T650, T652, T654, and T656 4062-xxxx Service Manual • Start diagnostics • Maintenance • Safety and notices • Trademarks • Index July 12, 2016 www.lexmark.com P/N 12G9824...
Page 2: Product Information
Trademarks Lexmark and the Lexmark logo are trademarks of Lexmark International, Inc., registered in the United States and/or other countries. PCL® is a registered trademark of the Hewlett-Packard Company. PCL is Hewlett-Packard Company’s designation of a set of printer commands (language) and functions included in its printer products.
Page 3: Table Of Contents
4062 Table of contents Product information..................2 Edition notice....................2 Notices and safety information..............17 Laser notices................................17 Safety information............................. 20 Preface......................25 Service manual conventions.......................... 25 Change history..............................25 General information................... 29 Media guidelines............................... 29 Supported paper sizes, types, and weights ......................29 Tools required for service..........................33 Diagnostic information................
Page 4 4062 Avoiding jams ................................55 Understanding jam numbers and locations ......................56 How to clear 200-201 paper jams .......................... 57 How to clear 202-203 paper jams.......................... 80 How to clear 230 paper jams........................... 93 How to clear 231-239 paper jams ..........................104 How to clear 241-245 paper jams ...........................115 How to clear 250 paper jams...........................131 How to clear 260 paper jams..........................132...
Page 5 4062 Install MICR Cartridge..............................163 Invalid Engine Code..............................163 Invalid Network Code..............................163 Invalid PIN..................................163 Load manual feeder with <x> ..........................163 Load <src> with <x>..............................164 Load staples.................................164 Maintenance ................................164 Menu access turned off by system administrator....................164 Menus are Disabled..............................164 Must be in Ready state to enter menus........................164 Network/Network <x>/Network <x>, <y>...
Page 6 4062 Securely clearing disk space...........................170 Serial <x> ..................................170 Some held jobs were lost............................170 Staples <x> empty or misfed ...........................170 Staples <x> low or missing............................170 Standard Bin Full ................................170 Submitting selection ..............................170 Too many failed panel logins...........................170 Toner low ..................................171 Tray <x>...
Page 7 4062 58 Too many disks installed ............................ 177 58 Too many ﬂash options installed........................177 58 Too many trays attached ............................ 177 59 Incompatible Duplex ............................178 59 Incompatible envelope feeder ......................... 178 59 Incompatible output bin <x>..........................178 59 Incompatible tray <x> ............................178 61 Remove defective hard disk..........................
Page 8 4062 Disk Full service check .............................193 Routine Maintenance Needed service check.....................193 Replace fuser service check............................194 Replace cartridge service check ..........................194 Printer hardware errors..........................194 Procedure before starting the 9yy service checks ...................194 9yy errors..................................196 Service menus...................233 Understanding the printer control panel....................233 Understanding the colors of the Sleep button and indicator lights..........
Page 9 Print cartridge clamp assembly removal ......................278 Print cartridge ID connector assembly removal ....................279 T650 left side cover removal ..........................279 T652, T654, and T656 left side cover removal ....................280 Switch (media size) assembly removal .......................282 System card assembly removal..........................283 NVM card assembly removal ..........................285 Right side removals............................
Page 10 T650, T652, and T654 operator panel latch assembly removal ..............304 T650, T652, and T654 operator panel door assembly removal ..............305 T650, T652, and T654 left operator panel hinge assembly removal ............306 T650, T652, and T654 right operator panel hinge assembly removal............308 T656 operator panel door assembly removal....................310...
Page 11 T650 printhead assembly removal........................334 T652, T654, and T656 printhead assembly removal ..................336 MPF cam gear removal..........................337 T652, T654, and T656 redrive motor assembly removal..............338 Sensor (duplex input) removal (T652, T654, T656)................340 Sensor (standard bin exit) removal ......................341 Sensor (toner density) removal ........................341 Standard bin actuator assembly removal ....................
Page 12 Lower interface cable assembly removal ......................411 Media size actuator removal ...........................412 Media tray catch spring removal ..........................412 T652 and T654 media out actuator removal......................413 Media size actuator removal ...........................414 Media tray catch spring removal ..........................414 Media tray roller catch assembly removal ......................415 Sensor (HCIT tray raised HP) with cable assembly removal................415...
Page 13 4062 Sensor (pass through) with cable removal ......................418 Sensor (pass through) with cable removal ......................418 Tray roller catch assembly removal ........................419 Tray roller catch assembly removal ........................419 Upper interface cable assembly removal ......................419 Output expander removals.......................... 420 Output expander rear door assembly removal ....................420 Output expander left outer cover removal......................421 Output expander left inner cover removal ......................421 Output expander right outer cover removal ......................422...
Page 14 Maintenance kits................................455 Parts catalog..................... 458 Legend................................458 Assembly 1: Covers............................459 Assembly 2: T650, T652, and T654 operator panel................463 Assembly 3: T656 Operator panel, MPF and smart card..............465 Assembly 4: Drive motor assemblies and duplex.................. 467 Assembly 5: Media path and ducts......................471 Assembly 6: Printhead, charge, and transfer...................473...
Page 15 POR sequence..............................519 Printer control..............................519 Printer theory..............................519 T650 with duplex, paper path, rolls, and sensors .....................519 T652 and T654 with duplex, paper path, rolls, and sensors ................ 520 Functions of main components ..........................521 Media tray assembly..............................522 MPF ....................................524 Registration .................................526 Transfer ..................................527...
Page 16 4062 Paper path, rolls, and sensors..........................549 Duplex ..................................552 Appendix D: Acronyms................557 Acronyms................................557 Index......................559 Part number index..................569 Part name index..................581 Table of contents...
Page 17: Notices And Safety Information
4062 Notices and safety information Laser notices Laser notice The printer is certiﬁed in the U.S. to conform to the requirements of DHHS 21 CFR, Chapter I, Subchapter J for Class I (1) laser products, and elsewhere is certiﬁed as a Class I laser product conforming to the requirements of IEC 60825-1.
Page 18 4062 Aviso de láser Esta impresora se ha certiﬁcado en EE. UU. de conformidad con los requisitos de DHHS 21 CFR, capítulo I, subcapítulo J, para los productos láser de Clase I (1), y en otros países está certiﬁcada como un producto láser de Clase I de acuerdo con los requisitos de IEC 60825-1.
Page 19 4062 Luokan I lasertuotteita ei pidetä haitallisina. Tulostimen sisällä on luokan IIIb (3b) laser, joka on nimellisteholtaan 5 mW:n galliumarsenidilaser ja toimii 770–795 nanometrin aallonpituuksilla. Laserjärjestelmä ja tulostin ovat rakenteeltaan sellaisia, että käyttäjä ei joudu alttiiksi luokkaa 1 suuremmalle säteilylle normaalin käytön, ylläpidon tai huollon aikana.
Page 20: Safety Information
4062 Class I 레이저 제품은 위험한 제품으로 간주되지 않습니다. 프린터에는 770-795 나노미터의 파장 영역에서 작 동하는 공칭 5밀리와트 갈륨 비소 레이저인 클래스 IIIb(3b) 레이저가 내부에 포함되어 있습니다. 레이저 시스 템과 프린터는 정상적인 작동, 사용자 유지 관리 또는 사전 설명된 서비스 조건에는 사람에게 클래스 I 수준 이 상의...
Page 21 4062 AVERTISSEMENT—RISQUE DE BLESSURE La batterie lithium de ce produit n'est pas destinée à être remplacée. Il existe un risque d'explosion si une batterie lithium est placée de façon incorrecte. Ne rechargez pas, ne démontez pas et n’incinérez pas une batterie lithium. Mettez les batteries lithium usagées au rebut selon les instructions du fabricant et les réglementations locales.
Page 22 4062 PRECAUCIÓN: POSIBLES DAÑOS PERSONALES La batería de litio de este producto no debe reemplazarse. Existe riesgo de explosión si se sustituye incorrectamente una batería de litio. No recargue, desmonte ni incinere una batería de litio. Deseche las baterías de litio según las instrucciones del fabricante y las normativas locales. Informações de Segurança •...
Page 23 4062 安全信息本产品的安全性以原来设计和特定产品的测试结果和认证为基础。万一使用来经许可的替换部件，制造商 • 不对安全性负责。本产品的维护信息仅供专业服务人员使用，并不打算证其他人使用。 • 本产品在拆卸、维修时，遭受电击或人员受伤的危险性会增高，专业服务人员对这点必须有所了触，并采 • 取必要的预防措施。当心一可能的伤害：本产品中的锂电池不可更换。如果不正确更换锂电池，可能会有爆炸危险。不要再充电、拆解或焚烧锂电池。丢弃旧的锂电池时应按照制造商的指导及当地法规进行处理。 Notices and safety information...
Page 24 4062...
Page 25: Preface
July 11, 2016 • Removed 41X0792 from the topic “T650, T652, and T654 operator panel” in the “Parts catalog” chapter. • Updated the description of 40X4462 from the topic “T650, T652, and T654 operator panel” in the “Parts catalog” chapter. Preface...
Page 26 4062 June 28, 2016 • Updated the ”LES Applications” topic in the “Service menus” chapter. June 20, 2016 • Removed 40X7003 in the “Universal trays and accessories” topic in the “Parts catalog” chapter. January 8, 2016 • Changed the part number of the input sensor from 40X4368 to 40X8673. December 16, 2015 •...
Page 27 4062 September 29, 2014 • Updated the Assembly 7 parts catalog art in the Parts catalog chapter. July 2, 2014 • Added staple cartridge holder (40X7466) to parts catalog assembly 14. November 11, 2013 • Deleted all instances of 40X5057. July 30, 2013 •...
Page 28 4062 October 25, 2011 • Replaced PN 40X4310 with PN 40X8310 for the HCIT media out actuator in “HCIT Sheet option tray assembly” on page 487. September 1, 2011 • Replaced PN 40X4365 with PN 40X6994 for the MPF pick solenoid assembly in “Pick arm assembly, trays, and MPF”...
Page 29: General Information
Note: For an unlisted paper size, select the closest larger listed size. For information on card stock and labels, see the Card Stock & Label Guide on the Lexmark Web site. Paper sizes supported by the printer Note: An optional 250‑sheet Universally Adjustable Tray is available for sizes smaller than A5, such as index cards.
Page 30 4062 Paper size Dimensions 250‑ or Optional Multipurpose Duplex unit 550‑sheet 2000‑sheet feeder trays (standard tray or optional) 210 x 297 mm (8.3 x 11.7 in.) 148 x 210 mm (5.8 x 8.3 in.) 105 x 148 mm (4.1 x 5.8 in.) JIS B5 182 x 257 mm (7.2 x 10.1 in.)
Page 31: Paper Types And Weights Supported By The Printer
4062 Paper size Dimensions 250‑ or Optional Multipurpose Duplex unit 550‑sheet 2000‑sheet feeder trays (standard tray or optional) 7 3/4 Envelope 98 x 191 mm (Monarch) (3.9 x 7.5 in.) 9 Envelope 98 x 225 mm (3.9 x 8.9 in.) 10 Envelope 105 x 241 mm (4.1 x 9.5 in.)
Page 32: Paper Types And Weights Supported By The Output Bins
4062 Paper type 250‑ or 550‑sheet Optional Multipurpose feeder Duplex unit trays (standard or 2000‑sheet tray optional) Card stock Envelopes Labels • Paper • Vinyl Transparencies Printing labels requires a special label fuser cleaner which is included with the special cartridge required for label applications.
Page 33: Tools Required For Service
4062 Paper type Standard exit bin Optional hardware (350 or 550 Output Expander 5‑Bin Mailbox StapleSmart sheets) (550 sheets) or High Finisher (500 sheets) Capacity Output (500 sheets) Stacker (1850 sheets) Labels • Paper • Vinyl Transparencies Supports 60‑90 g/m (16‑24 lb) paper weights.
Page 34 4062...
Page 35: Diagnostic Information
4062 Diagnostic information • “Troubleshooting overview” on page 35 • “Fixing print quality issues” on page 37 • “Paper jams” on page 55 • “Understanding the printer messages” on page 158 • “User attendance messages” on page 180 • “Printer hardware errors” on page 194 CAUTION—SHOCK HAZARD: Remove the power cord from the electrical outlet before you connect or disconnect any cable or electronic card or assembly for personal safety and to prevent damage to the printer.
Page 36: Power-On Reset (Por) Sequence
4062 • Make sure the printer is properly grounded. Check the power cord ground terminal. • Make sure the power supply line voltage is within 10% of the rated line voltage. • Make sure the machine is securely installed on a level surface in a well‑ventilated area. •...
Page 37: Fixing Print Quality Issues
4062 You can enter Safe Mode in one of the following ways: • Enable Safe Mode from the Conﬁguration menu, and then POR the printer. • Press the Stop and Back keys, and then POR the printer. Return the printer to standard operating mode to service the printer and return to full‑function printing. Safe mode print behavior The following table outlines the behavior for this printer model while in Safe Mode: Safe Mode engine features...
Page 38: Initial Print Quality Check
4062 The symptoms described in this chapter might require replacement of one or more CRUs (Customer Replaceable Units) designated as supplies or maintenance items, which are the responsibility of the customer. With the customer's permission, you might need to install a toner cartridge. Initial print quality check Before troubleshooting speciﬁc print problems, complete the following initial print quality check: •...
Page 39 Check the printhead assembly for proper connection. If necessary, replace the connections or the printhead assembly. Go to “T650 printhead assembly removal” on page 334 “T652, T654, and T656 printhead assembly removal” on page 336. Does the problem remain? Step 8 Contact next level of Problem is solved.
Page 40: Repeating Defects Check
4062 Repeating defects check Actions Step 1 Contact next level of Problem is solved. support. If the distance between defects is equal to 1.11 inch (28.3 mm), then replace the charge rollers. Does the problem remain? Step 2 Contact next level of Problem is solved.
Page 41 Check the left and right transfer roll bracket for damage. If necessary, replace the left or right transfer roll brackets. Go to “T650 printhead assembly removal” on page 334 “T652, T654, and T656 printhead assembly removal” on page 336. Does the problem remain? Step 5 Go to step 6.
Page 42: Solid Black Pages Check
Check the printhead assembly for proper connection. If necessary, replace the connections or the printhead assembly. Go to “T650 printhead assembly removal” on page 334 “T652, T654, and T656 printhead assembly removal” on page 336. Does the problem remain? Step 10 Contact next level of Problem is solved.
Page 43 4062 Action Step 3 Go to step 4. Problem is solved. Check the charge roll electrical contact for damage, and if necessary, replace the charge roll assembly. Go to “Charge roll assembly removal” on page 297. Does the problem remain? Step 4 Go to step 5.
Page 44: Vertical Lines And Bands (Process Direction) Check
4062 Action Step 11 Contact your next Problem is solved. level of support. Check the system card for damage, and if necessary, replace the HVPS. Go to “System card assembly removal” on page 283. Does the problem remain? Vertical lines and bands (process direction) check Leading edge Trailing edge Action...
Page 45: Horizontal White Stripes And Bands (Side To Side Direction) Check
Check the printhead assembly for proper connection. If necessary, replace the connections or the printhead assembly. Go to “T650 printhead assembly removal” on page 334 “T652, T654, and T656 printhead assembly removal” on page 336. Does the problem remain? Step 7 Contact next level of Problem is solved.
Page 46: Vertical Stripes (Process Direction) Check
Check the printhead assembly for proper connection. If necessary, replace the connections or the printhead assembly. Go to “T650 printhead assembly removal” on page 334 “T652, T654, and T656 printhead assembly removal” on page 336. Does the problem remain? Step 6 Contact next level of Problem is solved.
Page 47: Horizontal Stripes (Side To Side Direction) Check
4062 Action Step 5 Go to step 6. Problem is solved. Check the print cartridge for proper installation, and if necessary, clean and reinstall the print cartridge. Does the problem remain? Step 6 Go to step 7. Problem is solved. Check the heat roll and pressure roll.
Page 48: Partial Lack Check
4062 Action Step 4 Go to step 5. Problem is solved. Check the charge roll assembly for contamination and wear, and if necessary replace the charge roll assembly. Go to “Access door removal” on page 270. Does the problem remain? Step 5 Go to step 6.
Page 49: Spots Check
Problem is solved. Check the printhead installation. If necessary, reinstall and adjust the printhead assembly. Go to “T650 printhead assembly removal” on page 334 “T652, T654, and T656 printhead assembly removal” on page 336. Does the error remain? Step 6 Contact next level of Problem is solved.
Page 50 Problem is solved. Check the printhead installation. If necessary, reinstall and adjust the printhead assembly. Go to “T650 printhead assembly removal” on page 334 “T652, T654, and T656 printhead assembly removal” on page 336. Does the problem remain? Diagnostic information...
Page 51: Background (Fog) Check
4062 Action Step 8 Contact next level of Problem is solved. support. Perform a print test. Does the problem remain? Background (fog) check Leading edge A B C D A B C D A B C D A B C D Trailing edge Action Step 1...
Page 52: Skew Check
Problem is solved. Check the printhead installation, and reinstall and adjust the printhead assembly if necessary. Go to “T650 printhead assembly removal” on page 334 “T652, T654, and T656 printhead assembly removal” on page 336. . Does the problem remain? Step 7 Contact next level of Problem is solved.
Page 53: Media Damage Check
4062 Action Step 5 Go to step 6. Problem is solved. Check the alignment assembly for proper adjustment. Go to “Alignment assembly adjustment” on page 268. If necessary, replace the alignment assembly. Go to “Output cover assembly removal” on page 333 Does the problem remain? Step 6 Contact the next...
Page 54: No Fuse Check
4062 Action Step 5 Go to step 6. Problem is solved. Check the alignment assembly for proper adjustment. Go to “Alignment assembly adjustment” on page 268. If necessary, replace the aligner assembly. Go to “Alignment assembly removal” on page 271. Does the problem remain? Step 6 Contact the next...
Page 55: Paper Jams
4062 Action Step 4 Go to step 5. Problem is solved. Remove the fuser unit assembly, and check the heat roll and pressure roll for contamination or cracks. If necessary, replace the fuser unit assembly. Go to “Fuser unit assembly removal” on page 331.
Page 56: Understanding Jam Numbers And Locations
4062 • Do not slide paper into the tray. Load paper as shown in the illustration. • Make sure that the paper guides are properly positioned. • Push the tray ﬁrmly into the printer after loading paper. Use recommended paper •...
Page 57: How To Clear 200-201 Paper Jams
4062 Jam numbers Area 271–279 Optional output bins 280–282 StapleSmart II Finisher Staple cartridge How to clear 200-201 paper jams 200 and 201 paper jams Push the release latch, and then lower the multipurpose feeder door. Push the release latch, and then open the front cover. Lift and pull the print cartridge out of the printer.
Page 58 4062 Remove the jammed paper. CAUTION—HOT SURFACE: The inside of the printer might be hot. To reduce the risk of injury from a hot component, allow the surface to cool before touching. Note: If the paper is not easy to remove, then open the rear door and remove the paper from there. Align and reinstall the print cartridge.
Page 59 4062 Error code Description Action 200.09 Printhead laser start failure Go to “Printhead laser start failure service check” on page The printhead laser start process failed because it did not receive proper feedback signal from the printhead motor. 200.10 Printhead motor synchronization error The printhead motor is not synchronized when media reaches the sensor (input).
Page 60 4062 Error code Description Action 200.17 Sensor (input) lingering jam (tray 1 and tray level Go to “Sensor (input) lingering jam service not low) check” on page The media reached the sensor (input) but did not clear it within the speciﬁed time. 200.18 Sensor (input) lingering jam (tray 1 and tray level low)
Page 61 4062 Error code Description Action 200.37 Sensor (input) lingering jam (tray 3 and tray level Go to “Sensor (input) lingering jam service not low) check” on page The media reached the sensor (input) but did not clear it within the speciﬁed time. 200.38 Sensor (input) lingering jam (tray 3 and tray level low)
Page 62 4062 201 error messages Error code Description Action 201.00 Sensor (fuser output) area jam (type 1 fuser) Go to “Sensor (fuser output) service check” on page The media is jammed in the sensor (fuser output) area. 201.01 Main drive motor assembly load error (type 1 fuser) Go to “Main drive motor assembly load error service check”...
Page 63 4062 Error code Description Action 201.30 Operator panel door assembly interlock switch Go to “Operator panel door assembly switch failure (type 2 fuser) failure service check” on page The printer detected that the switch (operator panel door interlock) did not cycle prior to printer restart.
Page 64 4062 Error code Description Action 201.57 Sensor (fuser output) late jam (type 1 fuser and Go to “Sensor (fuser output) late jam service fuser page count exceeds life) check” on page The media is late reaching the sensor (fuser output) within the speciﬁed time. 201.75 Sensor (fuser output) late jam (type 1 fuser and fuser page count exceeds life)
Page 65 4062 Sensor (input) service check Action Step 1 Go to step 2. Problem is solved. Fan the media, ensure the media is properly installed and check the paperpath for obstructions. Does the problem remain? Step 2 Go to step 3. Problem is solved.
Page 66 4062 Action Step 4 Go to step 5. Problem is solved. Check the fuser unit assembly for excess wear and damage. If necessary, replace the fuser unit assembly. See “Fuser unit assembly removal” on page 331. Does the problem remain? Step 5 Go to step 7.
Page 67 4062 Action Step 10 Go to step 11. Problem is solved. Remove obstructions in the aligner assembly. Does the problem remain? Step 11 Contact next level of Problem is solved. support. Perform a print test. Does the problem remain? Sensor (input) early jam service check Action Step 1 Go to step 2.
Page 68 4062 Action Step 7 Go to step 8. Problem is solved. Remove any prestaged or jammed media in all the trays. Does the problem remain? Step 8 Go to step 10. Go to step 9. Check the sensor (input) for proper operation. Enter the diagnostic mode.
Page 69 Go to step 13. Problem is solved. Check the above sensor for proper connection, and if necessary, replace the connection or sensor (duplex input). See “Sensor (duplex input) removal (T652, T654, T656)” on page 340. Does the problem remain? Diagnostic information...
Page 70 Problem is solved. Perform a print test and check the duplex drive motor assembly for proper operation. If necessary, replace the duplex drive motor assembly. See “T652, T654, and T656 duplex drive motor assembly removal” on page 328. Does the problem remain? Step 14 Go to step 15.
Page 71 4062 Action Step 19 Go to step 20. Problem is solved. Check the sensor (input) for proper operation. Enter the diagnostic mode. Select Base sensor test. Observe the line item “input.” Does the problem remain? Step 20 Go to step 21. Problem is solved.
Page 72 4062 Sensor (input) static jam service check Action Step 1 Go to step 2. Problem is solved. Remove any prestaged or jammed media. Does the problem remain? Step 2 Go to step 4. Go to step 3. Check the sensor (input) for proper operation. Enter the diagnostic mode.
Page 73 Step 4 Go to step 5. Problem is solved. Replace the printhead. See “T650 printhead assembly removal” on page 334 “T652, T654, and T656 printhead assembly removal” on page 336. Does the problem remain? Step 5 Contact next level of Problem is solved.
Page 74 4062 Action Step 7 Go to step 8. Problem is solved. Check if the display on the operator panel changes every time the sensing area of the sensor (narrow media) is interrupted or blocked? Enter the diagnostic mode. Select Base sensor tests. Observe the line item “input.”...
Page 75 4062 Main drive motor assembly load error service check Action Step 1 Go to step 2. Problem is solved. Check the fuser wiper cover assembly for missing parts or damage, such as cracks. If necessary, replace the fuser wiper cover assembly.
Page 76 Problem is solved. Check the operator panel assembly door for damage. If necessary, replace the operator panel assembly door. See “T650, T652, and T654 operator panel door assembly removal” on page 305 “T656 operator panel door assembly removal” on page 310.
