Note: When adjusting the temperature, holding the
keys down changes the temperature by 5 F/C°
increments.
To set the minimum cooling setpoint while in the
Installer Configuration Menu:
1. Answer NO to all prompts until the minimum
cooling setpoint prompt appears in the display.
Press YES to enter the minimum cooling setpoint
menu.
2. Use the UP/DOWN arrow keys to adjust the
minimum cooling setpoint temperature. Press YES
to store the value.
The display now shows the anti-short cycle timer
prompt. See the Setting the Anti-short Cycle Timer
(Anticycl) section for instructions.
Setting the Anti-short Cycle Timer (Anticycl)
The anti-short cycle timer establishes the minimum
on/off times for the cooling and heating stages. The
timer is adjustable from 0 to 5 minutes in 1-minute
increments. Set the anti-short cycle to 0 for equipment
that possesses its own anti-short cycle timer.
!
CAUTION: Risk of Property Damage.
Do not set the T600MSP-2 thermostat anti-short
cycling timer to 0 minutes if the controlled equipment
is not protected by its own internal anti-short cycling
timer. Doing so may result in damage to the
controlled equipment.
To set the anti-short cycle time while in the Installer
Configuration Menu:
1. Answer NO to all prompts until the anti-short cycle
timer prompt appears in the display. Press YES to
enter the anti-short cycle timer menu.
2. Use the UP/DOWN arrow keys to adjust the
minimum on/off times for the heating and cooling
stages. Press YES to store the value.
The display now shows the heating cycles per hour
setup prompt. See the Setting the Maximum Heating
Cycles per Hour (Heat cph) section for instructions.
Setting the Maximum Heating Cycles per Hour
(Heat cph)
The heating cycles per hour establishes the maximum
number of times the equipment is turned on and off in
one hour. The selection ranges from 3 to 8 cycles per
hour.
8
T600MSP-2 Programmable Thermostat Installation Instructions
Note: A higher number of heating cycles per hour
results in more accurate temperature control, but could
accelerate the wear of mechanical components in the
equipment.
To set the maximum number of heating cycles per
hour while in the Installer Configuration Menu:
1. Answer NO to all prompts until the heating cycles
per hour prompt appears in the display. Press
YES to enter the heating cycles per hour menu.
2. Use the UP/DOWN arrow keys to adjust the
maximum number of heating cycles per hour.
Press YES to store the value.
The display now shows the cooling cycles per hour
setup prompt. See the Setting the Maximum Cooling
Cycles per Hour (Cool cph) section for instructions.
Setting the Maximum Cooling Cycles per Hour
(Cool cph)
The cooling cycles per hour establishes the maximum
number of times the equipment turns on and off in one
hour. The selection ranges from 3 to 4 cycles per hour.
Note: A higher number of cooling cycles per hour
results in more accurate temperature control, but could
accelerate the wear of mechanical components in the
equipment.
To set the maximum number of cooling cycles per
hour while in the Installer Configuration Menu:
1. Answer NO to all prompts until the cooling cycles
per hour prompt appears in the display. Press
YES to enter the cooling cycles per hour menu.
2. Use the UP/DOWN arrow keys to adjust the
maximum number of cooling cycles per hour.
Press YES to store the value.
The display now shows the minimum heating/cooling
deadband prompt. See the Setting the Heating/Cooling
Deadband (Deadband) section for instructions.
Setting the Heating/Cooling Deadband (Deadband)
The heating/cooling deadband setting establishes the
minimum difference between the heating and cooling
setpoints. The range is adjustable from 2 to 4 F°
(1 to 2 C°).
To change the minimum deadband between the
heating and cooling setpoints while in the Installer
Configuration Menu:
1. Answer NO to all prompts until the deadband
setpoint prompt appears in the display. Press YES
to enter the deadband setpoint menu.
2. Use the UP/DOWN arrow keys to adjust the
minimum deadband between the heating and
cooling setpoints. Press YES to store the value.
