- Page 1 Installation Guide Installation USB VGA KVM Console Extender GCE500U PART NO. M1125-a...
-
Page 3: Table Of Contents
Table of Contents Package Contents System Requirements Overview Rack Mounting Grounding Standard Installation Advanced Installation Operating Modes LED Indications Federal Communications Commission (FCC) Statement CE Statement SJ/T 11364-2006 Limited Warranty Contact... -
Page 4: Package Contents
Package Contents 1 x GCE500U Local Unit 1 x GCE500U Remote Unit 1 x USB KVM Cable 2 x Rack Mount Kit 2 x Grounding Cable 2 x Power Adapter 1 x Installation Guide 1 x Warranty Card... -
Page 5: System Requirements
System Requirements - A Solid CAT5e/6 Cable Console - VGA, SVGA, SXGA, UXGA, WUXGA or Multisync monitor - USB Keyboard and mouse Computer - VGA, SVGA, SXGA, UXGA, WUXGA or Multisync video output - An available USB port... -
Page 6: Overview
Overview Front View CPU Port Remote LED Local LED Operating Mode Pushbutton Link LED Remote LED Local Remote... - Page 7 Rear View Power Jack USB Mouse Port USB Keyboard Port Extension Input/Output Port VGA Monitor Port Local & Remote Unit...
- Page 8 Side View Grounding Terminal Local & Remote Unit...
-
Page 9: Rack Mounting
Rack Mounting Step 1 Unscrew the screws that are in the bottom of the housing, then screw the provided mounting bracket on top of the units with the screws. - Page 10 Step 2 Screw the other side of the bracket onto any available area on the rack.
-
Page 11: Grounding
To prevent damage to your installation, it is important that your devices are properly grounded. Use the pro- vided grounding wires to ground the Local and Remote Unit of the GCE500U. Connect one end of the wire to the grounding terminal and the other end of the wire to a suitable grounded object. -
Page 12: Standard Installation
Standard Installation Note: Please make sure your computer is completely shutdown before you begin. Step 1 Connect the power adapter between the wall outlet and the unit (Both local and remote units) - Page 13 Step 2 Connect the provided USB KVM Cable between the local unit’s CPU port and the computer Local unit...
- Page 14 Step 3 Connect your VGA monitor to the console VGA port, USB keyboard and mouse to the Console USB keyboard and mouse port respectively (Both local and remote units)
- Page 15 Step 4 Connect your CAT5e/6 Cable between the Extension Input/Output Ports from the local and remote unit. Final Step Turn on your computer and monitors.
-
Page 16: Advanced Installation
Advanced Installation Note: Please make sure your computers are completely shutdown before you begin. Step 1 Connect the power adapter between the wall outlet and the unit (Both local and remote units). - Page 17 Connect the provided USB KVM Cable between the local unit’s CPU port and the console VGA and keyboard port of the KVM. (KVM example: IOGEAR’s GCS1734 ) Step 3 Please refer to the user manual of the specific KVM to complete the KVM installation.
- Page 18 Step 4 Connect your VGA monitor to the console VGA port, USB keyboard and mouse to the Console USB keyboard and mouse port respectively (Both local and remote units).
- Page 19 Step 5 Connect your CAT5e/6 Cable between the Extension Input/Output Ports from the local and remote unit. Final Step Turn on your computers and monitors.
-
Page 20: Operating Modes
Operating Modes Mode Description Local Only local console has access Remote Only remote console has access Note: Remote Mode cannot be selected by the Operating Mode Pushbut- ton, it only occurs when Auto Mode grants the access to the remote console. -
Page 21: Led Indications
LED Indications LED Status Description Local LED ON Local Mode Remote LED OFF Local LED OFF Remote Mode Remote LED ON Both Local and Remote LED flash Auto Mode Link LED ON Extension connection is established Link LED flashes Extension connection is not established... -
Page 22: Federal Communications Commission (Fcc) Statement
Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential setting. -
Page 23: Ce Statement
CE Statement This device has been tested and found to comply with the requirements set up in the council directive on the approximation of the law of member states relating to EMC Directive 89/336/EEC, Low Voltage Directive 73/23/EEC and R&TTE Directive 99/5/EC. The product has been approved for LVD and covered the following countries: Belgium, Denmark, France, Germany, Italy, Portugal, U.K., Spain, Sweden... -
Page 24: Sj/T 11364-2006
SJ/T 11364-2006 有毒有害物质或元素 部件名称 多溴联苯 多溴二苯醚 铅 (Pb) 汞 (Hg) 镉（Cd） 六价 (Cr(VI)) （PBB） （PBDE） 电器部件 ● ○ ○ ○ ○ ○ 机构部件 ○ ○ ○ ○ ○ ○ ○:表示该有毒有害物质在该部件所有均质材料中的含量均在SJ/T 11363-2006规定的限量要求之下。 ●:表示符合欧盟的豁免条款，但该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T 11363-2006的限量要求。 ×: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出SJ/T 11363-2006的限量要求。... -
Page 25: Limited Warranty
For further inquiries please contact IOGEAR. -
Page 26: Contact
Contact IOGEAR 19641 Da Vinci Foothill Ranch, CA 92610 P 949.453.8782 F 949.453.8785 Visit us at: www.iogear.com... - Page 28 About Us About Us IOGEAR offers connectivity solutions that are innovative, fun, and stylish, helping people enjoy daily life using our high technology products. GREEN IOGEAR is an environmentally conscious company that emphasizes the importance of conserving natural resources. The use of our technology solutions helps reduce electronic waste.
