Hunt Electronic HVRM-S400E Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HVRM-S400E
Installation Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HVRM-S400E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hunt Electronic HVRM-S400E

Summary of Contents for Hunt Electronic HVRM-S400E

  • Page 1 HVRM-S400E Installation Guide...

  • Page 2: Fcc Compliance Statement

    FCC Compliance Statement Caution : Any changes or modifications in construction of this device which are not expressly approved the party responsible for compliance could void the user's authority to operate the equipment. NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 3: Important Notice

    HVRM-S400E is secured after installation. 5. HVRM-S400E is made of metal. Therefore you can hurt human beings if you throw it to them or hit on them. When installing HVRM-S400E, be cautious to locate on safe places where children are unreachable.

  • Page 4: Table Of Contents

    Contents Introduction ......................... 6 1.1. Digital video recorder for security applications..............6 1.2. Features ......................... 6 1.3. Unpacking........................7 1.3.1. Package contents...................... 7 Installation ........................... 7 Connections ........................7 2.1. 2.2. First-time use........................ 10 Quick Setup Menu ....................10 2.2.1. Operating instructions ......................
  • Page 5 Connecting external device with serial port ................. 39 5.1. Connecting text input device ..................40 Connecting PAN/TILT/ZOOM ..................41 5.2. 5.2.1. Connecting between HVRM-S400E and SPD1800 ............ 41 5.2.1.1. Set PTZ on HVRM-S400E................42 Viewing with connected PTZ ................44 5.2.1.2. 5.2.1.2.1. Controlling pan / tilt ....................44 5.2.1.2.2.

  • Page 6: Introduction

    1. Introduction 1.1. Digital video recorder for security applications The HVRM-S400E is a video recording system that can record up to four camera signals with associated audio signals while simultaneously providing live multi screen viewing and playback. The unit has comprehensive search and playback facilities for viewing stored video.

  • Page 7: Unpacking

    - The HVRM-S400E sets video signal’s impedance (75Ω) automatically Impedance is set as 75Ω basically. If connecting a device to video output, impedance will be “Hi-z” status. - The HVRM-S400E automatically configures itself as a PAL or NTSC unit by detecting the signal format of the first connected camera (lowest camera input number) 2.
  • Page 8 Configure the alarm output as N/O or N/C in the menu system. 7. Connect to your network via the Ethernet port. - The HVRM-S400E is delivered with the DHCP function switched on, so IP address are assigned automatically if the network server uses DHCP. (Refer to the System settings/Connectivity/Network setup...

  • Page 10: First-Time Use

    2.2. First-time use To open the quick setup menu, press the MENU key on the front panel and select the Quick setup submenu. Fill in the basic settings to get the unit operational. The unit begins recording automatically. Press the EXIT key to close the menu.
  • Page 11 the year (YYYY) first. >>> TIME FORMAT • Select between 24 Hour and 12 Hour (AM/PM) format. >>> CURRENT TIME • Fill in the current time. >>> CURRENT DATE • Fill in the current date. >>> APPLY • Select this item to save your current time and date settings. Changing time settings All recorded video is time stamped for authentication.
  • Page 12 >>> RECORDING >>> CONFIGURATION STATUS • This shows the current setting of the HVRM-S400E. When the HVRM-S400E is still configured in the same way as it was during the last quick setup, the configuration status displays Original setup. Otherwise it shows Custom setup.

  • Page 13: Operating Instructions

    3. Operating instructions The purpose of the front panel keys is explained here. The functions available can be limited by setting passwords. An administrator has access to many more functions in the menu. Refer to Menu System for a full list of available menu items.
  • Page 14 LEFT key: In zoom mode, press to move the zoomed area to the left. MENU key: Press to active the setup menu for configuration of the HVRM-S400E on the local monitor (in live mode only). ENTER key: In menu mode, selects a submenu or menu item or saves selections made in menus.

