HVRM-T1600M / T800M / T400M,
T1600Q / T800Q
Install & User's Guide
(v 1.0)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HVRM-T1600M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hunt Electronic HVRM-T1600M

  • Page 1 English HVRM-T1600M / T800M / T400M, T1600Q / T800Q Install & User’s Guide (v 1.0)
  • Page 2: Introduction

    Introduction Thank you for purchasing a Hunt digital video recorder. This manual is for HVRM-T1600Q, HVRM-T800Q, HVRM-T1600M, HVRM-T800M, HVRM- T400M. Before product installation and operation, please become thoroughly familiar with this user manual and other manuals referenced by this manual.
  • Page 3 Install&User Manual Caution As this equipment undergone EMC registration and suitable for business purpose, distributors and users are aware of this point. FCC Compliance Statement Caution : Any changes or modifications in construction of this device which are not expressly approved the party responsible for compliance could void the user's authority to operate the equipment.
  • Page 4: Important Notice

    Install&User Manual Important Notice 1. Do not place heavy objects on the top of the product. 2. Product is for indoor use. It is not weatherproof. Use product with referring to its environmental specifications (Temperature & Humidity). To clean the product, gently wipe the outside with a clean dry cloth.
  • Page 5: Table Of Contents

    Install&User Manual Contents INTRODUCTION ................1 KEY FEATURES ................9 INSTALL MANUAL ............... 12 1. FEATURE .................. 12 Supplied Accessories ....................... 12 1.1.1. T1600M/T800M/T400M Series ........Error! Bookmark not defined. 1.1.2. T1600Q/T800Q Series ..........Error! Bookmark not defined. 1.2. Description & Function ....................14 1.2.1.
  • Page 6 Install&User Manual 3 MENU USE ................47 Menu Structure ......................47 Function Menu ....................... 47 Factory Reset ........................ 48 4 MONITORING ............... 54 Basic Screen ......................... 54 Single Fll Screen Mode ....................54 Multi Screen Mode ......................54 Screen Description ......................55 Auto Switch Mode ......................
  • Page 7 Install&User Manual Playback Mode ......................62 Playback on Standard monitor (16 / 9 / 4 division) ..........62 5.1.1 Playback function ....................62 5.1.2 SEARCH MODE ......................63 Time Search ......................63 5.2.1 Schedule Search ....................63 5.2.2 Event Search ......................64 5.2.3 Thumbnail Search ....................
  • Page 8 Install&User Manual Sync Event ......................89 6.5.2 Motion Detection ....................91 6.5.3 Sensor ........................92 6.5.4 Preset ........................92 6.5.5 Recording setup ......................94 Program setup ......................94 6.6.1 Manual/Schedule recording setup ................96 6.6.2 WEB VIEWER ..............100 System requriement ....................100 Login ..........................
  • Page 9 USER MANUAL FOR MOBILE VIEWER ......112 Log-In page ....................... 112 Monitoring page ......................112 TROUBLE SHOOTING ............114 AVAILABLE HDD ..............116 COMPATITABLE CD/DVD LIST ..........117 SPECIFICATION ..............117 HVRM-T1600M, HVRM-T800M, HVRM-T400M ..............117 HVRM-T1600Q, EH800L ...................... 120 PRODUCT SIZE ..............123...
  • Page 10: Key Features

    HVRM-T800Q : 1/4/9 channel mode  Auto Switching HVRM-T1600M : Composite x 2, DVI x 1 HVRM-T800M : Composite x 2, DVI x 1 HVRM-T400M : Composite x 2, DVI x 1 HVRM-T1600Q : Composite x 2, VGA x 1...
  • Page 11 High-Resolution (H.264) and available to record max. 5 seconds before triggering an event. Also, convert function is available protecing privacy.  H.264 Video recording with High-Quality HVRM-T1600M : CIF(360x240) 480ips HVRM-T800M : 2CIF(704x240) 240ips HVRM-T400M : D1 (704x480) 120ips HVRM-T1600Q : CIF(360x240) 240ips HVRM-T800Q : CIF(360x240) 240ips ...
  • Page 12 Install&User Manual Back up device It is available to backup to DVD-R, CD-R, USB memory by user‟s choice. (HVRM-T1600Q, HVRM-T800Q is available as an option.)  Supprots various back up device : DVD-R, CD-R, USB memory  Extention HDD Storage (External extention Storage device) Network It supports variable network like LAN, XDSL and easily control from remote site using PC cliet viewer.
  • Page 13: Install Manual

    Install&User Manual Install Manual 1. Feature Supplied Accessories Unpack and check all the items as below 1.1.1. T1600M/T800M/T400M Series AC Cord, Remocon, Setup CD, SATA Cable, HDD Fixing Screw, Quick Guide...
  • Page 14: T1600Q/T800Q Series

    Install&User Manual 1.1.2. T1600Q/T800Q Series AC Cord, Remocon, Setup CD, SATA Cable, HDD Fixing Screw, Quick Guide...
  • Page 15: Description & Function

