Placing the ISDN Order Through Your Telephone Company
AT&T To order ISDN service for the AT&T® 5ESS switch, supply the
5ESS telephone company with the information provided in
Switch Table A-2.
NI1
Table A-2 Line Configuration for AT&T 5ESS NI1
Required Information
Line Type
Line Code
Interface Type
Directory Numbers
Maximum Terminals
Maximum B Channels
Actual User
Circuit-switched Voice
Circuit-switched Voice Channel
Circuit-switched Data
Circuit-switched Data Channel
Terminal Type
Display
Circuit-switched Voice Limit
Circuit-switched Data Limit
Voice or Data
Call Appearance Preference
Flexible Call Offering (FCO)
* The Directory Number, Circuit-switched Voice, and Circuit-switched Voice Limit
parameters should be set to 2 to allow both analog ports to be used simultaneously.
Otherwise, if those parameters are set to 1, the ISDN line can only place or receive one
call at a time.
† FCO (also referred to as Additional Call Offering) allows you to receive an incoming call
while a dual-channel Multilink PPP call is active. If you do not want this feature, which
may cost extra, FCO is not required.
Specification
Standard (2B+D) National ISDN-1 line
2B1Q
U interface with an RJ-45 jack
2 *
1
2
Yes
2
Any
*
2
Any
A (Basic Terminal)
Yes
*
2
2
Both
Idle
Yes †
A-3