  • Page 15: Viewing Pictures

    3.2. Viewing pictures The unit has one monitor output. The monitor picture display depends on how the system has been set up. It shows full screen or quad live or playback camera pictures. Alarms, motion, and video loss warnings are also displayed on the monitor.

  • Page 16: Playback Mode

    Copy Select Copy from the “File format”. - To play the HUNT ELECTRONIC USA INC. AVI format you can use a normal Windows compatible MPEG-4 player such as Media Player but you must ensure that an XVID codec is installed. (Check the Internet for this codec.)

  • Page 17: Search Mode

    5. Select USB memory to copy from the “Select disk”. 6. Press Start button to start Copy. 7. Press EXIT button to back to previous menu after completing Copy. Backup Select Backup from the “File format”. Type starting time to backup from the “Start date/time”. Set a range to backup from the “Duration”.

  • Page 18: Menu System

    4.1.1. Accessing the menu from the unit To open the menu (in live mode only): Press the MENU key. The main menu appears on the monitor. If the administrator password is enabled, the HVRM-S400E asks for a password when the main menu is activated.

  • Page 19: Quick Setup

    4.2. Quick Setup > The quick setup menu provides easy setup of recording and time. For recording, all four cameras are configured to record with the same settings and conditions. If the current time or date is changed and applied, the time of the previously recorded images is shifted so that no images are lost.

  • Page 21: Camera

    4.3. Camera > Use the Camera Setup menu to access the submenus for setting the camera names, for locking cameras and for controlling cameras. Quick Setup Camera Recording Camera 1 Name Camera 1 Camera 2 Status Camera 3 Type NTSC Camera 4 Color Auto...

  • Page 22: Recording

    • Video loss detection can be toggled On (default) and Off for each camera >> PTZ Home If you do not operate while PTZ Idle Time, It will move to preset #1 position • >> PTZ Idle Time Set PTZ Operating Time, If you set 20 Sec after 20sec it will go to preset #1 position. •...
  • Page 23 >>> RECORDING RESOLUTION • Set recording resolution of all cameras [CIF /Half D1/ Full D1]. • [Limitation] ‘Recording Resolution’ Half D1 NTSC Max - IPS (frame/sec) Max - Pre-event Rec (sec) Max - IPS 12.5 (frame/sec) Max - Pre-event Rec (sec) Full D1 NTSC...

  • Page 24: Event Source

    4.5. Event Source > • The sensitivity of the motion detection has six levels, Very Low, Q1, Q2, Q3, Q4 and Q5 or set to Off for no detection. • To setup the motion detect area for the whole screen, select Select All. •...

  • Page 25: System

    4.6. System > Use the System Settings menu to get access to those items that are used to configure the system >> LANGUAGE • A language is selectable from the list with the up/ down scroll keys. Press the play key to confirm. >>...
  • Page 26 The HVRM-S400E can record and display ASCII data on the monitor. The external device can be a text input device. >>> RECORDING • Set On to record text data on the hard disk of the HVRM-S400E. Text is recorded separately from images, but is synchronized based on time information. >>> MONITORING •...
  • Page 27 >>> TIMEOUT • If the text device does not send a delimiter, the text is recorded as a single block. Enter the time (in milliseconds) that must expire after the last received character to separate text blocks. >>> LINES • If the text device does not send a delimiter or use a timeout, enter the number of lines to be used for a single block of text.
  • Page 28 • When connected, the status shows Connected. >>> PORT • The HVRM-S400E provides flexible network communication port configuration. If the HVRM-S400E is on a special network, the network port can be changed to the appropriate number. For network communication port information, ask your network administrator.
  • Page 29 >> INPUTS AND OUTPUTS Inputs and outputs can be configured in this menu as Normally Closed (NC) or Normally Open (NO). • Select either NC or NO with the up/down scroll keys. Press the play key to confirm. • Outputs have the following fixed purpose: •...
  • Page 30 >>> DISPLAY CAMERA WITH INPUT ALARM • Select if the HVRM-S400E switches automatically to a full screen image of the camera when an input alarm becomes active for that camera. • In case of multiple input alarms shortly after each other, the last input alarm is used for display.
  • Page 31 • The interval can be configured with a slider from Off (disable) to 60 seconds (default 10 seconds). >>> EXIT PLAYBACK ON EVENT • When set to On, the HVRM-S400E exits playback to display a live event. >>> VGA MODE •...
  • Page 32 * characters. • To lock the keys on the front of the HVRM-S400E, set key lock to On and enter a four-digit password. (To unlock all the keys on the front panel, use Keys 1 to 4 to enter the password.)
  • Page 33 • Set Remote Setup to Enable (default) or Disable. When set to Disable, configuration is possible only via the front panel. PC users cannot configure the HVRM-S400E with the remote configuration software. When set to Enable, both local and remHVRM-ote users can configure the HVRM-S400E.
  • Page 34 This setting is used for time synchronization over the network. HVRM-S400E can be synchronized by setting them up as a client for an SNTP server. The HVRM-S400E can also be set up to act as a local time server, when it is configured in SNTP server mode >>>...
  • Page 35 Select Save Settings to save the current settings to a USB memory stick. >>> LOAD SETTINGS • Select Load Settings to load previously saved settings from a USB memory stick into the HVRM-S400E. >>> UPDATE FIRMWARE • For authorized personnel only! Select Update Firmware to load new firmware from a USB memory...