    Install&User Manual 1.2. Description & Function 1.2.1. Front 1.2.1.1. T1600M/T800M/T400M Series Front Item Description DVD-Multi (For Back up use for recorded data by DVD/CD media Back up) Channel Button To select video input channel REC LED Displays recording status COPY LED Displays copy status HDD LED Displays HDD running.
  • Page 16 Install&User Manual To change Monitor/ Stop Menu To enter menu To escape from menu or close pop-up window Enter/Play To enter playback mode or select menu ◀/REW To move or select in menu and change replay speed to reverse direction in playback mode ▶/FWD To move or select in menu and change replay speed to forward direction in playback mode...
  • Page 17 Install&User Manual 1.2.1.2. T1600Q/T800Q Series Front Item Description DVD-Multi (For Back up use for recorded data by DVD/CD media Back up) Channel Button To select video input channel REC LED Displays recording status COPY LED Displays copy status HDD LED Displays HDD running.
  • Page 18 Install&User Manual ◀/REW To move or select in menu and change replay speed to reverse direction in playback mode ▶/FWD To move or select in menu and change replay speed to forward direction in playback mode ▲/Pause To move or select in menu and pause live/ replay video ▼/Stop To stop replay in playback mode...
  • Page 19: Rear

    Input/ Output name Descrtiption Ground Ground between DVR & external device CH1~16 BNC input for camera connection HVRM-T1600M : 16EA, HVRM-T800M : 8EA, HVRM- T400M : 4EA Loop out BNC output(Loop) for camera connection Monitor/ Spot BNC connection for monitor output...
  • Page 20 Install&User Manual 번호 Input/ Output name Descrtiption Ground Ground between DVR & external device Power connector Socket for AC100V~AC240V power cord...
  • Page 21 Install&User Manual 1.2.2.2. T1600Q/T800Q Series REAR 번호 Input/ Output name Descrtiption Ground Ground between DVR & external device Power connector Socket for AC100V~AC240V power cord CH1~16 BNC input for camera connection HVRM-T1600Q : 16EA, HVRM-T800Q : 8EA Monitor/ Spot BNC connection for monitor output Audio Input(RCA) RCA connection for Audio input Audio Output...
  • Page 22: Remote Controller

    Install&User Manual 1.2.3. REMOTE CONTROLLER It is available to use all functions of DVR. If several DVR are set with unique ID numbers, they can be controlled with one remote controller. To use remote controller, it is necessary to set ID first which want use. Keep pressing ID button repetedely (Up to Max. 16 times) and use it matching DVR &...
  • Page 23 Install&User Manual SEARCH To indicate search menu CHANNEL BUTTON To select channel SELECT Not use In case of selecting over 10 (+10 + 1) Not use Not use MENU Covert to menu screen HELP Not use ◀/REW Move setting menu to left direction/REW ▶/FWD Move setting menu to right direction/FWD ▲/PAUSE...
  • Page 24: Installation

    Install&User Manual 2. Installation Installation and Connection 2.1.1 Connecting & Running 2.1.1.1 Connecting camera Connect CCTV camera to DVR with BNC cable as below [T1600M/T800M/T400M Series] [T1600Q/T800Q Series] - The video type for all channels should be either NTSC or PAL, not be combined both - DVR sets video signal‟s impedance (75Ω) automatically.
  • Page 25: Connecting Audio

    Install&User Manual 2.1.1.3 Connecting Audio Connect audio signal to DVR with using RCA cable or D-SUB as below; [T1600M/T800M/T400M Series] [T1600Q/T800Q Series] 2.1.1.4 Supplying Power Connect power cable as below; [T1600M/T800M/T400M Series] [T1600Q/T800Q Series] - When supplying power, DVR starts booting automatically. - In order to cut off power, press power switch on DVR front during 5 seconds, then select “YES”...
  • Page 26: Running Osd Menu

    Install&User Manual Running OSD menu 2.2.1 OSD menu configuration Press [MENU] in keypad of front to open configuration menu as below; (1) Main Menu : The selected tab is show in bright color and the related sub-menu will be shown left- below the tab. To move to the previous/next tab, use the [◀/▶] arrow buttons. To move to a sub-menu press the [Enter] key.
  • Page 27: Setting Remote Controller

    Install&User Manual Keep pressing [▲/▼], [◀/▶] arrow button until the word is looking for and press Enter. In case of deleting input word press [], spacing words press [] button. To exit from dialogue box, press [Enter] after finishing word input. 2.2.2 Setting remote controller 2.2.2.1...
  • Page 28: Install Examples

    Install&User Manual To select a specific DVR, keep pressing the ID button of remote controller until a buzzer sounds during 2 seconds. 2.2.2.3 Operaable range of remote controller 2.2.2.4 Loading the batteris into the remote controller Remote controller required two AAA-type batteries. Please, refer the following installation step. 2.Taking care the the poles 1.
  • Page 29 Install&User Manual [T1600Q/T800Q Series] 2.2.3.2 Advance configuration [T1600M/T800M/T400M Series] [T1600Q/T800Q Series] 2.2.3.3 External storage & Back up configuration 28...
  • Page 30: Basic Setting

    Install&User Manual [T1600M/T800M/T400M Series] [T1600Q/T800Q Series] 2.2.3.4 Internet/ Intranet configuration [T1600M/T800M/T400M Series] [T1600Q/T800Q Series] 2.2.4 Basic Setting 29...
  • Page 31: Viewing Image