Page 77 4062 Sensor (toner empty) service check Action Step 1 Go to step 2. Problem is solved. Inspect the print cartridge pulse wheel for damage, and if necessary, replace the print cartridge pulse wheel. Does the problem remain? Step 2 Go to step 3. Problem is solved.
Page 78 4062 Action Step 3 Problem is solved. Go to step 4. Enter the diagnostic mode. Select Base sensor test. Observe the line item “exit.” Does the display on the operator panel change every time the sensing area of the above sensor is interrupted or blocked? Step 4 Contact next level of Problem is solved.
Page 79 4062 Action Step 6 Go to step 7. Check the sensor (fuser output) for proper operation. Enter the Diagnostic mode Select Base sensor test. Observe the line item, “output.” Does the display on the operator panel change every time the sensing area of the above sensor is interrupted or blocked? Step 7 Go to step 8.
Page 80: How To Clear 202-203 Paper Jams
Step 4 Go to step 5. Problem is solved. Replace the printhead. See “T650 printhead assembly removal” on page 334 “T652, T654, and T656 printhead assembly removal” on page 336. Does the problem remain? Step 5 Contact next level of Problem is solved.
Page 81 4062 If the paper is not exiting the printer: Pull down the top rear door. Slowly remove the jammed paper to avoid tearing it. Close the top rear door. Press 202 error messages Error code Description Action 202.00 Paper jam around fuser exit or redrive area (type Go to “Paper jam around fuser exit or redrive 1 fuser)
Page 82 4062 Error code Description Action 202.07 Sensor (fuser output) lingering jam (type 1 fuser) Go to “Sensor (fuser output) lingering jam service check” on page 89 Media reached the sensor (fuser output), but did not clear it in the speciﬁed time 202.09 Sensor (fuser output) lingering jam (type 1 fuser) Media reached the sensor (fuser output), but did...
Page 83 4062 Error code Description Action 202.31 Sensor (fuser output) static jam (type 2 fuser) Go to “Sensor (fuser output) static jam service check” on page 90 Media remains on the sensor (fuser output) during the warm-up sequence. 202.32 Sensor (fuser output) lingering jam (type 2 fuser) Go to “Sensor (fuser output) lingering jam service check”...
Page 84 4062 Error code Description Action 202.53 Sensor (narrow media) static jam (type 1 fuser and Go to “Sensor (narrow media) static jam fuser page count exceeded life) service check” on page 91 Media remains on the sensor (narrow media) during the warm‑up sequence. 202.54 Sensor (fuser output) bounce (type 1 fuser and Go to...
Page 85 4062 Error code Description Action 202.63 Sensor (fuser output) static jam and sensor Go to “Paper jam around fuser exit or redrive (narrow media) static jam (type 1 fuser and fuser area service check” on page 87 page count exceeded life) Media remains on the sensor (fuser output) and the sensor (narrow media) during the warm‑up sequence.
Page 86 4062 Error code Description Action 202.82 Sensor (fuser output) lingering jam (type 2 fuser Go to “Sensor (fuser output) lingering jam and fuser page count exceeded life) service check” on page 89 Media reached the sensor (fuser output), but did not clear it in the speciﬁed time.
Page 87 4062 203 error messages Error code Description Action 203.00 Paper jam around redrive area Go to “Paper jam around fuser exit or redrive area service check” on page Page may be jammed in redrive area. 203.01 Internal duplex drive motor control failure (internal Go to “Internal duplex drive motor control duplex)
Page 88 4062 Action Step 4 Go to step 5. Problem is solved. Check the sensor (fuser output) for damage. If necessary, replace the fuser unit assembly. See “Fuser unit assembly removal” on page 331. Does the problem remain? Step 5 Go to step 6 Go to step 6.
Page 89 4062 Sensor (fuser output) lingering jam service check Action Step 1 Go to step 2. Problem is solved. Check the fuser wiper cover assembly for missing parts or damage, such as cracks. If necessary, replace the fuser wiper cover assembly. See “Fuser wiper cover assembly removal”...
Page 90 Problem is solved. Perform a print test and check the redrive motor assembly for proper operation. If necessary, replace the redrive motor assembly. “T652, T654, and T656 redrive motor assembly removal” on page 338. Does the above component operate properly?
Page 91 4062 Action Step 4 Replace the fuser Problem is solved. unit assembly. See Check the above sensor for proper connection, and if necessary, “Fuser unit replace the connection. assembly removal” on page 331. Does the problem remain? Step 5 Contact next level of Problem is solved.
Page 92 Contact next level of Problem is solved. tech support. Replace the duplex media entrance drive motor assembly if problem remains. See “T652, T654, and T656 duplex drive motor assembly removal” on page 328. Does the problem remain? Redrive motor load error service check...
Page 93: How To Clear 230 Paper Jams
4062 Action Step 4 Go to step 4. Problem is solved. Check all connections on the system card assembly, and if necessary, replace the connections. Does the problem remain? Step 5 Contact next level of Problem is solved. support. Replace the redrive motor assembly if problem remains. See “Redrive assembly removal”...
Page 94 4062 Pull down the bottom rear door. Push the tab down. Remove the jammed paper. Close the bottom rear door. Insert the standard tray. Press Diagnostic information...
Page 95 4062 Front paper jams Remove the standard tray from the printer. Push the tab down. Remove the jammed paper. Insert the standard tray. Press 230 error messages Error code Description Action 230.00 Paper jam around internal duplex (internal duplex) Go to “Paper jam around internal duplex service check”...
Page 96 4062 Error code Description Action 230.05 Sensor (duplex input) lingering jam (internal Go to “Sensor (pass through) late jam service duplex) check” on page Media reached the sensor (duplex input) but did not clear it in the speciﬁed time. 230.06 Sensor (input) late jam from duplex (internal Go to “Sensor (input) late jam service check”...
Page 97 Go to step 6. Problem is solved. Check the sensor (duplex input) for damage, and if necessary, replace the sensor (duplex input). See “Sensor (duplex input) removal (T652, T654, T656)” on page 340. Does the problem remain? Step 6 Contact next level of Problem is solved.
Page 98 4062 Sensor (pass through) late jam service check Action Step 1 Go to step 2. Problem is solved. Replace the media, or change the media size setup in all the trays. Does the problem remain? Step 2 Go to step 3. Problem is solved.
Page 99 4062 Action Step 7 Go to step 8. Problem is solved. Perform a print test and check the pick arm assembly for the appropriate media tray if media is properly picked and advanced out of the tray. If necessary, replace the appropriate pick arm assembly.
Page 100 Enter the diagnostic mode. Select Duplex tests. Select Sensor test. Observe the line item “input.” If necessary, replace the connection or the sensor (duplex input). “Sensor (duplex input) removal (T652, T654, T656)” on page 340. Does the problem remain? Step 8 Go to step 9.
Page 101 Go to step 2. Problem is solved. Check the sensor (duplex input) for damage, and if necessary, replace the sensor (duplex input). See “Sensor (duplex input) removal (T652, T654, T656)” on page 340. Step 2 Contact next level of Problem is solved.
Page 102 Contact next level of Problem is solved. support. Check all cable connections on the system card assembly. If necessary, replace the duplex drive motor assembly. See “T652, T654, and T656 duplex drive motor assembly removal” on page 328. Does the problem remain?
Page 103 Enter the diagnostic mode. Select Duplex tests. Select Sensor test. Observe the line item “input.” If necessary, replace the connection or the sensor (duplex input). “Sensor (duplex input) removal (T652, T654, T656)” on page 340. Does the problem remain? Step 4 Go to step 5.
Page 104: How To Clear 231-239 Paper Jams
4062 How to clear 231-239 paper jams 231–239 paper jams (optional external duplex unit) Rear paper jams Push in and hold the latch while pulling up the rear duplex door. Remove the jammed paper. Close the rear duplex door. Press Front paper jams Remove the standard tray from the printer.
Page 105 4062 Raise the recessed duplex bar. Remove the jammed paper. Replace the duplex jam access tray. Insert the standard tray. Press 231‑237 error messages Error code Description Action 231.00 Sensor (duplex input) late jam (external duplex) Go to “Sensor (duplex input) late jam service check”...
Page 106 4062 Error code Description Action 235.00 Sensor (duplex double-feed) lingering jam Go to “Sensor (duplex double-feed) lingering (external duplex) jam service check” on page 110. Media reached the sensor (duplex double-feed) within the speciﬁed time but did not clear it within the speciﬁed time.
Page 107 4062 Error code Description Action 238.05 Sensor (duplex input) static jam and sensor Go to “Sensor (duplex input) lingering jam (double-feed) static jam (external duplex) service check” on page 102. Media remains on the sensor (duplex input) and the sensor (double-feed) during the warm-up sequence.
Page 108 4062 Error code Description Action 239.11 Sensor (input) late jam from duplex (external Go to “Sensor (input) late jam service check” duplex) on page Media is late reaching the sensor (input) within the speciﬁed time during the second side printing using the external duplex.
Page 109 4062 Action Step 3 Go to step 4. Problem is solved. Remove obstructions in the media path. Does the problem remain? Step 4 Go to step 5. Problem is solved. Remove, and then properly reinstall the external duplex assembly. Does the problem remain? Step 5 Go to step 6.
Page 110 4062 Sensor (duplex exit) service check (external duplex only) Action Step 1 Go to step 2. Problem is solved. Check the sensor (duplex exit) for damage, and if necessary, replace the external duplex unit assembly. Does the problem remain? Step 2 Contact next level of Problem is solved.
Page 111 4062 Sensor (duplex exit) lingering jam service check Action Step 1 Go to step 2. Problem is solved. Remove all media present in media path. Does the problem remain? Step 2 Go to step 3. Problem is solved. Reinstall all media properly. Does the problem remain? Step 3 Go to step 4.
Page 112 4062 Action Step 3 Go to step 4. Problem is solved. Remove obstructions in the media path. Does the problem remain? Step 4 Go to step 5. Problem is solved. Remove, and then properly reinstall the external duplex assembly. Does the problem remain? Step 5 Go to step 6.
Page 113 Observe the line item “input.” If necessary, replace the external duplex unit assembly (external duplex only) or the duplex input sensor assembly (internal duplex only). See “T652, T654, and T656 duplex input sensor assembly removal” on page 317. Does the problem remain?
Page 114 4062 Action Step 4 Go to step 5. Problem is solved. Check the sensor (duplex exit) for damage, and if necessary, replace the external duplex unit assembly. Does the problem remain? Step 5 Contact next level of Problem is solved. support.
Page 115: How To Clear 241-245 Paper Jams
4062 Action Step 6 Go to step 7. Problem is solved. Check all cable connections on the external duplex assembly, and if necessary, replace the connections. Does the problem remain? Step 7 Contact next level of Problem is solved. support. Check the external duplex assembly for damage, and if necessary, replace the external duplex assembly.
Page 116 4062 241 error messages Error code Description Action 241.00 Media tray 1 area jam Go to “Tray area jam service check” on page 125. The media is jammed in the media tray 1 area. 241.01 Pick motor control failure (media tray 1) Go to “Tray pick motor load error service check”...
Page 117 4062 242 error messages Error code Description Action 242.00 Media tray 2 area jam Go to “Tray area jam service check” on page 125. The media is jammed in the media tray 2 area. 242.02 Sensor (pass through) late jam (tray 2) Go to “Sensor (pass through) late jam service check”...
Page 118 4062 Error code Description Action 242.32 Tray 2 pick motor overrun failure (tray 2) Go to “Tray pick motor lost encoder failure service check” on page 129. The pick motor encoder continues to detect pulses after the motor was turned off. 242.33 Tray 2 not ready (tray 2) Go to...
Page 119 4062 Error code Description Action 242.66 Pick motor underspeed error (tray 2) Go to “Tray pick motor control failure service check” on page 128. The pick motor does not rotate at the speciﬁed speed. 242.67 Pick motor overspeed error (tray 2) The pick motor does not rotate at the speciﬁed speed.
Page 120 4062 Error code Description Action 243.18 Pick retry timeout (tray 3) The engine timed out waiting for the tray 3 to 243.19 report ready before the ﬁrst pick attempt. Thus, turn the machine off, and then turn it on. 243.33 Tray 3 not ready (tray 3) Go to “Tray not ready service check”...
Page 121 4062 Error code Description Action 243.66 Pick motor underspeed error (tray 3) Go to “Tray pick motor control failure service check” on page 128. The pick motor does not rotate at the speciﬁed speed. 243.67 Pick motor overspeed error (tray 3) The pick motor does not rotate at the speciﬁed speed.
Page 122 4062 Error code Description Action 244.18 Pick retry timeout (tray 4) The engine timed out waiting for the tray 4 to 244.19 report ready before the ﬁrst pick attempt. Thus, turn the machine off, and then turn it on. 244.33 Tray 4 not ready (tray 4) Go to “Tray not ready service check”...
Page 123 4062 Error code Description Action 244.66 Pick motor underspeed error (tray 4) Go to “Tray pick motor control failure service check” on page 128. The pick motor does not rotate at the speciﬁed speed. 244.67 Pick motor overspeed error (tray 4) The pick motor does not rotate at the speciﬁed speed.
Page 124 4062 Error code Description Action 245.18 Pick retry timeout (tray 5) The engine timed out waiting for the tray 5 to 245.19 report ready before the ﬁrst pick attempt. Thus, turn the machine off, and then turn it on. 245.33 Tray 5 not ready (tray 5) Go to “Tray not ready service check”...
Page 125 4062 Error code Description Action 245.66 Pick motor underspeed error (tray 5) Go to “Tray pick motor control failure service check” on page 128. The pick motor does not rotate at the speciﬁed speed. 245.67 Pick motor overspeed error (tray 5) The pick motor does not rotate at the speciﬁed speed.
Page 126 4062 Action Step 3 Go to step 4. The problem is solved. Check if the display on the operator panel changes every time the sensing area of the media tray sensor (pass through) is interrupted or blocked. Enter the Diagnostic mode. Select Input tray tests.
Page 127 4062 Sensor (pass through) static jam service check Action Step 1 Go to step 2. Problem is solved. Remove any prestaged or jammed media in the media path. Does the problem remain? Step 2 Go to step 3. Problem is solved. Check if the display on the operator panel changes every time the sensing area of the media tray sensor (pass through) is interrupted or blocked.
Page 128 4062 Action Step 4 Go to step 5. Problem is solved. Check all connections on the pick arm assembly, and if necessary, replace the connections. Does the problem remain? Step 5 Go to step 6. Problem is solved. Check all connections on the system card assembly, and if necessary, replace the connections.
Page 129 4062 Action Step 5 Go to step 6. Problem is solved. Replace the pick arm assembly. See “Pick arm assembly removal” on page 320. Does the problem remain? Step 6 Contact next level of Problem is solved. support. Replace the system card assembly. See “System card assembly removal”...
Page 130 4062 Tray not ready service check Action Step 1 Go to step 2. Problem is solved. Check the size sensing ﬁngers on the media tray for damage, and if necessary, replace the media tray assembly. Does the problem remain? Step 2 Contact next level of Problem is solved.
Page 131: How To Clear 250 Paper Jams
4062 How to clear 250 paper jams 250 paper jam Remove the paper from the multipurpose feeder. Flex the sheets of paper back and forth to loosen them, and then fan them. Do not fold or crease the paper. Straighten the edges on a level surface. Load the paper into the multipurpose feeder.
Page 132: How To Clear 260 Paper Jams
4062 250 error messages Error code Description Action 250.00 MPF area jam Go to “Sensor (input) service check” on page The media is jammed in the media tray 5 area. 250.03 Sensor (input) late jam (MPF) Go to “Sensor (input) late jam service check” on page The media is late reaching the sensor (input) 250.06...
Page 133 4062 Adjust the paper guide. Lower the envelope weight. Press 260 error messages Error code Description Action 260.00 Envelope feeder area jam Go to “Envelope feeder area jam service check” on page 134. The media is jammed in the envelope feeder area. 260.01 Envelope feeder assembly error Go to...
Page 134 4062 Envelope feeder area jam service check Action Step 1 Go to step 2. Problem is solved. Remove the envelope feeder. Does the problem remain? Step 2 Go to step 3. Problem is solved. Remove all media present in media path. Does the problem remain? Step 3 Go to step 4.
Page 135 4062 Envelope feeder assembly error service check Action Step 1 Go to step 2. Problem is solved. Remove the envelope feeder. Does the problem remain? Step 2 Go to step 3. Problem is solved. Remove all media present in media path. Does the problem remain? Step 3 Go to step 4.
Page 136 4062 Action Step 3 Go to step 4. Problem is solved. Remove obstructions in the media path. Does the problem remain? Step 4 Go to step 5. Problem is solved. Properly install the envelope feeder assembly. Does the problem remain? Step 5 Go to step 6.
Page 137: How To Clear 270 Paper Jams
4062 Action Step 6 Go to step 7. Problem is solved. Check all connections on the system card assembly, and if necessary, replace the connections. Does the problem remain? Step 7 Go to step 8. Problem is solved. Replace the envelope feeder assembly. Does the problem remain? Step 8 Contact next level of...
Page 138 4062 Close the output bin door or doors. Press 270 error messages Error code Description Action 271.03 Sensor (output pass through) lingering jam (high Go to “Sensor (output pass through) lingering capacity output and output expander) jam service check” on page 139.
Page 139 4062 Error code Description Action 27x.50 Left tamper does not leave home position failure Go to “Left tamper does not leave home (offset stacker) position failure (offset stacker) service check” on page 142. The sensor (left tamper HP) does not detect that the tamper has moved from home position.
Page 140 4062 Action Step 3 Go to step 4. Problem is solved. Check if the display on the operator panel changes every time the sensing area of the sensor (output pass through) is interrupted or blocked. Enter the diagnostic mode. Select Output bin tests. Select Sensor test.
Page 141 4062 Sensor (output pass through and mailbox empty) static jam service check Action Step 1 Go to step 2. Problem is solved. Remove any prestaged or jammed media from the media path. Does the problem remain? Step 2 Go to step 3. Problem is solved.
Page 142 4062 Left tamper does not leave home position failure (offset stacker) service check Action Step 1 Go to step 2. Problem is solved. Check all the connections on the output option controller card, and if necessary, replace the connections. Does the problem remain? Step 2 Go to step 3.
Page 143 4062 Action Step 3 Go to step 4. Problem is solved. Check if the display on the operator panel changes every time the sensing areas of the sensor (mailbox empty) is interrupted or blocked. Enter Diagnostic mode. Select Output bin tests. Select Sensor test.
Page 144: How To Clear 280 Paper Jams
4062 Action Step 3 Go to step 4. Problem is solved. Check if the display on the operator panel changes every time the sensing areas of the sensor (mailbox empty) is interrupted or blocked. Enter Diagnostic mode. Select Output bin tests. Select Sensor test.
Page 145 4062 Close the StapleSmart II Finisher door. Press 281 paper jam Clear the jam from the stapler output bin. Press 282 paper jam To prevent paper jams, the stapler motor does not run when the stapler door is open. Close the stapler door until it clicks into place. Press Diagnostic information...
Page 146 4062 283 staple jam Press the latch to open the stapler door. Pull the latch of the staple cartridge holder down, and then pull the holder out of the printer. Use the metal tab to lift the staple guard, and then remove any loose staples. Diagnostic information...
Page 147 4062 Press down on the staple guard until it snaps into place. Push the cartridge holder ﬁrmly back into the stapler unit until the cartridge holder clicks into place. Close the stapler door. Press 280 error messages Error code Description Action 28x.25 Invalid ejector motor manager status (staple...
Page 148 4062 Error code Description Action 28x.31 Transport motor encoder not detected (staple Go to “Transport motor encoder not detected ﬁnisher) (staple ﬁnisher) service check” on page 154. The output option transport motor encoder is not detected upon startup. 28x.32 Transport motor encoder not detected (staple ﬁnisher) The transport motor encoder detection is lost during normal operation.
Page 149 4062 Error code Description Action 28x.40 Left tamper does not leave home position failure Go to “Sensor (mailbox empty) lingering jam (staple ﬁnisher) service check” on page 142. The sensor (left tamper HP) does not detect that the tamper has moved from home position. 28x.41 Left tamper does not move to home position failure (staple ﬁnisher)
Page 150 4062 Error code Description Action 28x.50 Left tamper home position jam (staple ﬁnisher) Go to “Sensor (mailbox empty) lingering jam service check” on page 142. The left tamper home position is not detected by the sensor (left tamper HP). 28x.51 Right tamper home position jam (staple ﬁnisher) The left tamper home position is not detected by the sensor (right tamper HP).
Page 151 4062 Error code Description Action 28x.60 The status of stapler motor is not deﬁned (staple Go to “Transport motor encoder not detected ﬁnisher) (staple ﬁnisher) service check” on page 154. A software failure has occurred with the output option. 28x.61 DMID command is not received for 500 ms after main motor runs (staple ﬁnisher) A software failure has occurred with the output...
Page 152 4062 Error code Description Action 28x.68 Staple ready home position jam (staple ﬁnisher) Go to “Sensor (self priming) late failure (staple ﬁnisher) service check” on page 154. The sensor (self priming) within the stapler assembly does not detect a ready staple prior to a staple job.
Page 153 4062 Sensor (stapler pass through) lingering jam service check Action Step 1 Go to step 2. Problem is solved. Remove, and then reinstall the staple ﬁnisher. Does the problem remain? Step 2 Go to step 3. Problem is solved. Remove obstructions between the sensor (stapler pass through) machine and the media bin in the media path.
Page 154 4062 Transport motor encoder not detected (staple ﬁnisher) service check Action Step 1 Go to step 2. Problem is solved. Check all connections on the staple ﬁnisher controller card for damage. If necessary, replace the connections. Does the problem remain? Step 2 Contact next level of Problem is solved.
Page 155 4062 Action Step 5 Contact next level of Problem is solved. support. Replace the stapler assembly. Go to “SFP stapler assembly rear door assembly removal” on page 431. Does the problem remain? Paddle home position jam (staple ﬁnisher) service check Action Step 1 Go to step 2.
Page 156 4062 Sensor (stapler pass through) static jam service check Action Step 1 Go to step 2. Problem is solved. Remove any prestaged or jammed media from the media path. Does the problem remain? Step 2 Go to step 3. Problem is solved. Check if the display on the operator panel changes every time the sensing area of the sensor (stapler pass through) is interrupted or blocked.
Page 157 4062 Sensor (output pass through) late jam service check Action Step 1 Go to step 2. Problem is solved. Remove, and then reinstall the output option. Does the problem remain? Step 2 Go to step 3. Problem is solved. Remove obstructions between the base machine and the output option.
Page 158: Understanding The Printer Messages
4062 Sensor (media in stapler) static jam (staple ﬁnisher) service check Action Step 1 Go to step 2. Problem is solved. Check if the sensor (media in stapler) is properly installed. If necessary, reinstall the sensor. Does the problem remain? Step 2 Contact next level of Problem is solved.
Page 159: Check Duplex Connection
4062 Check duplex connection Try one or more of the following: • Turn the printer off and then back on. If the error occurs a second time: Turn the printer off. Unplug the power cord from the wall outlet. Remove the duplex unit. Reattach the duplex unit.
Page 160: Defragmenting Flash Do Not Power Off
4062 Defragmenting Flash DO NOT POWER OFF Wait for the message to clear. Warning—Potential Damage: Do not turn the printer off while this message appears on the display. Deleting Wait for the message to clear. Deleting held jobs Wait for the message to clear. Deletion complete Wait for the message to clear.
Page 161: Enabling Menus
4062 Disk recovery takes place in several phases. The percentage completed during each phase appears on the display. Enabling Menus Wait for the message to clear. Encrypting disk x/y XX% DO NOT POWER OFF Wait for the message to clear. Warning—Potential Damage: Do not power off while the printer is encrypting the printer hard disk.
Page 162: Insert Staple Cartridge
4062 Insert staple cartridge Try one or more of the following: • Insert a staple cartridge to clear the message. • Press to clear the message and print without using the staple feature. Insert Tray <x> Insert the speciﬁed tray into the printer. Install bin <x>...
Page 163: Install Tray
The printer does not have a MICR cartridge installed. Install a MICR cartridge to continue printing. Invalid Engine Code You need to download valid engine code for the printer. For more information, visit the Lexmark Web site at www.lexmark.com. Note: Engine code may be downloaded while this message appears on the display. Invalid Network Code You need to download valid network printing code for the internal print server.

