Table 3: Operation of Auxiliary Contact
Configuration
Contact
Setup
Occupied
Status
Normally Opened
Closed
Normally Closed
Opened
To configure the auxiliary contact while in the Installer
Configuration Menu:
1. Answer NO to all prompts until the auxiliary
contact prompt appears in the display. Press YES
to enter the auxiliary contact menu.
2. Use the UP/DOWN arrow keys to select Normally
Open (N.O.) or Normally Closed (N.C.). Press
YES to store the selection.
The display now shows the progressive recovery
prompt. See the Enable/Disable Progressive Recovery
(Prog rec) section for instructions.
Enable/Disable Progressive Recovery (Prog rec)
When the progressive recovery is enabled, the desired
occupied temperature is attained by the time the
occupied schedule starts
When the progressive recovery is disabled, the system
restarts at the programmed occupied time.
Note: Programming one of the digital inputs to
remote NSB disables the progressive recovery
function.
To enable/disable the progressive recovery feature
while in the Installer Configuration Menu:
1. Answer NO to all prompts until the progressive
recovery prompt appears in the display. Press
YES to enter the Progressive Recovery menu.
2. Use the UP/DOWN arrow keys to select on or off.
Press YES to store the selection.
3. The exit menu is displayed. Press YES to exit the
Installer Configuration Menu or press NO to return
to the beginning of the menu (digital input
configuration).
Operation
Contact
Programming/Operating the T600MSP-2
Unoccupied
Once the T600MSP-2 thermostat is configured through
Status
the Installer Configuration Menu, the thermostat's
Opened
operating parameters can be programmed through the
Main User Menu (access the Main User Menu by
Closed
pressing the MENU key during normal thermostat
operation). The Main User Menu contains the basic
operating features of the T600MSP-2 thermostat.
The Main User Menu uses Auto Help. Auto Help is
displayed automatically in the Main User Menu when
there is a pause in programming activity. To exit Auto
Help, continue with the programming selection.
When the thermostat is in the Main User Menu and is
left unattended for 45 seconds, it reverts to the Status
Display Menu.
Follow the steps in Table 4 to program the T600MSP-2
thermostat.
Table 4: Programming the T600MSP-2 Thermostat
RoomTemp
75.0 °F
Override
schd Y/N
Resume
schd Y/N
Temperat
set? Y/N
Sys mode
set? Y/N
Fan mode
set? Y/N
Continued on the next page . . .
T600MSP-2 Programmable Thermostat Installation Instructions
Press the MENU key while in the
Status Display Menu to enter the Main
User Menu.
Overrides Unoccupied Setpoints
Only Appears if Thermostat is in
Unoccupied State
See Enabling Override Schedule.
Resumes Regular Programmed
Schedule and Setpoints
Only Appears if Thermostat is in
Override Mode
See Resuming the Programmed
Schedule.
Sets the Temperature Setpoints
See Entering Temperature Setpoints.
Selects the System Mode
Default: Automatic Mode (auto)
See Selecting the System Mode.
Selects the Fan Mode
Default: Automatic (auto)
See Selecting the Fan Mode.
11