    Install&User Manual 2.2.4.1 Viewing Image When power is on, eDVR starts automatically and displayed in basic 16ch-split screen after booting. <Reference> If user password is set, a prompt for entering the password will be appeared. Factory default is reserved as not responding keypad on DVR front (It is not from factory default). 2.2.4.2 Setting Date &...
  • Page 32 Install&User Manual (3) Select On/Off using [◀/▶] arrow button and press [ESC] button. (1)Select NTP Function (2)Select “Client or Server or Both” using [◀/▶] or [▲/▼] arrow button and press [Enter] button. (3)Select “Public or Both” using [◀/▶] arrow button and press [ESC] button on „Client or Both‟mode.
  • Page 33: Record Setting

    Install&User Manual 2.2.4.3 Record Setting Select “Record” pressing menu button in front. Program Setting Set resolution, frame rate, quality by each channel that user want record in “Program” of record menu. Schedule Setting 32...
  • Page 34: Connecting And Configuring Dio Ports

    Install&User Manual Set recording mode as “Scheduel & Event” and set by date/ time. Checking method for recording <Reference> If recodrding setting is finished correctly, “REC LED” in front is flickering. In addition, it is marked [S] indicating that all channels are recroding. Connecting and configuring DIO ports 2.3.1 Wire Handling...
  • Page 35: Connecting And Configuring Sensor

    2.3.3 Connecting and configuring sensor 2.3.3.1 Specification In order to run sensor input DVR normally, the following conditions are required. Input Ch Transistor input HVRM-T1600M. HVRM-T1600Q : 16EA, HVRM-T800M, HVRM-T800Q : 8EA HVRM-T400M : 4EA Spec Input type N.C, N.O supprt...
  • Page 36 Install&User Manual Setting Sensor (1) Press [Menu] button and select “Event” when OSD menu is appeared. (2) Move to sub menu pressing [Enter] or using [▼] button and select [Enter] All sensor It is used when setting for all sensors and set Off, or Normal Open (N.O.) / Normal Close (N.C.) type.
  • Page 37 Install&User Manual 2.3.3.2 Connecting relat and setting Specification In order to run relay output of DVR normally, the following conditions are required. Output Ch. 2EA relay outputs Output type Dry contact SPEC Connecting type Connect the trimmed wire to terminal block 30V 1A Perfromance 125V 0.5A...
  • Page 38: Connecting Serial Port

    Install&User Manual 2.3.3.3 Connecting serial port Configuring serial ports for Pan/Tilt/Zoom If DVR supports thru. COM port, it is available to connect PTZ camera and control it. For a list of supported protocols, please refer to the list on the OSD configuration menu. The following figure shows how to connect PTZ camera to RS485 (COM2/COM3).
  • Page 39 Install&User Manual Serial communication port diagram COM1 Connection (RS-232) Text Keyboard Transparent Com1 COM2/COM3 Connection (RS-485) Dome Camera Com2, 3 Receiver Available PTZ is same as below table. Model Name Manufacturer Webgate Keyboard KBD300A, WGI SPD1800/2600 Webgate WKC-100 Keyboard BOSCH AutoDome, TC8560X-4 Bosch Pelco PELCO(P), PELCO(D)
  • Page 40 Install&User Manual Samsung Electric Samsung SCC641 Panasonic Panasonic WV-CS850 SDZ160/330, Samsung SPD, Samsung Techwin Keyboard SCC3000, Samsung SRX-100B LG GAC-PT2 Merit Merit-Lilin FastDome Elmo PTC200C Elmo Canon Canon VC-C4 Dongyang Unitech HTC-230S Honeywell Honeywell 755/655, HRX-2000, ScanDome2 RVision Elbex Elbex VIDO VIDO Vicon...
  • Page 41 Install&User Manual 2.3.3.4 Connection to external device via Seria port Text input device connection (ATM / POS / Access Control) Using COM1/RS232, TEXT DATA can be recorded with synchronizing POS/ATM. Like above picture, connect COM1/RS232 (9pin D-Sub) in Device menu and configure Serial and Text.
  • Page 42: Usb Device Connection

    Install&User Manual Text Set up (1) Select “Deice” on OSD, and move to sub menu. (2) Select “Text”and configure relevant text information <Reference> Since external device can not be recognized, before installing, please, ask to the shop. 2.3.3.5 USB Device Connection USB port is for the simple video copy (within 1 hour) on USB Flash memory.
  • Page 43 Install&User Manual <Reference> It should be formatted by FAT32. In case of normal connection, if executing Copy menu, disk will be recognized same as below and Set copy range  Select Drive  Execute Copy. [CD/DVD Copy] [RE4 Copy] Select the channel to copoy 42...
  • Page 44 Install&User Manual [AVI Copy] <Reference> A USB Flash memory which should install additional program on Windows OS, can not be recognized. 2.3.3.6 Video In/Out connection Video Input/Output is Loop through and check the connectivity automatically and set end resistance. For instance, if connected by Video input, end resistance is configured by75Ω and if Video in/output is same, it will be Hi-z mode.
  • Page 45: Hdd

    Install&User Manual [T1600Q/T800Q Series] 2.3.3.7 Audio In/Out connection There are 4 RCA Audio Input and 1 RCA output. 2.3.4 ※ Please, refer to Appendix for available HDD list 2.3.4.1 HDD registration and format After mounting HDD and booting system, “Disk Manager” will execute automatically. If not, please, check the connectivity of HDD.
  • Page 46: Remote Monitor And Control

