siemens.com (choose: industry standard servers). Safety notes and other important information Warranty...
  • Page 118 Related Publications [12] RemoteView Service Board S2/S2 LP 1.x Mounting and Setting Up User’s Guide [13] PRIMERGY RX300 S2 Operating Manual [14] System Board D1889/D2089 Technical Manual [15] BIOS-Setup Reference Manual [16] Integrated Mirroring User’s Guide [17] Global Array Manager Client Software User’s Guide...

  • Page 119: Index

    Index accessible drives 9, notational conventions air duct note about the laser cache module parallel interface 11, chipDISK 11, processor Controller 10, 64, conversion of SCSI 1-channel version RemoteView to 2-channel version RemoteView Service Board S2 converting form low profile to standard LP 11, slots ROMB...
  • Page 121 Information on this document On April 1, 2009, Fujitsu became the sole owner of Fujitsu Siemens Compu- ters. This new subsidiary of Fujitsu has been renamed Fujitsu Technology So- lutions. This document from the document archive refers to a product version which was released a considerable time ago or which is no longer marketed.