  • Page 36: Profiles

    4.7. Profiles > The recording schedule is divided by weekday day, weekday night, weekend day and weekend night. Users can configure start and end time of each schedule. >> PROFILES >>> CURRENT PROFILE Shows the profile (Weekday - Day, Weekday - Night, Weekend - Day, Weekend – •...
  • Page 37 >> EXCEPTION DAYS Exception days can be set, apart from the four standard periods, e.g. Christmas. Start time and date, and duration of the Exception days can be configured. • Up to 30 exception days can be set that override the calendar list. •...

  • Page 38: Utility

    • When set to Continuous (default), the HVRM-S400E overwrites older images when the hard disk is full. • When set to Linear, the HVRM-S400E stops recording when the hard disk is full and the administrator has to delete video manually.

  • Page 39: Connecting External Device With Serial Port

    >> DELETE VIDEO • Data can be deleted from a designated time frame. This can be set from the beginning of the recorded data (fixed) to a user defined time. • Select the date and time up to which the recorded data is to be deleted and then select Delete >>...

  • Page 40: Connecting Text Input Device

    5.1. Connecting text input device In addition to images, the HVRM-S400E can record text data received from POS/ATM through the RS232 serial port. Connect RS232 to 9pin D-sub of HVRM-S400E, and configure the “Text” sub-menu under the “System” tab. Set “Serial Setup” under the “System / Text” menu tab to “RS232” and “Device” to “Text.” Please be careful to set [Baud Rate].

  • Page 41: Connecting Pan/Tilt/Zoom

    Following explains how to connect HVRM-S400E and SPD1800. 5.2.1. Connecting between HVRM-S400E and SPD1800 - Connect COM Port RS-232 of ‘RS-232 to RS-485 Converter’ to COM Port RS-232 of HVRM-S400E. - RS-232 to RS-485 Converter: ADAM-4520 (Data Acquisition Modules) - Refer to www.advantech.com for detailed information.

  • Page 42: Set Ptz On Hvrm-S400E

    5.2.1.1. Set PTZ on HVRM-S400E Please connect PTZ available device to RS-232 port and set Device, Baud Rate, and so on at Connectivity -> Com Port of system tab. After completing Com Port setup, configure PTZ address and PTZ port for each channel under the “Camera”...

  • Page 44: Viewing With Connected Ptz

    5.2.1.2. Viewing with connected PTZ Pan/Tilt/Zoom (PTZ) devices can be controlled through the HVRM- S400E series, when PTZ device is connected and properly configured under “Serial Setup.” First, press the [SELECT] button. Channel selection icon will be displayed. Move the icon to the channel to control with the [Arrow] button.