Page 164: Load With
4062 Load <src> with <x> <src> is a tray or feeder, and <x> is a paper type or size. Try one or more of the following: • Load the paper tray or other source with the correct paper type and size. •...

Page 165: No Held Jobs
4062 Network <x>, <y> indicates a network interface is the active communication link, where <x>, <y> • indicates the active interface is connected to the printer through channel y on PCI connector x. If x equals 0, then the standard network interface is active. Note: The current interface displays on the menus settings page.
Page 166: Power Saver
4062 Power Saver The printer is saving power while it waits for the next print job. Send a job to print to take the printer out of Power Saver mode. Printer busy, Continue, Quit Try one or more of the following: •...
Page 167: Reattach Bin
4062 Reattach bin <x> Try one or more of the following: • Turn the printer off and then back on. If the error occurs a second time: Turn the printer off. Unplug the power cord from the wall outlet. Remove the speciﬁed bin. Reattach the bin.

Page 168: Remote Management Active Do Not Power Off
4062 Reattach the envelope feeder. Connect the power cord to a properly grounded outlet. Restart the printer. • Press to clear the message and print without using the envelope feeder. Remote Management Active DO NOT POWER OFF The printer settings are being conﬁgured. Wait for the message to clear. Warning—Potential Damage: Do not turn the printer power off while Remote Management Active appears on the display.
Page 169: Resetting Active Bin
4062 Resetting active bin Wait for the message to clear. Resetting the printer Wait for the message to clear. Resetting without replacing may affect print quality. You selected No from the “Verify PC unit replaced” screen. Wait for the message to clear. Restoring Factory Defaults Wait for the message to clear.
Page 170: Securely Clearing Disk Space
4062 Securely clearing disk space The printer hard disk wiping process needs to recover. The message clears when all blocks are cleared. Serial <x> The printer is using a serial cable connection. The serial port is the active communication link. Some held jobs were lost Try one or more of the following: Continue appears, and then press...
Page 171: Toner Low
4062 Toner low Try one or more of the following: • Replace the print cartridge. • Press to clear the message and continue printing. Tray <x> Empty Load paper in the tray to clear the message. Tray <x> Low Load paper in the speciﬁed tray to clear the message. Tray <x>...
Page 172: Waiting
4062 Waiting The printer has received data to print, but is waiting for an End‑of‑Job command, a Form Feed command, or additional data. Try one or more of the following: • Press to print the contents of the buffer. • Cancel the current print job.
Page 173: 37 Insufficient Memory For Flash Memory Defragment Operation
4062 37 Insufficient memory for Flash Memory Defragment operation Try one or more of the following: • Continue appears, and then press Press the arrow buttons until to stop the defragment process and continue printing. • Delete fonts, macros, and other data in printer memory. •...
Page 174: 42.Xy Cartridge Region Mismatch
4062 42.xy Cartridge region mismatch Install a print cartridge that matches the region number of the printer. x indicates the value of the printer region. y indicates the value of the cartridge region. x and y can have the following values: Europe, the Middle East, and Africa Asia Latin America...
Page 175: 53 Unformatted Flash Detected
4062 53 Unformatted ﬂash detected Try one or more of the following: • Continue appears, and then press Press the arrow buttons until to stop the defragment operation and continue printing. • Format the ﬂash memory. If the error message remains, the ﬂash memory may be defective and require replacing.
Page 176: 56 Parallel Port Disabled
4062 Connect the power cord to a properly grounded outlet. Turn the printer power back on. 56 Parallel port <x> disabled <x> is the number of the parallel port. Try one or more of the following: Continue appears, and then press •...
Page 177: 58 Too Many Bins Attached
4062 • The print job was created using data from a device in the USB port and the device is no longer in the port. • The printer hard disk contains jobs that were stored while installed in a different printer model. Continue appears, and then press Press the arrow buttons until to clear the message.
Page 178: 59 Incompatible Duplex
4062 Connect the power cord to a properly grounded outlet. Turn the printer back on. 59 Incompatible Duplex Only options designed speciﬁcally for this printer are supported. Try one or more of the following: • Remove the duplex unit. • Press to clear the message and continue printing without using the duplex unit.
Page 179: 62 Disk Full
4062 62 Disk full Try one or more of the following: • Continue appears, and then press Press the arrow buttons until to clear the message and continue processing. • Delete fonts, macros, and other data stored on the printer hard disk. •...
Page 180: 1565 Emulation Error, Load Emulation Option
1565 Emulation error, load emulation option The printer automatically clears the message in 30 seconds and then disables the download emulator on the ﬁrmware card. To ﬁx this, download the correct download emulator version from the Lexmark Web site at www.lexmark.com. User attendance messages User attendance messages (0‑99)
Page 181 4062 Error code Description Action 44.01 An RFID error occurred. “RFID error service check” on page 186. 44.11 “RFID error service check” on page 186. 44.12 44.13 44.14 44.15 44.16 44.17 44.18 44.19 44.20 44.21 44.22 44.23 44.24 44.25 44.26 44.27 44.28 44.29...
Page 182 4062 Error code Description Action The printer was not able to connect with the “Network software eror service check” on standard network. page 190. The printer was not able to connect with an optional network. The internal option installed is unsupported. “Unsupported Option in Slot [x] service check”...
Page 183: System Timeout Service Check
4062 System timeout service check Action Turn off the printer, wait for a few seconds, and then turn on the Contact next level of Problem is solved. printer. support. Does the problem remain? Invalid print cartridge service check Action Install the proper print cartridge. Contact next level of Problem is solved.
Page 184: Short Paper Service Check
4062 Short paper service check Action Step 1 Go to step 2. Problem is solved. Set the media tray guides properly for the media being used. Does the problem remain? Step 2 Go to step 3. Problem is solved. Remove and then reinstall the switch (media size). Go to “Switch (media size) assembly removal ”...
Page 185: Insufficient Collation Area Service Check
4062 Insufficient Collation Area service check Action Step 1 Go to step 2. Problem is solved. Delete fonts, macros, and other data in RAM. Does the problem remain? Step 2 Contact next level of Problem is solved. support. Install additional memory. Does the problem remain? Insufficient Memory service check Action...
Page 186: Rfid Error Service Check
4062 Action Step 6 Contact next level of Problem is solved. support. Reset the active media bin. Does the problem remain? RFID error service check Action Step 1 Go to step 2. Problem is solved. Use new RFID media. Does the problem remain? Step 2 Go to step 3.
Page 187: Rfid Error Service Check
4062 RFID error service check Action Step 1 Go to step 2. Problem is solved. Reinstall the RFID ﬁrmware card, RFID interface card, RFID cable, and RFID option. Go to “RFID UHF option installation and removal” on page 402. Does the problem remain? Step 2 Contact next level of Problem is solved.
Page 188: Network Service Check
4062 Network service check Action Step 1 Go to step 3. Go to step 2. If the device is physically connected to the network, verify that the Ethernet cable is properly connected on both ends. Is the cable properly connected? Step 2 Go to step 3.
Page 189 4062 Action Step 10 Go to step 12. Go to step 11. Have the network administrator verify that the subnet addresses of the IP addresses of the printer and the computer are identical. Are the subnet addresses identical? Step 11 Go to step 12.
Page 190: Network Software Eror Service Check
4062 Action Step 19 Go to step 20. Problem is solved. Properly reseat the wireless card. Does the problem remain? Step 20 Go to step 21. Go to step 20. Check the antenna for damage, and replace if necessary. Does the problem remain? Step 21 Go to step 23.
Page 191: Invalid Tray Conﬁguration Service Check
4062 Invalid Tray Conﬁguration service check Action Step 1 Go to step 2. Problem is solved. Place the RFID option above all other optional input trays or place at least one optional input tray under it. Does the problem remain? Step 2 Go to step 3.
Page 192: Too Many Trays Attached Service Check
4062 Too Many Trays Attached service check Action Contact next level of Problem is solved. Turn off the printer, and unplug it. support. Remove the excess trays. Plug in the printer, and turn it on. Does the problem remain? Incompatible Duplex service check Action Contact next level of Problem is solved.
Page 193: Incompatible Output Tray [X] Service Check
4062 Incompatible Output Tray [x] service check Action Contact next level of Problem is solved. Turn off the printer, and unplug it. support. Remove the incompatible trays. Plug in the printer, and turn it on. Does the problem remain? Defective Disk service check Action Replace the hard disk with a higher-capacity hard disk.
Page 194: Replace Fuser Service Check
4062 Replace fuser service check Action Step 1 Go to step 2. The problem is solved. Update the printer ﬁrmware to at least P631a/E220. Replace the fuser. Go to “Fuser unit assembly removal” on page 331. Does the problem remain? Step 2 Contact the next The problem is...
Page 195 4062 se is required to access the printer diagnostic information • Click History Information, copy all information, and then save it as a text ﬁle. E-mail the text ﬁle to your next level of support. B. Collecting the ﬁrmware logs (Fwdebug and logs.tar.gz) from the SE menu Notes: •...
Page 196: 9Yy Errors
4062 D. Collecting information from the user Ask the user for information about the following: • Print job being run • Operating system being used • Print driver being used • Other information on what was happening when the 9yy error occurred 9yy errors 900.xx–906.xx error messages Error code Description...
Page 197 4062 Error code Description Action 915.00 The redrive motor encoder detection is lost during Go to “Redrive motor assembly service check” normal operation. on page 217. 915.01 The redrive motor does not rotate at the speciﬁed speed. 916.00 The duplex drive motor encoder detection is lost Go to “Internal duplex drive motor service during normal operation.
Page 198 4062 Error code Description Action 920.31 The fuser hot roll temperature does not increase Go to “Fuser (920.07, 920.31, 920.32) failure while the lamp is turned on. service check” on page 220. 920.32 The fuser hot roll temperature is not maintained properly while the media in the fuser nip.
Page 199 4062 Error code Description Action 920.56 The fuser hot roll temperature does not increase Go to “Fuser unit assembly removal” on while the lamp is turned on. page 331. Fuser page count has exceeded life. Replace the fuser unit assembly. 920.57 The fuser hot roll temperature is not maintained properly while the media in the fuser nip.
Page 200 4062 922.xx error messages Error code Description Action 922.00 Fuser hot roll failed to reach target departure. Go to “Fuser (922.00, 922.25) failure service check” on page 222. 922.02 The fuser hot roll does not reach the “beginning Go to “Fuser (922.02–922.04 and 922.06–...
Page 201 4062 Error code Description Action 922.50 Fuser hot roll failed to reach target departure. Go to “Fuser unit assembly removal” on page 331. Fuser page count has exceeded life. Replace the fuser unit assembly. 922.52 The fuser hot roll does not reach the “beginning lamp detection”...
Page 202 4062 Error code Description Action 922.75 Fuser hot roll failed to reach target departure. Go to “Fuser unit assembly removal” on page 331. Fuser page count has exceeded life. Replace the fuser unit assembly. 922.77 The fuser hot roll does not reach the “beginning lamp detection”...
Page 203 4062 Error code Description Action 923.50 Fuser hot roll has exceeded the proper operating Go to “Fuser unit assembly removal” on temperature. page 331. Replace the fuser unit assembly. 923.51 Fuser hot roll has exceeded the proper operating temperature. Replace the fuser unit assembly. 923.75 Fuser hot roll has exceeded the proper operating temperature.
Page 204 4062 925.xx error messages Error code Description Action 925.00 The machine detected a 115 V lamp in a 220 V Go to “Fuser (923.00–923.01, 923.25–923.26) machine. The fuser lamp has an excessive wattage failure service check” on page 224. 925.01 rating.
Page 205 334. • A non‑supported printhead is installed. • 930.00 Hsync signal is intermittent or noisy. Go to “T652, T654, and T656 printhead assembly removal” on page 336. • Printhead ID resistor circuit is not to spec. Replace the printhead. 931.00...
Page 206 LVPS zero cross test fails. Replace the LVPS card Go to “T650 LVPS card assembly removal” on assembly. page 290. 940.00 Go to “T652, T654, and T656 LVPS card assembly removal” on page 292. 950.xx–990.xx error messages Error code Description Action 950.00– Mismatch between system card EEPROM and Go to “NVRAM mismatch (950.00 through...
Page 207 4062 Error code Description Action 954.xx NVRAM chip failure with system card assembly. Go to “System card assembly removal” on page 283. Replace the system card assembly. 955.xx The Code ROM or NAND Flash failed the Cyclic Redundancy Check (CRC) or the NAND experienced an uncorrectable multi‑bit failure.
Page 208 4062 Error code Description Action 982.04 An output option was not fully seated onto the Go to “Output option is missing service check” printer or has been removed while the main power on page 230. is turned on. 982.07 Exceeded the maximum number of input or output Go to “Too many options installed service options.
Page 209 Note: Before troubleshooting, determine the operating system used when the error occurred. If possible, determine whether a PostScript or PCL ﬁle was sent to the device when the error occurred. Ask the customer which Lexmark Solutions applications are installed on the device. Action Step 1 Go to step 2.
Page 210 4062 Action Step 4 Contact the next The problem is solved. level of support Replace the RIP board, and then restart the device. Note: If an error displayed is different from the original 900.xx, then consult the service check for that error. Does the problem remain? Step 5 Contact the next...
Page 211 Step 13 Contact the next The problem is solved. level of support Install a Lexmark‑recommended memory option, and then send a print job to the device. Does the problem remain? Step 14 Go to step 15. Go to step 19.
Page 212 4062 Action Step 16 Go to step 17. The problem is solved. Upgrade the ﬁrmware. Contact your next level of support for the correct ﬁrmware level to use. Restart the printer to operating mode. Send the printer a print job. Does the problem remain? Step 17 Contact the next...
Page 213 4062 Action Step 22 Contact the next Go to step 23. level of support Replace the faulty ISP option, and then restart the device. Run a job to test the new option. Does the problem remain? Step 23 Go to step 24. The problem is solved.
Page 214 4062 System software (901.xx) error service check Action Step 1 Go to step 2. The problem is solved. POR the machine, and then print a simple test page to determine if the problem is ﬁrmware related, or if the customer is sending a corrupted print job.
Page 215 4062 Paperport link driver error service check Action Step 1 Go to step 2. The problem is solved. POR the machine, and then print a simple test page to determine if the problem is system software related, or if the customer is sending a corrupted print job.
Page 216 4062 Paperport device interface error service check Action Step 1 Go to step 2. The problem is solved. POR the machine, and then print a simple test page to determine if the problem is system software related, or if the customer is sending a corrupted print job.
Page 217 Does the problem remain? Step 3 Contact the next The problem is level of support. solved. Replace the redrive motor assembly. Go to “T652, T654, and T656 redrive motor assembly removal” on page 338. Does the problem remain? Diagnostic information...
Page 218 4062 Transfer problem service check Action Step 1 Go to step 2. The problem is solved. Check the HVPS. Does the problem remain? Step 2 Go to step 3. The problem is solved. Check the system board. Does the problem remain? Step 3 Go to step 4.
Page 219 Contact the next The problem is level of support. solved. Replace the duplex drive motor assembly. Go to “T652, T654, and T656 duplex drive motor assembly removal” on page 328. Does the problem remain? Fuser hot roll control code service check Action Turn off the machine, and then turn it back on.
Page 220 Replace the LVPS card assembly. Go to “T650 LVPS card assembly removal” on page 290 “T652, T654, and T656 LVPS card assembly removal” on page 292. Does the problem remain? Fuser (920.07, 920.31, 920.32) failure service check...
Page 221 Replace the LVPS card assembly. Go to “T650 LVPS card assembly removal” on page 290 “T652, T654, and T656 LVPS card assembly removal” on page 292 Does the problem remain? Fuser (920.25–920.29) failure service check Action Step 1 Go to step 2.
Page 222 4062 Fuser (922.00, 922.25) failure service check Action Step 1 Go to step 2. The problem is solved. Turn off the machine, and then turn it back on. Does the problem remain? Step 2 Go to step 3. The problem is solved.
Page 223 Replace the LVPS card assembly. Go to “T650 LVPS card assembly removal” on page 290 “T652, T654, and T656 LVPS card assembly removal” on page 292 Does the problem remain? Fuser (922.27–922.29, 922.31–922.32) failure service check Action Step 1 Go to step 2.
Page 224 4062 Fuser (923.00–923.01, 923.25–923.26) failure service check Action Step 1 Go to step 2. The problem is solved. Turn off the machine, and then turn it back on. Does the problem remain? Step 2 Go to step 3. The problem is solved.
Page 225 4062 Main cooling fan service check Action Step 1 Go to step 2. The problem is solved. Check for cooling fan obstructions. Does the problem remain? Step 2 Go to step 3. The problem is solved. Check the connections on the main cooling fan, and replace the connections if necessary.
Page 226 4062 Action Step 2 The problem is Go to step 3. solved. Check the sensor (toner empty) for proper operation. Enter the Diagnostics menu. Select Base sensor test > Sensor tests. Observe the line item, “toner empty.” Does the display on the operator panel change every time the sensing area of the sensor is interrupted or blocked? Step 3 Go to step 4.
Page 227 The problem is level of support. solved. Replace the printhead assembly. Go to “T650 printhead assembly removal” on page 334 “T652, T654, and T656 printhead assembly removal” on page 336. Does the problem remain? Motor (printhead polygon mirror) service check Action Step 1 Go to step 2.
Page 228 4062 Action Step 3 Go to step 4. The problem is solved. Replace the main drive motor assembly. Go to “Main drive motor assembly removal” on page 274. Does the problem remain? Step 4 Contact the next The problem is level of support.
Page 229 Replace the original operator panel assembly with a new and not previously installed operator panel door assembly or the operator panel assembly. Go to “T650, T652, and T654 operator panel door assembly removal” on page 305 “T656 operator panel door assembly removal” on page 310.
Page 230 4062 Motor (HCIT tray lift) service check Action Step 1 Go to step 2. The problem is solved. Check and remove all obstructions in the HCIT lift area. Does the problem remain? Step 2 Go to step 3. The problem is solved.
Page 231 4062 Too many options installed service check Action Remove the appropriate input or output options. Contact the next The problem is level of support. solved. Does the problem remain? The printer has detected a hot plug service check Action Contact the next The problem is Turn off the printer, and then install all the options.
Page 232 4062...
Page 233: Service Menus
4062 Service menus Understanding the printer control panel T650, T652, and T654 printer models Item Description Display Shows messages and pictures that communicate the status of the printer Navigation buttons • Press the up or down arrow button to scroll through menus or...
Page 234 4062 Item Description Stop or Cancel button Stops all printer activity Menu button Opens the menu index Note: The menus are available only when the printer is in Ready state. USB port Connects a ﬂash drive to the printer Note: Only the front USB port supports ﬂash drives.
Page 235: Understanding The Colors Of The Sleep Button And Indicator Lights
Diagnostics menu Entering the Diagnostics menu For models T650, T652, and T654 Turn off the printer. From the control panel, press and hold the down and right arrow buttons while turning the printer on. Release the buttons when the screen with the progress bar appears.
Page 236: Exiting The Diagnostics Menu
Release the buttons when the screen with the progress bar appears. Exiting the Diagnostics menu Note: This is applicable only to models T650, T652, and T654. From the menu, select Exit Diagnostics to reset the printer. The printer then performs a POR, and returns to Ready state.
Page 237: Print Tests
General printer information, including current page count, installed memory, processor speed, serial number, engine ID, and system card ID For models T560, T652, T654 From the Diagnostics menu, select REGISTRATION. Press the down arrow button until Quick Test with a check mark appears.
Page 238 From the Diagnostics menu, select PRINT TESTS. Depending on your printer model, select Prt Quality Pgs or Printing Quality Test Pages. For models T650, T652, and T654 The print quality pages consist of four pages. The DIAGNOSTICS version of the ﬁrst print quality test page contains a mixture of graphics and text, which includes the following: •...
Page 239: Hardware Tests
