Hunt Electronic HVR-04E Installation Manual

4-analog, 12-ip channel network digital video recorder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HVR-04E
Installation Guide
v 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HVR-04E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hunt Electronic HVR-04E

Summary of Contents for Hunt Electronic HVR-04E

  • Page 1 HVR-04E Installation Guide v 1.0...

  • Page 2: Fcc Compliance Statement

    FCC Compliance Statement Caution: Any changes or modifications in construction of this device which are not expressly approved the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 3: Important Notice

    3. Be sure to use a DC adapter that is provided by Hunt Electronic USA, Inc. Connecting HVR-04E directly to an AC current will cause electric damages to HVR-04E. 4. Be careful not to drop the HVR-04E. Physical shocks may harm the product. In addition, be sure the HVR-04E is secured after installation.

  • Page 4: Table Of Contents

    5.2. Dialogue Box to Edit a Word... 16 Setting remote controller ... 17 6.1. Setting remote control DIP switch... 17 6.2. Set ID of HVR-04E ... 17 6.3. Selecting HVR-04E... 18 6.4. Operable range of remote controller ... 19 6.5.
  • Page 5 Connecting Serial Port ... 33 12.1.1. Connecting RS232... 33 12.1.2. Connecting RS485... 33 12.1.3. Connecting RS422... 33 12.2. Configuring Serial Port ... 34 Connecting USB Device ... 35 Connecting External Storage ... 37 14.1. IEEE1394 Bay... 37 14.2. Connecting IEEE1394 Device... 37 HVR-04E...
  • Page 6 Registering & Formatting HDD... 38 Network Monitoring & Managing ... 39 15.1. Connecting Ethernet ... 39 15.2. Configuring HVR-04E’s Network Information ... 40 Using DVR Manager... 41 16.1. PC System Requirements for running DVR Manager ... 41 16.1.1. Installing DVR Manager ... 41 16.1.2.

  • Page 7: Overview

    OVERVIEW 1. What is HVR-04E? The HVR-04E is a 4-Analog, 12-IP channel network digital video recorder. The HVR-04E can record and display 4 analog video channels and 12 IP video channels simultaneously. Video, Audio, and Text Event- Logs are digitized and stored on two internal hard-drives.

  • Page 8: Supplied Accessories

    HVR-04E 2. Supplied Accessories Unpack and check all the items as below. 1. HVR-04E (1) 3. AC Power Cord (1) 5. Remote Controller (1) 7. Plug Bracket (1) 2. DC Power Supply (1) (110V~220V) 4. CD-ROM (Including DVR Manager) (1) 6.

  • Page 9: Description & Function

    OVERVIEW HVR-04E 3. Description & Function HVR-04E Front (1) LED (2) IEEE1394 connecter (3) Remote controller receiver (4) USB connecter (5) Function buttons (6) Bracket fixing hole for rack mount...
  • Page 10 HVR-04E OVERVIEW HVR-04E Rear (7) Power switch (8) Ethernet connector (9) BNC connector for Video input (10) Audio input / output connector (11) RS232 connecter (9Pin D-Sub) (12) Terminal block for RS232 & 422/485 (13) Terminal block for Sensor input...

  • Page 11: Installation And Connection

    INSTALLATION AND CONNECTION 4. Connecting & Running HVR-04E 4.1. Connecting camera (1) Connect CCTV camera to HVR-04E with BNC cable as shown below. (2) Set video type (NTSC/PAL) by rear panel’s switch. <Note> The video type for all channels should be either NTSC or PAL. NTSC is the standard used in North America.

  • Page 12: Connecting Monitor

    (1) Connect CCTV monitor to HVR-04E with BNC cable as shown below. <Note> HVR-04E has two video output ports ; for Monitor and VCR. The output signals from the two ports are same and either port may be used. 4.3. Connecting Audio (1) Connect audio signal to HVR-04E.
  • Page 13 INSTALLATION AND CONNECTION HVR-04E...

  • Page 14: Supplying Power

    HVR-04E 4.4. Supplying Power (1) Connect power cable to HVR-04E. (2) Turn on the power switch located on the HVR-04E rear panel. <Note> Use the plug bracket to secure the power cable if needed. <Note> To connect EARTH, refer to the following picture.

  • Page 15: Running Osd Menu

    [◄◄ / ►►] or [▲/▼] arrow buttons. After the value is set, press the [EXIT] button. To exit the Setting Page, press the [EXIT] button. (4) Help message: Related information for each menu/setting will be displayed here. HVR-04E...

