AC Power Feeds in the Rack

Systems can be ordered with the AC power cords for the PDU installed either:
Top: Power and I/O cables are routed from above the rack.
Bottom: Power and I/O cables are routed from below the rack.
AC Power Feeds...
Without UPS
With Single-Phase UPS
With Three-Phase UPS
NOTE: The example power feed illustrations on the following pages show the connections to
two PDUs and one UPS. If you have a power configuration with four PDUs and two UPS's, you
will need to make additional connections.
38 NS7 System Installation Specifications
Examples
Example AC feed at bottom of rack without
UPS (page 39)
Example AC feed at top of rack without UPS (page 40)
Example AC feed at top of rack with single-phase
UPS (page 41)
Example AC feed at the bottom of rack with
single-phase UPS (page 42)
Example AC feed at top of rack with three-phase
UPS (page 43)
Example AC feed at the bottom of rack with
three-phase UPS (page 44)