If you press a button on the control panel while running the test: Models T650, T652, and T654—Then x appears on the corresponding diagram. It only disappears when • the button is released.
Page 240 4062 USB HS Test Mode From the Diagnostics menu, navigate to HARDWARE TESTS > USB HS Test Mode. Find and select the port to be tested, and then press the Select button. Select a test, and then press the Select button. Port Test Port 0...
Page 241: Duplex Tests
4062 If the page has a print of an arrow and a sheet with a prohibition sign, then the test fails. Possible causes are: • Bad RFID media • RFID UHF option failure Try the test again with a new piece of RFID media. If the test fails again, then replace the RFID UHF option. If the page is without an arrow but has a print of a sheet with a prohibition sign, then the test also fails.
Page 242 4062 Check the page for the correct offset between the placement of the ﬁrst scan line on the front and back side of a duplexed sheet. If duplex top margin needs adjustment, then adjust ﬁrst the top margin setting in the Registration menu. Note: A positive offset moves the text down the page and widens the top margin, while a negative offset moves the text up the page and narrows the top margin.
Page 243 4062 • A positive value moves the left margin to the right and widens the left margin. A negative value moves the left margin to the left and narrows the left margin. Touch Submit, and then print a quick test page to verify the adjustment. Sensor Test This test determines whether the duplex sensors and switches are working properly.
Page 244: Input Tray Tests
4062 Duplex Feed 2 This test feeds a blank sheet of paper to the duplex paper stop position 2. This can be run using any of the supported paper sizes. From the Diagnostics menu, navigate to DUPLEX TESTS > Duplex Feed 2. The power indicator blinks while the paper is feeding and Duplex Feed 2 Feeding…...
Page 245: Output Bin Tests
Depending on your printer model, touch Back or press the Back button to return to OUTPUT BIN TESTS. Feed To All Bins Note: This is applicable only to models T650, T652, and T654. This test veriﬁes whether media can be fed to all standard and optional bins. No information is printed on the media.
Page 246 Sensor Test (output expander) This test determines whether the bin sensor for the output expander is working correctly. Note: This is applicable only in models T650, T652, and T654. From the Diagnostics menu, navigate to: OUTPUT BIN TESTS > Sensor Test > Output Bin [x] Notes: •...
Page 247 Sensor Test (high capacity output stacker) This test determines whether the bin sensor for the output expander is working correctly. Note: This is applicable only to models T650, T652, and T654. From the Diagnostics menu, navigate to: OUTPUT BIN TESTS > Sensor Test > HC Bin [x] Notes: x represents the number of the output option to be tested.
Page 248: Staplesmart Finisher Tests
4062 StapleSmart FINISHER TESTS Staple Test This test veriﬁes the operation of the staple mechanism in the ﬁnisher. The printer feeds eight pieces of media to the ﬁnisher and accumulates all eight pieces in the ﬁnisher. After the last sheets are accumulated, the pack is stapled.
Page 249: Base Sensor Test
4062 • Bin near full Manually actuate each sensor to make it toggle between Open and Closed. If the sensor does not toggle, then it is malfunctioning. Press the Back or Sleep button to exit the test. BASE SENSOR TEST This test determines whether the following sensors inside the printer are working properly.
Page 250: Printer Setup
4062 Disk Test/Clean Note: This is applicable only to model T656. Warning—Potential Damage: This test destroys all data and should not be attempted on a good disk. From the Diagnostics menu, navigate to DEVICE TESTS > Disk Test/Clean. Touch Yes to continue. Note: This test cannot be canceled, and this may run approximately 1½...
Page 251 4062 Serial Number Note: The value of the setting can only be viewed. From the Diagnostics menu, navigate to PRINTER SETUP > Serial Number. Depending on your printer model, touch Back or press the Back button to return to PRINTER SETUP. Engine Setting [x] Warning—Potential Damage: Do not change these settings unless requested to do so by your next level of support.
Page 252: Ep Setup
4062 Edge to Edge When enabled, this setting shifts all four margins (top, bottom, left, and right) to the physical edge of the page (printable area of a supported paper size). Set the setting to Off to restore normal margins. EP SETUP EP Defaults This setting restores each printer setting listed in EP SETUP to its factory default value.
Page 253 4062 Print Contrast This setting controls the developer voltage offset. From the Diagnostics menu, navigate to EP SETUP > Print Contrast. Set the setting to Low, Medium, or High. Note: Medium is the factory default setting. Apply the changes. Charge Roll This setting controls the charge roll voltage.
Page 254: Reports
From the Diagnostics menu, navigate to EVENT LOG > Print Log. Note: You can fax this event log to Lexmark or to your next level of support for veriﬁcation or diagnosis. Depending on your printer model, touch Back or press the Back button to return to EVENT LOG.
Page 255: Conﬁguration Menu
4062 Conﬁguration menu Maintenance page count When selected, the printer displays the current value for the maintenance kit counter. This counter tracks printer usage. A print job containing a single page increments the counter by one, while a duplex print job increments the counter by two.
Page 256: Size Sensing
4062 This generates reports on several Conﬁguration menu settings, including the following: • Reset Cnt • Maintenance Counter Value • Disable Scanner • Disk Encryption • Panel Menu • PPDS Emulation • Reports • Size Sensing • Factory Defaults • Debug Information Note: Some settings are applicable only to some printer models.
Page 257: Ppds Emulation
This is applicable only to some printer models. LES Applications Note: This setting is for touch-screen models only. This setting allows you to enable or disable Lexmark Embedded Solutions (LES) applications. This setting does not affect built‑in applications. From the Conﬁguration menu, select LES Applications.
Page 258: Energy Conserve
MP Feeder • Envelope Feeder Note: This is available only in models T650, T652, and T654. • Manual Env or Manual Envelope (depending on your printer model) Depending on your printer model, touch Submit or press the Select button to apply the changes.
Page 259: Action For Prompts
4062 Action for Prompts This setting determines what action is required from the printer to resolve any paper- or envelope-related change prompts. From the Conﬁguration menu, select Action for Prompts. Select one of the following: • Prompt User—Printer always requires user intervention to resolve the change prompt. This is the factory default setting.
Page 260: Font Sharpening
4062 This setting allows you to erase the contents of the hard disk. From the Conﬁguration menu, select Wipe Disk. Touch Wipe disk (fast) or Wipe disk (secure), and then touch Yes to continue. Note: Erased data is unrecoverable. Font Sharpening Note: This is not supported when the device generates an output at 600 dpi resolution.
Page 261: Key Repeat Rate
Touch Submit to apply the changes. Best Speed Note: This is applicable only to models T650, T652, and T654. From the Conﬁguration menu, select Best Speed. Set the setting to For short jobs or For long jobs.
Page 262 4062...
Page 263: Repair Information
“Top side removals” on page 332 • “MPF cam gear removal” on page 337 • “T652, T654, and T656 redrive motor assembly removal” on page 338 • “Sensor (duplex input) removal (T652, T654, T656)” on page 340 • “Sensor (standard bin exit) removal ” on page 341 •...
Page 264: Adjustments
If the horizontal line does not fall within the deﬁned limit or spec, then it is considered skewed and the printhead must be adjusted. Go to “Polygon and Oscillating printhead mechanical registration adjustment” on page 266 Lexmark C544 Quick Test Printer Information Margin Settings...
Page 265 4062 Printhead Skew + Paper Feed Skew Duplex Skew Speciﬁcation Side Print Sequence Thru Printer 16 lb. to 24 lb. +/-0.007 mm/mm +/-0.005 mm/mm All Other Papers +/-0.010 mm/mm +/-0.005 mm/mm Card Stock +/-0.007 mm/mm +/-0.007 mm/mm Labels +/-0.010 mm/mm +/-0.010 mm/mm •...
Page 266: Polygon And Oscillating Printhead Mechanical Registration Adjustment
Select Quick Test Page. The test page should only be printed on letter or A4 paper from Tray 1. The Quick Test Page consists of alignment diamonds, horizontal lines that can be used for mechanical registration adjustment. An example of the printhead alignment printout is shown below: Lexmark Hd Quick Test Device Information...
Page 267: Oscillating Printhead Assembly Electronic Adjustment
Test Page consists of alignment diamonds, horizontal lines that can be used for skew adjustment, page count setting, printer serial number code levels, and print registration settings. An example of the printhead alignment printout is shown below: Lexmark Hd Quick Test Device Information...
Page 268: Alignment Assembly Adjustment
4062 Press the down or up buttons to the desired setting, and press the Select button. Print the Quick Test page again and check that the darkest line in the center graph is equal to zero. If it is, then check to see if the left, top, and bottom margins are detected. If it is not, then repeat step 5. Note: The alignment of the left margin positions the black plane to the right or left.
Page 269: Fuser Solenoid Adjustment
4062 Step B Print a copy of the Quick Test Page and check the margin adjustments printed on the test page. These settings should be within the range speciﬁed in “Registration” on page 236. The reference screw can be adjusted without loosening the locknut.
Page 270: Removal Procedures
4062 Removal procedures Keep the following tips in mind as you replace parts: • Some removal procedures require removing cable ties. You must replace cable ties during reassembly to avoid pinching wires, obstructing the paper path, or restricting mechanical movement. •...
Page 271: Alignment Assembly Removal
268. Remove the side cover, left. Go to “T650 left side cover removal” on page 279 “T652, T654, and T656 left side cover removal” on page 280. Remove the six screws (A) securing the metal cover to the machine.
Page 272 4062 Remove the inner deﬂector. Go to “Inner deﬂector removal” on page 299. Remove the MPF pick solenoid assembly. Go to “MPF pick solenoid assembly removal” on page 275. Remove the two screws (B) securing the alignment assembly to the machine. Note: The adjuster screw (C) requires a hex wrench to loosen and tighten.
Page 273: Main Cooling Fan Removal
Main cooling fan removal Remove the side cover, left assembly. Go to “MPF cam gear removal” on page 337 “T652, T654, and T656 left side cover removal” on page 280. Remove the six screws (A) securing the metal shield to the machine.
Page 274: Main Drive Motor Assembly Removal
4062 Remove the metal shield. Remove the two screws (B) securing the fuser cooling fan to the machine. Remove the fuser cooling fan. Remove the fuser cooling fan connection (C). Main drive motor assembly removal Remove the system card assembly. Go to “System card assembly removal”...
Page 275: Mpf Pick Solenoid Assembly Removal
Remove the MPF lift plate assembly. Go to “MPF lift plate assembly removal” on page 300. Remove the side cover, left. Go to “MPF cam gear removal” on page 337 “T652, T654, and T656 left side cover removal” on page 280. Repair information...
Page 276 4062 Remove the six screws (A) securing the metal cover to the machine. Remove the metal cover. Repair information...
Page 277 4062 Remove the screw (B) securing the MPF pick solenoid assembly to the machine. Remove the MPF pick solenoid assembly. Disconnect the connection (C) from the MPF pick solenoid assembly. Repair information...
Page 278: Print Cartridge Clamp Assembly Removal
4062 Print cartridge clamp assembly removal Note: This procedure can be applied to the left or right printer cartridge hold down assembly. Remove the laser cover. Go to “Laser cover removal” on page 289. Remove the screw (A) securing the print cartridge clamp assembly to the machine. Remove the print cartridge clamp assembly.
Page 279: Print Cartridge Id Connector Assembly Removal
4062 Print cartridge ID connector assembly removal Remove the print cartridge. Remove the main drive motor assembly. Go to “Main drive motor assembly removal” on page 274. Release the two hooks (A) securing the print cartridge ID connector assembly to the machine. Remove the print cartridge ID connector assembly.
Page 280: T652, T654, And T656 Left Side Cover Removal
Open the MPF tray door assembly. Open the operator panel door assembly. Remove the cover assembly, rear lower. Go to “T650 rear lower cover assembly removal” on page 326 “T652 and T654 rear lower cover assembly removal” on page 326. Repair information...
Page 281 4062 Remove the four screws (A) securing the side cover, left to the machine. Swing the side cover, left away from the machine. Remove the side cover, left. Repair information...
Page 282: Switch (Media Size) Assembly Removal
Switch (media size) assembly removal Remove the side cover, left. Go to “MPF cam gear removal” on page 337 “T652, T654, and T656 left side cover removal” on page 280. Remove the six screws (A) securing the metal cover to the machine.
Page 283: System Card Assembly Removal
Remove the side cover, left. Go to “MPF cam gear removal” on page 337 “T652, T654, and T656 left side cover removal” on page 280. Remove the six screws (A) securing the metal shield to the machine.
Page 284 4062 Remove the metal shield. Warning—Potential Damage: When disconnecting all the electrical connections, ensure that the connectors and harnesses do not become damaged. Repair information...
Page 285: Nvm Card Assembly Removal
(C) are properly aligned and inserted into the system card assembly, or damage will occur. NVM card assembly removal Warning—Potential Damage: When replacing the operator panel assembly (T650, T652, and T654 only), NVM card assembly (T656 only), or the system card assembly, only replace one component at a time.
Page 286 4062 Remove the metal shield. Gently remove the NVM card assembly (B) from the machine. Repair information...
Page 287: Right Side Removals
Right side removals T652, T654, and T656 duplex cooling fan removal Remove the side cover, right. See “T652, T654, and T656 right side cover removal” on page 295. Remove the screw (A) securing the duplex cooling fan to the machine.
Page 288: Hvps Card Assembly Removal
HVPS card assembly removal Remove the side cover, right. Go to “T650 right side cover removal” on page 294 “T652, T654, and T656 right side cover removal” on page 295. Remove the four screws (A) securing the HVPS card assembly to the machine.
Page 289: Laser Cover Removal
“Fuser wiper cover assembly removal” on page 332. Remove the side cover, left. Go to “T650 left side cover removal” on page 279 “T652, T654, and T656 left side cover removal” on page 280. Remove the side cover, right. Go to “T650 right side cover removal”...
Page 290: T650 Lvps Card Assembly Removal
4062 Remove the laser cover. T650 LVPS card assembly removal Warning—Potential Damage: WARNING: When replacing the LVPS card assembly, ensure that the voltage selection switch is set to the proper setting, or damage will occur. Remove the door assembly, rear. Go to “Rear door assembly removal”...
Page 291 4062 Disconnect the connector (C) from the LVPS card assembly. Remove the LVPS card assembly. Installation warning: Replacement Warning: When replacing the LVPS card assembly, ensure that all connections are replaced. Installation warning: Replacement Warning: When replacing the LVPS card assembly, ensure that the connector pins (D) properly engage the system card.
Page 292: T652, T654, And T656 Lvps Card Assembly Removal
“Rear door assembly removal” on page 327. Remove the side cover, right. Go to “T652, T654, and T656 right side cover removal” on page 295. Disconnect the connector (A) from the LVPS card assembly. Remove the two screws (B) from the LVPS card assembly.
Page 293: Print Cartridge Cooling Fan Removal
Print cartridge cooling fan removal Remove the side cover, right. Go to ““T650 right side cover removal” on page 294 “T652, T654, and T656 right side cover removal” on page 295. Remove the screw (A) securing the print cartridge cooling fan to the machine.
Page 294: T650 Right Side Cover Removal
4062 Disconnect the connection (B) from the print cartridge cooling fan. Installation warning: Replacement Warning: When replacing the print cartridge cooling fan, ensure that it is installed as shown in the picture. T650 right side cover removal Open the operator panel door assembly. Open the MPF tray door assembly.
Page 295: T652, T654, And T656 Right Side Cover Removal
Open the operator panel door assembly. Open the MPF tray door assembly. Remove the cover assembly, rear lower. Go to “T652 and T654 rear lower cover assembly removal” on page 326. Remove the ﬁve screws (A) securing the side cover, right to the machine.
Page 296: Sensor (Toner Empty) Removal
4062 Sensor (toner empty) removal Remove the HVPS card assembly. Go to “HVPS card assembly removal” on page 288. Remove the screw (A) securing the sensor (toner empty) to the machine. Remove the sensor (toner empty). Disconnect the connection (B) from the sensor (toner empty). Sensor (input) removal Remove the inner deﬂector.
Page 297: Front Side Removals
4062 Remove the sensor (input). Disconnect the connection (B) from the sensor (input). Front side removals Charge roll assembly removal Warning—Potential Damage: When removing the charge roll assembly, avoid touching the charge roll surface. Open the MPF door assembly. Open the operator panel front cover assembly. Detach the left side of the charge roll assembly from the machine.
Page 298: T650, T652, And T654 Lcd Screen Bezel Removal
Remove the charge roll assembly. Installation warning: When replacing the charge roll assembly, avoid touching the charge roll surf T650, T652, and T654 LCD screen bezel removal Locate the LCD screen bezel from the operator panel door assembly. Gently detach the LCD screen bezel.
Page 299: Inner Deﬂector Removal
4062 Inner deﬂector removal Note: The MPF lift plate assembly can be detached and allowed to hang by the harness. The connection to the MPF lower deﬂector assembly does not need to be disconnected. Remove the MPF lift plate assembly. Go to “MPF lift plate assembly removal”...
Page 300: Media Turn Guide Removal
4062 Media turn guide removal Remove the MPF tray door assembly. Go to “T650, T652, and T654 MPF tray door assembly removal” on page 302. Gently bend the left side of the media turn guide to release the hook (A) as shown in the picture.
Page 301: Mpf Media Out Actuator Removal
4062 Disconnect the connector (B) from the MPF lower deﬂector assembly. Remove the MPF lift plate assembly. Installation warning: When replacing the MPF lift plate assembly, ensure that the lever (C) is held down when reinstalling the MPF lift plate assembly, or damage will occur. Installation warning: When replacing the MPF lift plate assembly, ensure that the MPF pick solenoid assembly does not become damaged.
Page 302: T650, T652, And T654 Mpf Tray Door Assembly Removal
Remove the MPF pick roll assembly. Installation warning: When replacing the MPF pick roll assembly, do not touch the rubber surface. T650, T652, and T654 MPF tray door assembly removal Open the operator panel door assembly. Open the MPF tray door assembly, and position it as shown in the picture.
Page 303 4062 While holding the MPF tray in its uppermost position, swing the MPF tray door assembly away from the machine to detach the MPF tray from the machine. Repair information...
Page 304: T650, T652, And T654 Operator Panel Latch Assembly Removal
Slide the MPF tray door assembly in the direction of the arrow to detach it from the machine. Remove the MPF tray door assembly. T650, T652, and T654 operator panel latch assembly removal Open the operator panel door assembly. Remove the four screws (A) securing the operator panel latch assembly to the machine.
Page 305: T650, T652, And T654 Operator Panel Door Assembly Removal
Release the two hooks (B). Remove the operator panel latch assembly. T650, T652, and T654 operator panel door assembly removal Warning—Potential Damage: When replacing the operator panel assembly or the system card assembly, only replace one component at a time. Replace the required component and perform a POR before replacing another component.
Page 306: T650, T652, And T654 Left Operator Panel Hinge Assembly Removal
Remove the two screws (C) securing the USB socket to the assembly. Remove the USB socket. Disconnect the connector (D) from the assembly. T650, T652, and T654 left operator panel hinge assembly removal Remove the operator panel door assembly. Go to “T650, T652, and T654 operator panel door assembly removal”...
Page 307 4062 Remove the harnesses (C) from the operator panel hinge assembly, left. Detach the spring (D) from the operator panel hinge assembly, left. Detach the spring (E) from the operator panel hinge assembly, left. Remove the E-clip (F) from the operator panel hinge assembly, left. Remove the pin (G) from the operator panel hinge assembly, left.
Page 308: T650, T652, And T654 Right Operator Panel Hinge Assembly Removal
4062 Remove the operator panel hinge assembly, left. T650, T652, and T654 right operator panel hinge assembly removal Remove the operator panel door assembly. Go to “T650, T652, and T654 operator panel door assembly removal” on page 305. Detach the spring (A) from the operator panel hinge assembly, right.
Page 309 4062 Remove the pin (D) from the operator panel hinge assembly, right. Remove the operator panel hinge assembly, right. Repair information...
Page 310: T656 Operator Panel Door Assembly Removal
4062 T656 operator panel door assembly removal Warning—Potential Damage: When replacing the operator panel assembly or the system card assembly, only replace one component at a time. Replace the required component and perform a POR before replacing another component. If this procedure is not followed, the printer will be rendered inoperable. Never replace two or more components without a POR after installing each one or the printer will be rendered inoperable.