  • Page 16: Dialogue Box To Edit A Word

    HVR-04E 5.2. Dialogue Box to Edit a Word There are two methods to set word. (1) Using number button Enter the related numbers in order of horizontal/vertical. (For example, in order to select “C”, press [3] and [2] buttons.) (2) Using arrow button Select a value using the [◄◄...

  • Page 17: Setting Remote Controller

    6. Setting remote controller 6.1. Setting remote control DIP switch Set the remote control DIP switch to “ON.” 6.2. Set ID of HVR-04E When controlling several HVR-04Es with one remote controller, set Remote Control ID as follows. (1) Press [MENU] button.

  • Page 18: Selecting Hvr-04E

    If several HVR-04Es are set with unique ID numbers, they can be controlled with one remote controller. To select a specific HVR-04E, press the ID button of remote controller until the 8 LEDs on the front of the HVR-04E light up and a buzzer sounds.

  • Page 19: Operable Range Of Remote Controller

    6.5. Loading the batteries into remote controller Remote controller requires two AAA-type batteries. 2. Taking care that the poles(+/-) 1. Remove the battery cover. are correctly positioned <Note> Batteries are not included as a packing accessory. HVR-04E 3. Replace the battery cover.

  • Page 20: Hvr-04E Configuration

    HVR-04E INSTALLATION AND CONNECTION 7. HVR-04E Configuration 7.1. Basic Configuration 7.2. Advanced Configuration Hunt Electronic USA, Inc. 2003.05.21 (v 1.0)

  • Page 21: External Storage & Backup Configuration

    INSTALLATION AND CONNECTION HVR-04E 7.3. External Storage & Backup Configuration 7.4. Internet/Intranet Configuration...

  • Page 22: Hvr-04E Basic Setting

    HVR-04E INSTALLATION AND CONNECTION HVR-04E Basic Setting 8.1. Viewing Image After initial start-up, images from Ch.1~4 are displayed in a quad-split screen. <Note> If user password is set, a prompt for entering the password will appear. Hunt Electronic USA, Inc.

  • Page 23: Setting Date & Time

    INSTALLATION AND CONNECTION HVR-04E 8.2. Setting Date & Time (1) Press [MENU] button, and select “Quick Setup” tab. (2) Select “Date/Time” and enter the Settings Page by pressing [ENTER]. 8.2.1. Time Zone (1) Select “Time Zone” and press [ENETR] button to configure.

  • Page 24: Time Format

    HVR-04E INSTALLATION AND CONNECTION 8.2.3. Time Format (1) Select “Time Format” using the [◄◄ / ►►] or the [▲/▼] buttons and press [ENTER]. (2) Two Time Formats are available; ‘MM/DD/YYYY’ and ‘YYYY/MM/DD’. Select a value using [▲/ ▼] buttons, and press the [EXIT] button when finished. (Default value is ‘MM/DD/YYYY’.) 8.2.4.

  • Page 25: Setting Recording Condition

    INSTALLATION AND CONNECTION HVR-04E 8.3. Setting Recording Condition Recording conditions under the “Quick Setup” menu tab apply the same values to all analog channels 1~4. All settings are applied for 24 hours/day regardless of the values set for “Time Schedule” or “Alarm Rec.”...

  • Page 26: Configuration Status

    HVR-04E (1) Press [MENU] button, and select “Quick Setup.” (2) Move to sub-menu by pressing [ENTER] or the [▼] button. (3) Select “Recording” using the [▲/▼] buttons and press the [ENTER] button. 8.3.1. Configuration Status Displays the recording configuration status. When setting up through the “Quick Setup” menu, “Quick Setup”...

  • Page 27: Quality

    INSTALLATION AND CONNECTION HVR-04E 8.3.5. Quality When “Recording Speed/Quality” is set as “Custom,” values can be set manually. (1) Select “Quality” using [▲/▼] buttons and press the [ENTER] button. (2) Select a value using the [◄◄ / ►►] button. Press the [EXIT] button when finished.

  • Page 28: Connecting And Configuring Sensor

    HVR-04E INSTALLATION AND CONNECTION 9. Connecting and Configuring Sensor 9.1. Connecting Sensor Input To connect a sensor to S1, fix the wire to “S1” and “G“. <Note> Devices connected to the sensor input should have “Dry contact.” The following diagram is of an electric circuit with approximately 12mA flows.

  • Page 29: Setting Sensor At Osd Menu

    “On” or “Off.” Press [EXIT] when finished. <NOTE> When activated, the “Pre / Post Alarm” function will cause the HVR-04E to record images at the specified Speed and Quality for a length of time before and/or after the sensor is triggered.

