HP Integrity NonStop X NS7 Planning Manual page 53

Enclosure Type Number of
Enclosures
c7000 enclosure
NonStop X NS7
Server Blade:
BL460c Gen8
(64GB RAM)
BL460c Gen8
(128GB RAM)
BL460c Gen8
(192GB RAM)
BL460c Gen9
(64GB RAM)
BL460c Gen9
(128GB RAM)
BL460c Gen9
(192GB RAM)
Storage/Networking:
Gen8 CLIM
Gen9 CLIM
SAS disk
enclosure, empty
400GB SSD,
12G SAS, SFF,
2.5in SC
300GB, 15k rpm
HDD, 12G SAS,
SFF, 2.5 in SC
Disk blank
CLIM patch
panels
Maintenance
switch (Ethernet)
IB switches
IB FDR
managed switch,
expansion
IB cluster switch
IB ADI switch
Manageability:
Rack-mounted
system console
Keyboard and
display for
console
Weight
lbs kg
270 122
25 11
27 12
29 13
12 5
12 5
12 5
55 24
45 20
38 17
1 .45
.34 .15
.1 .04
5 2
6 3
21 9
18 8
10 5
Dimensions and Weights for NS7 AC Systems
Total
lbs kg
53