    Install&User Manual 2.3.5 Remote monitor and control Via Internet/Intranet, in remote site, user can access with PC. 2.3.5.1 Ethernet connection [T1600M/T800M/T400M Series] [T1600Q/T800Q Series] (1) Cut Power. (2) Connet Ethernet cable to DVR and Hub. (3) Input Power. <Reference> To protect DVR demage, after connecting Ethernet cable, input Power. Please, check Ethernet cable connection firmly.
  • Page 47 Install&User Manual Ethernet Set type as Ethernet and input IP, Netmask,Gateway, DNS. The way to input is using directional key or mouse wheel. PPPoE Set type xDSL, and move to xDSL menu. First, change Ethernet Port Please, input ID and Password for PPPoE. After changing interval over 1 min, register WRS address and product and input Group ID.
  • Page 48: User Manual

    Install&User Manual User Manual 3 Menu Use Menu Structure The menu structure will be shown like below image, and each menu setting method descriped from chapter 4 to chapter 6. Function Menu To execute Function menu, click the right button of mouse or select „FUNC‟ button on front panel.
  • Page 49: Factory Reset

    Install&User Manual Factory Reset In order to reset value to factory value, go to System Setting->System->Setting, and once press Factory Reset then the warning message will be appear, click “Yes” to reset the DVR value to factory. Default Value from Factory System Time Zone UTC 00:00 Dublin...
  • Page 50 Install&User Manual Holiday Select UTC 00:00 Dublin Date Format Time MM/DD/YYYY Over Write(Auto Deletion) Block Playback Disk Disk Full Alarm Warning Disk Manager >> Disk Status >> User No Password used Setup DVR Alias DVR0 DVR Keyboard ID Remote Controller Utility Language English...
  • Page 51 Install&User Manual Group Newbie Status Not Registerd Device Camera Camera Number Name Cam 1 Status Type NTSC Color Color Enable Bright Contrast PTZ Home Idle Time PTZ Port None PTZ Address Monitor Alarm Pop-up(Sec) User Sequence << Configuration Monitor SEQ Time(Sec) Covert >>...
  • Page 52 Install&User Manual Delimiter 0D0A Timeout(ms) 1000 Lines Serial Port Com1 Device Interface RS232 Serial Baud Rate 9600 Parity Bit None Stop Bit Data Bit Event Event Check Always Event Action Relay1 Action Duration 10 Sec Event Normal Event >> Source System Event >>...
  • Page 53 Install&User Manual Program initial value HVRM-T800Q Record mode Normal Event Division Half Half Half Half Half Half HVRM-T1600Q Record mode Normal Event Division Half Half Half Half Half Half HVRM-T400M Record mode Normal Event Division Half Half 52...
  • Page 54 Install&User Manual Half Half Half Half HVRM-T800M Record mode Normal Event Division Half Half Half Half Half Half HVRM-T1600M Record mode Normal Event Division Half Half Half Half Half Half 53...
  • Page 55: Monitoring

    Press [MULTI] for multi channel display or click “Display” icon from Function menu. Press [MULTI] button every time, screen mode for HVRM-T1600M, HVRM-T1600Q is changed to 1~4, 5~8, 9~12, 13~16, 4C, 1~9, 8~16, 1~10, 16 screens, and for HVRM-T800M, HVRM-T800Q is 1~4, 5~8, 4C, 9screens, and for HVRM-T400M is 1~4screens.
  • Page 56: Screen Description

    Install&User Manual Screen Description The status bar from monitoring screen, it shows DVR‟s current status that included Date/Time, Record, Motion/Sensor Detection, Manual Record, Text input and HDD‟s record capacity. Auto Switch Mode There are System Standard modes and User Defined mode in Auto Switch mode. And Users Sequence mode operates by the press [SEQ] button.
  • Page 57: User Sequence Mode

    Install&User Manual Auto Switch mode can be set in every division mode by the press [Auto] button. Press [Auto] button once more to leave from Auto Switch mode. 4.5.2 User Sequence Mode Press [AUTO] button or click [Sequence] icon from Function menu with mouse. Auto Switch model can be set from “Monitor”...
  • Page 58: Event Screen

    Install&User Manual User mode can define max. 16 channels. As shown above picture, the 16ch DVR can be define between channel 1 ~ 16, the 8ch DVR from 1 ~ 8 and the 4ch DVR from 1 ~4. Event Screen When there is an event occurred, the green color [M] and red color [S] will be display from status bar.
  • Page 59: Zoom Screen Mode

    Install&User Manual 1. If Alarm Pop-up Hold (sec) set to Off, Alarm Pop-up will not operate. 2. If Alarm Pop-up Hold (sec) set to Keep, it does not return to previous screen before press any button Zoom Screen Mode From single full screen mode, press [FUNC] and D-Zoom button then select + button to activate zooming the image.
  • Page 60: Ptz Control

    Install&User Manual PTZ Control Connect PTZ controller to DVR and set relevant protocol from “Serial Setup” menu, then PTZ can operate while monitoring live images. The method of operating PTZ, press PTZ button from DVR‟s front panel, or click PTZ icon from Function menu.
  • Page 61: Pan/Tilt

