H P
N e t S e r v e r
L H 4 a n d L H 4 r
Entry-level enterprise servers
The HP NetServer LH 4 has the power, reliability, and expansion room to
handle everything from Web hosting to ERP applications, for fast-growing
workgroups all the way up to corporate data centers.
Up to four-way processing with Intel
Capacity for up to 12 Ultra2 SCSI and Ultra3 SCSI drives driven by an
integrated dual-channel HP NetRAID controller with I
Up to 4GB ECC buffered EDO DRAM with memory scrubbing
Hot-swap power supplies and redundant hot-swap fans standard
Automatic hardware-level IRQ re-directs using HP's Smart IRQ
technology to ease configuration and boost performance
Supports industry-leading DAT or DLT technology
HP TopTools for Servers with Web interface for device management, and
TM
HP OpenView
ManageX/SE for NOS and application management
Integrated HP Remote Assistant and optional HP TopTools Remote
Control card for easiest remote access, advanced security, and
diagnostics
As entry-level enterprise servers, the
HP NetServer LH 4 and LH 4r close
the performance gap for workgroups
and departments on the fast track, with
four-way processing power, high
availability, and excellent value.
®
Pentium III 550MHz processors
O
2
Advertisement
Related Manuals for HP XLWW
Summary of Contents for HP XLWW
- Page 1 L H 4 a n d L H 4 r Entry-level enterprise servers The HP NetServer LH 4 has the power, reliability, and expansion room to handle everything from Web hosting to ERP applications, for fast-growing workgroups all the way up to corporate data centers.
-
Page 2: Specifications
Intel Pentium III Xeon 550MHz processors only Intel Pentium III Xeon 550MHz and 700MHz processors only Intel Pentium III Xeon 550MHz processor only Not included with HP NetServer LH 4r , 1MB , 2MB 256MB high-performance 50ns ECC buffered EDO DRAM standard... - Page 3 3 hot-swap power supplies standard N+1 redundancy optional Combine HP NetServer LH 4 and LH 4r units with HP NetServer Rack Storage/12 for cluster configurations. See http://www.hp.com/netserver/products/cluster for details Automatic Server Restart (ASR) that reboots the server in the event of a NOS hang...
- Page 4 America, Europe, and Asia Pacific during warranty Optional HP SupportPack for 4-hour response during standard business hours Optional HP SupportPack for 24 hours a day, 7 days a week Optional HP SupportPack for Comprehensive Technical Support Comprehensive reseller support framework to ensure successful support of...
-
Page 5: Regulatory Compliance
specifications N e t S e r v e r L H 4 a n d L H 4 r Features Regulatory Compliance Electromagnetic Emissions Electromagnetic Immunity Safety USA: FCC Title 47, Part 15 Class A (Self Declaration) EU Countries: EN 55022 Class A Korea: M of C Class A Japan: VCCI Class A Australia/New Zealand: CISPR 22 Class A... -
Page 6: Product Accessory
Internal Storage Expansion Disk Controllers & SCSI Cables Please see the HP NetServers Configuration Guide for important technical information when choosing your accessories or go to http://www.hp.com/go/netserver. For HP SureStore backup see http://www.hp.com/storage. Ultra3 SCSI performance can only be achieved by using an Ultra3 SCSI controller or an Ultra3 SCSI RAID Controller with the Ultra3 drives. - Page 7 Network Interface Cards Remote Management Uninterruptible Power Supply Conversion Kit Please see the HP NetServers Configuration Guide for important technical information when choosing your accessories or go to http://www.hp.com/go/netserver. Product Accessory HP NetServer Rack Storage/12 (Ultra2) HP NetServer Rack Storage/12 (Ultra3)
- Page 8 Remote NOS, Applications, LAN, WAN, and Management Phone Support Please see the HP NetServers Configuration Guide for important technical information when choosing your accessories or go to http://www.hp.com/go/netserver. LH 3 to LH 4 upgrade kit requires secondary fan tray and second power supply cage with one power supply module, Product No. D6093A...
- Page 9 Integrated control panel with display Easy conversion from pedestal to 8U rack Integrated HP Remote Assistant Hot-swap power modules HP Smart IRQ for easy configuration 1 PCI/ISA slot 7 PCI slots (2x64-bit) Eight Totally Cool hot-swap fans 2 open half-height...
- Page 10 Operating Temperature Operating Humidity Acoustic Emissions Power Supply Power Availability Power Consumption System Dimensions System Weight Choose Your HP NetServer LH 4 or LH 4r Product Number Processor D8552A Pentium III Xeon 550/512KB D8553A Pentium III Xeon 550/512KB D8556A Pentium III Xeon 550/1MB...