  • Page 30: Connecting & Configuring Relay Out

    HVR-04E 10. Connecting & Configuring Relay Out 10.1. Connecting Relay Out HVR-04E has total four ports of Relay Out. To connect a device to “O1,” connect the wires to two “O1”s. <Note> The rated voltage and current of Relay Out are as follows. Do not exceed the rated values.

  • Page 31: Configuring Relay Out

    Each relay can be synchronized with a sensor input or with motion detection for each of the four time schedules (Weekday (Day), Weekday (Night), Weekend (Day), Weekend (Night)). Relays can also be controlled locally by pressing the [SEARCH/RELAY] button followed by the relay number (1-4). Relays can also be controlled remotely through the “DVR Manager Software.”...

  • Page 32: Connecting External Device With Serial Port

    11. Connecting External Device with Serial Port 11.1. Connecting Text Input Device (ATM / POS / Access Control) In addition to images, the HVR-04E can record text data received from POS/ATM through the RS232 serial port. Connect RS232 to 9pin D-sub of HVR-04E, and configure the “Text” sub-menu under the “System” tab.

  • Page 33: Connecting & Configuring Serial Ports For Pan/Tilt/Zoom

    12. Connecting & Configuring Serial Ports for Pan/Tilt/Zoom 12.1. Connecting Serial Port The HVR-04E has most major PTZ protocols already pre-programmed. Makes and models not supported can still be controlled using the Transparent Protocol. For a list of supported protocols, refer to the list on the OSD Configuration menu.

  • Page 34: Configuring Serial Port

    HVR-04E INSTALLATION AND CONNECTION 12.2. Configuring Serial Port Configure PTZ serial ports and available modes at “System / Serial Setup”. After completing serial setup, configure base address and port for each channel under the “Camera” menu tab. When connecting PTZ devices to several cameras, be sure the base address matches the address for the camera.

  • Page 35: Connecting Usb Device

    The disk should be formatted with FAT32 type. Stranded Wire: Peel off the wiring cover 8~10mm and solder it. Wire gage should be AWG 22 ~ 26. Solid Wire: Peel off the wiring cover 8~10mm and solder it. Wire gage should be AWG 20 ~ HVR-04E...
  • Page 36 HVR-04E INSTALLATION AND CONNECTION If properly connected, the disk is recognized automatically as in the following picture. To copy images, the process is as follows: Set copy range (up to 1 minute) Select drive Copy (press “Start”). <Note> USB Flash products that require a Windows program to operate may not be recognized by the HVR- 04E.

  • Page 37: Connecting External Storage

    When using FireWire supported external HDD, hard drive bays can be connected to 1 port in the front panel or 2 ports in the rear panel. The HVR-04E does not supply power to the hard drive bay; therefore only bays that use external power can be used.

  • Page 38: Registering & Formatting Hdd

    HVR-04E INSTALLATION AND CONNECTION 14.4. Registering & Formatting HDD “Disk Manager” will automatically run on start-up after installing a HDD. If “Disk Manager” does not automatically run on start-up, make sure the HDD is properly installed. (1) Press [ENTER] button at “Select Disk”.

  • Page 39: Network Monitoring & Managing

    2) Connect HVR-04E to hub with Ethernet cable. 3) Turn on HVR-04E’s power switch. <Note> 1. Supply power to HVR-04E after connecting Ethernet cable to protect against electrical damage to HVR-04E. 2. Check cable connection status. 3. Check LED on HVR-04E’s rear panel after supplying power.

  • Page 40: Configuring Hvr-04E's Network Information

    15.2. Configuring HVR-04E’s Network Information The following description is on based on Ethernet connection. For more detailed information on the Network Settings Page, please refer to “HVR-04E OSD User’s Guide”. (1) Press [MENU] button. (2) Select “System” using the [◄◄ / ►►] buttons and press [ENTER].

  • Page 41: Using Dvr Manager

    16.1.1. Installing DVR Manager (1) Insert Setup CD-ROM into CD-ROM drive of administrator’s PC (2) Doubleclick the DVR Manager setup file. Install Shield Wizard will be automatically installed. (3) Click the “I Agree” button to accept the license agreement HVR-04E Recommended Requirements P-Ⅲ...
  • Page 42 (5) Browse and choose a directory if the default directory is not preferred. Click the “Install” button, after selecting a directory to install. (6) Click the “Close” button after DVR Manager program is installed successfully Hunt Electronic USA, Inc. 2003.05.21 (v 1.0)

  • Page 43: Uninstalling Dvr Manager

    HVR-04E 16.1.2. Uninstalling DVR Manager (1) Click Windows “Start” Button. (2) Select and Click ‘Uninstall’ icon to run Uninstall Shield. (3) DVR Manager program will be automatically deleted. 16.2. Configstation Click icon on desktop to run “DVR Manager Configstation” program.

