Paper Path

1. Main machine paper feed path
2. Bypass paper feed path
3. Optional tray paper feed path
4. Duplex paper feed path

Drive Layout

1. Duplex exit motor
2. Fusing drive gear
3. Drum gear
4. Registration clutch
