- Page 1 Grandstream Networks, Inc. Configuring UCM6100 Series with HT503 Grandstream Networks, Inc. www.grandstream.com...
-
Page 2: Table Of Contents
Figure 8: Method 1 - Configure FXO Port on the HT503: Channel Dialing ..........10 Figure 9: Method 1 - HT503 Basic Settings ....................10 Figure 10: Method 2 - Create Extension 5000 on the UCM6100..............11 Firmware Version 1.0.1.25 Configuring UCM6100 Series with HT503 Page 1 of 18... - Page 3 Reproduction or transmittal of the entire or any part, in any form or by any means, electronic or print, for any purpose without the express written permission of Grandstream Networks, Inc. is not permitted. Firmware Version 1.0.1.25 Configuring UCM6100 Series with HT503...
-
Page 4: Change Log
Minor updates for corrections or editing are not documented here. Firmware Version 1.0.1.25 This is the initial version. Firmware Version 1.0.1.25 Configuring UCM6100 Series with HT503 Page 3 of 18... -
Page 5: Overview
When using the IVR in UCM6100 series, please be aware that if "Dial Trunk" option is turned on in IVR settings, the call into the IVR will be able to dial outbound call using UCM6100's trunk. The IVR's permission level will be used when making outbound calls in this case. -
Page 6: Method 1: Register Ht503 To Ucm6100
Figure 2: Method 1 - Create Extension 5001 on the UCM6100 Create IVR on UCM6100 On the UCM6100 web GUI, create an IVR extension under PBX->Call Features->IVR. This is to receive Firmware Version 1.0.1.25 Configuring UCM6100 Series with HT503 Page 5 of 18... -
Page 7: Configure Fxs Port On Ht503
1. Connect an analog phone to the HT503 FXS port. 2. On the HT503 web GUI, go to FXS Port setting page, configure to register the FXS port to the Firmware Version 1.0.1.25 Configuring UCM6100 Series with HT503 Page 6 of 18... -
Page 8: Configure Fxo Port On Ht503
2. On the HT503 web GUI, go to FXO Port setting page, configure to register the FXO port to the UCM6100 extension 5001. Please refer to the highlighted settings and other necessary settings in the following figures. In this example, the UCM6100 IP address is 192.168.40.207. Firmware Version 1.0.1.25 Configuring UCM6100 Series with HT503 Page 7 of 18... -
Page 9: Figure 5: Method 1 - Configure Fxo Port On The Ht503: Registration
Figure 6: Method 1 - Configure FXO Port on the HT503: DTMF Settings There are a few necessary changes to be made in FXO termination section and Channel Dialing section as well. Firmware Version 1.0.1.25 Configuring UCM6100 Series with HT503 Page 8 of 18... -
Page 10: Figure 7: Method 1 - Configure Fxo Port On The Ht503: Fxo Termination
Set "Number of Rings" option to 1. If you happen to experience caller ID issue, you may set it to 2. Firmware Version 1.0.1.25 Configuring UCM6100 Series with HT503 Page 9 of 18... -
Page 11: Configure Unconditional Call Forward On Ht503
IVR of the UCM6100. The IVR on UCM6100 would allow the user to further enter extension number or key pressing digit to reach the desired destination. Firmware Version 1.0.1.25 Configuring UCM6100 Series with HT503 Page 10 of 18... -
Page 12: Method 2: Connect Ucm6100 To Ht503 Using Peer Sip Trunk
In IVR settings, if "Dial Other Extensions" is enabled, the calls dialing into the UCM6100 IVR will be able to reach the internal extensions registered to the UCM6100. Also, you can assign the "Key Pressing Event" to different destinations. Firmware Version 1.0.1.25 Configuring UCM6100 Series with HT503 Page 11 of 18... -
Page 13: Create Peer Sip Trunk On Ucm6100
Create Peer SIP Trunk on UCM6100 On the UCM6100 web GUI, create a peer SIP trunk under PBX->Basic/Call Routes->VOIP Trunks. In this example, the HT503 IP address is 192.168.40.137. Firmware Version 1.0.1.25 Configuring UCM6100 Series with HT503 Page 12 of 18... -
Page 14: Configure Outbound Rule On Ucm6100
This would allow the extension on the UCM6100 to reach numbers in PSTN network via the peer SIP trunk we just configured. Figure 13: Method 2 - Configure Outbound Rule on the UCM6100 Firmware Version 1.0.1.25 Configuring UCM6100 Series with HT503 Page 13 of 18... -
Page 15: Configure Inbound Rule On Ucm6100
2. On the HT503 web GUI, go to FXO Port setting page, configure to register the FXO port to the UCM6100 extension 5000. Please refer to the highlighted settings and other necessary settings in the following figures. In this example, the UCM6100 IP address is 192.168.40.207. Firmware Version 1.0.1.25 Configuring UCM6100 Series with HT503 Page 14 of 18... -
Page 16: Figure 15: Method 2 - Configure Fxo Port On The Ht503: Registration
Figure 16: Method 2 - Configure FXO Port on the HT503: DTMF Settings There are a few necessary changes to be made in FXO termination section and Channel Dialing section. Firmware Version 1.0.1.25 Configuring UCM6100 Series with HT503 Page 15 of 18... -
Page 17: Figure 17: Method 2 - Configure Fxo Port On The Ht503: Fxo Termination
Set "Number of Rings" option to 1. If you happen to experience caller ID issue, you may set it to 2. In the sample setup, it's set to 2. Set "PSTN Ring Thru FXS" to "No". Firmware Version 1.0.1.25 Configuring UCM6100 Series with HT503 Page 16 of 18... -
Page 18: Exchange Sip Port Settings For Fxs And Fxo On Ht503
Figure 19: Method 2 - HT503 Basic Settings How to Dial Once the HT503 and the UCM6100 are set up as above, the inbound call and the outbound call will be working as described below. Firmware Version 1.0.1.25 Configuring UCM6100 Series with HT503 Page 17 of 18... - Page 19 The inbound call will go through the inbound route set up on the UCM6100. * Asterisk is a Registered Trademark of Digium, Inc. Firmware Version 1.0.1.25 Configuring UCM6100 Series with HT503 Page 18 of 18...
