Spare Parts List

Table 1-1: Spare Parts List
Item Description
Server Blade Enclosure Components (Figure 1-1)
1 Hot-plug power supply (600W)
2 Center wall assembly
3 ProLiant BL e-Class Integrated Administrator module
4 Fan backplane assembly (with cable*)
5 Fan cage
6 Hot-plug fan, 60-mm
7 Enclosure status assembly
8 Server blade blank kit*
a) five-bay blank *
b) one-bay blank *
Server Blade Components
9a ProLiant BL10e server blade
a) 700-MHz processor model
b) 800-MHz processor model *
c) 900-MHz processor model *
9b ProLiant BL10e G2 server blade
1-GB processor model
10 Diagnostic adapter *
11 Lithium battery, 3.3-V
Mass Storage Devices
12 ATA hard drive assembly
a) 30-GB hard drive, 4200 RPM
b) 40-GB hard drive, 4200 RPM *
c) 40-GB hard drive, 5400 RPM *
Memory for ProLiant BL10e server blade
13 DIMM A: 512-MB registered 133-MHz SDRAM
DIMM B: 256-MB registered 133-MHz SDRAM *
DIMM C: 128-MB registered 133-MHz SDRAM *
* Not shown
HP ProLiant BL e-Class System Maintenance and Service Guide
HP CONFIDENTIAL Codename: Kerr Part Number: 249066-005 Last Saved On: 5/12/03 2:58 PM
Illustrated Parts Catalog
Spare Part Number
253082-001
253081-001
253075-001
253080-001
253086-001
253079-001
253083-001
253088-001
253087-001
289227-001
313346-001
333507-001
253089-001
234556-001
258317-001
289228-001
313347-001
159227-001
159377-001
159226-001
continued
