AudioCodes 420HD IP Phone with Microsoft® Lync™ Server

1. Before Installing

Congratulations on purchasing your AudioCodes 420HD IP Phone! Before you begin using the phone,

make sure that the following items are included in the shipped box:



420HD IP Phone



AC power adapter (optional)



Cat 5e Ethernet cable



Phone base stand



Handset



Handset cord



Wall-mounting screws

2. Physical Description

Softkeys

Navigation Control

Volume Keys

Mute Key

Headset Key

Speakerphone Key

Quick Guide

Alphanumerical Keypad

LCD Screen

MENU Key

VOICEMAIL Key

CONTACTS Key

REDIAL Key

TRANSFER Key

HOLD Key

Page 1 AudioCodes 420HD IP Phone with Microsoft® Lync™ Server Quick Guide 1. Before Installing Congratulations on purchasing your AudioCodes 420HD IP Phone! Before you begin using the phone, make sure that the following items are included in the shipped box: ...
Page 2 3. Cabling the Phone Prior to connecting power, refer to the Compliancy and Regulatory Information Warning: document at www.audiocodes.com/library.  To cable the phone: Connect the short, straight end of the phone cord to the handset and the longer straight end of the cord to the handset jack on the phone.
Page 3 5. Upgrading IP Phone Firmware for Microsoft Lync Server 2010 If you need to upgrade your phone's firmware for Lync, refer to the Software Upgrade Configuration Note, downloadable from http://www.audiocodes.com/downloads. 6. Signing in to Lync  To sign in with Microsoft Lync client, see the Microsoft Lync BToE Configuration Note.
Page 4 Forward softkey and then select Do not forward calls. Notice Information This Quick Guide describes the quick setup for AudioCodes 420HD IP Phone Version 2.0.x. If you have a later version, verify with AudioCodes that the information in this document is compatible with your IP Phone.