Page 311 4062 Remove eight screws (E) securing the scanner controller cage cover to the cage. An X658 model is represented in the graphic below, however, the card cage cover removal procedure is similar for all models. Remove the printer controller card cage cover. Disconnect the USB cable and the cover closed interlock switch harness.
Page 312 4062 Lift the operator panel door assembly out of the machine. Repair information...
Page 313: T656 Operator Panel Cover Latch Assembly Removal
4062 T656 Operator panel cover latch assembly removal Lift the operator panel cover assembly. Remove the ten screws (A) securing the operator panel cover latch assembly to the operator panel cover assembly. Remove the operator panel cover latch assembly. Sensor shield assembly removal Remove the inner deﬂector.
Page 314: Transfer Roll Assembly Removal
4062 Transfer roll assembly removal Open the operator panel door assembly. Remove the print cartridge. Gently unsnap the transfer roll assembly from the machine. Remove the transfer roll assembly. Installation warning: When replacing the transfer roll assembly, do not touch the foam surface. Left transfer roll bracket assembly removal Remove the transfer roll assembly.
Page 315: Right Transfer Roll Bracket Assembly Removal
4062 Remove the screw (E). Remove the ground wire (F). Installation warning: When reinstalling the transfer roll bracket assembly, left, ensure that the bushing (C), spring (D), and ground wire (F) are properly replaced. Right transfer roll bracket assembly removal Remove the transfer roll assembly.
Page 316: Transfer Deﬂector Removal
Note: When removing the duplex drive motor assembly, it does not need to be completely removed from the machine. It may be allowed to gently hang out of the way by the harness. Remove the duplex drive motor assembly. See “T652, T654, and T656 duplex drive motor assembly removal” on page 328.
Page 317: T652, T654, And T656 Duplex Input Sensor Assembly Removal
Installation warning: When replacing the duplex assembly, ensure that the lower duplex drive belt (D) is properly reattached. T652, T654, and T656 duplex input sensor assembly removal Remove the media tray. Gently place the printer on its left or right side.
Page 318 4062 Detach the front left duplex guide spring (A) from the duplex guide assembly, front. Detach the front right duplex guide spring (B) from the duplex guide assembly, front. Fully open the duplex guide assembly, front 90°, and detach it from the machine. Remove the duplex guide assembly, front.
Page 319: Media Out Actuator Removal
4062 Media out actuator removal Remove the pick arm assembly. Go to “Pick arm assembly removal” on page 320. Release the hook (A) securing the media out actuator to the unit. Remove the media out actuator. Option drive shaft removal Gently place the printer on its left or right side.
Page 320: Pick Arm Assembly Removal
4062 Pick arm assembly removal Remove the media tray from the machine. Place the machine on the left or right side. Remove the spring (A). Remove the two E-clips (B) securing the pick arm assembly to the machine. Repair information...
Page 321 4062 Remove the screw (C) securing the pick arm assembly to the machine. Remove the band (D) from the pick arm assembly. Remove the cover from the pick arm assembly. Remove the three connections (E) from the pick arm assembly. Repair information...
Page 322: Pick Roll Assembly Removal
4062 Remove the wiring harness (F) from the pick arm assembly. Remove the pick arm assembly. Installation warning: When replacing the pick arm assembly, ensure that the harnesses are properly rerouted. Installation warning: When replacing the pick arm assembly, ensure that the connections are properly replaced.
Page 323: Sensor (Media Level) Removal
4062 Sensor (media level) removal Remove the pick arm assembly. Go to “Pick arm assembly removal” on page 320. Release the hooks (A) securing the sensor (media level) to the assembly. Remove the sensor (media level). Sensor (media out) removal Remove the pick arm assembly.
Page 324: Rear Side Removals
4062 Rear side removals Rear connection access cover removal Gently detach the two hinges (A) of the connection access cover, rear from the machine. Remove the connection access cover, rear. T650 rear connection bezel assembly removal Remove the side cover, left. Go to “T650 left side cover removal”...
Page 325: T652 And T654 Rear Connection Bezel Assembly Removal
Remove the connection bezel assembly, rear. T652 and T654 rear connection bezel assembly removal Remove the side cover, left. Go to “T652, T654, and T656 left side cover removal” on page 280. Remove the cover assembly, rear lower. Go to “T652 and T654 rear lower cover assembly removal”...
Page 326: T650 Rear Lower Cover Assembly Removal
Remove the three screws (A) securing the cover assembly, rear lower to the machine. Remove the cover assembly, rear lower. T652 and T654 rear lower cover assembly removal Open the rear lower door. Remove the four screws (A) securing the cover assembly, rear lower to the machine.
Page 327: Rear Door Assembly Removal
Position the door assembly, rear at a 45° angle as shown in the picture. Remove the door assembly, rear. T652, T654, and T656 rear duplex guide assembly removal Remove the cover assembly, rear lower. Go to “T652 and T654 rear lower cover assembly removal” on page 326.
Page 328: T652, T654, And T656 Duplex Drive Motor Assembly Removal
Remove the screw (D) securing the rear duplex guide handle to the assembly. Remove the duplex guide assembly, rear. T652, T654, and T656 duplex drive motor assembly removal Remove the fuser access door. See “HVPS card assembly removal” on page 288.
Page 329 4062 Remove the three screws (A) securing the duplex drive motor assembly to the machine. Note: When removing the duplex drive motor assembly, the upper duplex drive belt (B) will become detached. Remove the band (C) from the duplex drive motor assembly. Remove the cover from the duplex drive motor assembly.
Page 330: Fuser Access Door Assembly Removal
4062 Fuser access door assembly removal Remove the door assembly, rear. Go to “Rear door assembly removal” on page 327. Press the two tabs (A) on the fuser access door assembly, and detach it from the machine. Swing the fuser access door assembly away from the machine. Repair information...
Page 331: Fuser Unit Assembly Removal
4062 Unsnap the fuser access door assembly from the machine. Remove the fuser access door assembly. Fuser unit assembly removal Remove the fuser wiper cover assembly. Go to “Fuser wiper cover assembly removal” on page 332. Remove the door assembly, rear. Go to “Rear door assembly removal”...
Page 332: Top Side Removals
4062 While pressing the two tabs (B), pull the redrive assembly from the machine. Top side removals Fuser wiper cover assembly removal Press the button (A) securing the fuser wiper cover assembly to the machine. Remove the fuser wiper cover assembly. Repair information...
Page 333: Media Support Removal
4062 Media support removal Gently detach the two bosses (A) of the media support from the machine. Remove the media support. Output cover assembly removal Unsnap the output cover assembly from the machine. Remove the output cover assembly. Repair information...
Page 334: T650 Printhead Assembly Removal
4062 T650 printhead assembly removal Note: When replacing the printhead assembly, ensure that the printhead is properly calibrated, or print quality issues will occur. Go to “Alignment assembly adjustment” on page 268. Remove the laser cover. Go to “Laser cover removal” on page 289.
Page 335 4062 Remove the three screws (C) securing the printhead assembly to the machine. Remove the printhead assembly. Installation warning: When replacing the printhead assembly, ensure that the printhead is properly calibrated, or print quality issues will occur. Repair information...
Page 336: T652, T654, And T656 Printhead Assembly Removal
4062 T652, T654, and T656 printhead assembly removal Warning—Potential Damage: When replacing the printhead assembly, ensure that the printhead skew is properly adjusted, or print quality issues will occur. Remove the laser cover. Go to “Laser cover removal” on page 289.
Page 337: Mpf Cam Gear Removal
4062 Remove the four screws (C) securing the printhead assembly to the machine. Remove the printhead assembly. Installation warning: When replacing the printhead assembly, ensure that the printhead skew is properly adjusted, or print quality issues will occur. MPF cam gear removal Remove the alignment assembly.
Page 338: T652, T654, And T656 Redrive Motor Assembly Removal
4062 T652, T654, and T656 redrive motor assembly removal Remove the laser cover. Go to “Laser cover removal” on page 289. Remove the six screws (A) securing the metal cover to the machine. Remove the metal cover. Repair information...
Page 339 4062 Disconnect the connection (B) from the redrive motor assembly. Disconnect the connection (C) from the sensor (standard media bin full). Release the hooks (D) securing the output option interface cable assembly to the machine. Detach the output option cable assembly. Repair information...
Page 340: Sensor (Duplex Input) Removal (T652, T654, T656)
Remove the redrive motor assembly. Sensor (duplex input) removal (T652, T654, T656) Remove the duplex input sensor assembly. Go to “T652, T654, and T656 duplex input sensor assembly removal” on page 317. Release the hooks (A) securing the senor (duplex media path) to the bracket.
Page 341: Sensor (Standard Bin Exit) Removal
4062 Sensor (standard bin exit) removal Remove standard bin actuator assembly. Release the hooks (A) securing the sensor (standard bin exit) to the assembly. Remove the sensor (standard bin exit). Sensor (toner density) removal Remove the sensor shield assembly. Go to “Sensor shield assembly removal ”...
Page 342: Tray Roller Catch Assembly Removal
4062 Press the tab (B) to release the standard bin actuator assembly from the machine. Remove the standard bin actuator assembly. Tray roller catch assembly removal Remove the media tray. Remove the HVPS card assembly. Go to “HVPS card assembly removal” on page 288.
Page 343: 5-Bin Mailbox Removals
4062 5-bin mailbox removals 5-bin mailbox rear door assembly removal Open the rear door assembly and twist the rear door strap vertical and remove the strap. Pry the rear door hinges out of the bottom hinges and remove. Repair information...
Page 344: 5-Bin Mailbox Left Outer Cover Removal
4062 5-bin mailbox left outer cover removal Open the rear door assembly. Grasp the upper rear corner of the left outer cover and pull it off the 5-bin mailbox assembly. 5-bin mailbox left inner cover removal Remove the 5-bin mailbox rear door assembly. Go to “5-bin mailbox rear door assembly removal”...
Page 345: 5-Bin Mailbox Right Outer Cover Removal
4062 Remove the single screw (A) on the top and the four screws (B) on the inside of the left inner cover. Remove the 5-bin mailbox left inner cover. 5-bin mailbox right outer cover removal Open the rear door assembly. Grasp the upper rear corner of the right outer cover and pull it off the 5-bin mailbox assembly.
Page 346: 5-Bin Mailbox Right Inner Cover Removal
4062 5-bin mailbox right inner cover removal Remove the 5-bin mailbox rear door assembly. Go to “5-bin mailbox rear door assembly removal” on page 343. Remove the 5-bin mailbox right outer cover. Go to “5-bin mailbox right outer cover removal” on page 345.
Page 347: 5-Bin Mailbox Top Cover Removal
4062 5-bin mailbox top cover removal Open the rear door assembly. Remove the cable cover panel by lifting up on the right side and pull to the right and out. Remove the two screws (A) on each side of the top cover. Pull the left side up ﬁrst and carefully unroute the cables from the channels and then remove the top cover.
Page 348: 5-Bin Mailbox Media Bin Full Actuator Removal
4062 5-bin mailbox media bin full actuator removal Remove the 5-bin mailbox left inner cover. Go to “5-bin mailbox left inner cover removal” on page 344. Grasp the media bin full actuator and pull the pins from the bosses. Sensor (5-bin mailbox pass through) removal Remove the 5-bin mailbox left outer cover.
Page 349 4062 Lift up the deﬂector gate above the sensor (pass through) and using a ﬂat-blade screwdriver, release the tabs securing the sensor. Disconnect the appropriate harness from the controller card (J11) for the upper sensor (pass through) and (J5) for the lower sensor (pass through). Note: The use of a spring hook facilitates the unrouting of the cables.
Page 350: Sensor (5-Bin Mailbox Media Bin Empty) Removal
4062 Sensor (5-bin mailbox media bin empty) removal Remove the 5-bin mailbox left outer cover. Go to “5-bin mailbox left outer cover removal” on page 344. Release the connecting tabs on the sensor (media bin empty) and remove from its bracket. Disconnect the harness from the sensor (media bin empty).
Page 351: 5-Bin Mailbox Static Brush Mylar Assembly Removal
4062 Remove the two screws (A) securing the controller card assembly to the 5-bin mailbox assembly. Remove the 5-bin mailbox controller card assembly. 5-bin mailbox static brush mylar assembly removal Remove the 5-bin mailbox top cover. Go to “5-bin mailbox top cover removal” on page 347.
Page 352: 5-Bin Mailbox Media Bin Fifth Deﬂector Removal
4062 Remove the 5-bin mailbox static brush mylar assembly. 5-bin mailbox media bin ﬁfth deﬂector removal Remove the rear door assembly. Go to “5-bin mailbox rear door assembly removal” on page 343. With a spring hook, carefully remove the upper deﬂector gate spring and for ease of reassembly, temporarily hook the spring to the upper frame tab.
Page 353: 5-Bin Mailbox Media Bin First Through Fourth Deﬂector Removal
4062 Unsnap each side of the deﬂector gate and remove. Installation note: The static brush mylar assembly is attached to the media bin ﬁfth deﬂector. Do not forget to reinstall it on the new deﬂector. 5-bin mailbox media bin ﬁrst through fourth deﬂector removal Remove the rear door assembly.
Page 354: 5-Bin Mailbox Media Bin Extension Assembly Removal
4062 Unsnap each side of the deﬂector and remove. Installation note: The static brush mylar assembly is attached to the media bin ﬁfth deﬂector. Do not forget to reinstall it on the new deﬂector. 5-bin mailbox media bin extension assembly removal Fully extend the media bin extension.
Page 355 4062 Remove the top cable cover panel. Remove the screw (A) securing the appropriate 5-bin mailbox deﬂector gate solenoid. Repair information...
Page 356: 5-Bin Mailbox Transport Solenoid Removal
4062 Remove and unroute the cable to the deﬂector gate solenoid. Disconnect the proper deﬂector gate solenoid harness from the controller card. Installation note: To ease the cable unrouting, cut the appropriate cable. 5-bin mailbox transport solenoid removal Remove the 5-bin mailbox left outer cover. Go to “5-bin mailbox left outer cover removal”...
Page 357 4062 Remove the two screws (A) securing the controller card assembly and move the card to the side. Remove the four screws (B) securing the left frame assembly to the 5-bin mailbox assembly. Repair information...
Page 358 4062 Move the left frame assembly out of the way. Remove the 5-bin mailbox sensor (deﬂector gate HP) by pressing the tabs. Disconnect the harness from the 5-bin mailbox sensor (deﬂector gate HP). Repair information...
Page 359: 250-Sheet Option Tray Removals
4062 250-sheet option tray removals 250-sheet media tray assembly removal Note: This removal procedure can be applied to 250-sheet option drawer assembly. Find the 250-sheet media tray assembly in the 250-sheet option drawer assembly. Remove the 250-sheet media tray assembly from the 250-sheet option drawer assembly. 250-sheet tray pick arm bracket assembly removal Note: Carefully remove the base machine from the input option tray assembly before proceeding.
Page 360: 250-Sheet Tray Media Out Actuator Removal
4062 Remove the three screws (A) securing the 250-sheet tray pick arm bracket assembly to the drawer. Remove the 250-sheet tray pick arm bracket assembly. 250-sheet tray media out actuator removal Note: Carefully remove the base machine from the input option tray assembly before proceeding. Remove the 250-sheet tray pick arm bracket assembly.
Page 361: 250-Sheet Tray Frame Assembly Removal
4062 Remove the 250-sheet tray media out actuator from the drawer. 250-sheet tray frame assembly removal Note: The 250-sheet tray frame assembly is not a FRU. Remove the 250-sheet tray pick arm bracket assembly. Go to “250-sheet tray pick arm bracket assembly removal”...
Page 362: 250-Sheet Tray Controller Card Assembly Removal
4062 Remove the 250-sheet tray frame assembly. 250-sheet tray controller card assembly removal Remove the 250-sheet tray frame assembly. Go to “250-sheet tray frame assembly removal” on page 361. Disconnect the three connectors from the 250-sheet tray controller card assembly. Repair information...
Page 363 4062 Remove the three screws (B) securing the 250-sheet tray controller card assembly to the 250-sheet tray frame. Remove the 250-sheet tray controller card assembly. Repair information...
Page 364: 550-Sheet Option Tray Removals
Remove the 550-sheet media tray assembly from the 550-sheet option drawer assembly. 550-sheet tray pick arm bracket assembly removal Remove the 550-sheet media tray assembly. Go to “T652 and T654 media out actuator removal” on page 413. Remove the two 550-sheet tray pick arm bracket assembly cable connectors (A) from the 550-sheet tray controller card assembly.
Page 365 4062 Remove the four screws (C) securing the 550-sheet tray pick arm bracket assembly to the drawer. Remove the 550-sheet tray pick arm bracket assembly. Repair information...
Page 366: 550-Sheet Tray Bellcrank Recoil Spring Removal
4062 550-sheet tray bellcrank recoil spring removal Remove the 550-sheet tray pick arm bracket assembly. Go to “550-sheet tray pick arm bracket assembly removal” on page 364. Remove the 550-sheet tray bellcrank recoil spring from the 550-sheet tray pick arm bracket assembly. 550-sheet tray frame assembly removal Note: The 550-sheet tray frame assembly is not a FRU.
Page 367 4062 Remove the four screws (A) securing the 550-sheet tray frame assembly to the drawer. Repair information...
Page 368: 550-Sheet Tray Controller Card Assembly Removal
4062 Remove the 550-sheet tray frame assembly. 550-sheet tray controller card assembly removal Remove the 550-sheet tray frame assembly. Go to “Media size actuator removal” on page 414. Disconnect the three connectors from the 550-sheet tray controller card assembly. Repair information...
Page 369: 550-Sheet Tray Option Drive Shaft With Spring Removal
4062 Remove the three screws (A) securing the 550-sheet tray controller card assembly to the 550-sheet tray frame. Remove the 550-sheet tray controller card assembly. 550-sheet tray option drive shaft with spring removal Remove the 550-sheet tray frame assembly. Go to “Media size actuator removal”...
Page 370: Anti-Tip Latch Assembly Removal
4062 Pull the drive roll gear (B), the shaft with spring (C), and the bevel out through the opening. Remove the 550-sheet tray option drive shaft with spring. Anti-tip latch assembly removal Note: Carefully remove the base machine from the input option tray assembly before proceeding. The left and right anti-tip latch assemblies are the same, and only one is in a package.
Page 371 4062 Remove the anti-tip latch assembly. Repair information...
Page 372: High Capacity Input Tray (Hcit) Removals
4062 High capacity input tray (HCIT) removals High capacity input tray (HCIT) media tray assembly removal Open the HCIT media tray assembly until it reaches a stop. Press the latches (A) on the left and right sides of the HCIT tray slides. Slide the HCIT media tray assembly out of the drawer.
Page 373: High Capacity Input Tray (Hcit) Tray Cover, Front Removal
4062 High capacity input tray (HCIT) tray cover, front removal Open the HCIT media tray assembly until it reaches a stop. Remove the six screws (A) securing the HCIT tray cover, front to the HCIT media tray assembly. Repair information...
Page 374 4062 Remove the HCIT tray cover, front. Repair information...
Page 375: High Capacity Input Tray (Hcit) Cover, Rear Removal
4062 High capacity input tray (HCIT) cover, rear removal Remove the HCIT media tray assembly. Go to “High capacity input tray (HCIT) media tray assembly removal” on page 372. Remove the four screws (A) securing the HCIT cover, rear to the drawer. Repair information...
Page 376: High Capacity Input Tray (Hcit) Cover, Right Removal
4062 Remove the HCIT cover, rear. High capacity input tray (HCIT) cover, right removal Note: Carefully remove the base machine from the HCIT tray assembly before proceeding. Repair information...
Page 377 4062 Note: Before removing the HCIT right cover, ﬁrst remove the right side anti-tip latch assembly. Go to “High capacity input tray (HCIT) anti-tip latch assembly removal” on page 380. Remove the high capacity input tray (HCIT) cover, rear. Go to “High capacity input tray (HCIT) cover, rear removal”...
Page 378: High Capacity Input Tray (Hcit) Cover, Left Removal
4062 Remove the HCIT cover, right. High capacity input tray (HCIT) cover, left removal Note: Carefully remove the base machine from the HCIT tray assembly before proceeding. Repair information...
Page 379 4062 Note: Before removing the HCIT left cover, ﬁrst remove the left side anti-tip latch assembly. Go to “High capacity input tray (HCIT) anti-tip latch assembly removal” on page 380. Remove the high capacity input tray (HCIT) cover, rear. Go to “High capacity input tray (HCIT) cover, rear removal”...
Page 380: High Capacity Input Tray (Hcit) Anti-Tip Latch Assembly Removal
4062 Remove the HCIT cover, left. High capacity input tray (HCIT) anti-tip latch assembly removal Note: Carefully remove the base machine from the HCIT tray assembly before proceeding. The left and right anti-tip latch assemblies are the same, and only one is in a package. The instructions below are for removing the left latch;...
Page 381: High Capacity Input Tray (Hcit) Drawer Slide Assembly Removal
4062 High capacity input tray (HCIT) drawer slide assembly removal Note: The left and right drawer slide assemblies are the same, and only one is in a package. The instructions below are for removing the left slide; removing the right slide has similar instructions. Remove the HCIT media tray assembly.
