- Page 1 PS/2 KVM Console Extender User Manual (GCE250)
- Page 3 Microsoft and Windows are registered trademarks of Microsoft Corporation. IBM is a registered trademark of International Business Machines, Inc. Macintosh, G3/G4 and iMac are registered trademarks of Apple Computer, Inc. IOGEAR makes no warranty of any kind with regards to the information presented in this document.
-
Page 4: Table Of Contents
Table of Contents Table of Contents: Package Contents Features System Requirements Introduction Installation Operation Troubleshooting Twisted Pair Wiring Diagram Twisted Pair Pin Assignment Specifications Technical Support Radio & TV Interference Statement Limited Warranty... -
Page 5: Package Contents
Package Contents This package contains: 1 PS/2 KVM Extender Local Unit 1 PS/2 KVM Extender Remote Unit 1 Custom KVM Cable 2 Power Adapters 1 User Manual 1 Warranty Registration Card If any items are missing or damaged please contact your dealer. -
Page 6: Features
Features Features - Allows remote access of up to 500ft away via CAT5e cables - Auto Signal Compensation (ASC) helps make installation easy, with no need to configure dip switches - Dual console operation - control your system from both the local and remote keyboards, mice, and monitors - Easy to use - push button selection between local and remote consoles - Plug-n-Play - no need to install any software driver... -
Page 7: System Requirements
- Category 5e rated UTP (Unshielded Twisted Pairs) cable with solid conductors is the minimum requirement to connect the GCE250 local unit to the GCE250 remote unit. Cable of a lesser standard will result in degrading of the video signal. For best performance, we strongly recommend Category 5e or Category 6 cables. -
Page 8: Introduction
Introduction GCE250 Local Unit Front View 1. Operating Mode Selection Switch Pressing this button cycles you through the operating mode choices: • Local - only the local console can control the system(s); • Auto - both consoles can control the system(s). - Page 9 Introduction GCE250 Local Unit Rear View 1. Monitor Port The HDB-15 Video connector of the KVM cable that connects to the computer’s or KVM switch’s video port plugs into this port. 2. Keyboard Port The keyboard connector of the KVM cable that connects to the computer’s or KVM switch’s keyboard port plugs into this port.
- Page 10 Introduction GCE250 Remote Unit Front View 1. LEDs The Remote Unit has two LEDs (Power and On Line) to indicate the operating status of the Local and Remote units. 2. Mouse Port The remote PS/2 mouse plugs into this connector.
-
Page 11: Installation
Installation Setting up the PS/2 KVM Extender System is simply a matter of plugging in the cables: GCE250 Local Unit Front View GCE250 Remote Unit GCE250 Local Unit Rear View... - Page 12 2. Plug the cables from the local console devices (mouse, keyboard, monitor), into their ports on the Console side of the GCE250 Local Unit. Each port is marked with an appropriate icon to indicate which it is. (This step is optional, you may operate with remote consoles only).
- Page 13 Installation Console side of the GCE250 Remote Unit. Each port is marked with an appropriate icon to indicate itself. 9. Plug the second power adapter (supplied with this package) into an AC source at the remote location; plug the adapter’s power cable into the power jack.
-
Page 14: Operation
Operation Operation: Once the installation is completed, you can access your computer and KVM switch from either local or remote console. You can select either local or auto by pushing the SELECT button. The auto mode allows either console to take over, and allow the other console to view. -
Page 15: Local Unit
Local Unit: i t c i t c i t c . ) t i t c v i t i t c . ) t i t c v i t Operation... -
Page 16: Remote Unit
Operation Remote Unit: y l i v i t v i t . t i . t i... -
Page 17: Troubleshooting
Troubleshooting f i c Troubleshooting d i l l l i... -
Page 18: Twisted Pair Wiring Diagram
Twisted Pair Wiring Diagram Twisted Pair Wiring Diagram T568B AT&T 568A... -
Page 19: Twisted Pair Pin Assignment
Twisted Pair Pin Assignments Twisted Pair Pin Assignments... -
Page 20: Specifications
Specifications Specifications " 5 " 5 ) . t c i t " 5 " 5 " 4 " 5... -
Page 21: Technical Support
23 Hubble Drive Irvine, CA 92618 You may also reach us online at www.iogear.com/support 24 hours a day. Please be ready to give a brief description of the problem, and what you were doing when the problem occurred, before calling Service Support. -
Page 22: Radio & Tv Interference Statement
Radio & TV Interference Statement Radio & TV Interference Statement WARNING!!! This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause interference to radio communications. This equipment has been tested and found to comply with the limits for a Class B computing device pursuant to Subpart J of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment. -
Page 23: Limited Warranty
Limited Warranty Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR’S LIABILITY FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK OR ITS DOCUMENTATION EXCEED THE PRICE PAID FOR THE PRODUCT. The direct vendor makes no warranty or representation, expressed, implied, or statutory with respect to the contents or use of this documentation, and especially disclaims its quality, performance, merchantabil- ity, or fitness for any particular purpose. - Page 24 Contact info. 23 Hubble • Irvine, CA 92618 • (P) 949.453.8782 • (F) 949.453.8785 • www.iogear.com...
