Page 1: Quick Start
Quick Start Guide VGA CAT5e/6 Extender Kit GVE130 PART NO. Q1126... -
Page 2: Package Contents
Package Contents 1 x VGA Extender (Local Unit) 1 x VGA Extender (Remote Unit) 1 x 6ft VGA Male to Female Cable 2 x Power Adapter 1 x Quick Start Guide 1 x Warranty Card... - Page 3 SJ/T 11363-2006 The following contains information that relates to China.
-
Page 4: Start Here
Overview Start Here! Local Unit 1. VGA Input Port 2. VGA Output Port 3. Extension Input/Output Port 4. DC Power Jack 5. Power LED... - Page 5 Remote Unit 1. VGA Output 2. Video Gain Control Switch 3. Extension Input/Output Port 4. DC Power Jack 5. Power LED...
-
Page 6: Installation
Installation Note: Make sure your source device and all displays are powered off before you start. Step 1 Plug the power adapter to the power outlet and the power jack of the VGA Extender (Both Local and Remote Unit) Step 2 Connect a provided VGA extension cable (Male to Female) between your video source’s output (Male connecter from the cable) and the local unit of the VGA extender’s input port (Female... - Page 7 Step 3 Connect VGA Male to Male cables between your displays’ input ports and VGA extender’s output ports (Both Local and Remote Unit). We suggest using two equivalent model of display on local and remote unit to ensure the user experience. Step 4 Connect a solid CAT5e/6 cable between the local and remote unit of the Extension Input/Output Port...
- Page 8 Video Gain Control Switch* Setting CAT5e/6 Cable Length (meters) No longer than 150 140-150 130-140 120-130 110-120 100-110 90-100 80-90 70-80 60-70 50-60 40-50 30-40 20-30 10-20 0-10 *Setting may vary depending on different CAT cables. Please use the suggested setting for a reference and fine tune the setting if needed.
-
Page 9: Warranty
WE’RE HERE TO HELP YOU! NEED ASSISTANCE SETTING UP THIS PRODUCT? Make sure you: 1. Use the live chat at www.iogear.com to try and solve any issues you may be having with the product 2. Visit the Tech Info Library/FAQ on www.iogear.com (under the Support tab) 3. - Page 10 About Us About Us IOGEAR offers connectivity solutions that are innovative, fun, and stylish, helping people enjoy daily life using our high technology products. GREEN IOGEAR is an environmentally conscious company that emphasizes the importance of conserving natural resources. The use of our technology solutions helps reduce electronic waste.
