Summary of Contents for Crestron TPS-4500IMPC

  • Page 1 Crestron TPS-4500IMPC Interface Module Operations Guide...
  • Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2003 Crestron Electronics, Inc.
  • Page 3: Table Of Contents

    Crestron TPS-4500IMPC Contents Interface Module: TPS-4500IMPC Introduction...1 Features & Functions...1 Specifications...1 Physical Description ...2 Industry Compliance...5 Setup...5 Network Wiring ...5 Hardware Hookup...7 Problem Solving...8 Troubleshooting...8 Further Inquiries ...10 Future Updates...10 Return and Warranty Policies ...11 Merchandise Returns / Repair Service ...11 CRESTRON Limited Warranty ...11...
  • Page 5: Interface Module: Tps-4500Impc

    Interface Module: TPS-4500IMPC Introduction Features & Functions The TPS-4500IMPC is an interface module designed for, and included with the Crestron TPS-4500 and TPS-4500V tilt touchpanels. The sleek design of the touchpanel base left little room for all the connectors that define the touchpanel's versatility.
  • Page 6: Physical Description

    2.81 in (7.12 cm) 1.25 in (3.18 cm) Ports There are five ports that serve various functions on the TPS-4500IMPC. Refer to the following diagrams and descriptions of each port. 2 • Interface Module: TPS-4500IMPC 5.82 in (14.78 cm) 5.32 in (13.52 cm)
  • Page 7 NOTE: BNC connectors are physically located next to the twisted pair connectors. Image is for illustration purposes only. Refer to the physical view of the TPS-4500IMPC on page 2 for actual connector positions. NOTE: The TPS-4500IMPC allows the use of either balanced or unbalanced signals for video input.
  • Page 8 Interface Module CAUTION: If power is provided to the TPS-4500IMPC from the +24VDC on a Cresnet connector or the PW-2420RU, power must not be applied to the power input on the touchpanel base. NOTE: When power is supplied through this connector, Crestron recommends disconnecting the +24 VDC on the Cresnet connector (if it is connected).
  • Page 9: Industry Compliance

    Crestron TPS-4500IMPC CAUTION: The 10-pin RJ-45 net/video connector cable supplied by Crestron is a custom cable and is the only one that should be used. The end of the cable has a metal shield that is required to protect the equipment.
  • Page 10 Downloads | Product Manuals | Wiring Diagrams section of the Crestron website (www.crestron.com). NOTE: Do not power up system until all wiring is verified. Care should be taken to ensure data (Y, Z) and power (24, G) connections are not crossed.
  • Page 11: Hardware Hookup

    Repeat the procedure for the other three conductors. Hardware Hookup The TPS-4500IMPC serves as an interface between the touchpanel and the Cresnet system. Refer to the illustration after this paragraph for proper connections; apply power last. When making network connections to a control system or Cresnet peripherals, refer to “Network Wiring”...
  • Page 12: Problem Solving

    PAIR) OR COAX (UNBALANCED) FOR EACH VIDEO SIGNAL Problem Solving Troubleshooting The following table provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. TPS-4500IMPC Troubleshooting TROUBLE No power to the touchpanel.
  • Page 13 TPS-4500. Incorrect video format selection. Incorrect VT Pro-e project file loaded. Damaged connector pins. Interface Module: TPS-4500IMPC • 9 Interface Module CORRECTIVE ACTION Confirm that power is supplied via the power pack or the Cresnet connector (not both).
  • Page 14: Further Inquiries

    If after reviewing this Operations Guide, you cannot locate specific information or have questions, please take advantage of Crestron's award winning customer service team by calling: • In the US and Canada, call Crestron’s corporate headquarters at 1-888-CRESTRON [1-888-273-7876]. • In Europe, call Crestron International at +32-15-50-99-50.
  • Page 15: Return And Warranty Policies

    CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures.
  • Page 16 Crestron Electronics, Inc. Operations Guide - DOC. 6163 15 Volvo Drive Rockleigh, NJ 07647 08.03 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
