EasyLAN 100i
Interface Board
Intermec EasyCoder F2 – Installation & Operation Ed. 2
The Intermec EasyLAN 100i Ethernet interface board provides
the printer with a 10BaseT Ethernet or 100BaseTX Fast Ethernet
network connection. You can communicate with the printer via
a LAN (Local Area Network) or provide the printer with its own
home page, so you can reach the printer via internet on the world
wide web (www).
EasyLAN 100i supports most major computer systems and environ-
ments. You can assign passwords to restrict both login and printer
access. The internal EasyLAN 100i web pages allow you to con-
tinuously monitor printer status and to upgrade the fl ash memory of
the printer when new fi rmware becomes available.
EasyLAN 100i supports SNMP for remote monitoring.
When an EasyLAN 100i interface board is fi tted in the printer, some
extra menus will be added to the Setup Mode (see chapter 7 "Setup
Mode"). The Ethernet port is addressed in Intermec Fingerprint 7.3
or later as device "net1:" (communication channel 5).
Appendix 3 Interfaces
RJ-45
connector
101