    Install&User Manual LiveEye Fine CRR-1600 Tokina Tokina Kodicom Kodicom KRE Nuvico Nuvico Press desired channel button. Press PTZ button from front panel or click PTZ icon from function menu with mouse. PTZ menu (Pan/Tilt, Zoom/Focus, Load Preset, Save Preset) will be appear. Then press [Enter] button or click from mouse.
  • Page 62: Auxiliary Off

    Install&User Manual 4.9.6 Auxiliary Off This menu is used to stop operation of specific function of PTZ device. Using up / down button or mouse wheel to select the Aux Number. Select Off and press Enter button or click from mouse. 4.9.7 Menu It is to go into connected PTZ‟s menu, using up/down/left/right and enter key from front panel for setting the menu, and press ESC button for exit the menu.
  • Page 63: Playback

    Install&User Manual 5 Playback Playback Mode 5.1.1 Playback on Standard monitor (16 / 9 / 4 division) Please, push play button in monitoring mode or mouse click play buttion in Function menu. If pushing Play button or FWD button, video playbacks in forward direction at 1× speed. If pushing REW button, video playbacks in reverse direcetion at 1×...
  • Page 64: Search Mode

    Install&User Manual SEARCH MODE This menu is to playback specific time data from the time frame and searching log at Playback mode. There are Time, Calendar, Event, Thumbnail mode. Please, push Search button on the front panel or click in Function menu. 5.2.1 Time Search Select date and time to search and playback video will be moved to the selected point.
  • Page 65: Event Search

    HVRM-T1600M, HVRM-T1600Q HVRM-T800M,HVRM- T800Q HVRM-T400M Depends on models, HVRM-T1600M, HVRM-T1600Q shows the status of recording for 1~16ch, HVRM-T800M, HVRM-T800Q for 1 ~ 8ch, HVRM-T400M for 1~4ch. Year : Select Year to search. With mouse wheel, user can change it. Month : Select Month to search.
  • Page 66: Thumbnail Search

    Enter and change the value by Up and Down button. With mouse, click and scroll the wheel. Event Channel : Select the channel for search HVRM-T1600M, HVRM-T1600Q from Ch1 to Ch16 HVRM-T800M, HVRM-T800Q from Ch1 to Ch8 HVRM-T400M from Ch1 to Ch4 Event Type...
  • Page 67: Copy

    Install&User Manual Start Time : Input the date and time for starting search and change the value using up-down direction key or mouse wheel. Interval : Set Interval value by Up-down button or mouse wheel. View video : If pushing search button, 16 cycles will be shown based on start time. Press [Func] to return to the search or use mouse wheel.
  • Page 68: Re4

    5.3.2 User can back up by HDD, USB memory and play back suing mini-player or Control Center. Select channel position and press Enter or use mouse wheel to open the channel list like below. [HVRM-T1600M, HVRM-T1600Q] [HVRM-T800M, HVRM-T800Q] [HVRM-T400M] Type : Select RE4 using up-down button or mouse wheel.
  • Page 69: Avi

    Install&User Manual Start time : Set start date or time to copy. After selecting part for change and set the vaule using up-down key or mouse wheel. End time : Set End date or time to copy. After selecting part for change and set the vaule using up-down key or mouse wheel.
  • Page 70: Configuration

    Install&User Manual 6. Configuration Recording Structure There are 4 modes in DVR recording. Configuration relation structure is like below. Please, refer to the below each item for detailed recording configuration. System Setup Time and Disk and authority can be configured. 6.2.1 Date/Time Time set should be configured prior to the recording.
  • Page 71: Time Setup

    Install&User Manual 6.2.1.1 Time Setup Caution: under recording, if user changes Time, it will affect time change on previously recorded video data in accordance with. Therefore, we recommend backup before time change. Press Main Menu of Function or [MENU] button on the front panel. Move to “quick setup”...
  • Page 72: Ntp Setup

    Install&User Manual <Caution> Except date/time configuration, other configuration records automatically, but “date/time” configuration influences critical effect to HDD recording file system, It doesn‟t record automatically. To apply the changed value, user must press [apply] button. 6.2.1.2 NTP Setup NTP(Network Time Protocol) make time of connected devices synchronized. There are NTP server and client which get time signal from the server.
  • Page 73: Disk

    Install&User Manual NTP Local server IP In NTP local server Enable, configure server ip. Input IP address of NTP server or DVR set by NTP server In local network. Interval Configure interval of time sync. Caution: If use NTP client mode, user must set NTP on. 6.2.2 Disk It explains how to add or remove or format internal or external HDD.
  • Page 74 Install&User Manual If mounted Disk is full, alarm warning to user. 6.2.2.1 Disk This is menu for the management of internal or external HDD. Manage status, bad block, size, Yes or No etc. Type : display location or type of disk. Int A (Internal A HDD), Int B (Internal B HDD), Ext (External HDD) Model : HDD model name.
  • Page 75: User Setup

    Install&User Manual - HDD is not used. - If No, keep previous HDD without change. 6.2.2.2 Disk Status Temperature and status of HDD will be shown. 6.2.3 User Setup There are administrator and user and administrator can use all functions. The max. number of user is 10 person.
  • Page 76 Install&User Manual <Reference> Admin Password is “12345” in factory default and from user 1 to 10 in order “11111”,”22222”,.. and user10 is “00000”. In case of 9 channel DVR user, press “0” for figure 0, in case of 16 channel, press button “10” Password change Select user ...
  • Page 77: Utility