  • Page 44: Monitor

    HVR-04E INSTALLATION AND CONNECTION 16.3. Monitor Click the related icon and run the “DVR Manager Monitor” program. 16.4. Playback Click the related icon and run the “DVR Manager Playback” program. Hunt Electronic USA, Inc. 2003.05.21 (v 1.0)

  • Page 45: Appendix

    APPENDIX HVR-04E APPENDIX APPENDIX...

  • Page 46: Appendix #1 Installing And Replacing Internal Hdd

    HVR-04E Appendix #1 Installing and Replacing internal HDD Compatible HDD It is recommended to use the following HDD models with the HVR-04E. If a non-recommended HDD is used, Hunt Electronic USA, Inc. will not guarantee the warranty. Manufacturer : MAXTOR Series Model No.
  • Page 47 APPENDIX HVR-04E <Note> The dip switch should be set at ‘MASTER’ position for the first installed or built-in HDD. Additional HDD should be set as ‘SLAVE.’ Identical dip switch setting may cause system conflict or mal-function. (3) Remove the 6 screws as illustrated below and pull up the cover from the rear part to open (4) Take out power and data cable of HDD from Main PCB ASS’Y.
  • Page 48 HVR-04E APPENDIX (5) Fix the HDD with provided screws. Connect power and data cables to HDD Installing single HDD Installing 2 HDDs <Note> Caution for HDD Management 1. Replacing ‘SLAVE’ HDD of internal 2 HDDs causes permanent data loss in the SLAVE HDD.
  • Page 49 APPENDIX HVR-04E (8) Assemble the top cover. Registering & Formatting HDD “Disk Manager” will automatically run on start-up after installing a HDD. If “Disk Manager” does not automatically run on start-up, make sure the HDD is properly installed. (9) Press [ENTER] button at “Select Disk”.
  • Page 50 5. [X] HDD cable is not <Note> HDD Managing Command 1. Format : Format as HVR-04E’s file system. Not available to PC file system. 2. Add : Add HDD for recording. Need to format. 3. Add Used : Add a HDD that has been used and formatted. There is no need to reformat 4.

  • Page 51: Appendix #2 Video Input

    APPENDIX HVR-04E Appendix #2 Video Input Video type / impedance setup switch It’s possible to set up Impedance of Video input line. When one Video output is connected to several Input as below, the impedance of one input should be 75...

  • Page 52: Appendix #3 Using Cd-Rom

    1. Insert the supplied CD-ROM into CD-ROM drive of PC. 2. Open the user’s guide, PDF file. : HVR-04E Installation Guide : HVR-04E User’s Guide : DVR Manager User’s Guide ( HVR-04E Remote Management Program) : Version 5.1 Hunt Electronic USA, Inc. 2003.05.21 (v 1.0) APPENDIX...

  • Page 53: Appendix #4 Specification

    Max. 120ips in total at NTSC (Analog Ch 60ips + IP Video Ch 60ips) DVR Manager TCP/IP, ARP, ICMP, DHCP, PPPoE 10/100Mbps Ethernet (RJ-45) Firmware upgrade via Network Monitoring : Max. 5 Users Playback : Max. 5 Users Password (User or Administrator Authentication) Watermarking (Against image forging) HVR-04E...
  • Page 54 HVR-04E Display Monitoring Viewer Playback Performance Playback Speed Function Environment Operation Temperature Storage Temperature Operation Humidity Storage Humidity Data Backup/Expansion/Copy HDD Expandable Data Backup Analogue VCR Backup Reminder Data Copy Input/Output Video Audio Digital Output Digital Output Schedule Sensor Input Max.

  • Page 55: Ptz Control

    Daily : Day / Night Weekly : Weekdays / Weekends Conditions : Normal / Event POS/ATM transaction information corresponding video data DC 12V Max 4.5A (Internal 2 HDD) Typical 2.9A (Internal 2 HDD) Max. 54W Typical 35W HVR-04E archived along with...
  • Page 56 HVR-04E Mechanical Dimension (WⅹDⅹH) Weight 306ⅹ280ⅹ67(mm) 3.5Kg (With one HDD) Hunt Electronic USA, Inc. 2003.05.21 (v 1.0) APPENDIX...
  • Page 57 APPENDIX Hunt Electronic USA, Inc. Technical Support: 1-888-993-4868 978 West 10 Street Azusa, California 91702 Tel : (626) 812-8868 Fax : (626) 812-8828 URL: www.huntcctv.com E-mail: info@huntcctv.com HVR-04E...
