- Page 1 USB KVM Console Extender User Manual (GCE700)
- Page 3 Microsoft and Windows are registered trademarks of Microsoft Corporation. IBM is a registered trademark of International Business Machines, Inc. Macintosh, G3/G4 and iMac are registered trademarks of Apple Computer, Inc. IOGEAR makes no warranty of any kind with regards to the information presented in this document.
-
Page 4: Table Of Contents
Table of Contents Table of Contents: Package Contents Features System Requirements Introduction Installation Operation Troubleshooting Twisted Pair Wiring Diagram Twisted Pair Pin Assignment Specification Technical Support Radio & TV Interference Statement Limited Warranty... -
Page 5: Package Contents
Package Contents This package contains: 1 USB KVM Console Extender Local Unit 1 USB KVM Console Extender Remote Unit 1 Custom KVM Cable 2 Power Adapters 1 User Manual 1 Warranty Registration Card If any items are missing or damaged please contact your dealer. -
Page 6: Features
Features Features - Allows remote access up to 500 away via CAT5e cables - Auto Signal Compensation (ASC) helps make installation easy, with no need to configure DIP switches - Dual console operation - control your system from both local and remote USB keyboards, USB mice, and monitors - USB over-current detection and prevention - Easy to operate - push button selection between local and remote console... -
Page 7: System Requirements
Requirements Consoles: - VGA, SVGA, or Multisync monitor capable of the highest resolution that you will be using on any computer in the installation - USB keyboard - USB mouse Computers: - VGA, SVGA or Multisync card - Available USB port Cables: - Category 5e rated UTP (Unshielded Twisted Pairs) cable with solid conductors is the minimum requirement to connect the GCE700 local unit to the GCE700 remote unit. -
Page 8: Introduction
Introduction GCE700 Local Unite Front View 1. Operating Mode Selection Switch Pressing this button toggles between the choices of operating modes: • Local - only the local console can control the system(s); • Auto - both consoles can control the system(s). 2. - Page 9 Introduction GCE700 Local Unit Rear View 1. USB Port Plug the USB Type B connector of the USB KVM Cable supplied with this package in here. 2. Monitor Port The HDB-15 VGA Connector of the USB KVM Custom Cable supplied with this package plugs in here.
- Page 10 Introduction GCE700 Remote Unit Front View 1. LEDs The Remote Unit has two LEDs (Status and On Line) to indicate the operating status of the Local and Remote units. 2. USB Keyboard and Mouse Port The remote USB keyboard and USB mouse plug into these ports.
-
Page 11: Installation
Installation Setting up the USB KVM Console Extender System is simply a matter of plugging in the cables: GCE700 Local Unit Front View GCE700 Remote Unit GCE700 Local Unit Rear View... - Page 12 Installation Installation 1. Make sure that all the equipment to be connected up is powered off. 2. Plug the cables from the local console devices (mouse, keyboard, monitor), into their ports on the Console side of the Local Unit 3. Plug the appropriate connectors on the USB KVM extension cable supplied with this unit into the CPU side of the Local Unit.
- Page 13 Installation 8. Plug the cables from the remote console devices (USB mouse, USB keyboard, monitor), into their ports on the Console side of the Remote Unit. 9. Plug the second power adapter (supplied with this package) into an AC source; plug the adapter’s power cable into the Power Jack of the Remote Unit.
-
Page 14: Operation
Operation Operation: Once the installation is completed, you can access your computer and KVM switch from either local or remote console. You can select either local or auto by pushing the SELECT button. The auto mode allows either console to take over, and allow the other console to view. -
Page 15: Local Unit
Local Unit: Remote Unit: i t c i t c i t c i t c i t c i t c Operation... -
Page 16: Troubleshooting
Troubleshooting Troubleshooting f i c d i l l l i... -
Page 17: Twisted Pair Wiring Diagram
Twisted Pair Wiring Diagram Twisted Pair Wiring Diagram T568B AT&T 568A... -
Page 18: Twisted Pair Pin Assignment
Twisted Pair Pin Assignments Twisted Pair Pin Assignments... -
Page 19: Specification
Specifications Specifications ) . t c i t " 5 " 5 " 5... -
Page 20: Technical Support
23 Hubble Drive Irvine, CA 92618 You may also reach us online at www.iogear.com/support 24 hours a day. Please be ready to give a brief description of the problem, and what you were doing when the problem occurred, before calling Service Support. -
Page 21: Radio & Tv Interference Statement
Radio & TV Interference Statement Radio & TV Interference Statement WARNING!!! This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause interference to radio communications. This equipment has been tested and found to comply with the limits for a Class B computing device pursuant to Subpart J of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment. -
Page 22: Limited Warranty
Limited Warranty Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR’S LIABILITY FOR DIRECT, INDIRECT, SPECIAL, INCIDEN- TAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK OR ITS DOCUMENTATION EXCEED THE PRICE PAID FOR THE PRODUCT. The direct vendor makes no warranty or representation, expressed, implied, or statutory with respect to the contents or use of this documentation, and especially disclaims its quality, performance, merchantability, or fitness for any particular purpose. - Page 24 Contact info. 23 Hubble • Irvine, CA 92618 • (P) 949.453.8782 • (F) 949.453.8785 • www.iogear.com...
