Table 4: Programming the T600MSP-2
Thermostat (Cont.)
Sets the Occupied and Unoccupied
Time Periods
Schedule
See Programming the Daily Schedule
set? Y/N
– Two-Event and Programming the
Daily Schedule – Four-Event.
Clock
Sets the Day and Time
set? Y/N
See Setting the Day and Time.
Sets a Permanent Hold on the
Schedule
Schedule or Resumes the Schedule
hold? Y/N
See Setting Schedule Hold.
Enabling Override Schedule
Note: Enabling Override Schedule only appears
when in the Unoccupied Mode.
The override schedule prompt only appears when the
thermostat is in the unoccupied state. This menu
selection gives the user the option of overriding the
unoccupied setpoints with the occupied setpoints for
the amount of time specified under the Establishing
the Temporary Occupancy Time (TOccTime)
parameter (see Configuring the T600MSP-2 section).
Note: If one of the digital inputs is configured to
operate as a remote override contact, this menu is
disabled.
To override the unoccupied state while in the Main
User Menu:
1. Answer NO to all prompts until the Override
Schedule prompt appears. If the thermostat is in
the unoccupied state, this is the first prompt.
2. Press YES to enable the temporary override. The
T600MSP-2 returns to the Status Display Menu.
When scrolling through the Status Display Menu,
Override now appears for the schedule status
parameter.
Resuming the Programmed Schedule
This menu only appears when the T600MSP-2 is in
the:
•
unoccupied override mode
•
permanent occupied hold mode
•
permanent unoccupied hold mode
12
T600MSP-2 Programmable Thermostat Installation Instructions
Note: If the T600MSP-2 thermostat is not in one of
these modes, this prompt does not appear. Answering
YES to this prompt enables the T600MSP-2
thermostat to resume the regular scheduled program
and setpoints.
To resume the schedule while in the Main User Menu:
1. Answer NO to all prompts until the Resume
Schedule prompt appears. If the thermostat is in
the temporary occupancy state, this is the first
prompt.
2. Press YES to resume the programmed schedule.
The T600MSP-2 thermostat returns to the Status
Display Menu.
Entering Permanent Temperature Setpoints
The first prompt appearing in the Main User Menu of
the T600MSP-2 thermostat is to set the permanent
temperature setpoints. Permanent setpoints are stored
in the programmed schedule.
To enter the permanent heating and cooling setpoints
for the occupied and unoccupied modes, follow the
steps in Table 5. When changing the temperatures,
pressing the keys once changes the temperature
0.5 F/C° and holding down the keys changes the
temperature by 5 F/C° increments.
Table 5: Entering Permanent Temperature
Setpoints
RoomTemp
Press MENU from the Status Display
75.0°F
Menu to enter the Main User Menu.
Answer NO to all prompts until the
temperature set prompt appears in
Temperat
the display (it may be the first
set? Y/N
prompt). Press YES to enter
temperature setting menu.
Press YES to change occupied
Cooling
cooling setpoint. Press NO to
set? Y/N
advance to occupied heating setpoint
menu.
Use the UP/DOWN arrow keys to set
Cooling
temperature. Press YES to store
75.0°F
value and advance to next menu.
Press YES to change the occupied
Heating
heating setpoint. Press NO to
set? Y/N
advance to unoccupied cooling
setpoint menu.
Continued on Next Page. . .
