- Page 1 Quick Start Guide 60GHz Wireless 4K @ 30Hz Video Extender GW4K30GH60 PART NO. Q1577 www.iogear.com...
-
Page 2: Package Contents
Package Co ents 1 x HDMI Extender Transmitter 1 x HDMI Extender Receiver 1 x IR Blaster Cable 1 x IR Receiver Cable 2 x 5 VDC/2A Switching Power Supply 1 x Quick Start Guide 1 x Warranty Card 2 x HDMI Cables System Requirements 1 HDMI source device (Bluray, Satellite box, PC etc.) 1 HDMI display device (HDTV, projector with HDMI port, etc.) - Page 3 Overview Transmitter A. Power input B. HDMI input C. Power input with USB (optional) D. Data transmission indicator E. Power indicator F. SET button Receiver G. Power input H. HDMI output I. Power input with USB (optional) J. Data transmission indicator K.
-
Page 4: Hardware Installation
GW4K30GH60 transmitter. STEP 3 The GW4K30GH60 is unique in that it has an option for dual power input. Using the included power adapter, plug the power supply cable into the power inlet port. For optional method, if you have a... - Page 5 Connect the included HDMI cable to your TV vacant HDMI port. STEP 5 Connect the other side of your cable to the HDMI output port on your GW4K30GH60 receiver. STEP 6 Using the included power adapter, plug the power supply cable into the power inlet port.
- Page 6 Hardware Installation These devices operate in line-of-site mode only. 60 GHz signals will NOT go through walls or any obstructions and is intended for same room use only. However the advantage over 2.4 and 5GHz bands is that there is zero latency and the video is uncompressed which makes this device ideal for gamers where latency is number one concern.
- Page 7 Q Transmitter and receiver will not connect wirelessly A 1. Please check if the wireless connection light is on and blinking 2. Restart the transmitter and receiver by starting the transmitter first, then receiver in that order. You can also press the transmitter “set” button and then the receiver “set”...
-
Page 8: Compliance Information
Compliance Information Compliance Information WARNING: This product can expose you to chemicals including styrene which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital service, pursuant to Part 15 of the FCC rules. -
Page 9: Limited Warranty
Limited Warranty This product carries a 1 Year Limited Warranty. For the terms and conditions of this warranty, please go to https://www.iogear.com/support/warranty Register online at https://www.iogear.com/register Important Product Information Product Model Serial Number... - Page 10 Contact WE’RE HERE TO HELP YOU! NEED ASSISTANCE SETTING UP THIS PRODUCT? Make sure you: 1. Visit www.iogear.com for more product information 2. Visit www.iogear.com/support for live help and product support IOGEAR https://iogear.custhelp.com support@iogear.com www.iogear.com...