Page 382: High Capacity Input Tray (Hcit) Tray Lift Drive Motor Assembly Removal
4062 High capacity input tray (HCIT) tray lift drive motor assembly removal Note: Carefully remove the base machine from the HCIT tray assembly before proceeding. Remove the HCIT cover, right. Go to “High capacity input tray (HCIT) cover, right removal” on page 376.
Page 383: High Capacity Input Tray (Hcit) Controller Card Assembly Removal
4062 High capacity input tray (HCIT) controller card assembly removal Note: Carefully remove the base machine from the HCIT tray assembly before proceeding. Remove the HCIT cover, left. Go to “High capacity input tray (HCIT) cover, left removal” on page 378.
Page 384: High Capacity Input Tray (Hcit) Media Size Actuator Assembly Removal
4062 Remove the three screws (A) securing the HCIT controller card assembly. Remove the HCIT controller card assembly and the shield. High capacity input tray (HCIT) media size actuator assembly removal Note: Carefully remove the base machine from the HCIT tray assembly before proceeding. Remove the HCIT controller card assembly.
Page 385 4062 Slide the cam size sensing plate (B) through the access hole in the rear side frame. Snap loose the actuator switch (C) and remove. Repair information...
Page 386 4062 Remove the four screws (D) securing the card mount option with the media size actuator to the frame. Remove the card mount option with the media size actuator. Installation notes: Re-install the card mount option with the media size actuator to the frame by inserting the leftmost part of it through the hole, and then securing it with the four screws.
Page 387: High Capacity Input Tray (Hcit) Pick Arm Bracket Assembly Removal
4062 High capacity input tray (HCIT) pick arm bracket assembly removal Note: Carefully remove the base machine from the HCIT tray assembly before proceeding. Remove the HCIT cover, left. Go to “High capacity input tray (HCIT) cover, left removal” on page 378.
Page 388 4062 Remove the ﬁve screws (A) securing the HCIT pick arm bracket assembly. Remove the HCIT pick arm bracket assembly from the drawer by slightly lifting and removing it. Repair information...
Page 389: High Capacity Input Tray (Hcit) Tray Closed Latch With Spring Removal
4062 High capacity input tray (HCIT) tray closed latch with spring removal The left and right tray closed latches with springs are the same, and only one is in a package. The instructions below are for removing the left latch; removing the right latch has similar instructions. Remove the HCIT media tray assembly.
Page 390: High Capacity Stacker Right Cover Removal
4062 Remove the rear door assembly from the hinges by gently prying the hinges off the bosses. High capacity stacker right cover removal Remove the high capacity stacker rear door assembly. Go to “High capacity stacker rear door assembly removal” on page 389.
Page 391: High Capacity Stacker Left Cover Removal
4062 Remove the right cover. High capacity stacker left cover removal Remove the high capacity stacker rear door assembly. Go to “High capacity stacker rear door assembly removal” on page 389. Using a #1 phillips screwdriver, remove the three screws (A) securing the left cover to the high capacity stacker assembly.
Page 392: High Capacity Stacker Controller Card Cover Panel Removal
4062 High capacity stacker controller card cover panel removal Remove the media output bin assembly. Go to “High capacity stacker rear door assembly removal” on page 389. Remove the two screws (A) securing the controller card cover panel on the rear of the assembly. Remove the screw (B) securing the ground strap to the right frame.
Page 393: High Capacity Stacker Switch (Media Bin Hp) Removal
4062 High capacity stacker switch (media bin HP) removal Remove the high capacity stacker controller card cover panel. Go to “High capacity stacker controller card cover panel removal” on page 392. Remove the two screws (A) securing the high capacity stacker switch (media bin HP) to the left frame. Disconnect the high capacity stacker switch (media bin HP) harness from the upper controller card.
Page 394: High Capacity Stacker Sensor (Media Bin Full) Bracket Assembly Removal
4062 Remove the high capacity stacker sensor (media bin full) assembly. High capacity stacker sensor (media bin full) bracket assembly removal Remove the high capacity stacker left cover. Go to “High capacity stacker left cover removal” on page 391. Release the tab securing the bracket to the left frame. Remove the bracket from the frame and disconnect the sensor (media bin full) and media bin full actuator.
Page 395: High Capacity Stacker Controller Card Assembly (Upper And Lower) Removal
4062 High capacity stacker controller card assembly (upper and lower) removal Remove the high capacity stacker controller card cover panel. Go to “High capacity stacker controller card cover panel removal” on page 392. Disconnect the harnesses from the controller card. Note: Pay careful attention to where the power input and output harnesses are attached.
Page 396: High Capacity Stacker Left Frame Removal
4062 Carefully remove the right frame. Note: When installing the right frame, make sure the media output bin assembly is aligned properly. High capacity stacker left frame removal Remove the left media output bin recoil spring. Remove the two screws (A) securing the switch (media bin HP) to the left frame. Remove the high capacity stacker standard output bin LED.
Page 397 4062 Remove the four screws (B) securing the left frame to the high capacity stacker assembly. Carefully remove the left frame. Note: When installing the left frame, make sure the media output bin assembly is aligned properly. Repair information...
Page 398: High Capacity Stacker Upper Deﬂector Gate Removal
4062 High capacity stacker upper deﬂector gate removal Remove the rear door assembly. Go to “High capacity stacker rear door assembly removal” on page 389. With a spring hook, carefully remove the upper deﬂector gate spring and for ease of reassembly, temporarily hook the spring to the upper frame tab.
Page 399: Sensor (High Capacity Stacker Pass Through) Removal
4062 Unsnap each side of the deﬂector gate and remove. Sensor (high capacity stacker pass through) removal Remove the rear door assembly. Go to “High capacity stacker rear door assembly removal” on page 389. Using needle-nose pliers or your ﬁnger, pull out and downward on the sensor (pass through) until the sensor unsnaps.
Page 400 4062 Disconnect the sensor (pass through) harness from the controller card and remove the sensor. Repair information...
Page 401: High Capacity Stacker Left Mounting Bracket Removal
4062 High capacity stacker left mounting bracket removal Remove the high capacity stacker left cover. Go to “High capacity stacker left cover removal” on page 391. Remove the eight screws (A) securing the high capacity stacker left mounting bracket. Pull the bracket up and let it rest on the assembly with the cables intact. Sensor (high capacity stacker deﬂector gate HP) removal Remove the high capacity stacker left mounting bracket.
Page 402: Other Removals
4062 Unclip the sensor tabs and remove. Other removals RFID UHF option installation and removal Prepare the following RFID UHF option components: RFID UHF option Firmware card User ﬂash card Fuser wiper Interface card, plastic tee, screw RFID cable Documentation CD Repair information...
Page 403 4062 Unplug the power cord from the electrical outlet, and then disconnect all cables from the printer. Open the system board door, and loosen the screw on the system board cover. Remove the cover. Repair information...
Page 404 4062 Install the ﬁrmware card into the system board. Repair information...
Page 405 4062 Install the ﬂash card into the system board. Repair information...
Page 406 4062 Remove the metal cover from the system card opening. Locate the interface card mounting area on the system board. Repair information...
Page 407 4062 Snap the plastic tee card holder into place on the system board. Angle the interface card through the connector opening. Insert the interface card into the plastic tee card holder. Repair information...
Page 408 4062 Insert the long thumbscrew into the hole in the interface card. Turn it just enough to hold the card in place. Do not tighten yet. Insert the screws to secure the mounting bracket to the system board. Tighten the thumbscrew, and insert the interface card plug into the blue connector on the system board. Repair information...
Page 409 4062 Replace the system board cover. Lift the printer off the 250/550 sheet optional drawer, place the RFID option on top of the drawer, and place the printer on top of the RFID option. Repair information...
Page 410 4062 Unpack the RFID cable, and attach between the RFID option and the interface card. Reconnect all printer cables. Remove the old fuser wiper (or blank). Repair information...
Page 411: Lower Interface Cable Assembly Removal
4062 Install the new wiper. Turn the printer on. To remove the RFID UHF option, reverse the order of installation. Lower interface cable assembly removal Remove the 550-sheet frame assembly. Go to “Media size actuator removal” on page 414. Disconnect the lower interface cable connector (A) from the 550-sheet controller card. Pinch the options auto connect (B) to separate the lower interface cable assembly from the 550-sheet frame.
Page 412: Media Size Actuator Removal
4062 Media size actuator removal Note: Carefully remove the base machine from the input option tray assembly before proceeding. Remove the 250-sheet controller card assembly. Go to “250-sheet tray controller card assembly removal” on page 362. Remove the screw (A) securing the media size actuator to the 250-sheet frame. Remove the media size actuator.
Page 413: T652 And T654 Media Out Actuator Removal
4062 Release the media tray catch spring. T652 and T654 media out actuator removal Remove the 550-sheet pick arm bracket assembly. Go to “550-sheet tray pick arm bracket assembly removal” on page 364. Release the hook (A) securing the media out actuator with spring to the 550-sheet pick arm bracket assembly.
Page 414: Media Size Actuator Removal
4062 Media size actuator removal Remove the 550-sheet controller card assembly. Go to “550-sheet tray controller card assembly removal” on page 368. Remove the screw (A) securing the media size actuator to the 550-sheet frame. Remove the media size actuator. Media tray catch spring removal Remove the 550-sheet frame assembly.
Page 415: Media Tray Roller Catch Assembly Removal
4062 Media tray roller catch assembly removal Remove the media tray catch spring. Go to “Media tray catch spring removal” on page 414. Remove the tray roller catch assembly from the drawer. Sensor (HCIT tray raised HP) with cable assembly removal Note: Carefully remove the base machine from the HCIT tray assembly before proceeding.
Page 416 4062 Release the hooks (B) securing the sensor to the rear frame. Remove the sensor (HCIT tray raised HP). Repair information...
Page 417: Sensor (Hcit Pass Through) With Cable Removal
4062 Sensor (HCIT pass through) with cable removal Note: Carefully remove the base machine from the HCIT tray assembly before proceeding. Remove the HCIT cover, left. Go to “High capacity input tray (HCIT) cover, left removal” on page 378. Disconnect the sensor (HCIT pass through) cable connector from the HCIT controller card assembly. Note: Remove the cable restraint, and observe the routing for reinstallation.
Page 418: Sensor (Pass Through) With Cable Removal
4062 Sensor (pass through) with cable removal Remove the 250-sheet frame assembly. Go to “250-sheet tray frame assembly removal” on page 361. Disconnect the sensor (pass through) cable connector from the 250-sheet controller card. Remove the sensor (pass through) with cable. Sensor (pass through) with cable removal Remove the 550-sheet frame assembly.
Page 419: Tray Roller Catch Assembly Removal
4062 Tray roller catch assembly removal Remove the media tray catch spring. Go to “Media tray catch spring removal” on page 412. Remove the tray roller catch assembly from the drawer. Tray roller catch assembly removal Remove the media tray catch spring. Go to “Media tray catch spring removal”...
Page 420: Output Expander Removals
4062 Release the two hooks (B) securing the options auto connect to the 550-sheet frame. Remove the upper interface cable assembly. Output expander removals Output expander rear door assembly removal Open the rear door assembly. Hold the door to approximately 45° angle, and force out the left hinge and slide the right hinge out to remove the door.
Page 421: Output Expander Left Outer Cover Removal
4062 Output expander left outer cover removal Remove the output expander rear door assembly. Go to “Output expander rear door assembly removal” on page 420. Grasp the lower rear corner of the left outer cover and pull out to remove. Output expander left inner cover removal Remove the output expander left outer cover.
Page 422: Output Expander Right Outer Cover Removal
4062 Output expander right outer cover removal Remove the output expander rear door assembly. Go to “Output expander rear door assembly removal” on page 420. Grasp the lower rear corner of the right outer cover and pull out to remove. Output expander right inner cover removal Remove the output expander right outer cover.
Page 423: Output Expander Media Bin Latch (Left And Right) Removal
4062 Output expander media bin latch (left and right) removal Remove the output expander left or right inner cover. Go to “Output expander left inner cover removal” on page 421 “Output expander right inner cover removal” on page 422. If removing the right side media bin latch, use a springhook to pull the media bin latch spring off the spring post on the output expander frame.
Page 424: Output Expander Media Bin Full Actuator Removal
4062 Rotate the output bin assembly downward and out of the slots to remove. Output expander media bin full actuator removal Remove the output expander left inner cover. Go to “Output expander left inner cover removal” on page 421. Unsnap the actuator from its hinges and pull out to remove. Output expander sensors (media bin full) assembly removal Remove the output bin left inner cover.
Page 425 4062 Release the tabs securing the sensors (media bin full) and remove. Installation note: Be sure to replace the sensors in the correct order. Make sure their positions are not switched. Remove the output expander controller card cover panel. Go to “Output expander controller card cover panel removal”...
Page 426: Output Expander Sensor (Media Bin Full) Bracket Assembly Removal
4062 Output expander sensor (media bin full) bracket assembly removal Remove the output expander left inner cover. Go to “Output expander left inner cover removal” on page 421. Grasp the sensor bracket and pull away from the option while releasing the tab. If replacing the bracket, remove the sensors (media bin full) from the bracket.
Page 427: Output Expander Controller Card Cover Panel Removal
4062 Output expander controller card cover panel removal Remove the output expander media output bin assembly. Go to “Output expander media output bin assembly removal” on page 423. Remove the screw (A) on the back side of the option. Remove the grounding screw (B) on the right output option frame guide the grounding cable through the hole in the frame.
Page 428: Sensor (Output Expander Pass Through) Removal
4062 Remove the two screws (A) securing the controller card to the frame. Remove the controller card. Replacement Note: Be sure to replace the interface connectors in their proper orientation as the two have common connection pins. Sensor (output expander pass through) removal Remove the output expander controller card cover panel.
Page 429: Output Expander Deﬂector Gate Removal
4062 Pull the connector harness through the frame and remove. Output expander deﬂector gate removal Use a spring hook to disconnect the upper end of the deﬂector gate spring. Temporarily hook the upper end of the deﬂector gate spring to the left frame. Repair information...
Page 430: Sensor (Output Expander Deﬂector Gate Hp) Removal
4062 Pull the deﬂector gate out of its hinges and remove. Sensor (output expander deﬂector gate HP) removal Remove the output expander left inner cover. Go to “Output expander left inner cover removal” on page 421. Remove the four screws securing the left frame assembly to the option. Pull the left frame assembly out far enough to gain access to the sensor (deﬂector gate HP).
Page 431: Sfp Stapler Assembly Removals
4062 Disconnect the harness to the sensor and remove. SFP stapler assembly removals SFP stapler assembly rear door assembly removal Open the rear door assembly. Force the left hinge out of the slot by pushing the door to the right. Once the left hinge has been disengaged, pull the right hinge out.
Page 432: Sfp Stapler Assembly Right Cover Removal
4062 SFP stapler assembly right cover removal Remove the two screws (A) on the inside of the exit bin compartment securing the right cover. Pull out on the front side of the right cover to disengage the tabs. Remove the right cover. Repair information...
Page 433: Sfp Stapler Assembly Left Cover Removal
4062 SFP stapler assembly left cover removal Remove the two screws (A) on the inside of the exit bin compartment securing the left cover. Pull out on the front side of the left cover to disengage the tabs. Remove the left cover. Repair information...
Page 434: Sfp Stapler Assembly Top Cover Removal
4062 SFP stapler assembly top cover removal Remove the left and right cover. Go to “SFP stapler assembly left cover removal” on page 433 “SFP stapler assembly right cover removal” on page 432. Remove the two screws (A) from the left and right side of the top cover. Pull up and toward the front to remove the top cover.
Page 435: Sfp Stapler Assembly Handle Cover Removal
4062 SFP stapler assembly handle cover removal Remove the left and right cover. Go to “SFP stapler assembly left cover removal” on page 433 “SFP stapler assembly right cover removal” on page 432. Remove two screws (A) from each side of the SFP stapler assembly. Lift up and to the rear to remove the cover.
Page 436: Sfp Stapler Assembly Led Sensor Cover Removal
4062 SFP stapler assembly LED sensor cover removal Remove the screw (A) securing the LED sensor cover to the underside of the output bin. Remove the output bin LED. Go to “SFP stapler assembly standard output bin LED and LED clear lens removal”...
Page 437: Sensor (Sfp Stapler Assembly Finisher Bin Media Present) Removal
4062 Remove the LED sensor cover. Sensor (SFP stapler assembly ﬁnisher bin media present) removal Remove the LED sensor cover. Go to “SFP stapler assembly LED sensor cover removal” on page 436. Using a ﬂat-blade screwdriver, release the tabs (A) on the sensor and remove it from the sensor cover. Remove the harness connected to the media bin present sensor.
Page 438: Sfp Stapler Assembly Standard Output Bin Led And Led Clear Lens Removal
4062 SFP stapler assembly standard output bin LED and LED clear lens removal Remove the LED sensor cover. Go to “SFP stapler assembly LED sensor cover removal” on page 436. Remove the two screws (A) securing the LED to the cover. Remove the LED and disconnect the harness.
Page 439: Sfp Stapler Assembly Tamper Drive Belt Removal
4062 SFP stapler assembly tamper drive belt removal Remove the tamper recoil spring. Pull the belt out the tamper belt holder and remove the belt from the pulley. SFP stapler assembly tamper drive motor assembly removal Remove the top cover. Go to “SFP stapler assembly top cover removal”...
Page 440: Sfp Stapler Assembly Media Stack Flap And Media Stack Flap Actuator Removal
4062 Remove the two screws (A) securing the tamper drive motor assembly to the tamper frame. Remove the tamper drive motor assembly. SFP stapler assembly media stack ﬂap and media stack ﬂap actuator removal Remove the handle cover. Go to “SFP stapler assembly handle cover removal”...
Page 441: Sfp Stapler Assembly Stapler Unit Assembly Removal
4062 SFP stapler assembly stapler unit assembly removal Remove the right cover. Go to “SFP stapler assembly right cover removal” on page 432. Remove the four cable harnesses attached to the stapler unit assembly. Repair information...
Page 442: Sfp Stapler Assembly Paddle Drive Motor Assembly Removal
4062 Remove the three screws (A) securing the stapler unit assembly. Remove the stapler unit assembly. SFP stapler assembly paddle drive motor assembly removal Remove the left cover. Go to “SFP stapler assembly left cover removal” on page 433. Disconnect the paddle motor harness from the controller card. Remove the cable from the harness clip.
Page 443: Sensor (Sfp Stapler Assembly Paddle Hp) Removal
4062 Using your ﬁngers, pinch tab (A) securing the sensor (media stack) and remove. Sensor (SFP stapler assembly paddle HP) removal Remove the left cover. Go to “SFP stapler assembly left cover removal” on page 433. Disconnect the harness to the sensor (paddle home position). Using your ﬁngers, pinch tab (A) securing the sensor (paddle home position) and remove.
Page 444: Sensor (Sfp Stapler Assembly Stapler Access Door Interlock) Removal
4062 Sensor (SFP stapler assembly stapler access door interlock) removal Remove the right cover. Go to “SFP stapler assembly right cover removal” on page 432. Disconnect the harness to the sensor (stapler access door interlock). Using your ﬁngers, pinch tab (A) securing the sensor (stapler access door interlock) and remove. Sensor (SFP stapler assembly tamper HP left and right) removal Remove the SFP stapler assembly top cover.
Page 445 4062 Using your ﬁngers, pinch the tabs (A) securing the staple ﬁnisher sensor (tamper HP left and right) and remove. Repair information...
Page 446: Sensor (Sfp Stapler Assembly Bin Full Send) Removal
4062 Sensor (SFP stapler assembly bin full send) removal Remove the stapler/stacker controller card assembly. Go to “Stapler/stacker controller card assembly removal” on page 450. Remove the two screws (A) securing the staple ﬁnisher sensor (bin full send). Disconnect the harness and remove. Repair information...
Page 447: Sensor (Sfp Stapler Assembly Bin Full Receive) Removal
4062 Sensor (SFP stapler assembly bin full receive) removal Remove the right cover. Go to “SFP stapler assembly right cover removal” on page 432. Remove the two screws (A) securing the sensor (bin full receive). Disconnect the harness and remove. Repair information...
