Summary of Contents for Crestron TPS-4500IMC
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-800-CRESTRON...
-
Page 3: Table Of Contents
Crestron TPS-4500IMC Contents Interface Module: TPS-4500IMC Description... 1 Functional Description ... 1 Physical Description... 1 I/O Ports ... 1 Leading Specifications... 3 Setup ... 4 Network Wiring... 4 Hardware Hookup ... 5 Problem Solving ... 8 Troubleshooting... 8 Further Inquiries ... 8 Future Updates ... -
Page 5: Interface Module: Tps-4500Imc
The opposite side offers a network/video connection to the touchpanel. At the shorter sides of the TPS-4500IMC, the enclosure extends to form feet at a right angle to the side. There are three holes per foot for inserting screws to further stabilize the unit to a mounting surface. - Page 6 Interface Module Physical Views of the TPS-4500IMC CAUTION: Verify that jumpers and six-pin video connector are installed 0.235 in (0.597 cm) 0.750 in (1.905 cm) 0.750 in (1.905 cm) • NTSC/PAL VIDEO – These three ports are made active with the purchase and installation of the TPS-VID, composite and S-video input for TV video card.
-
Page 7: Leading Specifications
Leading Specifications for the TPS-4500IMC SPECIFICATION Dimensions Weight As of the date of manufacture, the TPS-4500IMC has been tested and found to comply with specifications for CE marking. Operations Guide - DOC. 5890 DESCRIPTION +24V... -
Page 8: Setup
Cresnet Network Interconnect Drawing (Doc. 5411). The document can be obtained from the Downloads page (CABLES and MANUAL Libraries) of the Crestron website (www. crestron.com). Search for the CRESNET.PDF files. When calculating the wire gauge for a particular network run, the length of the run and the power factor of each network unit to be connected must be taken into consideration. -
Page 9: Hardware Hookup
Repeat the procedure for the other three network conductors. Hardware Hookup The TPS-4500IMC serves as an interface between the touchpanel and the Cresnet system. Refer to the illustration on the next page for proper connections; apply power last. When making network connections to the CNX Generation control system or Cresnet peripherals, refer to "Network... - Page 10 CAUTION: If there is no video, do not make a connection to this port, but leave connector and jumpers attached to the NTSC/PAL VIDEO six- pin connector on the TPS-4500IMC. Failure to do so may damage the TPS-4500IMC. Video balance is determined by external connections. Refer to the two diagrams on the next page.
- Page 11 Balanced Using Twisted Pair Cable NTSC/PAL VIDEO COMP JUMPERS REMOVED. Unbalanced Using Coax Cable NTSC/PAL VIDEO COMP Operations Guide - DOC. 5890 COMP + _ S COMP + _ S JUMPERS REMAIN IN PLACE. Interface Module: TPS-4500IMC • 7 Interface Module...
-
Page 12: Problem Solving
Touchpanel is not responding. Further Inquiries If after reviewing this Operations Guide for the TPS-4500IMC, you cannot locate specific information or have questions, please take advantage of Crestron's award winning customer service team by calling: • In the US and Canada, call Crestron’s corporate headquarters at 1-888-CRESTRON [1-888-273-7876]. -
Page 13: Future Updates
Crestron TPS-4500IMC Future Updates As Crestron improves functions, adds new features, and extends the capabilities of the TPS-4500IMC, additional information may be made available as manual updates. These updates are solely electronic and serve as intermediary supplements prior to the release of a complete technical documentation revision. -
Page 14: Return And Warranty Policies
CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 15 Crestron TPS-4500IMC Interface Module This page intentionally left blank. Interface Module: TPS-4500IMC • 11 Operations Guide - DOC. 5890...
- Page 16 Crestron Electronics, Inc. Operations Guide – DOC. 5890 15 Volvo Drive Rockleigh, NJ 07647 12.00 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
