Specifications

RJ-21 Patch Panel Interconnect Tray

Table 5-4: RJ-21 Patch Panel Interconnect Tray Specifications
Feature
Dimensions
Height
Depth
Width
Network transfer rate
10 Base-T (half-duplex)
10 Base-T (full-duplex)
100 Base-TX (half-duplex)
100 Base-TX (full-duplex)
Connector
Cable support
10 Base-TX
100 Base-TX
Power requirements
Temperature range
Operating
Non-operating
Relative humidity, noncondensing
Operating
Non-operating
Wet bulb temperature
Operating
Non-operating
1
Operating temperature has an altitude derating of 1°C per 304.8 m (1.8°F per 1,000 ft). The
interconnect tray should not be exposed to direct sunlight. Upper operating limit is 3,048 m (10,000
ft) or 70Kpa/10.1 psia. Upper non-operating limit is 9,144 m (30,000 ft) or 30.3 KPa/4.4 psia.
2
Storage maximum humidity of 95% is based on a maximum temperature of 45°C (113°F). Altitude
minimum for storage is 70 KPa.
5-6
HP CONFIDENTIAL Codename: Kerr Part Number: 249066-004 Last Saved On: 5/12/03 3:10 PM
Description
3.3 cm (1.3 in)
28.7 cm (11.3 in)
42.7 cm (16.8 in)
10 Mbps
20 Mbps
100 Mbps
200 Mbps
(4) RJ-21 with 10 NIC ports per connector
(1) RJ-45 IA NIC port
(1) DB-9 IA Serial Local port
(2) RJ-45 Reserved
Categories 3, 4, or 5 UTP (2 or 4 pair); up to 100 m (328 ft)
Category 5 UTP (2 or 4 pair); up to 100 m (328 ft)
12 V at 525 mA, 5 Vaux at 500 mA, 5V at 20 mA
1
10° to 35°C (50° to 95°F)
-30° to 60°C (-22° to 140°F)
2
20% to 80%
5% to 95%
28°C (82.4°F)
38.7°C (101.7°F)