Page 448: Sensor (Sfp Stapler Assembly Media In Stapler) Removal
4062 Sensor (SFP stapler assembly media in stapler) removal Remove the stapler unit assembly from the. Go to “SFP stapler assembly stapler unit assembly removal” on page 441. Using a ﬂat-blade screwdriver, release the tabs (A) securing the sensor. Using needlenose pliers, carefully grip the sensor and pull it out and disconnect the harness. Installation note: Using needlenose pliers, place the rear most tab in the sensor bracket ﬁrst.
Page 449: Sensor (Sfp Stapler Assembly Deﬂector Hp) Removal
4062 Sensor (SFP stapler assembly deﬂector HP) removal Remove the left cover. Go to “SFP stapler assembly left cover removal” on page 433. Disconnect the harness to the sensor (deﬂector HP). Release the tabs (A) securing the sensor to the unit. Note: The tabs may be difficult to access.
Page 450: Stapler/Stacker Controller Card Assembly Removal
4062 Stapler/stacker controller card assembly removal Remove the left cover. Go to “SFP stapler assembly left cover removal” on page 433. Disconnect all harnesses to the controller card. Remove the three screws (A) securing the stapler/stacker controller card assembly. Repair information...
Page 451: Component Locations
4062 Component locations T650, T652, and T654 exterior locations Printer conﬁgurations Basic model Feature Paper Capacity Standard exit bin 350 or 550 sheets Printer control panel Not applicable Multipurpose feeder 100 sheets Standard tray (Tray 1) 250 or 550 sheets Based on 75 g/m (20 lb.) paper.
Page 452 4062 Feature/Option Paper Capacity 500 sheets 5‑bin mailbox 5‑bin mailbox 500 sheets Envelope feeder 85 envelopes Standard tray (Tray 1) 250 or 550 sheets Not applicable Duplex unit Optional tray (Tray 2) 250 or 550 sheets Optional tray (Tray 3) 250 or 550 sheets Optional 2000‑sheet tray (Tray 4) 2000 sheets...
Page 453: T656 Exterior Locations
You must use either a printer stand or printer base if you are using a high-capacity input tray, a duplex unit and an input option, or more than one input option. If you purchased a multifunction printer (MFP) that scans, copies, and faxes, you may need additional furniture. For more information, see www.lexmark.com/multifunctionprinters. Component locations...
Page 454: Connectors
4062 Feature/Option Paper Capacity 500 sheets 5‑bin mailbox 5‑bin mailbox 500 sheets Optional tray (Tray 2) 250 or 550 sheets Optional tray (Tray 3) 250 or 550 sheets Optional 2000‑sheet tray (Tray 4) 2000 sheets Caster base Not applicable Based on 75 g/m (20 lb) paper.
Page 455: Maintenance
Damaged, missing, or altered parts, especially in the area of the On/Off switch and the power supply • Damaged, missing, or altered covers, especially in the area of the top cover and the power supply cover • Possible safety exposure from any non-Lexmark attachments Individual maintenance part expected life Description Part...
Page 456 4062 Description Part Maintenance Interval Printer maintenance kit (220 V type 2 fuser) 40X4768 150K Maintenance...
Page 457 4062...
Page 458: Parts Catalog
4062 Parts catalog Legend The following column headings are used in the parts catalog: • Asm‑index—Identiﬁes the item in the illustration • P/N—Identiﬁes the part number of a FRU • Units/mach—Refers to the number of units in a printer • Units/opt—Refers to the number of units in an option •...
Page 459: Assembly 1: Covers
4062 Assembly 1: Covers Parts catalog...
Page 460 Side cover, right (T652) 40X4337 Side cover, right (T654) 40X7033 Side cover, right (T656) 40X4336 Inner cover, right (T650, T652, and T654) 40X4322 Inner cover, left (T650, T652, and T654) 40X4339 Access door (T650, T652, and T654) 40X7034 Access cover (T656)
Page 461 4062 Asm-index Units/mach Units/FRU Description Removal procedure 40X4326 Output cover assembly Parts catalog...
Page 462 4062 Parts catalog...
Page 463: Assembly 2: T650, T652, And T654 Operator Panel
4062 Assembly 2: T650, T652, and T654 operator panel Parts catalog...
Page 464 4062 Assembly 2: T650, T652, and T654 operator panel Asm-index Units/mach Units/FRU Description Removal procedure 40X4366 Operator panel cable assembly (T650, T652, and T654) 40X4462 Operator panel door assembly (T650, T652, and T654) 40X4380 Counterbalance spring (T650, T652, and T654)
Page 465: Assembly 3: T656 Operator Panel, Mpf And Smart Card
4062 Assembly 3: T656 Operator panel, MPF and smart card Parts catalog...
Page 466 4062 Assembly 3: T656 Operator panel, MPF and smart card Asm-index Units/mach Units/FRU Description Removal procedure 40X7039 Card reader cable assembly (T656) 40X1972 Inner cover, right (T656) 40X2045 Operator panel cable assembly (T656) 40X2089 MPF tray door assembly (T656) 40X2077 Counterbalance spring (T656) 40X2078 Spring connector (T656)
Page 467: Assembly 4: Drive Motor Assemblies And Duplex
4062 Assembly 4: Drive motor assemblies and duplex Parts catalog...
Page 468 Duplex assembly with 2 belts and 2 pulleys (T652, T654, and T656) 40X4351 Duplex guide handle (T652, T654, and T656) 40X4352 Duplex guide, rear (T652, T654, and T656) -- 40X4353 Duplex guide spring, rear (T652, T654, and T656) 40X4349 Duplex guide spring, right (T652, T654, and...
Page 469 4062 Asm-index Units/mach Units/FRU Description Removal procedure 40X5749 Main drive motor assembly with option drive shaft 40X4386 Fuser drive release linkage 40X4343 Redrive motor assembly (T652, T654, and T656) Parts catalog...
Page 470 4062 Parts catalog...
Page 471: Assembly 5: Media Path And Ducts
4062 Assembly 5: Media path and ducts Parts catalog...
Page 472 40X1868 Print cartridge clamp assembly 40X4389 LVPS cooling duct 40X4391 Main cooling duct (T650) 40X4392 Main cooling duct (T652, T654, and T656) -- 40X4319 Fuser access door assembly (T650) 40X4318 Fuser access door assembly (T652, T654, and T656) Parts catalog...
Page 473: Assembly 6: Printhead, Charge, And Transfer
4062 Assembly 6: Printhead, charge, and transfer Parts catalog...
Page 474 Charge roll arm assembly, left 40X4316 Charge roll link spring, left 40X1864 Print cartridge ID connector assembly 40X4363 Main cooling fan (T650) 40X4364 Main cooling fan (T652, T654, and T656) 40X4372 Sensor (standard bin exit) actuator assembly 40X4369 Sensor (standard bin exit) Parts catalog...
Page 475 4062 Parts catalog...
Page 476: Assembly 7: Pick Arm Assembly, Trays, And Mpf
4062 Assembly 7: Pick arm assembly, trays, and MPF Parts catalog...
Page 477 MPF cam gear 40X1883 MPF pick roll assembly with ﬂanges and clip -- 40X4458 MPF lift plate assembly (T650) 40X4459 MPF lift plate assembly (T652, T654, and T656) 40X4460 MPF tray door assembly (T650) 40X4461 MPF tray door assembly (T652)
Page 478 4062 Parts catalog...
Page 479: Assembly 8: Lvps, Fuser, And Electrical Cables 1
4062 Assembly 8: LVPS, fuser, and electrical cables 1 Parts catalog...
Page 480 4062 Assembly 8: LVPS, fuser, and electrical cables 1 Asm-index Units/mach Units/FRU Description Removal procedure 40X1870 100V type 1 fuser assembly 40X4418 110V type 1 fuser assembly 40X1871 220V type 1 fuser assembly 40X5853 100V type 2 fuser assembly 40X5854 110V type 2 fuser assembly 40X5855 220V type 2 fuser assembly...
Page 481: Assembly 9: Hvps, System Card, And Electrical Cables 2
4062 Assembly 9: HVPS, system card, and electrical cables 2 Parts catalog...
Page 482 40X8673 Sensor (input) 40X4358 Envelope / input option tray cable assembly -- 40X5911 System card assembly (T654) 40X7036 System card assembly (T656) 40X4375 System card assembly (T650) 40X4474 System card assembly (T652) 40X4376 Output option interface cable assembly Parts catalog...
Page 483: Assembly 10: 250-Sheet Option Tray Assembly
4062 Assembly 10: 250-sheet option tray assembly Parts catalog...
Page 484 4062 Assembly 10: 250-sheet option tray assembly Asm-index Units/mach Units/FRU Description Removal procedure 40X4569 Complete 250 sheet option tray assembly -- 40X3447 250 Sheet pick arm bracket assembly 40X3448 250 Sheet bellcrank recoil spring 40X4308 Pick roll assembly (2) 40X4369 Sensor (media low) 40X4369 Sensor (media empty)
Page 485: Assembly 11: 550-Sheet Option Tray Assembly
4062 Assembly 11: 550-sheet option tray assembly Parts catalog...
Page 486 4062 Assembly 11: 550-sheet option tray assembly Asm-index Units/mach Units/FRU Description Removal procedure 40X4576 Complete 550 sheet option tray assembly -- 40X3454 550 Sheet pick arm bracket assembly 40X4307 550 Sheet bellcrank recoil spring 40X4308 Pick roll assembly (2) 40X4369 Sensor (media low) 40X4369 Sensor (media empty)
Page 487: Assembly 12: Hcit Sheet Option Tray Assembly
4062 Assembly 12: HCIT Sheet option tray assembly Parts catalog...
Page 488 4062 Assembly 12: HCIT Sheet option tray assembly Asm-index Units/mach Units/FRU Description Removal procedure 40X4579 Complete HCIT option tray assembly 40X4590 HCIT pick arm bracket assembly 40X4595 Pick arm sensor cable assembly 40X4591 HCIT bellcrank recoil spring 40X4308 Pick roll assembly (2) 40X4369 Sensor (media low) 40X8310...
Page 489: Assembly 13: Sfp Stapler Assembly 1
4062 Assembly 13: SFP stapler assembly 1 Parts catalog...
Page 490 4062 Assembly 13: SFP stapler assembly 1 Asm-index Units/mach Units/FRU Description Removal procedure 40X5547 SFP stapler assembly (comes completely assembled) Parts catalog...
Page 491: Assembly 14: Sfp Stapler Assembly 2
4062 Assembly 14: SFP stapler assembly 2 Parts catalog...
Page 492 4062 Assembly 14: SFP stapler assembly 2 Asm-index Units/mach Units/FRU Description Removal procedure 40X4612 Handle cover 40X4613 Rear door assembly 40X5910 Stapler cover 40X7466 Staple cartridge holder 40X4610 Right cover 40X5544 Sensor (bin full receive) 40X4617 Finisher bin spring 40X5545 Standard output bin LED 40X5727 LED clear lens...
Page 493: Assembly 15: Sfp Stapler Assembly 3
4062 Assembly 15: SFP stapler assembly 3 Parts catalog...
Page 494 4062 Assembly 15: SFP stapler assembly 3 Asm-index Units/mach Units/FRU Description Removal procedure 40X4645 Media stack ﬂap actuator 40X4646 Media stack ﬂap 40X4369 Sensor (media stack) 40X4621 Left tamper motor assembly 40X4622 Right tamper motor assembly 40X4624 Tamper recoil spring 40X4369 Sensor (tamper HP right) 40X4369...
Page 495: Assembly 16: 5-Bin Mailbox 1
4062 Assembly 16: 5-bin mailbox 1 Parts catalog...
Page 496 4062 Assembly 16: 5-bin mailbox 1 Asm-index Units/mach Units/FRU Description Removal procedure 40X5550 Complete 5 bin mailbox unit assembly 40X5708 Top cover 40X5709 Rear door assembly 40X5712 Right outer cover 40X5713 Right inner cover 40X5756 Output bin LED bracket 40X5717 Output bin LED assembly 40X5714 Standard output bin LED bracket...
Page 497 4062 Assembly 17: 5-bin mailbox 2 Parts catalog...
Page 498 4062 Assembly 17: 5-bin mailbox 2 Asm-index Units/mach Units/FRU Description Removal procedure 40X5550 Complete 5 bin mailbox unit assembly 40X0028 Spring (top) 40X2036 Deﬂector gate (top) 40X4772 Static brush mylar assembly 40X2037 Deﬂector gate 40X2065 Spring 40X3242 Sensor (pass through) 40X2061 Deﬂector gate solenoid 40X4369...
Page 499: Assembly 18: High Capacity Stacker
4062 Assembly 18: High capacity stacker Parts catalog...
Page 500 4062 Assembly 18: High capacity stacker Asm-index Units/mach Units/FRU Description Removal procedure 40X5730 Complete high capacity stacker assembly -- 40X5737 Rear door assembly 40X1988 Deﬂector gate 40X3264 Sensor (pass through) 40X5733 High capacity output controller card assembly 40X5734 Right frame 40X5735 Right cover 56P4210...
Page 501: Assembly 19: Output Expander
4062 Assembly 19: Output expander Parts catalog...
Page 502 4062 Assembly 19: Output expander Asm-index Units/mach Units/FRU Description Removal procedure 40X5719 Complete output expander assembly 40X5722 Rear door assembly 40X1988 Deﬂector gate 40X3264 Sensor (pass through) 40X1991 Output expander media bin latch 40X5726 Right inner cover 40X5725 Right outer cover 40X5755 LED clear lens 40X4773...
Page 503: Assembly 20: Envelope Feeder And External Duplex
4062 Assembly 20: Envelope feeder and external duplex Parts catalog...
Page 504 4062 Assembly 20: Envelope feeder and external duplex Asm-index Units/mach Units/FRU Description Removal procedure 40X5739 Envelope feeder (T650, T652, and T654 only - will not ﬁt the T656) 40X5904 External duplex Parts catalog...
Page 505: Assembly 21: Rfid Uhf Option Assembly
4062 Assembly 21: RFID UHF Option assembly Parts catalog...
Page 506 4062 Assembly 21: RFID UHF Option assembly Asm-index Units/mach Units/FRU Description Removal procedure 40X1483 US RFID UHF option assembly includes: • RFID UHF option • Firmware card • User ﬂash card • Fuser wiper • Interface card, plastic tee, screw •...
Page 507: Assembly 22: Miscellaneous 1
Printer maintenance kit (110 V type 2 fuser) -- 40X4768 Printer maintenance kit (220 V type 2 fuser) -- 40X5937 128MB DIMM, DDR1, for T650 and T652 40X5938 256MB DIMM, DDR1, for T650 and T652 40X5939 512MB DIMM, DDR1, for T650 and T652...
Page 508 (US/Americas) 40X5039 MarkNet N8150 802.11n wireless print server (WW, except US/Americas) 56P2129 Lexmark N4000e print server 56P2744 Lexmark N4050e (1 port USB) wireless 802.11g (US/Americas) 40X1593 MarkNet N7000e Fash Ethernet 10/100BaseTX-USB 40X1594 MarkNet N7002e Fast Ethernet 10/100BaseTX - Parallel...
Page 509: Assembly 23: Miscellaneous 2
4062 Assembly 23: Miscellaneous 2 Asm-index Units/mach Units/FRU Description Removal procedure 40X4823 Parallel 1284-B interface card 40X1367 10-Foot parallel printer cable 40X2665 Fuser oil wiper (black housing) 40X2666 Fuser wax wiper (gray housing) 40X1368 2-Meter USB printer cable Parts catalog...
Page 510 4062 Parts catalog...
Page 511: Assembly 24: Power Cords
4062 Assembly 24: Power cords Asm-index Units/mach Units/FRU Description Removal procedure 40X0269 Power cord LV, USA and Canada, Latin America 40X0288 Power cord HV, Argentina 40X1766 Power cord HV, Bolivia and Peru 40X0273 Power cord HV, Chile, Uruguay 40X3141 Power cord HV, Paraguay, Austria, Belgium, France, Germany, Italy, Netherlands, Bluemark, Czech and Solvic countries, Greece, Hungary, Medmark 1, Medmark 2,...
Page 512 4062 Parts catalog...
Page 513: Assembly 25: Universal Trays And Accessories
4062 Assembly 25: Universal trays and accessories Asm-index Units/mach Units/FRU Description Removal procedure 40X5857 Universal media drawer with tray, 200 sheet 40X5858 Universal media tray, 200 sheet 40X5859 Universal media drawer with tray, 400 sheet 40X5860 Universal media tray, 400 sheet 40X5945 33”...
Page 514 4062...
Page 515: Appendix A: Printer Speciﬁcations
T650: 80 W; T652: 85 W; T654: 85 W; T656: 100 Power Saver The product is in energy‑saving mode. T650: 12 W; T652: 13 W; T654: 14 W; T656: 19 W The product is plugged into an electrical outlet, but the power switch is turned off.
Page 516: Total Energy Usage
Note: Some models may not apply to your product. Mode 1‑meter average sound pressure, dBA Printing 53 dBA for T650, 54 dBA for T652, 55 dBA for T654, 56 dBA for T656 Scanning Copying Ready 30 dBA for T650, T652, T654; 27 dBA for T656 Values are subject to change.
Page 517: Appendix B: Options And Features
– IPDS and SCS/TNe – PrintCryption – PRESCRIBE • Printer hard disk • Lexmark Internal Solutions Ports (ISP) – RS‑232‑C serial interface ISP – Parallel 1284‑B interface ISP – MarkNet N8150 802.11 b/g/n Wireless ISP – MarkNet N8130 10/100 Fiber ISP –...
Page 518 4062 Vertical kiosk presenter Horizontal kiosk presenter RFID UHF Appendix B: Options and features...
Page 519: Appendix C: Theory Of Operation
4062 Appendix C: Theory of operation POR sequence As the printer turns on, the engine code goes through a series of tests to verify hardware integrity. If a hardware failure is detected, then it is reported to the printer. If the POR sequence cannot be completed successfully, then the printer may post an error message.
Page 520: T652 And T654 With Duplex, Paper Path, Rolls, And Sensors
Sensor (fuser output, narrow media) Sensor (duplex input) Sensor (duplex double feed) Sensor (duplex exit) Pick arm assembly Sensor (option pass through) PC cartridge Sensor (input) PC drum T652 and T654 with duplex, paper path, rolls, and sensors Appendix C: Theory of operation...
Page 521: Functions Of Main Components
4062 Part Standard bin full actuator and sensor Diverter Sensor (fuser output, narrow media) Sensor (duplex input) Pick arm assembly Sensor (option pass through) PC cartridge Sensor (input) PC drum Functions of main components • Pic arm assembly (feed) • •...
Page 522: Media Tray Assembly
4062 Media tray assembly Part Side guides Wear strips End guides Detection of media size The media size set for the media tray assembly is transmitted to the switch (media size) by moving these guides. The media size is detected by the on/off information of these switches. Appendix C: Theory of operation...
Page 523 4062 Pick arm assembly Part Media out actuator Sensor (media empty) Pick roll assemblies Sensor (media low) Sensor (media empty) Pick roll assemblies Sensor (media low) Media out actuator Since all media trays are functionally equivalent in terms of the switch (media size), sensor (media empty), sensor (media low), only the components of one tray are described here.
Page 524: Mpf
4062 When the pick rolls pick up media, the remaining media decreases, and the media out actuator will lower and interact with the sensor (media low) and sensor (media empty) to determine the amount of media remaining. The pick arm assembly (autocompensator) is a paper pick device that generates its own normal force. This force generation is inherent in the fundamental design of the pick arm.
Page 525 4062 Part MPF pick solenoid Sensor (MPF media empty) MPF pick roll assembly MPF feed roll The MPF pick roll feeds the media set on the MPF into the printer. MPF pick solenoid The MPF pick solenoid transmits the driving force from the main drive motor assembly to the MPF pick roll. Sensor (MPF media empty) The sensor (MPF media out) detects whether media is present on the MPF.
Page 526: Registration
4062 Registration Part Aligner assembly Sensor (input) Sensor (input) The sensor (input) is located just before the print cartridge and can detect whether media exists in the input path. Aligner assembly The aligner assembly is used to feed the media through the input path and to ensure that media is fed through the machine in a perfectly straight manner and not in a skewed manner.
Page 527: Transfer
4062 Transfer Part Transfer roll Transfer roll assembly The transfer roll assembly applies charge to the rear surface of the media when the media passes between the transfer roll assembly and photo conductor (drum). Thus, the toner image is transferred from the photo conductor (drum) surface to the media surface.
Page 528 4062 Part Polygon printhead LD card assembly — This generates the laser beam. The beam is turned on or off according to a print data signal coming from the system card. Printhead motor/polygon mirror — The polygon mirror is mounted to the shaft of the printhead motor, and is rotated at a high speed by the printhead motor.
Page 529: Oscillating Printhead Assembly
4062 When a laser beam is scanned across the photoconductor (drum) surface from one end to the other while turning on and off the beam, one line of latent image is created. If the scanning by the laser beam is repeated while rotating the drum, a two-dimensional image is created.
Page 530: Fuser
4062 Part Oscillating printhead LD card assembly — This generates the laser beam. The beam is turned on or off according to a print data signal coming from the system card. Printhead motor/polygon mirror — The polygon mirror is mounted to the shaft of the printhead motor, and is rotated at a high speed by the printhead motor.
Page 531: Fuser Components
4062 Part Fuser unit assembly Fuser components The printhead scans the photo conductor drum surface with a laser beam. It consists of four components: laser diode (LD) card assembly, printhead motor, polygon mirror, and the start of scan card assembly. Appendix C: Theory of operation...
Page 532 4062 Part Fuser unit assembly Sensor (fuser output) Sensor (narrow media) Fuser solenoid Pressure roll Fuser lamp Heat roll The heat roll is a hollow metal tube with a coated surface. This tube is heated by the inner heater lamp. The heat is applied to the media passing between the heat roll and pressure roll, fusing the toner on the media.
Page 533: Fuser Unit Assembly (Types 1 And 2)
4062 Thermistor The thermistor monitors the surface temperature of the media-feed portion of the heat roll to control on/off of the main heater lamp and sub heater lamp. Sensor (fuser output) The sensor (fuser output) detects the arrival of media at the detection point in the exit area of the fuser, and also detects the ejection of media from this point.
Page 534: Exit
4062 Part Hot roll Full detac Full detac Pressure roll Hot roll Pressure roll Fuser lamp Exit Appendix C: Theory of operation...
Page 535: Drive
4062 Part Sensor (standard bin exit) Sensor (standard bin full) The sensor (standard bin full) detects whether the standard bin is full by moving the actuator up and down. Drive Main drive motor assembly The main drive motor is a DC motor that drives the print cartridge, aligner, MFP, and fuser. Redrive motor assembly The redrive motor assembly is a DC motor that drives the redrive assembly that transports the media into the standard bin or output option.
Page 536: Electrical Components And Controller
4062 Electrical components and controller Part LVPS card assembly Duplex cooling fan Print cartridge cooling fan HVPS card assembly System card assembly Main cooling fan Switch (printer front door interlock) The switch is a safety switch to cut off a 24 VDC power supply from the LVPS card assembly to the high volt power supply (HVPS) card assembly, printer system card assembly and to the main drive motor assembly, while the printer front door assembly is open.
Page 537: Printhead Control
4062 LVPS card assembly The LVPS card assembly generates low voltages 5V for logic circuits, 5V for laser diodes, and 24V for cooling fans. The LVPS is switchable and can be switched to work with 100V, 110V, and 220V machines. HVPS card assembly The HVPS card assembly generates AC power and feeds it to the developer roll, the transfer roll assembly, and the charge roll assembly.
Page 538: Xerographic And Print Cartridge Components
