- Page 1 Crestron TPS-4500IMW Wall-Mounted Interface Module Operations Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON...
-
Page 3: Table Of Contents
Crestron TPS-4500IMW Contents Wall-Mounted Interface Module: TPS-4500IMW Description... 1 Functional Description ... 1 Physical Description... 1 I/O Ports ... 1 Leading Specifications... 4 Setup ... 4 Network Wiring... 4 Hardware Hookup ... 5 Problem Solving ... 9 Troubleshooting... 9 Further Inquiries ... 9 Future Updates ... -
Page 5: Wall-Mounted Interface Module: Tps-4500Imw
(not supplied) so that the unit blends into any setting. Physical Description The TPS-4500IMW, shown on the next page, is an option (can be purchased separately). The unit mounts into a 1-gang electrical box (recommended 2.5" depth). The back of the unit is silk-screened and provides a network and video input connectors. - Page 6 Wall-Mounted Interface Module Physical Views of the TPS-4500IMW (Front with Insert Plate, Side, and Back) 1.485 in (3.772 cm) 2 • Wall-Mounted Interface Module: TPS-4500IMW Crestron TPS-4500IMW 75 Ohm INPUT + INPUT - GROUND COMP 4.273 in CRESTRON (10.853 cm) TPS-4500IMW 2.505 in...
- Page 7 Operations & Installation Guide (Doc. 5869) for details. NET/VIDEO Pinouts PIN # Operations Guide - DOC. 5913 Wall-Mounted Interface Module DESIGNATION +24V +24V Wall-Mounted Interface Module: TPS-4500IMW • 3 DESCRIPTION Power (Network) Ground (Network) Chrominance (Positive) Chrominance (Negative) Data (Network) Data (Network)
-
Page 8: Leading Specifications
SPECIFICATION Video Input Impedance Dimensions Weight As of the date of manufacture, the TPS-4500IMW has been tested and found to comply with specifications for CE marking. Setup Network Wiring NOTE: When making wire connections, refer to the latest revision of the Cresnet Network Interconnect Drawing (Doc. -
Page 9: Wire Gauge
Hardware Hookup Connections to the Back of the TPS-4500IMW The TPS-4500IMW serves as an optional interface between the touchpanel and the Cresnet system. Refer to the illustration after this paragraph for proper connections; apply power last. When making network connections to the CNX Generation control system or Cresnet peripherals, refer to "Network Wiring"... - Page 10 Wall-Mounted Interface Module been installed into the touchpanel and a video window object resides on a page within the uploaded VisionTools™ Pro-e project. Hardware Hookup Connections to the Back of the TPS-4500IMW CONNECT TO VIDEO SOURCE* CONNECT TO CNX GENERATION...
- Page 11 2.5" depth). Verify that the unit is installed into the electrical box as shown after this paragraph. Use the orientation of the RJ45 connector as a guide. Secure the TPS-4500IMW to the electrical box with the two #6- 32 flat head slotted screws (1-inch length), supplied.
- Page 12 Affix the insert plate into the opening in the decora wallplate. Refer to the diagram after this paragraph, for the proper orientation of the insert plate with respect to the installed TPS-4500IMW. Orientation of the Insert Plate Connect the TPS-4500IMW to the touchpanel using the network/video (10-pin) cable, supplied with touchpanel.
-
Page 13: Problem Solving
Further Inquiries If after reviewing this Operations Guide for the TPS-4500IMW, you cannot locate specific information or have questions, please take advantage of Crestron's award winning customer service team by calling: • In the US and Canada, call Crestron’s corporate headquarters at 1-888-CRESTRON [1-888-273-7876] or 1-201-767-3400. -
Page 14: Future Updates
Wall-Mounted Interface Module Future Updates As Crestron improves functions, adds new features, and extends the capabilities of the TPS-4500IMW, additional information may be made available as manual updates. These updates are solely electronic and serve as intermediary supplements prior to the release of a complete technical documentation revision. -
Page 15: Return And Warranty Policies
CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 16 Crestron Electronics, Inc. Operations Guide – DOC. 5913 15 Volvo Drive Rockleigh, NJ 07647 02.01 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