    Install&User Manual [Authority Check] [Wrong password message] 6.2.4 Utility Configure the name of DVR, remote controller ID, Language. DVR Alias Set the name of DVR. DVR Keyboard ID This menu is to set the address of keyboard when using all functions of DVR by keyboard. Factory default is “1”.
  • Page 78 Install&User Manual be set with the different value. Remote Controller ID Max 16 remote controller ID can be set and one remote controller can manage 16 DVRs. Registration order for Remote controller. Make remote controller direction to DVR. Press ID button and figure in accordance with configured remote controller ID. If IDs are matached correctly, DVR buzzes.
  • Page 79: Network

    Install&User Manual Factory Reset Change all configuration value by factory default. Caution : Only administrator is allowed. Network This is menu for configuring network. 78...
  • Page 80 Install&User Manual Type Configure type of Network (Ethernet/xDSL). If connected to cable modem or Lan directly to DVR, configure by “Ethernet”. If DVR connects to xDSL- one of PPPoE type, configure xDSL. But if it is not type of PPPoE, configure „Etherent‟.
  • Page 81: Xdsl

    Install&User Manual Bandwidth Menu for configuring network data transmission capacity. Without any additional configuration, it works but if user want to set, please, ask for administrator. 6.3.1 xDSL DVR is connected to xDSL line and use PPPoE type, please change type by xDSL and configure user ID and Password.
  • Page 82: Device Setup

    Install&User Manual WRS Interval For continuous registery, register inverval should be set to „WRS Interval‟. According to set value of static IP address, it renews the information in WRS server regularly. If user registers the interval „0‟ or eDVR does not transmit any data for 2 days, the data is removed from WRS. WRS URL This menu is to set server address to register.
  • Page 83: Camera Setup

    Install&User Manual 6.4.1 Camera Setup Select the camera to configure in Channel menu. 6.4.1.1 Title Configure camera name. If pressing [Enter] button or click mouse, test menu will be shown. For text string, text input box will be shown. Use directional key for text input. With mouse, just click the text.
  • Page 84: Monitor Setup

    User sequence can be edited. There are 16 user sequence mode and its interval is from 1 to 60seconds. Multi mode HVRM-T1600M, HVRM-T1600Q have predefined screen modes. 4E(4channels), 9B(basic 7 channels and additional 2 channels),10A(10 channels). In case of HVRM-T800M, HVRM- T800Q, it can use only 4E(4channels) and HVRM-T400M doesn‟t provide multi mode.
  • Page 85: Audio Setup

    Install&User Manual Display information Display information is to configure which information will be shown on live view and playback view. In live view, time,channel name, event, recording status, HDD, remote controller ID, text can be set and in playback view, time,command,channel name, event, text can be configured. 6.4.3 Audio Setup With this menu, user can configure Voice Channel, Audio recording, Volume, Synchronization,...
  • Page 86: Text Setup

    Install&User Manual Select audio in live view. If setting by “All”, input audio will be out in eery channels and if configured certain channel, input audio will be out on the selected channel only. 6.4.4 Text Setup Configure Text in Device menu. Recording Set On/Off of recording against Text input Sync Text with...
  • Page 87: Serial Setup

    Install&User Manual of a data. The reason of 2 Header is to detect maximum 2 data out because each device can output various datas. Delimiter Delimiter value can be different according to the manufacturer, please, refer to the product manual or seller. Time out Following lines defined here means maximum number of text line from one data.
  • Page 88: Ptz Setup

    Install&User Manual Interface Configure which interface user uses. COM1 is to RS-232C, COM2, COM3 are to RS-485. Baud rate/Parity/Stop Bit/Data Bit In put suitable value according to external device. 6.4.5.1 PTZ Setup Additional configuration for PTZ Address, PoirtPTZ PTZ Home Shift to Preset assigned if it has no movement in certain time while PTZ control.
  • Page 89: Event Check

    Install&User Manual 6.5.1 Event Check There are 3 items – Always, not apply, Timezon. In case of Timezone, with similar configuration window like schedule, user can configure event per weekday/time. • INDEX : Schedule configuration from 1 to 50 • Weekday •...
  • Page 90: Sync Event

    Install&User Manual After selecting INDEX, change directly weekday,time. 6.5.2 Sync Event Configuration for Event synchronization. Event Action There are 6 actions – relay 1 to 4, buzz, E-Mail. Action Duration Action Duration runs if relay and buzz are configured, and goes on during the configured time.
  • Page 91 Install&User Manual System Event source System Event source can configure Bad block, Disk full, Fan error, authorization failure, WRS registeration failure. E-Mail E-mail address Input E-mail address to get event alarm by E-Mail. 90...
  • Page 92: Motion Detection

    Install&User Manual Sender Address Not mandatory but necessary for receiver to find out which DVR sends event. Including Picture In general event, when sensor, MD, V-loss events are generated, the event information and channel video will be sent to e-mail together. But system event just send system event information.
  • Page 93: Sensor

    6.5.4 Sensor This menu is to setup the existing sensor input and type of sensor. HVRM-T1600M, HVRM-T1600Q have 16 inputs and HVRM-T800M, HVRM-T800Q have 8 inputs and HVRM-T400M has 4 inputs. Sensor has 2 types, Normal Open(N.O.) and Normal Close(N.C.).
  • Page 94 Install&User Manual 93...
  • Page 95: Recording Setup