4062 The fuser temperature control starts when the fuser ready in the system card assembly is turned on after a preset time period has passed from power on. If a failure occurs, the heater lamps are turned off, the fuser ready is turned off, and then the fuser temperature control is stopped.
Page 539 4062 Charge The charge roll places a uniform negative electrostatic charge on the surface of the drum. The drum surface is made of a photoconductive material that holds an electrical charge as long as the drum remains in darkness. Light striking the drum discharges the surface charge. HVPS Charge roll (-VDC)
Page 540 4062 This discharge/no discharge process creates an invisible, electrostatic image on the surface of the drum. This image is called a latent image. Modulated Laser Beam Printhead DRUM Drum Surface Drum Surface Image Voltage Laser Beam Laser Beam Discharge Level Invisible Latent Image Development The toner contained within the PC cartridge has an electrical property that causes it to adhere to the...
Page 541 4062 The toner adhering to the development roll is always in contact with the drum surface. When a less negative point on the drum (a discharged area) comes in contact with the more negative charged toner on the magnet roll, toner transfers from the magnet roll to that point on the drum. There is now a visible toner image on the drum surface.
Page 542 4062 Transfer As the paper travels between the transfer roll and the photoconductor (drum), the transfer roll applies a charge to the back of the printing paper. This positive charge transfers the negative charged toner image from the photoconductor (drum) to the top surface of the paper. The toner image is now on the paper and the paper is now stuck to the photoconductor (drum) due to the relative electrical differences between the negative electrical charge of the inner conductive layer of the drum and the positive electrical charge of the paper.
Page 543 4062 Auto density sensing The cleaning blade removes any toner that remains on the drum after the transfer process. The toner that the cleaning blade removes is collected inside the sealed PC cartridge. Part Sensor shield assembly Sensor (toner density) The image density sensor assembly uses a reﬂection type sensor that detects a pre-placed toner patch and image on the photoconductor (drum) and outputs pulses when the central line of the patch image aligns with the central line of the detector.
Page 544: High Capacity Input Tray (Hcit) Tray Assembly
4062 High capacity input tray (HCIT) tray assembly Part Rear media tray guide Media end guide Part Pick arm assembly Sensor (media empty) Appendix C: Theory of operation...
Page 545: 250-Sheet/550-Sheet Tray Assembly
4062 Part Sensor (media low) Sensor (tray raised HP) Tray lift drive motor HCF drawer assembly Sensor (pass through) Media size actuator 250-sheet/550-sheet tray assembly Part Lockable back restraint Media end guide Auto size ﬁnger actuator Rear media tray guide Appendix C: Theory of operation...
Page 546 4062 Media size sensing The media size set for the media tray assembly is set by positioning the right media guide, unlocking the slider lock, and sliding the rear paper guide. The rear paper guide triggers the movement of the auto size sensing ﬁnger, which then sets the switches of the controller card board.
Page 547 4062 550-sheet tray Sensor A Sensor B Tray full unblocked unblocked Tray low blocked blocked Tray empty blocked unblocked Note: Media size sensing through sensor blocking sequence Pick arm assembly Sensor A Media out actuator Sensor (media empty) Pick roll assemblies Sensor (media low) Since all media trays are functionally equivalent in terms of the switch (media size), sensor (media empty), sensor (media low), only the components of one tray are described here.
Page 548 4062 Switch (media size) This switch (media size) sets the size of media supplied from each media tray assembly. A signal indicating the media size is transmitted as a voltage to the printer system card assembly. Sensor (media empty) If media runs out in a media tray assembly, the actuator lowers and the actuator ﬂag, unlocks the sensing area of the sensor (media empty).
Page 549: Paper Path, Rolls, And Sensors
4062 Part Pick arm assembly Sensor (pass through) 550-sheet drawer assembly Sensor (media low) Sensor (media empty) Paper path, rolls, and sensors Media transport path The following is a cross section of the printer and the tandem tray module, showing the main components directly associated with the media path and transport.
Page 550 4062 Model T650 paper path, rolls, and sensors Part Standard bin full actuator and sensor Diverter Sensor (fuser output, narrow media) Sensor (duplex input) Sensor (duplex double feed) Sensor (duplex exit) Pick arm assembly Sensor (option pass through) PC cartridge Sensor (input) PC drum Appendix C: Theory of operation...
Page 551 4062 Model T652 and T654 paper path, rolls, and sensors Part Standard bin full actuator and sensor Diverter Sensor (fuser output, narrow media) Sensor (duplex input) Pick arm assembly Sensor (option pass through) PC cartridge Sensor (input) PC drum Functions of main components When the 250 or 550 sheet input trays are installed under the printer, additional trays are available.
Page 552: Duplex
4062 Media tray assembly It is necessary to adjust the media tray rear guide and media tray side guide of the media tray assembly to match the media size. Rear media guide The rear media tray guide assembly can be adjusted to different media sizes by moving it to the front or rear. The rear guide should come into contact with the media and hold it in position.
Page 553: Model T650 Duplex Paper Path
4062 Model T650 duplex paper path Part Standard bin full actuator and sensor Diverter Sensor (fuser output, arrow media) Sensor (duplex input) Sensor (duplex double feed) Sensor (duplex exit) Pick arm assembly Sensor (option pass through) PC cartridge Sensor (input) PC drum Appendix C: Theory of operation...
Page 554 4062 Model T652 and T654 duplex paper path Part Standard bin full actuator and sensor Diverter Sensor (fuser output, arrow media) Sensor (duplex input) Pick arm assembly Sensor (option pass through) PC cartridge Sensor (input) PC drum Functions of main components When the duplex is installed, duplex (double-sided) printing is available with the printer.
Page 555 4062 Sensor (duplex input) The sensor (duplex wait) detects whether media is remaining in the duplex. Duplex drive motor assembly The duplex drive motor assembly transmits driving force to the two duplex media transport roll assemblies and the duplex media center transport roll assembly middle that feeds media. Part Duplex drive motor assembly Sensor (duplex input)
Page 556 4062...
Page 557: Appendix D: Acronyms
4062 Appendix D: Acronyms Acronyms BLDC Brushless DC Motor Customer Replaceable Unit Customer Setup DIMM Dual Inline Memory Module DRAM Dynamic Random Access Memory Digital multimeter Enhanced Data Out EEPROM Electrically Erasable Programmable Read-Only Memory Electrophotographic Process EPROM Erasable Programmable Read-Only Memory Electrostatic Discharge Field Replaceable Unit Gigabyte...
Page 558 4062 Raster Imaging Processor Read Only Memory SDRAM Synchronous Dual Random Access Memory SIMM Single Inline Memory Module SRAM Static Random Access Memory Universally Adjustable Tray Used Parts Return V ac Volts alternating current V dc Volts direct current Volt Ohmmeter Appendix D: Acronyms...
Page 559: Index
4062 Index 80 Routine maintenance needed 179 Numerics 81 Routine Maintenance 179 1565 Emulation error, load emulation option 180 88 Cartridge low 179 200–282 Paper jam 179 88.yy Cartridge nearly low 179 250-sheet/550-sheet tray assembly, theory 545 88.yy Replace cartridge 179 281 paper jam 145 282 paper jam 145 Symbols...
Page 560 4062 paper prompts 258 feed test (ﬁnisher) 248 PPDS emulation 257 ﬁnisher tests (sensor test) 248 print quality pages 255 fuser page count 252 reset maintenance counter 255 fuser temperature 252 gap adjust 253 size sensing 256 input tray feed test 244 USB speed 261 input tray sensor tests 244 wipe disk 259...
Page 561 4062 EP setup Flushing buffer 161 automatic darkness adjustment 253 Formatting Disk x/y XX% 161 charge roll voltage 253 Formatting Flash 161 EP defaults 252 fuser components, theory 531 fuser control, theory 537 fuser page count 252 fuser temperature 252 fuser unit assembly (types 1 and 2), theory 533 gap adjust 253 fuser, theory 530...
Page 562 4062 271–279 137 sensor test (high capacity output stacker) 247 280 paper jams 144 sensor test (output expander) 246 283 staple jam 146 sensor test (standard bin) 246 stapler 146 Overﬂow bin full 165 laser notices 17 panel menus 256 Load <src>...
Page 563 4062 printer 59 Incompatible tray <x> 178 conﬁgurations 451, 453 61 Remove defective hard disk 178 models 451, 453 62 Disk full 179 Printer busy, Continue, Quit 166 80 Routine maintenance needed 179 81 Routine Maintenance 179 printer control panel 233 88 Cartridge low 179 indicator light 235 88.yy Cartridge nearly low 179...
Page 564 4062 Menus are Disabled 164 Unsupported USB device, please remove 171 Must be in Ready state to enter menus 164 Unsupported USB hub, please remove 171 Network 164 USB drive removed 171 Network <x> 164 USB/USB <x> 171 View supplies 171 Network <x>, <y>...
Page 565 4062 5-bin mailbox media bin extension assembly 354 high capacity stacker left frame 396 5-bin mailbox media bin ﬁfth deﬂector 352 high capacity stacker left mounting bracket 401 5-bin mailbox media bin ﬁrst through fourth high capacity stacker media output bin deﬂector 353 assembly 391 high capacity stacker rear door assembly 389...
Page 566 T650 rear lower cover assembly 326 assembly 415 T650 right side cover 294 sensor (high capacity stacker deﬂector gate T650, T652, and T654 LCD screen bezel 298 HP) 401 T650, T652, and T654 left operator panel hinge sensor (high capacity stacker pass through) 399...
Page 567 40 Submitting selection 170 skewed print 52 solid black pages 42 spots appear on prints 49 T650 paper path, theory 519 vertical lines and bands (process direction) appear T652 and T654 paper path, theory 520 on prints 44 Index...
Page 568 4062 vertical stripes (process direction) appear on prints 46 Unsupported disk 171 Unsupported USB device, please remove 171 Unsupported USB hub, please remove 171 USB drive removed 171 USB HS test mode 240 USB/USB <x> 171 View supplies 171 Waiting 172 xerographic and print cartridge components, theory 538 Index...
Page 569: Part Number Index
EU RFID UHF option assembly......................... 506 40X1556 Parts pack, ISP thumbscrew and standoff....................507 40X1592 Lexmark MarkNet N7020e (4 port USB) ethernet 10base T/100Base TX/1000BaseT....508 40X1593 MarkNet N7000e Fash Ethernet 10/100BaseTX-USB................. 508 40X1594 MarkNet N7002e Fast Ethernet 10/100BaseTX - Parallel..............508 40X1766 Power cord HV, Bolivia and Peru........................
Page 570 4062 Part name Page 40X1864 Print cartridge ID connector assembly....................474 40X1865 Printhead cable (T652, T654, and T656)....................474 40X1866 Sensor shield assembly..........................480 40X1868 Print cartridge clamp assembly......................... 472 40X1869 Transfer deﬂector with static brush......................472 40X1870 100V type 1 fuser assembly........................480 40X1871 220V type 1 fuser assembly........................480...
Page 571 550 Sheet option drawer assembly......................486 40X4302 Aligner assembly with ground strap and adj. screw (T650).............. 468 40X4303 Aligner assembly with ground strap and adj. screw (T652, T654, and T656)......468 40X4304 Pick arm assembly with spring, 250 sheet (T650)................477 40X4305 Pick arm assembly with spring, 500 sheet (T652, T654, and T656)..........477 40X4306 Pick arm spring (T650)..........................
Page 572 Duplex drive motor assembly (T652, T654, and T656)..............468 40X4345 Duplex (input) sensor assembly (T652, T654, and T656)..............468 40X4346 Duplex assembly with 2 belts and 2 pulleys (T652, T654, and T656)........... 468 40X4348 Duplex guide assembly, front (T652, T654, and T656)..............468 40X4349 Duplex guide spring, right (T652, T654, and T656)................
Page 573 4062 Part name Page 40X4354 Duplex drive belt, upper (T652, T654, and T656)................468 40X4355 LVPS card assembly............................. 480 40X4356 Duplex cooling fan, two wire........................480 40X4357 Duplex cooling fan cable assembly......................480 40X4358 Envelope / input option tray cable assembly..................482 40X4359 Print cartridge cooling fan, three wire.....................
Page 574 Media tray roller catch assembly......................486 40X4395 Tray roller catch assembly...........................477 40X4396 Operator panel hinge assembly with interlock switch, left (T650, T652, and T654)....464 40X4397 Operator panel hinge assembly, right (T650, T652, and T654)............464 40X4406 Print cartridge support roller........................472 40X4415 LCD screen bezel (T650n)..........................464...
Page 575 Output bail..............................460 40X4471 LCD screen bezel (T652dn)........................464 40X4472 Switch (media size) assembly........................477 40X4473 Option drive shaft with spring (T652, T654, and T656)..............468 40X4474 System card assembly (T652)........................482 40X4494 LCD screen bezel (T652n).......................... 464 40X4569 Complete 250 sheet option tray assembly....................484 40X4570 Anti-tip latch assembly......................
Page 576 40X4612 Handle cover..............................492 40X4613 Rear door assembly............................492 40X4615 Paddle drive motor............................494 40X4616 Operator panel latch assembly (T650, T652, and T654)..............464 40X4617 Finisher bin spring............................492 40X4618 Sensor (ﬁnisher bin media present)......................492 40X4619 Media output bin extension........................492 40X4621 Left tamper motor assembly........................
Page 577 Standard output bin LED..........................492 40X5547 SFP stapler assembly (comes completely assembled)...............490 40X5550 Complete 5 bin mailbox unit assembly..................496, 498 40X5551 Duplex guide spring, left (T652, T654, and T656)................468 40X5704 256MB user ﬂash memory card for T65X....................507 40X5708 Top cover.................................496 40X5709 Rear door assembly............................496...
Page 578 Right cover..............................500 40X5736 Left cover................................ 500 40X5737 Rear door assembly............................. 500 40X5739 Envelope feeder (T650, T652, and T654 only - will not ﬁt the T656)..........504 40X5746 Operator panel bezel, left ..........................464 40X5747 Output expander controller card......................502 40X5748 Left frame................................500...
Page 579 4062 Part name Page 40X5937 128MB DIMM, DDR1, for T650 and T652....................507 40X5938 256MB DIMM, DDR1, for T650 and T652....................507 40X5939 512MB DIMM, DDR1, for T650 and T652....................507 40X5945 33” banner drawer with tray........................513 40X5946 33” banner tray............................... 513 40X5947 48”...
Page 580 Sensor (input)..............................482 41X4417 Fuser wiper cover assembly........................460 56P2129 Lexmark N4000e print server........................508 56P2744 Lexmark N4050e (1 port USB) wireless 802.11g (US/Americas)............508 56P4191 Media bail assembly.............................496 56P4208 Switch (media bin HP)..........................500 56P4210 Media output bin recoil spring........................500 56P4212 Media bin full actuator..........................500...
Page 581: Part Name Index
100V type 2 fuser assembly........................480 40X4418 110V type 1 fuser assembly......................... 480 40X5854 110V type 2 fuser assembly........................480 40X5937 128MB DIMM, DDR1, for T650 and T652....................507 40X5302 12MB SO-DIMM, DDR2 for T654.......................507 40X5303 1GB (1024MB) SO-DIMM, DDR2 for T654....................507 40X1368 2-Meter USB printer cable..........................509...
Page 582 Adjustable label stacking device....................... 513 40X4302 Aligner assembly with ground strap and adj. screw (T650).............. 468 40X4303 Aligner assembly with ground strap and adj. screw (T652, T654, and T656)......468 40X4570 Anti-tip latch assembly......................484, 486, 488 40X5976 Banner transfer roll............................474 99A0954 Bevel gear with grease packet and washer..................
Page 583 Duplex guide, rear (T652, T654, and T656)..................468 40X4358 Envelope / input option tray cable assembly..................482 40X5739 Envelope feeder (T650, T652, and T654 only - will not ﬁt the T656)..........504 40X4385 Envelope feeder interface cover.......................472 40X4384 EP cooling fan duct (T625, T654, and T656)..................472 40X1484 EU RFID UHF option assembly.........................
Page 584 4062 Part name Page 40X4318 Fuser access door assembly (T652, T654, and T656)................472 40X4386 Fuser drive release linkage........................469 40X4419 Fuser interface cable assembly........................ 480 40X2665 Fuser oil wiper (black housing)......................... 509 40X2666 Fuser wax wiper (gray housing)........................ 509 41X4417 Fuser wiper cover assembly........................460 40X4612 Handle cover..............................492...
Page 585 Page 40X5861 Kiosk presenter ............................. 513 40X5969 Korean font card............................507 40X4320 Laser cover assembly, 250 sheet output (T650 and T652).............. 460 40X4321 Laser cover assembly, 500 sheet output (T654)..................460 40X7031 Laser cover assembly, 500 sheet output (T656)..................460 40X4415 LCD screen bezel (T650n).......................... 464 40X4471 LCD screen bezel (T652dn)........................464...
Page 586 40X4392 Main cooling duct (T652, T654, and T656)....................472 40X4363 Main cooling fan (T650)..........................474 40X4364 Main cooling fan (T652, T654, and T656)....................474 40X5749 Main drive motor assembly with option drive shaft................469 40X1593 MarkNet N7000e Fash Ethernet 10/100BaseTX-USB................. 508 40X1594 MarkNet N7002e Fast Ethernet 10/100BaseTX - Parallel..............508...
Page 587 Operator panel door assembly (T656)....................466 40X4631 Operator panel door latch assembly (T656)..................466 40X4396 Operator panel hinge assembly with interlock switch, left (T650, T652, and T654)....464 40X4397 Operator panel hinge assembly, right (T650, T652, and T654)............464 40X4616 Operator panel latch assembly (T650, T652, and T654)..............464 40X1863 Option drive shaft with spring (T650)......................
Page 588 4062 Part name Page 40X4304 Pick arm assembly with spring, 250 sheet (T650)................477 40X4305 Pick arm assembly with spring, 500 sheet (T652, T654, and T656)..........477 40X4313 Pick arm sensor cable assembly....................... 477 40X4595 Pick arm sensor cable assembly.......................488 40X4306 Pick arm spring (T650)..........................477 40X4307 Pick arm spring (T652, T654, and T656)....................477...
Page 589 Printhead cable (T652, T654, and T656)....................474 40X4367 Printhead cable assembly (T650)......................474 40X4463 Printhead with cable assembly (T650).....................474 40X4464 Printhead with cable assembly (T652 and T654)................. 474 40X7040 Printhead with cable assembly (T656).....................474 40X4613 Rear door assembly............................492 40X5709 Rear door assembly............................496 40X5737 Rear door assembly.............................
Page 590 Side cover, left (T654)..........................460 40X7032 Side cover, left (T656)..........................460 40X4338 Side cover, right (T650)..........................460 40X1862 Side cover, right (T652)..........................460 40X4337 Side cover, right (T654)..........................460 40X7033 Side cover, right (T656)..........................460 40X1889 Simplex assembly (T652, T654)........................ 472 40X5970 Simpliﬁed Chinese font card........................
Page 591 System card assembly (T652)........................482 40X5911 System card assembly (T654)........................482 40X7036 System card assembly (T656)........................482 40X5956 T650/T652 Card for IPDS and SCS/TNe....................507 40X7029 T650/T652 Card for PRESCRIBE Emulation ..................507 40X5955 T650/T652 Forms and Bar code card.....................507 40X5962 T650/T652 KS emulation card........................507 40X5957 T654 card for IPDS and SCS/TNe......................507...
Page 592 40X5860 Universal media tray, 400 sheet........................ 513 40X4571 Upper interface cable assembly......................484, 486 40X1483 US RFID UHF option assembly......................... 506 40X4377 USB cable assembly (T650, T652, and T654)..................464 40X2051 USB cable assembly (T656)........................466 99A1206 Wear strips, 3 row dimpled 250 sheet..................... 513 40X2787 Wear strips, 3 row dimpled 550 sheet.....................
Page 593 Print defects guide Page 1 of 1 Print defects guide Match a set of repeating defects on a print job to the marks on one of the vertical lines. The line that best matches the defects on the print job indicates which particular part may be causing the defect. For example, the distance between these two marks represents a repeating defect that occurs every 28.3 mm (1.11 in.), which means the charge rollers may need to be replaced.

This manual is also suitable for:

T650 T656 T654

Lexmark T652 Service Manual

Product Information

Edition Notice

Notices and Safety Information

Preface

General Information

Diagnostic Information

Service Menus

Repair Information

Quick Links

Service Manual

Related Manuals for Lexmark T652

Summary of Contents for Lexmark T652
