6 • 3.6-Inch Wall Mount Touchpanel: TPS-4L
Connectors, Controls & Indicators (Continued)
# CONNECTORS
CONTROLS &
INDICATORS
3 NET
4 RESET
1. Interface connectors for NET ports are provided with the unit.
2. To determine which is pin 1 on the cable, hold the cable so that the end of the eight pin modular jack
is facing away from you, with the clip down and copper side up. Pin 1 is on the far left.

Industry Compliance

As of the date of manufacture, the TPS-4L has been tested and found to comply with
specifications for CE marking and standards per EMC and Radiocommunications
Compliance Labelling.
NOTE: This device complies with part 15 of the FCC rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful interference and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Crestron Isys
1
, DESCRIPTION
Four-position terminal block connector for
data and power. Connects to Cresnet control
network.
Pin 1 (24) Power (24 Volts DC)
Pin 2 (Y) Data
Pin 3 (Z) Data
Pin 4 (G) Ground
(1) Miniature pushbutton behind faceplate,
used for resetting touchpanel.
Operations & Installation Guide – DOC. 6449A
®
TPS-4L