    6.6.1 Program setup Using [Program], adjust frame rate and quality and resolution and configure recording program for Manual&Event&Schedule. [HVRM-T1600M, HVRM-T1600Q] [HVRM-T800M,HVRM- T800Q] [HVRM-T400M] In event recording, one channel can record up to its max frame rate and if setting 2 channels as event recording, their recording frame rate will be adjusted automatically.
  • Page 96 Install&User Manual R (Resolution) There are 3 resolutions - D1(704x480), Half D1(704x240), CIF(352x240) F (FPS) It means frame per second and can select 1 to 30fps. Max. frame can be changed according to the configuration. Q (Quality) There are 5 recording quality - Q5/Q4/Q3/Q2/Q1. Recommended quality for event recording is Q3. Max R/F Max R/F shows the number of frame available according to the selected resolution.
  • Page 97: Manual/Schedule Recording Setup

    Install&User Manual If you want to configure channel no.1 as D1 30fps, you should adjust the other channel recording configuration. • On event recording of multi channel With mulity channel event recording, if configured recording value is over the system max performance, general reconrding will keep their recording configuration and event recording will be balanced down equally.
  • Page 98 Install&User Manual check and select each program default vaule and select one of 26 program from A to Z or several programs. Below picture show program A. • INDEX : Schedule unit from 1 to 50 • Weekday : Set the day applicable •...
  • Page 99: Event Recording Setup

    Install&User Manual Edition Select INDEX to edit and change weekday, program,time directly. In case that INDEX 50 are all configured, select the time zone to change by mouse click and click the time again, previouse configuartion will be deleted and new configuration will be shown.
  • Page 100 Install&User Manual 3. Set Event applying time. Event Time configuration Configure time for event recording and there are 3 mode – Always, no use, Timezone. In “Always”, event works all the time and in “Timezone”, works during configured time. Configuration of Timezone is similar with schedule configuration and can configure weekday,time for Event.
  • Page 101: Web Viewer

    Install&User Manual 7. Web Viewer WebViewer is Web application program loaded to monitor real-time image or to minitor the images recorded through Web browser to PC located remotely. WebViewer is divided into Login page and Monitor to do monitoring real-time images, Playback to replay reocorded images.
  • Page 102: User Setup

    Install&User Manual If didn‟t change the password in Control Center, ID and Password will be admin/12345. ID can not be changed. User Setup To access WebViewer, user authority and password can be changed in DVR or Control Center configuration In account menu, user password can be changed. Basic admin password is “12345”...
  • Page 103: Monitor

    Install&User Manual Login page provides manual installation program to use WebViewer function. PC that access to WebViewer first installs ActiveX to use WebViewer‟s function. At this time when installation is not smooth, installation program needs to download from Login Page and install manually.
  • Page 104: Move To Playback

    Install&User Manual Double click on one of the playback screen to convert in 1 channel mode. After conversion to 1channel mode, double click on screen to return to previous division channels. At division screen, it can change screen location. If 3channel image moves to 6ch, drag 3ch image and drop on 6ch location so as to exchange between 3ch and 6ch image 7.5.2 Move to Playback...
  • Page 105: Channel On/Off

    Install&User Manual 7.5.3 Channel On/Off It is On/Off button for the Channel located to left in page. Click the channel wanted to On or Off. And Default is On. 7.5.4 Sensor Indication The icon indicates when sensor occurs in system When it sensorsed, relevant sensor icon comes to Red, and indicates sensor number of video.
  • Page 106: Event Data

    Install&User Manual 7.5.7 Event data It shows real time event data occurred at the bottom of monitoring page. Indicated Event data list are as follow.. (Table. Event Icon) Button Function Motion Detect On Sensor Input Relay Output On No Video, Video Detected 1.2.1.
  • Page 107: Usingptz

    Install&User Manual of current monitoring channel. To save video, select the channel and click right button of mouse. Ans select “Save As” and point out the location and press Save button. 7.5.8 Using PTZ Among the icon on top of video on monitoring, click „PTZ‟ to acitivate interfacing to control Pan, Tilt, Zoom, and Focus.
  • Page 108: Using Audio

    Install&User Manual Reference Supported PTZ camera list can be refereed to „4.8 PTZ manipulation. 7.5.9 Using Audio In case of Channel setup sync with Audio, press right mouse button on the image to activate pop-up menu to “Listen” or activate Audio listen button. First default is Mute. In case of listening Audio, select pop-up menu or button.
  • Page 109: Playback

    Install&User Manual Playback This page is to playback recorded images, and user who has authority of „HDD‟ among user ID or administrator can use this function. Playback that is made up 16 divisions can play the images by searching through calander by recording period and moving the period.
  • Page 110: Printing

    Install&User Manual Save Iamge dialog box appears, then it can input message or select channel name, date, event data. Press „OK‟ to open dialog box for the saving location, then save bmp file. 7.6.2 Printing Select image with mouse for the channel to print image saved, and then click „Print‟ button. Window comes to input Memo, and click „OK‟...
  • Page 111: Web Monitor

