- Page 1 Display (VGA) Extender Video Display Extender over Cat Cable User Manual (GVE120) ®...
- Page 2 Apple Computer, Inc. All other brand and product names are trademarks or registered trademarks of their respective holders. IOGEAR® makes no warranty of any kind with regards to the information presented in this document. All information furnished here is for informational purposes only and is subject to change without notice.
-
Page 3: Table Of Contents
Package Contents... Overview... Features... Requirements... Introduction... Pictorial Introduction – Local Unit... Pictorial Introduction – Remote Unit... Installation of Video Extender... Technical Details... Technical Support... Specification... Radio & TV Interference Statement... Limited Warranty... Table of Contents... -
Page 4: Package Contents
Package Contents This package contains: 1- IOGEAR Video Extender (GVE120) • Remote Unite (GVE120R) • Local Unite (GVE120L) 1- VGA (HD15) male - VGA (HD15) male / 6 feet cable 2- 9V 500ma Power Adapter 1- Quick Start Guide 1- Warranty / Registration Card... -
Page 5: Overview
Overview The GVE120 Video Display Extender is ideal for factory and construction sites, or any installation where the display needs to reside in a harsh settings while you and your system equipment are in an environmentally friendly location. The Video Extender is also useful for control and security purposes, where you can have the system unit in a secure area at the same time that you put the display in an area that is convenient for viewing. -
Page 6: Features
Features • Superior Video Quality, Maintains Highest Signal Strength In All Applications Up to 1600 x 1200 @ 300 feet • Supports VGA, SVGA, and Mutisync Compatible Displays • Hassle free, no software to install, instant installation and use. • Sturdy design for long lasting durability •... -
Page 7: Requirements
Requirements VGA, SVGA, Multisynce Compatible Macintosh Users: • All MACs With Analog VGA Support PC Users: • All PCs With Analog VGA Support Accessories / Additional Products VGA Video Splitter – (2-port/GVS92, 4-port/GVS94, 8-port/GVS98) USB Flex™ Web Cam - USB Flaxable Web Camera (GCA210U) KVMP Switch –... -
Page 8: Introduction
Display Extender is a unique way bring your monitors signal to places usually out of reach. Send live, streaming video across the home or workplace. The IOGEAR’s® Video Display Extender is perfect for use in class rooms, conference and training rooms, and other sites that require video to be displayed at distant locations. - Page 9 Additional text is included, but indented, to further explain each of these actions. A glossary has been added at the end of the manual so you may look up unfamiliar terms. A few things should be mentioned before explaining the installation procedure: All IOGEAR’s® Video Display Extenders are tested before they are shipped.
-
Page 10: Pictorial Introduction - Local Unit
Pictorial Introduction – Local Unit (GVE120) Local Unite (GVE120) 1. The IOGEAR Logo, A mark of quality 2. Range (long/short) Switch 3. Remote I/O (RJ/45 port) 4. Power Port (AC 9V) 5. Power Indicator Light 6. Local Monitor Port 7. Local Computer Port... - Page 11 Pictorial Introduction – Local Unit (GVE120) Range Switch Slide the switch to the Long position if the Remote Unit is located a long distance away; slide the switch to the Short position if the Remote Unit is located a short distance away.
-
Page 12: Pictorial Introduction - Remote Unit
Pictorial Introduction – Remote Unit (GVE120R) Remote Unite (GVE120R) 1. The IOGEAR Logo, A mark of quality 2. Remote I/O (RJ/45 port) 3. Power Port (AC 9V) 4. Power Indicator Light 5. Monitor Port... - Page 13 Pictorial Introduction – Remote Unit (GVE120R) Remote I/O The Category 5, 5e, or 6 twisted pair cable that connects to the Local Unit plugs into this connector. Power Port (AC 9V) The power supply cable plugs into this connector. Power Indicator Light Lights to indicate that the unit is receiving power.
-
Page 14: Installation Of Video Extender
Installation of Video Extender Warning! Make absolutely sure that a protective ground wire with no potential difference is established between the AC sources for the Local and Remote units. Unequal grounding potential between the Local and Remote units will result in damage to the units and connected devices. Refer to the pictorial introduction as you follow the step-by-step directions below: Make sure that the computer and monitors you are using for the installation are powered Off. - Page 15 Plug the local monitor’s VGA cable into the Local Unit’s Monitor port. Plug one of the power adapters (supplied with this package) into your surge protector power strip; plug the adapter’s power cable into the Local Unit’s Power Port. Plug one end of your selected Category 5, 5e, or 6 twisted pair cable into the Local Unit’s Remote I/O port. Local Unite Power Adapter’s Cable Installation of Video Extender...
- Page 16 Installation of Video Extender 6. Slide the Range Switch to the Long position if the Remote Unit location is a long distance away; slide the switch to the Short position if the Remote Unit location is a short distance away. 7.
- Page 17 8.Plug the remote monitor’s VGA cable into the Remote Unit’s Monitor port. 9.Plug the second power adapter (supplied with this package) into a remote surge protector power strip; plug the adapter’s power cable into the Remote Unit’s Power Port. 10.Power On the computer and monitors. Note: Refer to the Cable Length table in the Technical Details section on page ___ for typical resolution/ refresh rate/distance ratios.
-
Page 18: Technical Details
Technical Details TP Pin Assignments Cable Length... - Page 19 Technical Details TP Wiring Diagram...
-
Page 20: Technical Support
Service Support can be reached at IOGEAR® from 8am to 5pm Pacific Standard Time, Monday through Friday or at the following address: 23 Hubble Drive Irvine, CA 92618 You may also reach us online at www.iogear.com/support 24 hours a day. -
Page 21: Specification
Specification... -
Page 22: Radio & Tv Interference Statement
Radio & TV Interference Statement WARNING!!! This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause interference to radio communications. This equipment has been tested and found to comply with the limits for a Class B computing device pursuant to Subpart J of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment. -
Page 23: Limited Warranty
Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR’S LIABILITY FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK, OR ITS DOCU- MENTATION EXCEED THE PRICE PAID FOR THE PRODUCT. The direct vendor makes no warranty or representation, expressed, implied, or statutory with respect to the contents or use of this documentation, and especially disclaims its quality, performance, merchantability, or fitness for any particular purpose. - Page 24 ® Contact info. 23 Hubble • Irvine, CA 92618 • (P) 949.453.8782 • (F) 949.453.8785 • www.iogear.com...
