Table 1: Installer Configuration Menu (Cont.)
Delays Fan Termination at Cycle's End
for 60 Seconds
Fan del
Default: No Delay (Off)
set? Y/N
See the Setting the Fan Delay (Fan
del) section.
Sets the Duration for Temporary
Occupancy Time
TOccTime
Default: Three Hours (3.0 hrs)
set? Y/N
See the Establishing the Temporary
Occupancy Time (TOccTime) section.
Room Air Sensor Calibration (Offset)
Cal RS
Default: 0.0°F (0.0°C)
set? Y/N
See the Room Air Sensor Calibration
(Cal RS) section.
Outdoor Air Sensor Calibration (Offset)
Cal OS
Default: 0.0°F (0.0°C)
set? Y/N
See the Outdoor Air Sensor
Calibration (Cal OS) section.
Enable/Disable Second Heating Stage
H Stage
Default: Two Stages
set? Y/N
See the Enable/Disable Second
Heating Stage (H Stage) section.
Enable/Disable Second Cooling Stage
C Stage
Default: Two Stages
set? Y/N
See the Enable/Disable Second
Cooling Stage (C Stage) section.
Disables Heating Operation based on
Outdoor Air Temperature
H lock
Default: 120°F (49°C)
set? Y/N
See the Setting the Heating Lockout
(H lock) section.
Disables Cooling Operation based on
Outdoor Air Temperature
C lock
Default: -40°F (-40°C)
set? Y/N
See the Setting the Cooling Lockout
(C lock) section.
Sets the Number of Events in 24-Hour
Period
2/4event
Default: Two Events (2.0)
set? Y/N
See the Selecting the Number of
Events (2/4event) section.
Sets the Auxiliary Contact as Normally
Open or Normally Closed
Aux cont
Default: Normally Open (N.O.)
set? Y/N
See the Configuring the Auxiliary
Contact (Aux cont) section.
Enable/Disable Progressive Recovery
Prog rec
Default: Off
set? Y/N
See the Enable/Disable Progressive
Recovery (Prog rec) section.
6
T600MSP-2 Programmable Thermostat Installation Instructions
Configuring the Digital Inputs (DI1 and DI2)
Press the configuration menu access key. The first
prompt is to program Digital Inputs DI1 and DI2.
The digital inputs display an alarm condition when the
input is closed. An alarm message is included on the
scrolling Status Display Menu and when the message
displays, the backlight momentarily lights up.
Each digital input can be programmed in one of five
conditions.
•
None – No function is associated with the input.
•
Service – A Service alarm is displayed.
•
Filter – A Filter alarm is displayed.
•
RemNSB – Remote Night Setback (NSB) timer
clock input. The scheduling is set per the digital
input when this option is selected. The time
continues to be displayed, but the menu related to
scheduling is disabled and no longer accessible.
−
Open Contact = Occupied setpoints
−
Closed Contacts = Unoccupied setpoints
•
RemOVR – Remote override contact. This
disables all override menu functions of the
thermostat. The override function is controlled
manually by a remote, momentarily closed
contact. When configured in this mode, the input
operates in a toggle mode. With this function
enabled, it is now possible to toggle between
unoccupied and occupied setpoints for the amount
of time set by the temporary occupancy time
parameter.
When override is enabled through the digital
inputs, an Override message appears in the
Status Display Menu.
To configure the digital inputs while in the Installer
Configuration Menu:
1. Press YES to configure Digital Input 1 or NO to
advance to Digital Input 2.
2. Use the UP/DOWN arrow keys to locate the
desired function for the Digital Input 1. Press YES
to select the desired function.
3. Press YES to configure Digital Input 2 or NO to
advance to the keypad lockout setup prompt.
4. Use the UP/DOWN arrow keys to locate the
desired function for the Digital Input 2. Press YES
to select the desired function.
The display now shows the keypad lockout setup
prompt. See the Enabling Keypad Lockout (Lockout)
section for instructions.