  • Page 45: Using Save Preset

    5.2.1.2.4. Using save preset To set a new preset point for dome camera during live monitoring mode Move dome camera to the desired position using the ‘Pan/Tilt’ and ‘Zoom/Focus’ menus. Press the [SELECT] button. Move the “Select” icon to the desired channel. Press the [MENU] button.

  • Page 46: Using The Control Center Lite

    The Control Center Lite is a software application that makes the installation and configuration of a unit faster and easier. The Control Center Lite runs on a PC that is connected to the HVRM-S400E via an Ethernet network connection. Although all settings can also be configured with the on-screen display menu of the HVRM-S400E itself, the Control Center Lite offers a very user-friendly alternative.

  • Page 47: How To Log In

    3> Choose components and press “Next” button. WESP SDK should be installed. 4> Select folder and press “Install” button. 6.3. How to Log in Click the “OK” button after inputting ID and Password. When login becomes correct, Control Center Lite program will run.

  • Page 48: Configuration Tool

    6.4. Configuration Tool Click icon on desktop to run “Control Center Lite Configuration Tool” program. 6.5. Monitor * For one unit of HVRM-S400E, maximum 3 users can simultaneously access to Monitoring. Click icon on desktop to run “Control Center Lite Monitor” program.

  • Page 49: Playback

    6.6. Playback * For one unit of HVRM-S400E, maximum 1 user can access to Playback. Click icon on desktop to run “Control Center Lite Playback” program.
  • Page 50 APPENDIX...

  • Page 51: Adding Or Replacing Of Hdd At Removable Hdd-Rack

    DB35.2 Series 7200.3 HDD Installation Procedure <note> When installing and removing HDD, the HVRM-S400E power should be turned off. (1) Check that dip switch of HDD is set to “Master” mode. (2) The HVRM-S400E power should be turned off. (3) Insert the key into the key hole of HDD rack and turn it anti-clockwise to release.
  • Page 52 (4) Pull the handle of HDD rack and remove the HDD case completely from HVRM-S400E rack. (5) Release the hook and open the cover by pulling lock as indicated in figure below. (6) Connect data and power cables to HDD and screw down the HDD to rack. Then close the cover.
  • Page 53 (7) Pull handle down and push the HDD case into the rack completely. (8) Insert the key and turn it clock wise to re lock the rack.

  • Page 54: Hdd Registration And Format

    HDD Registration and Format After completing HDD install and turning on power, “Storage Setup” menu automatically will be displayed shown as below figure. Please check HDD installation again in case of not showing the below figure. • Press [ENTER] key selected “Select disk” •...

  • Page 55: How To Recognize Manufacturing Date

    How to recognize manufacturing date The manufacturing date by HUNT can be recognized by S/N(Serial Number) attached at the each product. S/N : Serial Number Management number for each HUNT product to combine twelve alphabet character and digit including model name, manufacturing year/month/week You can see serial number by looking at the bottom of product attached label and system info of Configuration Tool.

  • Page 56: Technical Specifications

    Technical specifications Video Input Analog Ch. 4 BNC Connectors (NTSC/PAL Auto-Detect) Video Output Monitor (Mux) 1 BNC Connector & 1 VGA Video Compression Standard MPEG4 Speed 120/100ips (NTSC/PAL) Display Resolution 720x484(NTSC), 720x576(PAL) Multi Screen 1, 4ch Speed 120/100ips (NTSC/PAL) Recording Resolution 320x240(NTSC), 352x288(PAL) Internal...
  • Page 57 HUNT ELECTRONIC USA INC. 11790 Jersey Blvd. Rancho Cucamonga, CA 91730 Tel: (888)993-4868, (909)987-6999 Fax: (909)987-6997 techsupport@huntcctv.com www.huntcctv.com The contents of this manual can be modified in accordance with Firmware or Software upgrade. In the interest of continually improving products, approval & outlook can be modified without prior notice.