    Install&User Manual 7.6.4 Web Monitor Click „Go‟ button at top of page, and it can move Web monitor page. 7.6.5 Channel On/Off It is the same function like Channel On/Off function at Web Monitor. It is Channel On/Off button located on right of Page, and click On or Off page for wanted channel.
  • Page 112: Functional Function At The Buttom Of Monitor

    Install&User Manual 7.6.8. Functional function at the buttom of monitor ① Indicates playback range of recorded image. ② Press button as the time set at (5) so as to change the time zone to playback in forwarding and backwarding. ③ From left button, it can „Move a frame back‟, „Play backward‟, „Stop‟, „Play‟, „Move a frame forward‟.
  • Page 113: User Manual For Mobile Viewer

    Install&User Manual 8. User manual for Mobile Viewer Mobile viewer is viewer service to monitor video via mobile device. To access mobile viewer, user uses mobile device supporting Wi-Fi or smart phone or 3G. 8.1 Log-In page Below picture is Mobile viewer log-in page. To access log-in page via mobile viewer, please, type the address like http://IP/mvmenu.html.
  • Page 114 Install&User Manual For functions, please, refer to the below. [0] MENU : Move to Log In page [1] CH- : Move to the previous channel. [2] UP : Move to upside of Pan Tilt movement [3] WIDE : Zoom Out action [4] ...
  • Page 115: Trouble Shooting

    Install&User Manual Trouble shooting 1. DVR booting failure 1. Check the power 2. Check Power cord 2. No video on monitor 3. Check monitor power 4. Check cable between DVR and monitor 5. Check monitor cable port 6. Check DVR power is off 7.
  • Page 116 Install&User Manual 25. Check if Network cable is connected 26. Check DVR IP 27. Check Computer IP 28. Ping Test 29. Check PC specification if Webview video is not shown. 10. The cases necessary to contact the shop 30. In case of extraordinary working(ex: noise, smell or fume) 31.
  • Page 117: Available Hdd

    Install&User Manual #1. The way to check the manufacturing date It can be checked with its S/N(Serial Number). #2. S/N : Serial Number It means composite 12 digit number with product model name and production year,month, and week. It can be found on the attached label attached on the bottom of product or system info of configuration tool or system information 1 of DVR Func menu.
  • Page 118: Compatitable Cd/Dvd List

    User defined sequence / alarm pop-up Recording Compression H.264 / JPEG Resolution CIF/Half(2CIF)/D1(4CIF) Rate HVRM-T1600M : 480 at CIF, HVRM-T800M : 240 at 2CIF, HVRM-T400M : 120 at D1 Quality 5 levels Mode Manual & Event / Schedule & Event Scheulde...
  • Page 119 Install&User Manual Mode Instant playback / Search Speed 120 fps, Search Type Time, Calender, Event, Thumbnail Block Playback 1day ~ 31days Event & Alarm Event source MD, Sensor, Text Event check schedule 24hrs / 7day Event Action Recording, Relay, E-mail, Buzzer, Pop-up, Warning Message, PTZ preset MD Area 22x15(NTSC), 22x18(PAL)
  • Page 120 S.M.A.R.T. Temperature and Health Serial & I/O Serial port 1 RS-232C, 2 RS-485 Sensor input HVRM-T1600M : 16 dry-contact, HVRM-T800M : 8 dry-contact, HVRM-T400M : 4 dry-contact Relay output 2 relay Controller Device Front panel, IR remote, Joystick KBD, Mouse...
  • Page 121: Hvrm-T1600Q, Eh800L

    Install&User Manual HVRM-T1600Q, EH800L Video input Video input standard NTSC or PAL auto detect Connectors HVRM-T1600Q : 16ch, HVRM-T800Q : 8ch analog video inputs BNC connector Main Video output Main output output via BNC & VGA HVRM-T1600Q : 1,4,9,10,16 mode HVRM-T800Q : 1.4.9 mode User defined sequence / alarm pop-up 1280x1024, 1024,768 at VGA port...
  • Page 122 Install&User Manual Alarm source HDD fail, HDD almost full, Fan fail, Pwd fail, DDNS fail Alarm action Warning message, buzzer, e-mail, relay Audio Input/output 4 RCA input, 1R CA output Compression 16KHz, 16bit sampling ADPCM Direction Both Protocols 32 models including Bosch, Pelco, Sony, Merit- lilin, Honeywell Network Interface...
  • Page 123 Install&User Manual 8 dry-contact Relay output 2 relay Controller Device Front panel, IR remote, Joystick KBD, Mouse Software WebViewer Monitoring / Playback Mobile Viewer Monitoring with PTZ, iPhone & BB supported Control Center Standard, max 1000 clients ActiveX(COM) SDK Environmental & Physical Dimension W : 359.0, L : 413.3, H : 88.0 Operating temperature...
  • Page 124: Product Size

    Install&User Manual Product size T1600M/T800M/T400M Series 123...
  • Page 125 Install&User Manual T1600Q/T800Q Series 124...
  • Page 126 Install&User Manual HUNT ELECTRONIC USA INC. 11790 Jersey Blvd. Rancho Cucamonga, CA 91730 Tel: (888)993-4868, (909)987-6999 Fax: (909)987-6997 techsupport@huntcctv.com www.huntcctv.com 125...

This manual is also suitable for:

Hvrm-t800mHvrm-t400mHvrm-t800qHvrm-t1600q

Table of Contents
